SLIDE 1

ARM big.LITTLE Technology

Advanced Seminar – Computer Engineering Philipp Gsching 08.12.2015

1

SLIDE 2

1. Introduction
2. ARM Architecture

1.

Instruction Set

2.

Microarchitecture

3.

CPUs

3. big.LITTLE

1.

Cache Coherency

2.

Distributed Virtual Memory

3.

Performance

4. Conclusion

2

SLIDE 3

 Smartphone/Tablet use cases: 1.

Idle most of the time  low power CPU

2. High-performance requirements

 high performance CPU

 Difficult to achieve with one CPU

3

SLIDE 4

 Idea: ARM big.LITTLE

Fusing a low-power and a high-performance CPU in

ne chip

LITTLE

OS
UI
Internet
E-Mail
…

big

Gaming
HD – videos
Rich Web

Services

…

Cache Coherent Interconnect LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 1 3 4 L2 Cache L2 Cache

4

SLIDE 5

Basics

5

SLIDE 6

 Advanced RISC Machines  Founded:

1990 by Acorn, Apple and VLSI

 Origin:

Microcontrollers / Embedded Systems

 Business model: design and licensing of

Intellectual Property (IP)

 Revenue:

1.2 billion USD

( Intel: 55.8 billion USD )

 Employees:

3,300

( Intel: 106,700 )

 Market Share: > 90%

(2014, smartphone/tablet)

6

SLIDE 7

 ARM Instruction Set:

RISC (Reduced Instruction Set Computing)

7

SLIDE 8

RISC (ARM)

MOV r2, #8 MUL r1, r1, r2 ADD r0, r0, r1 ADD r0, r0, #4 LDR r3, [r0] ADD r3, r3, #1 STR r3, [r0]

CISC (IA-32)

ADD $1, 4(%eax, %ebx, 8)

8

SLIDE 9

Not strictly RISC

 ARM Instruction Set:

RISC (Reduced Instruction Set Computing)
16 general purpose registers + 2 status registers
32-bit fixed-size instructions
Condition Codes for (almost) all instructions
Barrel Shifter for ALU
16-bit fixed-size THUMB instructions
Digital Signal Processing (DSP) instructions
Cryptography Extension Instructions

9

SLIDE 10

RISC (ARM)

MOV r2, #8 MUL r1, r1, r2 ADD r0, r0, r1 ADD r0, r0, #4 LDR r3, [r0] ADD r3, r3, #1 STR r3, [r0] ADD r0, r0, r1, LSL #3 LDR r3, [r0, #4]! ADD r3, #1 STR r3, [r0]

CISC (IA-32)

ADD $1, 4(%eax, %ebx, 8) Microcode

10

SLIDE 11

Instruction Set Architecture (ISA) has no significant impact on performance and power consumption

Tech-independet, scaled to 1GHz, 45 nm process, normalized to A8 1 2 3 4

Average Power (normalized)

A8 (ARM, 0.6GHz, 65nm, iPhone 4) A15 (ARM, 1.66GHz, 32nm, Galaxy S4) Atom (x86, 1.66GHz, 45nm, Netbook) i7 (x86, 3.4GHz, 32nm, Desktop)

11

SLIDE 12

 ARM Instruction Set  Microarchitecture:

Technology-node and feature size
Voltage and Frequency Scaling
Power-domains
Clock-gating
Power-modes
Pipelining
Caches
SoC (System-On-A-Chip) design

12

SLIDE 13

 ARM Instruction Set  Microarchitecture:

Technology-node and feature size
Voltage and Frequency Scaling
Power-domains
Clock-gating
Power-modes
Pipelining
Caches
SoC (System-On-A-Chip) design

Reducing capacitance

13

SLIDE 14

 ARM Instruction Set  Microarchitecture:

Technology-node and feature size
Voltage and Frequency Scaling
Power-domains
Clock-gating
Power-modes
Pipelining
Caches
SoC (System-On-A-Chip) design

Dynamically adjusting supply voltage and clock speed according to need

14

SLIDE 15

 ARM Instruction Set  Microarchitecture:

Technology-node and feature size
Voltage and Frequency Scaling
Power-domains
Clock-gating
Power-modes
Pipelining
Caches
SoC (System-On-A-Chip) design

Power supply for different sections of core can be turned

n/off independently

15

SLIDE 16

 ARM Instruction Set  Microarchitecture:

Technology-node and feature size
Voltage and Frequency Scaling
Power-domains
Clock-gating
Power-modes
Pipelining
Caches
SoC (System-On-A-Chip) design

Clock for different sections of the core can be turned on/off independently

16

SLIDE 17

 ARM Instruction Set  Microarchitecture:

Technology-node and feature size
Voltage and Frequency Scaling
Power-domains
Clock-gating
Power-modes
Pipelining
Caches
SoC (System-On-A-Chip) design

Predefined low-power modes utilizing the above mentioned features

17

SLIDE 18

 ARM Instruction Set  Microarchitecture:

Technology-node and feature size
Voltage and Frequency Scaling
Power-domains
Clock-gating
Power-modes
Pipelining
Caches
SoC (System-On-A-Chip) design

Reducing idle time of different parts of core

18

SLIDE 19

 ARM Instruction Set  Microarchitecture:

Technology-node and feature size
Voltage and Frequency Scaling
Power-domains
Clock-gating
Power-modes
Pipelining
Caches
SoC (System-On-A-Chip) design

Reducing time and power intensive accesses to main memory

19

SLIDE 20

 ARM Instruction Set  Microarchitecture:

Technology-node and feature size
Voltage and Frequency Scaling
Power-domains
Clock-gating
Power-modes
Pipelining
Caches
SoC (System-On-A-Chip) design

Adjusting all components of a processor to one- another

20

SLIDE 21

 ARM Instruction Set  Microarchitecture:

Technology-node and feature size
Voltage and Frequency Scaling
Power-domains
Clock-gating
Power-modes
Pipelining
Caches
SoC (System-On-A-Chip) design

ARMs emphasis is on power consumption and size  Momentum for mobile market

21

SLIDE 22

Snoop Controller Unit L2 Cache (shared) Cluster SoC MMU TLB BUS Arbiter Core 1

µTLB Instr. Data

L1 Cache

Instr. Data

22

SLIDE 23

Snoop Controller Unit L2 Cache (shared) Cluster SoC MMU TLB BUS Arbiter Core 1

µTL B Instr. Data

L1 Cache

Instr. Data

Cortex A53

8-stage (integer), in-order

Cortex A57

15-stage (integer), out-of-order

23

SLIDE 24

LITTLE big CPU Cortex A53 Cortex A57 64-bit Yes Yes Cores 1 – 4 1 – 4 Frequency* 1.3 GHz 1.9 GHz L1 Cache 8 – 64 kB 48/32 kB L2 Cache 128 – 2,048 kB 512 – 2,048 kB Pipeline Integer depth 8 15 Out-of-order No Yes Performance 2.3 DMIPS/MHz 4.1 DMIPS/MHz Technology node* 20 nm 20 nm Core Size* 0.70 mm² 2.05 mm² Cluster Size* 4.58 mm² 15.10 mm² * Values for SoC Samsung Exynos 5433 (Galaxy Note 4)

24

SLIDE 25

1 2 3 4 5 6 7 8

400 500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800 1900

Power Consumption (W) Frequency (MHz)

Cortex-A Power Consumption

A53 (1 Core) A53 (4 Cores) A57 (1 Core) A57 (4 Cores) SoC: Samsung Exynos 5433 (Galaxy Note 4)

25

SLIDE 26

Heterogenous multi-processing

26

SLIDE 27

LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 1 3 4 L2 Cache L2 Cache

Connecting two heterogeneous clusters…

27

 Binary compatible

SLIDE 28

Big Cortex A57

AXI = Advanced eXtensible Interface

LITTLE Cortex A53 1 2 3 4 3 4 L2 Cache L2 Cache AXI 2 1 AXI

28

SLIDE 29

LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 1 3 4 L2 Cache L2 Cache AXI AXI Read_Adress Read_Data Write_Adress Write_Data Write_Ack

29

SLIDE 30

LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 1 3 4 L2 Cache L2 Cache AXI ACE AXI

Read_Adress Read_Data Write_Adress Write_Data Write_Ack

ACE

C_Address C_Data C_Response 30

SLIDE 31

LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 1 3 4 L2 Cache L2 Cache AXI ACE AXI ACE

C_Address C_Data C_Response

ACE = AXI Coherency Extension

31

SLIDE 32

LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 1 3 4 L2 Cache L2 Cache AXI ACE AXI ACE

Cache Coherent Interconnect

32

SLIDE 33

SoC

Cache Coherent Interconnect

GPU BUS 1 2 3 4 L2 Cache 2 1 3 4 L2 Cache Memory Controller Display Periphery

33

SLIDE 34

Valid Invalid Unique Shared Dirty Unique Dirty Shared Dirty Invalid Clean Unique Clean Shared Clean LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 1 3 4

Cache Coherent Interconnect

L2 Cache L2 Cache AXI ACE AXI ACE Coherency States Analogical to MOESI-protocol: Modified, Owned, Exclusive, Shared, Invalid

34

SLIDE 35

LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 1 3 4

Cache Coherent Interconnect

Cache Cache AXI ACE AXI ACE

35

SLIDE 36

LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 1 3 4

Cache Coherent Interconnect

Cache Cache AXI ACE AXI ACE

1. LITTLE  load(A)

36

SLIDE 37

LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 1 3 4

Cache Coherent Interconnect

Cache Cache AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)

37

SLIDE 38

LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 1 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)

Cache Cache

38

SLIDE 39

LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 1 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)

to main memory Cache Cache

39

SLIDE 40

LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 1 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)
5. CCI  return(A)

Cache Cache

40

SLIDE 41

LITTLE Cortex A53 2 3 4 Big Cortex A57 2 1 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)
5. CCI  return(A)

Au

Cache Au Cache

41

SLIDE 42

LITTLE Cortex A53 2 3 4 Big Cortex A57 2 1 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)
5. CCI  return(A)
6. big  load(A)

Au

Cache Cache Au

42

SLIDE 43

LITTLE Cortex A53 2 3 4 Big Cortex A57 2 1 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)
5. CCI  return(A)
6. big  load(A)

7. CCI  snoop(A)

Au

Cache Cache Au

43

SLIDE 44

LITTLE Cortex A53 2 3 4 Big Cortex A57 2 1 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)
5. CCI  return(A)
6. big  load(A)

7. CCI  snoop(A)

8. LITTLE  resp(hit)  return(A)

As

Cache Cache As

44

SLIDE 45

LITTLE Cortex A53

As

2 3 4 Big Cortex A57 2 1 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)
5. CCI  return(A)
6. big  load(A)

7. CCI  snoop(A)

8. LITTLE  resp(hit)  return(A)
9. CCI  return(A)

Cache Cache As

45

SLIDE 46

LITTLE Cortex A53

As

2 3 4 Big Cortex A57 2

As

3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)
5. CCI  return(A)
6. big  load(A)

7. CCI  snoop(A)

8. LITTLE  resp(hit)  return(A)
9. CCI  return(A)

Cache As Cache As

46

SLIDE 47

LITTLE Cortex A53

A′s

2 3 4 Big Cortex A57 2 1 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)
5. CCI  return(A)
6. big  load(A)

7. CCI  snoop(A)

8. LITTLE  resp(hit)  return(A)
9. CCI  return(A)

Cache As Cache As

47

SLIDE 48

LITTLE Cortex A53

A′s

2 3 4 Big Cortex A57 2 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)
5. CCI  return(A)
6. big  load(A)

7. CCI  snoop(A)

8. LITTLE  resp(hit)  return(A)
9. CCI  return(A)
10. LITTLE  makeUnique(A)

Cache As Cache As 1

48

SLIDE 49

LITTLE Cortex A53

A′s

2 3 4 Big Cortex A57 2 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)
5. CCI  return(A)
6. big  load(A)

7. CCI  snoop(A)

8. LITTLE  resp(hit)  return(A)
9. CCI  return(A)
10. LITTLE  makeUnique(A)
11. CCI  invalidate(A)

Cache As Cache As 1

49

SLIDE 50

LITTLE Cortex A53

A′s

2 3 4 Big Cortex A57 2 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)
5. CCI  return(A)
6. big  load(A)

7. CCI  snoop(A)

8. LITTLE  resp(hit)  return(A)
9. CCI  return(A)
10. LITTLE  makeUnique(A)
11. CCI  invalidate(A)
12. big  invalidated  resp(ack)

Cache --- Cache As 1

50

SLIDE 51

LITTLE Cortex A53

A′u

2 3 4 Big Cortex A57 2 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)
5. CCI  return(A)
6. big  load(A)

7. CCI  snoop(A)

8. LITTLE  resp(hit)  return(A)
9. CCI  return(A)
10. LITTLE  makeUnique(A)
11. CCI  invalidate(A)
12. big  invalidated  resp(ack)
13. CCI  resp(isUnique)

Cache --- Cache Au 1

51

SLIDE 52

LITTLE Cortex A53 1 2 3 4 Big Cortex A57 2 3 4

Cache Coherent Interconnect

AXI ACE AXI ACE

1. LITTLE  load(A)
2. CCI  snoop(A)
3. big  resp(miss)
4. CCI  load_mem(A)
5. CCI  return(A)
6. big  load(A)

7. CCI  snoop(A)

8. LITTLE  resp(hit)  return(A)
9. CCI  return(A)
10. LITTLE  makeUnique(A)
11. CCI  invalidate(A)
12. big  invalidated  resp(ack)
13. CCI  resp(isUnique)
14. LITTLE  store(A)

Cache --- Cache A′𝑣 1

52

SLIDE 53

LITTLE Cortex A53 1 1 1 A Big Cortex A57

Cache Coherent Interconnect

AXI ACE AXI ACE

TLB

Distributed Virtual Memory (DVM):

Threads on different cores

share the same virtual memory

Core A causes change in page

table  core Bs TLB entry out-

f-date
Core A issues invalidation

message  CCI broadcasts TLB entry invalidation  Core B invalidates TLB entry

1 1 1 B L2 Cache L2 Cache

TLB

 TLBs are read-only  DVM messages can only invalidate entries (can‘t fetch entries)

53

SLIDE 54

ACE Performance:

 ACE clock can be integer fractions of CPU clock (including

1:1)

 16 simultaneous write commands per cluster  8 simultaneous read commands per core

Snoop Performance:

 SCU is clocked with CPU clock  8 simultaneous snoops per cluster  Snoop response after:

13 cycles (L2 hit) 16 cycles (L1 hit) 6 cycles (Cache miss)

54

SLIDE 55

ACE Performance:

 ACE clock can be integer fractions of CPU clock (including

1:1)

 16 simultaneous write commands per cluster  8 simultaneous read commands per core

Snoop Performance:

 SCU is clocked with CPU clock  8 simultaneous snoops per cluster  Snoop response after:

13 cycles (L2 hit) 16 cycles (L1 hit) 6 cycles (Cache miss)

55

SLIDE 56

 Queue of 8 transaction, 16 cycle wait  Each transaction returns one cache line  64 byte cache line width  128-bit data channel width (16 bytes)

 32 kB L1 transfer: 32 𝑙𝐶𝑧𝑢𝑓𝑡

16 𝐶𝑧𝑢𝑓𝑡 + 16 = 2,013

 2 MB L2 transfer: 2 𝑁𝐶𝑧𝑢𝑓𝑡

16 𝐶𝑧𝑢𝑓𝑡 + 13 = 131,088

4 cycles

56

SLIDE 57

A53 @ 1.3 GHz E5520 @ 2.26 GHz

 Queue of 8 transaction, 16 cycle wait  Each transaction returns one cache line  64 byte cache line width  128-bit data channel width (16 bytes)

 32 kB: ~ 1.5 µs ~ 6.5 µs  2 MB: ~ 100 µs ~ 30 µs

4 cycles

57

SLIDE 58

58

0,01 0,1 1 10 920 1380 2300 3450 4600 6440 8280 10120 11960 14760 18040 21320 24600 27880 31160 34920 38200 41480 Power Consumption in W Performance in DMIPS

Samsung Exynos 5433 (Galaxy Note 4)

big.LITTLE Cortex A53 Cortex A57

SLIDE 59

59

0,01 0,1 1 10 920 1380 2300 3450 4600 6440 8280 10120 11960 14760 18040 21320 24600 27880 31160 34920 38200 41480 Power Consumption in W Performance in DMIPS

Samsung Exynos 5433 (Galaxy Note 4)

big.LITTLE Cortex A53 Cortex A57 Power advantage ~ 70% ~ 55%

SLIDE 60

60

0,01 0,1 1 10 920 1380 2300 3450 4600 6440 8280 10120 11960 14760 18040 21320 24600 27880 31160 34920 38200 41480 Power Consumption in W Performance in DMIPS

Samsung Exynos 5433 (Galaxy Note 4)

big.LITTLE Cortex A53 Cortex A57 ~ 25% Performance advantage

SLIDE 61

61

0,01 0,1 1 10 920 1380 2300 3450 4600 6440 8280 10120 11960 14760 18040 21320 24600 27880 31160 34920 38200 41480 Power Consumption in W Performance in DMIPS

Samsung Exynos 5433 (Galaxy Note 4)

big.LITTLE Cortex A53 Cortex A57 Thermal barrier: ~7 W  Temp. > 40-50 °C

SLIDE 62

62

0,01 0,1 1 10 920 1380 2300 3450 4600 6440 8280 10120 11960 14760 18040 21320 24600 27880 31160 34920 38200 41480 Power Consumption in W Performance in DMIPS

Samsung Exynos 5433 (Galaxy Note 4)

big.LITTLE Cortex A53 Cortex A57 Idle/low-power advantage

SLIDE 63

 smaller performance advantage (up to 25%) for

high performance applications  TDP usually too high for 8 cores at maximum frequency

 significant power advantages (up to 70%) for

high efficiency applications  better performance/power for entire system

 low power Idle (and background apps) not

available to high performance CPUs

63

SLIDE 64

 Heterogeneous CPUs are possible  big.medIUM.LITTLE:

Helio X20 SoC

64

SLIDE 65

Sources and References:



Papers

E. Blem, J. Menon, T. Vijayaraghavan, K. Sankaralingam. (2015, March). ISA Wars: Understanding the Relevance of ISA being RISC or CISC to Performance,

Power, and Energy on Modern Architectures. ACM Transactions on Computer Systems. [Type of medium]. Vol. 33, No.1, Article 3. Available: http://tocs.acm.org/

T. Mitra. (2014). Energy-Efficient Computing with Heterogeneous Multi-Cores, Presented at International Symposium on Integrated Circuits (ISIC).
V. Villebonnet, G. Da Costa, L. Lefevre, J.-M. Pierson, P. Stolf. (2014). Towards Generalizing "Big.Little" for Energy Proportional HPC and Cloud
Infrastructures. Presented at IEEE Fourth International Conference on Big Data and Cloud Computing.
S. Yoo, Y. Shim, S. Lee, S.-A. Lee, J. Kim. (2015, October). A case for bad big.LITTLE switching: How to scale power-performance in SI-HMP. Presented at

Hotpower’15, Monterey, CA, USA.



ARM Technical Reference Manuals and publications

ARMv7 Architecture Reference Manual, ARM Ltd., Cherry Hinton, Cambridge, 2014.
ARMv8 Architecture Reference Manual, ARM Ltd., Cherry Hinton, Cambridge, 2015.
CoreLink CCI-400 Cache Coherent Interconnect Technical Reference Manual, ARM Ltd., Cherry Hinton, Cambridge, 2012.
AMBA AXI and ACE Protocol Specification, ARM Ltd., Cherry Hinton, Cambridge, 2013.
Introduction to AMBA 4 ACE and big.LITTLE Processing Technology, ARM Ltd., Cherry Hinton, Cambridge, 2013.
ARM Cortex-A53 MPCore Processor Technical Reference Manual, ARM Ltd., Cherry Hinton, Cambridge, 2014.
ARM Cortex-A57 MPCore Processor Technical Reference Manual, ARM Ltd., Cherry Hinton, Cambridge, 2014.
big.LITTLE Technology: The Future of Mobile, ARM Ltd., Cherry Hinton, Cambridge, 2013.



Internet

A. Frumusanu, R. Smith. (2015, February). ARM A53/A57/T760 investigated - Samsung Galaxy Note 4 Exynos Review. Available:

http://www.anandtech.com/show/8718/the-samsung-galaxy-note-4-exynos-review/

B. Sigoure, (2010, November) How long does it take to make a context switch? Available: http://blog.tsunanet.net/2010/11/how-long-does-it-take-to-make-

context.html



Other

H.-D. Cho, K. Chung, T. Kim. (2012, February). Benefits of the big.LITTLE Architecture. Samsung Electronics, Seoul.
K. Yu, (2012) big.LITTLE Switchers – Evaluation on Exynos.bl Processor. Presented at 2012 Korea Linux Forum. Available:

http://events.linuxfoundation.org/images/stories/pdf/klf2012_yu.pdf

65

SLIDE 66

31 30 29 28

… Condition Code = ? Instruction Status Register

Bit Bit

31 30 29 28 27

… N Z C V Q e.g. 0000 := Zero flag (Z) is set 0001 := Zero flag (Z) is clear CMP r4, r5 ; (r4 – r5) == 0 ? ADDEQ r1, r2, r3 ; if equal: r1 := r2 + r3 ADDNE r1, r2, r4 ; else: r1 := r2 + r4 Not-executed instruction takes up 1 cycle

66

SLIDE 67

Registers r0 – r15 Barrel Shifter Operand A Operand B Result MOV r4, #2 ; binary: 0010 ADD r5, r4, r4, LSL #1 ; r5 := r4 + (r4 << 1) ; r5 := 0010 + 0100 ; r5 := 2 + 4 ALU Shift operation: +1 cycle N

67

SLIDE 68

68 Clock: 2,26 GHz (Turbo: 2,53 GHz) Cores: 4 (capable of hyperthreading) Cache: 8 MB (L1 64 kB per core, L2 256kB per core, 8 MB shared) TDP: 80 W Node: 45 nm Year: 2009

SLIDE 69

69
