Atmospheric and oceanic circulations PG Lectures, Autumn 2017 Mike Byrne & Arnaud Czaja Aim and learning outcomes Provide new PhD students in SPAT with an overview of why and how the atmosphere and ocean circulate and the implications for

slide-1
SLIDE 1

Atmospheric and oceanic circulations

PG Lectures, Autumn 2017 Mike Byrne & Arnaud Czaja

slide-2
SLIDE 2

Aim and learning outcomes

Provide new PhD students in SPAT with an overview of why and how the atmosphere and ocean circulate and the implications for Earth’s climate

slide-3
SLIDE 3

Aim and learning outcomes

  • 1. Describe the radiative drivers of atmospheric and oceanic

circulations

  • 2. Describe the structure of Earth’s winds (vs latitude and height)
  • 3. Understand angular momentum conservation and implications for the

tropical Hadley cell

  • 4. Physical origins of Ekman layers and ocean gyres
  • 5. Baroclinic instability in atmosphere and oceans, Rossby number,

geostrophic balance

  • 6. Atmospheric moisture transport: Influence on Earth’s water cycle and

thermohaline circulation

Provide new PhD students in SPAT with an overview of why and how the atmosphere and ocean circulate and the implications for Earth’s climate

slide-4
SLIDE 4

Structure of the week

  • Monday:
  • *attendance register*
  • Earth’s radiative budget
  • Observed climate: temperature and winds
  • Atmosphere: Hadley cell and angular momentum
  • Ocean: Ekman layers, gyres

  • Tuesday:
  • Baroclinic instability in the atmosphere, ocean, and classroom (tank

experiment)

  • Rossby number, geostrophic balance
  • Impact of atmospheric circulation: Earth’s water cycle
  • Friday: 3 groups present & discuss problem-set solutions
slide-5
SLIDE 5

Phenomena: Earth’s radiative balance — the circulation driver

solar energy received

NASA’s CERES satellite

slide-6
SLIDE 6

Phenomena: Earth’s radiative balance — the circulation driver

solar energy received terrestrial energy emitted

NASA’s CERES satellite NASA’s ERBE satellite

Stefan- Boltzmann Law:

B(T) = σT 4

e

slide-7
SLIDE 7

Phenomena: Earth’s radiative balance — the circulation driver

solar (SW) received minus terrestrial (LW) emitted

slide-8
SLIDE 8

Phenomena: Earth’s radiative balance — the circulation driver

implied atmosphere/ocean energy transport solar (SW) received minus terrestrial (LW) emitted

slide-9
SLIDE 9

Phenomena: Poleward energy transport by atmosphere and oceans

Trenberth & Caron (2001)

total implied

  • cean

atmosphere

slide-10
SLIDE 10

Phenomena: Surface temperature <-> pressure gradients -> circulations

from Schneider’s “Physics of Earth’s Climate”

slide-11
SLIDE 11

Phenomena: Surface temperature <-> pressure gradients -> circulations

from Schneider’s “Physics of Earth’s Climate”

weak gradients strong gradients

slide-12
SLIDE 12

Phenomena: Surface temperature (annual range)

from Schneider’s “Physics of Earth’s Climate”

slide-13
SLIDE 13

Phenomena: Annual-mean surface winds — much

stronger in zonal direction because of Earth’s rotation

from Schneider’s “Physics of Earth’s Climate”

slide-14
SLIDE 14

Phenomena: NH summer (JJA) surface winds, winds vary with the seasons

from Schneider’s “Physics of Earth’s Climate”

slide-15
SLIDE 15

Phenomena: NH summer (JJA) surface winds, winds vary with the seasons

from Schneider’s “Physics of Earth’s Climate”

“horse latitudes”

slide-16
SLIDE 16

Columbus knew about the surface-wind pattern

from Schneider’s “Physics of Earth’s Climate”

slide-17
SLIDE 17

Phenomena: Meridional (north-south) winds are much weaker

from Schneider’s “Physics of Earth’s Climate”

slide-18
SLIDE 18

Phenomena: Vertical structure of zonal winds

from Schneider’s “Physics of Earth’s Climate”

slide-19
SLIDE 19

Phenomena: Vertical structure of meridional mass circulation — by mass balance, Hadley and Ferrel cells must exist!

from Schneider’s “Physics of Earth’s Climate”

annual average

slide-20
SLIDE 20

Phenomena: Atmospheric meridional mass circulation — monsoons

from Schneider’s “Physics of Earth’s Climate”

Dec-Jan-Feb southern monsoons

slide-21
SLIDE 21

Phenomena: Atmospheric meridional mass circulation — monsoons

from Schneider’s “Physics of Earth’s Climate”

Jun-Jul-Aug northern monsoons (e.g. in India)

slide-22
SLIDE 22

Why are there strong winds in the upper atmosphere? Why are these winds increasingly westerly as you move poleward? Angular momentum and Earth’s rotation…

slide-23
SLIDE 23

Understanding winds and the Hadley circulation using angular momentum conservation

What is the angular momentum? “velocity times distance to rotation axis” What does it imply for upper- tropospheric winds in Hadley cell?

slide-24
SLIDE 24

Conservation of AM implies upper-level winds become stronger (more westerly) as air moves towards pole (opposite for surface winds)

umax = Ωasin2 φ cos φ

Latitude (degrees)

5 10 15 20 25 30 35 40 45 50

uMAX [m/s]

50 100 150 200 250 300

~125m/s @ 30deg

slide-25
SLIDE 25

Implies infinite winds at the poles! AM conservation breaks down and Hadley circulation stops at ~30deg because of baroclinic instability and turbulence (see tomorrow’s experiment)

umax = Ωasin2 φ cos φ

slide-26
SLIDE 26

In surface branch AM is not conserved because of friction. Easterly winds transfer momentum to ocean and drive oceanic circulations -> Ekman layers

Ocean

slide-27
SLIDE 27

Ekman layers

*Arnaud’s slides*

slide-28
SLIDE 28

Breakdown of Hadley cell due to Earth’s rotation

non-rotating rotating

slide-29
SLIDE 29

Macroturbulence in an Earth-like simulation Macroturbulence in a more realistic more

Breakdown of Hadley cell due to Earth’s rotation

slide-30
SLIDE 30

Effect of Earth’s rotation on atmosphere/ocean dynamics: The Rossby number

Can begin to understand the influence of rotation on circulation by doing a scale analysis of the momentum equation…

Du Dt + 1 ρ ∂p ∂x − fv = friction (east − westdir.) Dv Dt + 1 ρ ∂p ∂y + fu = friction (north − southdir.)

acceleration pressure-gradient force Coriolis force

slide-31
SLIDE 31

Effect of Earth’s rotation on atmosphere/ocean dynamics: The Rossby number

Can begin to understand the influence of rotation on circulation by doing a scale analysis of the momentum equation…

Du Dt + 1 ρ ∂p ∂x − fv = friction (east − westdir.) Dv Dt + 1 ρ ∂p ∂y + fu = friction (north − southdir.)

~V / T = V2/L ~fV

slide-32
SLIDE 32

Effect of Earth’s rotation on atmosphere/ocean dynamics: The Rossby number

Ro = acceleration Coriolis ∼ V fL

Ro = 0.1 1 10

geostrophic balance (jet stream) gradient balance (hurricanes) cyclostrophic balance (tornados)

slide-33
SLIDE 33

Geostrophic balance in Earth’s atmosphere: Mid- latitude weather systems

Ro = acceleration Coriolis ⇠ V fL ⇡ 0.1 ) fˆ z ⇥ u + 1 ρrp = 0 Geostrophic balance: “Pressure-gradient and Coriolis forces balance” -> flow along isobars

slide-34
SLIDE 34

Geostrophic balance in Earth’s atmosphere: Mid- latitude weather systems

Ro = acceleration Coriolis ⇠ V fL ⇡ 0.1 ) fˆ z ⇥ u + 1 ρrp = 0 Geostrophic balance: “Pressure-gradient and Coriolis forces balance”

slide-35
SLIDE 35

Geostrophic balance in Earth’s atmosphere: Mid- latitude weather systems

Ro = acceleration Coriolis ⇠ V fL ⇡ 0.1 ) fˆ z ⇥ u + 1 ρrp = 0 Geostrophic balance: “Pressure-gradient and Coriolis forces balance” PGF Coriolis

slide-36
SLIDE 36

Earth’s water cycle: atmospheric water vapour

ERA-40 Atlas

slide-37
SLIDE 37

Earth’s water cycle: atmospheric water vapour

ERA-40 Atlas

7%/K

δq∗ q∗ ≈ L RT 2 δT

Clausius-Clapeyron:

slide-38
SLIDE 38

Earth’s water cycle: moisture transport

from Schneider’s “Physics of Earth’s Climate”

Hadley cell weather systems

slide-39
SLIDE 39

Earth’s water cycle: precipitation

Tropical Rainfall Measuring Mission (TRMM)

slide-40
SLIDE 40

Earth’s water cycle: precipitation

from Schneider’s “Physics of Earth’s Climate”

slide-41
SLIDE 41

Earth’s water cycle: evaporation

from Schneider’s “Physics of Earth’s Climate”

slide-42
SLIDE 42

Earth’s water cycle: net precipitation (P-E)

from Schneider’s “Physics of Earth’s Climate”

slide-43
SLIDE 43

Earth’s water cycle: Impact of P-E on oceans and continents

World Ocean Atlas (2005)

  • cean salinity

Global Water Resource Archive

slide-44
SLIDE 44

Earth’s water cycle: P-E and the atmospheric circulation

from Schneider’s “Physics of Earth’s Climate”

) δ(P E) = r · δF

SURFACE

P − E > 0 moisture flux

ATMOS

P E = r · F = r · [qu] ⇡ [qr · u]

slide-45
SLIDE 45

Earth’s water cycle: P-E and the atmospheric circulation

from Schneider’s “Physics of Earth’s Climate”

) δ(P E) = r · δF

SURFACE

P − E > 0 moisture flux

ATMOS

P E = r · F = r · [qu] ⇡ [qr · u]

slide-46
SLIDE 46

Atmosphere moves moisture from dry subtropics (P-E < 0) to moist tropics & extratropics (P-E > 0)

Geophysical Fluid Dynamics Laboratory model

P E = r · F = r · [qu] ⇡ [qr · u]

(from a simulation)
