Ashwin Amurthur, Peter Qiao, Michael Magaraci, Avin Veerakumar How can Synthetic Biology Improve Medicine? Current Therapies Maximizing Specific Effects Minimizing Non- Specific Effects Leads to two main optimization parameters

slide-1
SLIDE 1

Ashwin Amurthur, Peter Qiao, Michael Magaraci, Avin Veerakumar

slide-2
SLIDE 2

How can Synthetic Biology Improve Medicine?

slide-3
SLIDE 3

Current Therapies

  • Maximizing Specific

Effects

  • Minimizing Non-

Specific Effects

  • Leads to two main
  • ptimization

parameters

– Targeting Specificity – Dosage Control

slide-4
SLIDE 4

Cancer As a Case Study

Current Cancer Therapies

  • Significant Off Target Effects

– Chemotherapy – Radiation Therapy

  • Dosage Control

– Passive Diffusion – Difficulty reaching tumors – Not optimized

slide-5
SLIDE 5

Cancer As a Case Study

Current Cancer Therapies

  • Significant Off Target Effects

– Chemotherapy – Radiation Therapy

  • Dosage Control

– Passive Diffusion – Difficulty reaching tumors – Not optimized

Proposed Bacterial Therapies

  • Specifically target cancer

cell lines

– Strains that actively seek hypoxic environments – Engineered cell-surface receptors allow for specific binding

  • Induced cytotoxicity

– Systems to regulate gene expression – Cancer-specific therapeutics

slide-6
SLIDE 6
slide-7
SLIDE 7
slide-8
SLIDE 8

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

Achieving Light-Activated Cell Lysis

Goal is to demonstrate that:

  • YF1/FixJ (pDawn) blue light sensor can be activated for

downstream transgene expression

  • YF1/FixJ blue light sensor allows for light dependent lysis
  • f mammalian cells
slide-9
SLIDE 9

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

YF1/FixJ BL Sensor Allows For Light- Dependent Transgene Expression

0h 1h 2h 3h 4h 6h 8h 22h

slide-10
SLIDE 10

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

Cytolysin A (ClyA)

(Wallace et. al, 2000)

slide-11
SLIDE 11

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

Light-triggered lysis of mammalian cells by pDawn-ClyA bacteria

(D) (L)

slide-12
SLIDE 12

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

ClyA hemolysis can be characterized through dose-response

ClyA Cytotoxicity Assay – SKBR3 1.26 * 105 HER2 receptors per cell (High HER2 expressing) ClyA Cytotoxicity Assay – HEK293T 4.23 * 103 HER2 receptors per cell (Low HER2 expressing)

slide-13
SLIDE 13

Spatial control of cell Lysis

slide-14
SLIDE 14

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

Targeting Cancer Cells

slide-15
SLIDE 15

Ice Nucleation Protein, NC Domain

  • Outer membrane protein

Discovered in P. syringae

  • Promotes ice crystallization
  • Can remove internal repeats

and display proteins on the surface of E. coli

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

slide-16
SLIDE 16

Displaying DARPin H10-2-G3

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

DARPin H10-2-G3

slide-17
SLIDE 17

Assaying Display of DARPin H10-2-G3

  • HA tag allowed detection of surface proteins

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

INPNC-HA (+IPTG) INPNC-HA (-IPTG)

slide-18
SLIDE 18

DARPin was Successfully Displayed!

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

DARPin-HA (-IPTG) DARPin-HA (+IPTG)

INPNC-DARPin-HA (-IPTG) INPNC-DARPin-HA (+IPTG)

slide-19
SLIDE 19

Can our Bacteria Bind to Cancer Cells?

  • SKBR3 Cells are derived

from breast tumors

  • Overexpress HER2

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

DAPI, HER2

Breast Tumor Tissue1 Our Cultured SKBR3 Cells

  • 1. Y. Xiao, X. Gao, G. Gannot, M.R. Emmert-Buck, S. Srivastava,

P.D. Wagner, M.A.Amos and P.E. Barker. Quantitation of HER2 and telomerase biomarkers in solid tumors with IgY antibodies and nanocrystal detection. International Journal of Cancer

slide-20
SLIDE 20

DARPin-displaying Bacteria Bind to SKBR3 Cells Preferentially

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

HEK293T (Basal HER2) SKBR3 (High HER2)

DAPI HER2 eGFP

+E. coli (+IPTG) +E. coli (-IPTG)

slide-21
SLIDE 21

DARPin-displaying Bacteria Bind to SKBR3 Cells Preferentially

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

DAPI, HER2, eGFP

slide-22
SLIDE 22

Submitted BioBricks

  • ClyA BioBricks
  • INPNC: BBa_K811003
  • INPNC-HA: BBa_K811004
  • INPNC-MCS: BBa_K811005
  • General surface display

vector for any iGEM team

  • Only one ligation needed!

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

slide-23
SLIDE 23

Summary

  • First light-activated

drug delivery in bacteria

  • First display of a

DARPin on cell surface

  • DARPin targeted

cancer cells in vitro

  • Created general

Surface Display platform

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

slide-24
SLIDE 24

Human Practices

slide-25
SLIDE 25
slide-26
SLIDE 26
slide-27
SLIDE 27
slide-28
SLIDE 28 http://2009.igem.org/Team:Stanford
  • Many people have tried

to apply synthetic biology to treat disease. – Over 75 Health/Medicine teams since 2009 – Many, many papers since 1995!

  • Where are they now?
  • Why?

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

Looking Back on Eight Years of iGEM: Where are We Now?

http://2008.igem.org/Team:MIT http://2011.igem.org/Team:Missouri_Miners
slide-29
SLIDE 29

Biological and Perception Barriers to Bacterial Therapeutics

Biological Barriers

  • E. coli produces

compounds that are immunogenic

  • Lab strains are poor

candidates for use in the human body Perception Barriers

  • Negative portrayal
  • f E. coli in the

media

  • Public unfamiliar

with synthetic biology

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

slide-30
SLIDE 30

The Hype Cycle

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion Linden, A. (2003). Understanding gartner’s hype cycles. Conshohocken: Gartner.

slide-31
SLIDE 31

Education & Outreach

  • Presentation/Q&A

session with high school students

  • Clark Park Science

Discovery Day

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

slide-32
SLIDE 32

Solving the Biological and Perception Problems

  • E. coli Nissle 1917

– Nonpathogenic – Used as a probiotic supplement in Canada and Europe – Low immunogenicity – Generally Regarded As Safe by the FDA

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

http://www.npr.org/blogs/thesalt/2012/07/09/156381323/confusion-at-the-yogurt-aisle-time-for- probiotics-101 http://www.msnbc.msn.com/id/27454348/ns/health- diet_and_nutrition/t/probiotics-more-hype- help/#.UHd2ScXA-f4 http://sitemaker.umich.edu/huffnagl e.lab/_the_probiotics_revolution___ book_
slide-33
SLIDE 33

The pDawn Expression System is Functional in Nissle 1917

  • Chemically

competent Nissle 1917 achieved light controlled clyA hemolysis

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

+1000 μg pDawn-his-ClyA +H2O (Neg. Control)

pDawn-mCherry Light pDawn-mCherry Dark pDawn-his-clyA Dark pDawn-his-clyA Light

slide-34
SLIDE 34

Recommendation for Future H&M iGEM Teams

  • When designing a project, keep clinical

endpoints in mind

  • Utilize strains of bacterial like Nissle 1917

– Scientific benefits – Perception benefits

  • Use outreach events as an opportunity to

smooth out the hype curve

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

slide-35
SLIDE 35

Project Summary

  • Light dependent clyA expression & hemolysis
  • INPNC based display of proteins

– Easily adapted for surface display of any protein

  • HER-2 dependent binding of bacteria to human cells
  • Modular binding & cell lysis systems

– Can be repurposed – Interchangable parts

  • A low cost way of improving the reliability of biobricks
  • A careful consideration of the adoption of bacterial

therapeutics

– Nissle 1917

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

slide-36
SLIDE 36

Future Directions

  • Use other wavelengths of light
  • Port the entire system into Nissle 1917
  • Integrate our system into E. coli. genome
  • Test our system in a mouse model

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

slide-37
SLIDE 37

Acknowledgements

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

  • Dr. Casim A. Sarkar
  • Dr. Jordan Miller
  • Dr. Mark Goulian
  • Najaf Shah
  • Daphne Ng
  • Sevile Mannickarottu
  • Henry Ma
  • Nikita Singh
  • Karsticum Computing Inc.
slide-38
SLIDE 38

Sponsors

slide-39
SLIDE 39

Questions and Answers

slide-40
SLIDE 40

Backup Slides

slide-41
SLIDE 41

Testing the System with mCherry

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion

slide-42
SLIDE 42

Testing the System with mCherry

  • Fused INPNC to mCherry

with 12aa GS Linker

  • Sonicated INPNC-

mCherry expressing E. coli and separated lysate and membrane fraction

Introduction Light-Based Drug Delivery Surface Display & Targeting Human Practices Conclusion
