Automating Drupal Migrations

How to go from an Estimated One Week to Two Minutes Down Time

About Dan Harris

• Founder Webdrips.com

○ Drupal-based web design and development shop ○ Founded in July, 2011. ○ Nine years Drupal experience ○ 21 years professional experience.

• Twitter @webdrips
• Email dan@webdrips.com

Note About the Migration Process

Although we’re covering a Drupal 6 to 7 migration in this presentation, most if not all of these ideas presented here should work for any Drupal to Drupal migration.

Overview: Initial Plan/Estimates

• Initial estimate: one week of downtime
• SQL queries would be used to export/import

when coverage was limited with Drupal Migrate

• Only automation provided by Migrate Modules
• Existing Drupal 7 Architecture

Overview: Updated Plan

• Virtually zero downtime

○ Intermediate: asking for one day down time or less

• Complete migration in one business day
• Over 99% automated
• D7 site to be built during migration from

scratch

About the Drupal 6 Site

• Architecturally, was a mess (Frankensite)

○ Migration provided chance to clean up architecture and code

• Six custom themes (1 custom/5 subthemes)
• 35 custom modules
• 151 contributed modules

About the Drupal 6 Site

• 1000 privileged users
• About 400k non-privileged users
• 25 Content Types, including Webforms
• Over 2,500 pages

About the Drupal 7 Site

• 106 Modules
• Bootstrap Primary Theme
• One Bootstrap subtheme, Four sub-

subthemes

• Six content types only
• 11 Features provided architecture

Automated Migration Process

Requirements

• Migrate modules: migrate, migrate_extras, migrate_d2d,

migrate_webform

• Import modules: menu_import, path_redirect_import
• Four custom modules
• Scripts migration and deployment
• Fast server with SSD

Migration Script Overview

Requirements:

• Create new Drupal D7 site
• Build out site architecture with features
• Enable Modules
• Migrate D6 to D7
• Import items that couldn’t be migrated

This provided for a repeatable/reliable process

Migration Script Highlights (Review)

Build the site:

drush site-install

Enable features and modules:

drush en feature_name -y

Migrate each entity:

drush mi entity

Custom Migration Modules

• 1. Disable “edits” to the D6 site
• a. Basically re-direct webform pages, admin pages,

and paths like node/add, node/edit, etc.

• 2. Views (implemented with features) only for

migration status and post-processing

• 3. Migrate_d2d module
• 4. CSV-based Migration

Drupal Migrate/D2D/Extras

• Handled most of the heavy lifting

○ Everything except menu links, path redirects, and slide shows

• Extensive drush support
• Plenty of methods available to massage data
• D2D: simplifies migration code

Migrating Users

Challenges

• Nearly 400K unprivileged users
• Needed to assign users to organic groups

○ Based on how webform questions answered

• Had to fix user passwords

○ Fixed by writing directly to the user table inside the migration

Migrate Users Code

Unprivileged vs. Privileged was a simple query:

class NvidiaPrivilegedUserMigration extends NvidiaUserMigration { protected function query() { $query = parent::query(); $query->condition('u.mail', '%nvidia.com', 'LIKE/NOT LIKE'); return $query; } }

Migrate Users Code

Fix the password:

public function complete($account, $row) { parent::complete($account, $row); $account->pass = $row->pass; db_update('users')

• >fields(array('pass' => $account->pass))
• >condition('uid', $account->uid)
• >execute();

$this->nvidia_memberships($row); }

Assign Users to Groups (Review)

public function nvidia_memberships($row) { $membership_query = Database::getConnection('default', 'd6source')->select ('webform_submissions', 'ws'); $membership_query->join('webform_submitted_data', 'wd', 'wd.sid = ws. sid'); $membership_query->fields('wd', array('cid')); $membership_query->fields('ws', array('nid')); $membership_query->addExpression('group_concat(data)', 'data'); $membership_query->groupBy('ws.sid'); $membership_query->groupBy('cid'); $membership_query->condition('ws.uid', $row->uid); $membership_query->condition('ws.nid', array (1234567,2345678,3456789,4567890,5678901), 'IN'); $membership_id = nvidia_og_membership_associate_user_with_program();

Node Migration Challenges

• Body images & links with absolute paths
• Empty fields sometimes caused display issues
• Had to deal with “interesting” architecture

decisions on the D6 site

• Moved larger files to the cloud
• Reduced the number of content types

Node Migration Code

Dealing with textarea images:

• Needed to use Simple HTML DOM Parser
• Code Review

How a Strange Dev. Decision can Affect a Migration

D6 product page and dB variables table (review) led to the following code

$variable_name = 'nvidia_product_disable_product_image_'.$row->nid; // drush_print_r($variable_name); $query = Database::getConnection('default', 'd6source')

• >select('variable', 'v')
• >fields('v', array('name', 'value'))
• >condition('v.name', $variable_name, '=')
• >execute()
• >fetchAll();

$product_image_disabled = $query[0]->value; if ($product_image_disabled == 'i:1;') { $row->field_inline_image = NULL; }

Remove Empty Textarea Fields

public function prepare($entity, stdClass $row) { foreach ($row as $key => $value) { if (!isset($row->$key) || $row->$key === null) { $entity->$key = NULL; } } }

“Non-Standard” Entity Migrations (Review)

• D2D handles established Drupal entities well

○ nodes, users, taxonomy, etc.

• But what if you want to migrate block content

to an entity?

○ CSV Migration to the rescue

Challenges

• Biggest challenge was reducing the

migration time

○ The original estimate just for migrating users was

• ver 40h

○ Eventually that time was reduced to ~ 3 hours ○ We tweaked my.cnf, php.ini, drush.ini ○ Got a really fast server with Intel Xeon processors, fast RAM, and a SSD

Challenges

• Installation of modules in order

○ circular dependencies ○ features that add fields need to be installed before migration

• Relationships between content

○ Both nodes need to exist before creating a relationship ○ “Parent” content that did not exist in original site

Migration timeline

• -7days to release: Content freeze
• -2days: Automated rebuild, content migration

and editorial approval.

• -8h: Registration lockdown and migration

start

• -2h: Batch processing of content by editors

and final tests

Accelerating migration

• Use Drush
• Single pass for each item

○ Migration objects are big and slow ○ Don’t load an object from DB twice

• Multithreading

○ https://www.deeson.co.uk/labs/multi-processing-part-2-how-make-migrate-move

Add multithreading to a working migration class

• Not very portable

○ needs a Drush extension ○ needs to run on the ‘fast’ server

• Very effective

Add multithreading to a working migration class

• Sub-class the migration
• Make all the sub-migrations use the same

index

• Make the sub-migration work on a small

‘chunk’ of the index

• Break the migration in parts and send

chunks of it to multiple threads

Add multithreading to a working migration class

<?php class NVMultiThread extends NvidiaUnprivilegedUserMigration { public function __construct($args) { $args += array( 'source_connection' => NVIDIA_MIGRATE_SOURCE_DATABASE, 'source_version' => 6, 'format_mappings' => array( '1' => 'filtered_html', '2' => 'full_html', '3' => 'plain_text', '4' => 'full_html', ), 'description' => t('Multithreaded Migration of users from Drupal 6'), 'role_migration' => 'Role', );

This is boilerplate needed by D2D

Add multithreading to a working migration class

parent::__construct($args); $this->limit = empty($args['limit']) ? 100 : $args['limit']; $this->offset = empty($args['offset']) ? 0 : $args['offset']; $this->map = new MigrateSQLMap('nvidiaunprivilegeduser', array( 'uid' => array( 'type' => 'int', 'unsigned' => TRUE, 'not null' => TRUE, 'description' => 'User migration reference', ), ), MigrateDestinationUser::getKeySchema() ); }

map/index table

index definition

Add multithreading to a working migration class

protected function query() { $query = parent::query(); $query->range($this->arguments['offset'], $this->arguments['limit']); return $query; } }

Modify original query to limit the number of items to work on

Measuring the improvement

• Same server
• Restore destination DB from backup after

each run

• Same source DB
• Both DBs in the same server
• MySQL optimizations for concurrency issues

Measuring the improvement

1000 rows, 100 per thread

Threads Time Speed 1 71s 845/min 2 60s 1000/min 3 54s 1111/min

Measuring the improvement

10,000 rows, 1000 per thread

Threads Time Speed 1 707s 848/min 2 303s 1980/min 3 300s 2000/min 4 291s 2061/min 5 351s 1709/min

Measuring the improvement

50,000 rows, 5000 per thread

Threads Time Speed 3 1990s 1507/min 4 1562s 1920/min 5 1303s 2302/min 6 1637s 1832/min

Conclusion

• Drop DNS TTL to 1 minute days before

launch

• Repeatability is key
• Migration is very powerful but can be slow
• Automation helps drop downtime close to

zero

Conclusion

• Ask for help
• There’s many ways to use Migration, if one

way is not working drop it and use it differently

○ CSV vs direct read from DB

• Weird things happen with orphaned fields

Questions?

dan@webdrips.com
