Automated testing for multiplayer Game AI Automated testing for multiplayer Game AI in Sea of Thieves in Sea of Thieves Robert Masella Rare - Microsoft Studios About Me About Me Senior Gameplay Engineer Worked on: Banjo Kazooie:

slide-1
SLIDE 1

Automated testing for multiplayer Game AI in Sea of Thieves Automated testing for multiplayer Game AI in Sea of Thieves

Robert Masella

Rare - Microsoft Studios

slide-2
SLIDE 2

About Me About Me

  • Senior Gameplay Engineer
  • Worked on:
  • Banjo Kazooie: Nuts and Bolts
  • Kinect Sports games
  • Sea of Thieves
  • Two years on AI
slide-3
SLIDE 3

Rare Rare

  • Microsoft first party studio
  • 30+ years of games
slide-4
SLIDE 4

Sea of Thieves Sea of Thieves

slide-5
SLIDE 5

Sea of Thieves Sea of Thieves

slide-6
SLIDE 6

What is Sea of Thieves? What is Sea of Thieves?

  • ‘Shared World Adventure Game’
  • Two main AI threats:
  • Skeletons on islands
  • Sharks in the sea
  • Other AI types being worked on
slide-7
SLIDE 7

Sea of Thieves Tech Sea of Thieves Tech

  • Uses Unreal Engine 4
  • Dedicated servers
  • AI processing runs on server
  • AI uses UE4 behaviour trees
  • With many extended classes
slide-8
SLIDE 8

This Talk This Talk

  • How we shipped weekly
  • AI behaving correctly on every build
  • Using automated testing and continuous delivery
slide-9
SLIDE 9

Why use automated tests? Why use automated tests?

  • Game as a service means constant build confidence necessary
  • Reduce manual testing
  • Reduce crunch!
slide-10
SLIDE 10

Testing AI Testing AI

  • Automated testing not widely used in game development
  • AI Unique challenges for testing AI
  • Multiplayer
slide-11
SLIDE 11

Imagine this scenario Imagine this scenario

  • Designer changes a number in AI perception asset
  • Causes AI to forget players leaving Line of Sight correctly
  • Not spotted by manual test
  • Bug released to players
slide-12
SLIDE 12

Consequences Consequences

  • Weeks later…
  • Players start to notice in build
  • More engineer time to track down
  • More testing time to verify fix
  • Every chance issue could reoccur
slide-13
SLIDE 13

How to avoid How to avoid

  • Add an automated test
  • Run it regularly
  • Now bug would be caught before release
  • Ideally before it enters build
slide-14
SLIDE 14

Testing at Rare Testing at Rare

  • Require testing with every check in
  • Sea of Thieves now has 10,000 tests
  • Test run remotely using TeamCity
slide-15
SLIDE 15

Automated Testing Organisation Automated Testing Organisation

  • Run core set of tests before every check in
  • Run longer running tests periodically
  • Run all tests multiple times:
  • Different platforms
  • Different configurations (e.g. shipping, debug)
  • Different conditions (e.g. high latency, high packet variance)
slide-16
SLIDE 16

Release Process Release Process

  • Fix gets to players in 30 hrs:

0 hrs 0 min Fix implementation completed 0 hrs 30 min Fix verified on our build farm 0 hrs 30 min Fix submitted 3 hrs 0 min Build built, deployed to test lab and testing begins 5 hrs 0 min Entire build verified 29hrs 0 min Build passed through certification, ready to be published to retail. 30hrs 0 min Build published to retail and available to players

slide-17
SLIDE 17

Test Types Test Types

  • Unit
  • Integration
  • Behaviour Tree
  • Multiplayer Integration
slide-18
SLIDE 18

Test Types Test Types

  • Favour unit tests over integration tests
  • 90% of tests are unit tests
  • Unit tests don’t cover interaction between big systems
  • And rarely test production assets
  • Ideal to have coverage by all test types
slide-19
SLIDE 19

Testing Standards Testing Standards

  • Names follow Given_When_Then pattern
  • E.g. AIWithHearingSense_ReceivesNoiseEvent_AIAcknowledgesNoise
  • Each test tests one thing
  • Make sure you’ve seen the test fail as well as pass
  • Minimise boilerplate
slide-20
SLIDE 20

Running Tests Running Tests

  • Run tests in Unreal Editor Automation window
slide-21
SLIDE 21

Unit Tests Unit Tests

  • Run without creating or ticking world
  • Unit tests can have test fixture for boilerplate code

#define IMPLEMENT_AIENTITY_TEST( TestName ) IMPLEMENT_UNIT_TEST( TestName, "AIEntity", AIEntityTestFixture ) IMPLEMENT_AIENTITY_TEST( UpdateTarget_OneEnemyEntitySeen_TargetSetToEntity ) { auto* AIEntity = SpawnTestAIEntity(); auto* EnemyEntity = SpawnEnemyEntity(); AIEntity->AddSeenEntity( EnemyEntity ); AIEntity->UpdateTarget(); TestEqual( AIEntity->GetTargetEntity(), EnemyEntity ); }

slide-22
SLIDE 22

Integration Tests Integration Tests

  • Mostly used Unreal Blueprint system:
  • https://docs.unrealengine.com/latest/INT/Engine/Blueprints/
slide-23
SLIDE 23

Integration Tests Integration Tests

  • Levels with limited game scenario
  • Most look for success criteria, or time out and fail
slide-24
SLIDE 24

Line of Sight integration test Line of Sight integration test

  • SkeletonAI_WhenLosesLineOfSightToTarget_MovesToPositionToRegainLineOfSight
slide-25
SLIDE 25

Line of Sight integration test Line of Sight integration test

slide-26
SLIDE 26

Line of Sight integration test Line of Sight integration test

  • Failing version
slide-27
SLIDE 27

Line of Sight integration test Line of Sight integration test

slide-28
SLIDE 28

Line of Sight integration test Line of Sight integration test

  • Failing version
  • Assertion: Test Timed Out
slide-29
SLIDE 29

Line of Sight integration test Line of Sight integration test

  • Passing version
slide-30
SLIDE 30

Line of Sight integration test Line of Sight integration test

slide-31
SLIDE 31

Line of Sight integration test Line of Sight integration test

  • Passing version
slide-32
SLIDE 32

Behaviour Tree Testing Behaviour Tree Testing

  • In Unreal, behaviour trees are assets
  • Tested with integration tests.
  • Also required testing for new node types
  • Preferred testing with unit tests
slide-33
SLIDE 33

Example Behaviour Tree Node Example Behaviour Tree Node

  • Node that triggers an input
slide-34
SLIDE 34

Behaviour Tree Node Testing Behaviour Tree Node Testing

  • Add node to a minimal behaviour tree created in code
  • Created environment required for coded behaviour tree in fixture
  • Also created helper functions for adding nodes

virtual void OnBeforeTest() override { BehaviorTree = CreateTreeRootWithSequence(); } UBTTask_TriggerInput* CreateTriggerInputTaskNodeAttachedToNode( UBTCompositeNode* ParentNode, UNotificationInputId NotificationId ) { auto* TestTask = NewObject< UBTTask_TriggerInput >(); TestTask->NotificationId = NotificationId; ParentNode->AddChild( TestTask ); return TestTask; }

slide-35
SLIDE 35

Node Testing Node Testing

  • Test that checks that input is triggered and of correct type

IMPLEMENT_UNIT_TEST_BEHAVIOUR_TREE_NODE( TriggerInputNode_NodeIsRun_CallsCorrectInputNotification ) { bool TestNotificationInput1Called = false; TestEntity->HandleNotificationCallback = [&]( UNotificationInputId NotificationInputId ) { if ( NotificationInputId == UTestNotificationInputId ) { TestNotificationInput1Called = true; } }; NotificationNode = CreateTriggerInputTaskNodeAttachedToNode( RootNode, UTestNotificationInputId ); RunTreeWithInitialTick(); TestTrue( TestNotificationInput1Called ); }

slide-36
SLIDE 36

Node Testing Node Testing

  • Test that checks that

input is triggered and of correct type

slide-37
SLIDE 37

Example Behaviour Tree Node II Example Behaviour Tree Node II

  • Decorator node that compares entity’s health
slide-38
SLIDE 38

Node Testing II Node Testing II

  • Test that checks that decorator fails if health is lower than expected

IMPLEMENT_UNIT_TEST_BEHAVIOUR_TREE_NODE( CompareCurrentHealth_CompareGreaterThanValueHealthIsLess_DecoratorNodeFails ) { bool TaskWithDecoratorExecuted = false; bool LowerPriorityTaskExecuted = false; auto* Decorator = CreateCompareCurrentHealthDecorator( EFloatValueComparisonType::GreaterThan, 0.1f ); AddTestExecutionChildNodeWithDecorator( RootNode, [&]() { TaskWithDecoratorExecuted = true; }, Decorator ); AddTestExecutionChildNode( RootNode, [&]() { LowerPriorityTaskExecuted = true; } ); AIEntity->SetHealth( 0.05f ); RunTreeWithInitialTick(); TestFalse( TaskWithDecoratorExecuted ); TestTrue( LowerPriorityTaskExecuted ); }

slide-39
SLIDE 39

Node Testing II Node Testing II

  • Test that checks that

decorator fails if health is lower than expected

slide-40
SLIDE 40

Multiplayer Integration Testing Multiplayer Integration Testing

  • Most AI integration tests require server only
  • Sometimes AI tests require client
  • Integration test framework supports tests over network
slide-41
SLIDE 41

Multiplayer Integration Testing Multiplayer Integration Testing

  • Use Yield Nodes to pass execution between server and clients
slide-42
SLIDE 42

‘Walking Dead’ Multiplayer Integration Test ‘Walking Dead’ Multiplayer Integration Test

  • SkeletonAI_Dies_DoesNotMoveDuringDeathOnClient_MP1
slide-43
SLIDE 43

‘Walking Dead’ Multiplayer Integration Test ‘Walking Dead’ Multiplayer Integration Test

slide-44
SLIDE 44

‘Walking Dead’ Multiplayer Integration Test ‘Walking Dead’ Multiplayer Integration Test

  • Failing version
slide-45
SLIDE 45

‘Walking Dead’ Multiplayer Integration Test ‘Walking Dead’ Multiplayer Integration Test

slide-46
SLIDE 46

‘Walking Dead’ Multiplayer Integration Test ‘Walking Dead’ Multiplayer Integration Test

  • Failing version
  • Assertion failed: ‘check velocity is low in dead state’
slide-47
SLIDE 47

‘Walking Dead’ Multiplayer Integration Test ‘Walking Dead’ Multiplayer Integration Test

  • Passing version
slide-48
SLIDE 48

‘Walking Dead’ Multiplayer Integration Test ‘Walking Dead’ Multiplayer Integration Test

slide-49
SLIDE 49

‘Walking Dead’ Multiplayer Integration Test ‘Walking Dead’ Multiplayer Integration Test

  • Passing version
slide-50
SLIDE 50

Testing drawbacks Testing drawbacks

  • Time to create tests
  • Tests on an evolving game
  • Intermittent integration tests
slide-51
SLIDE 51

Testing benefits Testing benefits

  • Shipped over 100 times in 2 years
  • Very low bug count
  • Improved code
  • Manual testers focus on other things
  • No crunch for 4 years!
slide-52
SLIDE 52

Conclusion - AI In Action Conclusion - AI In Action

  • Now lets see it altogether
slide-53
SLIDE 53

AI In Action AI In Action

slide-54
SLIDE 54

Rare Are Hiring Rare Are Hiring

www.rare.co.uk/careers

Particularly looking for gameplay and AI engineers!

slide-55
SLIDE 55

Questions? Questions?
