Applied Spark

From Concepts to Bitcoin Analytics

Andrew F. Hart – ahart@apache.org | @andrewfhart

My Day Job

• CTO, Pogoseat
• Upgrade technology for

live events

3/28/16 QCON-SP Andrew Hart 2

Additionally…

• Member, Apache Software Foundation

3/28/16 QCON-SP Andrew Hart 3

Additionally…

• Founder, Data Fluency

Software consultancy specializing in appropriate data solutions for startups and smb's Help clients make good decisions and leverage power traditionally accessible only to big business

3/28/16 QCON-SP Andrew Hart 4

Previously…

• NASA Jet Propulsion Laboratory

Building data management pipelines for research missions in many domains (Climate, Cancer, Mars, Radioastronomy, etc.)

3/28/16 QCON-SP Andrew Hart 5

Apache Spark

3/28/16 QCON-SP Andrew Hart 6

Spark is…

• General purpose cluster computing software that

maximizes use of cluster memory to process data

• Used by hundreds of organizations to realize

performance gains over previous-generation cluster compute platforms, particularly for map- reduce style problems

3/28/16 QCON-SP Andrew Hart 7

Spark…

• Was developed at the Algorithms,

Machines, and People laboratory (AMP Lab) at the University of California, Berkeley in 2009

• Is open source software presently under

the governance of the Apache Software Foundation

3/28/16 QCON-SP Andrew Hart 8

Why Spark Exists

• Confluence of three trends:

Increased volume of digital data Decreasing cost of computer memory (RAM) Data processing technology liberation

3/28/16 QCON-SP Andrew Hart 9

Digital data volume

• Early days

– low-resolution sensors, comparatively few people

• n the internet

– proprietary data, custom solutions, expensive, custom hardware

3/28/16 QCON-SP Andrew Hart 10

Digital data volume

• Modern era

– ubiquitous, high-resolution cameras – mobile devices packed with sensors – i.o.t. – open source software, cheap commodity hardware

3/28/16 QCON-SP Andrew Hart 11

We've gone from this Internet…

3/28/16 QCON-SP Andrew Hart 12

3/28/16 QCON-SP Andrew Hart 13

To this… (Humanity's global communication platform)

3/28/16 QCON-SP Andrew Hart 14

1.5 Billion connected PCs 3.2 Billion connected people 6 Billion connected mobile devices

3/28/16 QCON-SP Andrew Hart 15

What are we doing with all of this? Every minute:

• 18,000 votes cast on Reddit
• 51,000 apps downloaded by Apple users
• 350,000 tweets posted on Twitter
• 4,100,000 likes recorded on Facebook

3/28/16 QCON-SP Andrew Hart 16

We are awash in data…

• Monetizing this data is a core competency for

many businesses

• Need tools to do this effectively at today's scale

• 2. Tool support and technology liberation

3/28/16 QCON-SP Andrew Hart 17

3/28/16 QCON-SP Andrew Hart 18

How far do you want to go back? We have always used tools to help us cope with data

3/28/16 QCON-SP Andrew Hart 19

VisiCalc

• Early "big data" tool

– Allowed business to move from the chalk board to the digital spreadsheet – Phenomenal increase in productivity running numbers for business

3/28/16 QCON-SP Andrew Hart 20

Modern-era Spreadsheet Tech Microsoft Excel 1,048,576 rows x 16,384 columns

3/28/16 QCON-SP Andrew Hart 21

Open Source Alternatives Exist… Microsoft Excel 1,048,576 rows x 16,384 columns Apache OpenOffice 1,048,576 rows x 1,024 columns

3/28/16 QCON-SP Andrew Hart 22

Relational Database Systems

• Support thousands of tables,

millions of rows…

3/28/16 QCON-SP Andrew Hart 23

Relational Database Systems

• Support thousands of tables,

millions of rows…

• Viable open source alternatives

exist for many use cases

3/28/16 QCON-SP Andrew Hart 24

Modern Big Data Era

• MapReduce Algorithm (2004)

parallelize large-scale computation across clusters of servers

3/28/16 QCON-SP Andrew Hart 25

Modern Big Data Era

• Hadoop

Open source processing framework for MapReduce applications to run

• n large clusters of commodity

(unreliable) hardware

• 3. Commoditization of computer memory

3/28/16 QCON-SP Andrew Hart 26

Early Days…

• Main memory was

hand made.

• You could see

each bit.

3/28/16 QCON-SP Andrew Hart 27

Modern Era… AWS EC2 r3.8xlarge 244 GiB for US$1.41/hr*

3/28/16 QCON-SP Andrew Hart 28

Why talk about memory?

• Ability to use memory efficiently distinguishes

Spark from Hadoop, contributes to its speed advantages in many scenarios

3/28/16 QCON-SP Andrew Hart 29

How Spark Works

3/28/16 QCON-SP Andrew Hart 30

Primary abstraction in Spark: Resilient Distributed Datasets (RDD)

• Immutable (read-only), partitioned dataset
• Processed in parallel on each cluster node
• Fault-tolerant – resilient to node failure

3/28/16 QCON-SP Andrew Hart 31

Primary abstraction in Spark: Resilient Distributed Datasets (RDD)

• Uses the distributed memory of the cluster to

store the state of a computation as a sharable

• bject across jobs

(…instead of serializing to disk)

3/28/16 QCON-SP Andrew Hart 32

Traditional MapReduce:

3/28/16 QCON-SP Andrew Hart 33

Data on Disk Map-1 Map-2 . . . Map-n Tuples

• n Disk

Reduce-1 Reduce-2 . . . Reduce-n Tuples

• n Disk

HDFS Read HDFS Write HDFS Read HDFS Write

Spark RDD Architecture:

3/28/16 QCON-SP Andrew Hart 34

Data on Disk Map-1 Map-2 . . . Map-n Cluster Memory Reduce-1 Reduce-2 . . . Reduce-n Data on Disk HDFS Read HDFS Write RDD

Unified computational model:

• Spark unifies batch & streaming models, which

traditionally require different architectures

• Sort of like the limit theorem in Calculus

– If you imagine a time-series set of RDDs with ever smaller windows of time, you can approximate streaming workflows

3/28/16 QCON-SP Andrew Hart 35

Two ways to create an RDD in Spark Programs:

• "Parallelize" an existing collection (e.g.: Python

array) in the driver program

• Reference a dataset on external storage

– text files on disk – anything with a supported Hadoop InputFormat

3/28/16 QCON-SP Andrew Hart 36

RDDs from RDDs:

• RDDs are immutable (read-only)
• The result of applying transformations and

actions to an RDD is a new RDD

• RDD's can be persisted to memory

– reducing need to re-compute RDD every time

3/28/16 QCON-SP Andrew Hart 37

Writing Spark Programs: Think of spark programs as a way to describe a sequence of transformations and actions that should be applied to an RDD

3/28/16 QCON-SP Andrew Hart 38

Writing Spark Programs:

• Transformations create a new dataset from an

existing one (e.g.: map)

• Actions return a value after running a

computation (e.g.: reduce)

3/28/16 QCON-SP Andrew Hart 39

Writing Spark Programs:

• Spark provides a rich set of transformations:

map flatMap filter sample union intersection distinct groupByKey sortByKey cogroup pipe join cartesian coalesce

3/28/16 QCON-SP Andrew Hart 40

Writing Spark Programs:

• Spark provides a rich set of actions:

reduce collect count first take takeSample takeOrdered saveAsTextFile countByKey foreach

3/28/16 QCON-SP Andrew Hart 41

Writing Spark Programs:

• Transformations are lazily evaluated. They are
• nly computed when a subsequent action

(which must return a result) is run.

• Transformations get recomputed each time an

action is run (unless you explicitly persist the resulting RDD to memory)

3/28/16 QCON-SP Andrew Hart 42

Structure of Spark Programs: Spark programs have two principal components:

• Driver Program
• Worker function

3/28/16 QCON-SP Andrew Hart 43

Structure of Spark Programs: Driver program

• Executes on the master node
• Establishes context

3/28/16 QCON-SP Andrew Hart 44

Structure of Spark Programs: Worker (processing) function

• Executes on each worker node
• Computes transformations and actions
• n RDD partitions

3/28/16 QCON-SP Andrew Hart 45

Structure of Spark Programs: SparkContext

• Holds all of the information about the cluster
• Manages what gets shipped to nodes
• Makes life extremely easy for developers

3/28/16 QCON-SP Andrew Hart 46

Structure of Spark Programs: Shared Variables

• Broadcast variables: efficiently share static

data with the cluster nodes

• Accumulators: write-only variables that serve

as counters

3/28/16 QCON-SP Andrew Hart 47

Structure of Spark Programs: Worker (processing) function

• Executes on each worker node
• Computes transformations and actions
• n RDD partitions

3/28/16 QCON-SP Andrew Hart 48

Interacting with Spark

3/28/16 QCON-SP Andrew Hart 49

Spark APIs:

Spark provides APIS for several languages

• Scala
• Java
• Python
• R
• SQL

3/28/16 QCON-SP Andrew Hart 50

Using Spark: There are two main ways to leverage Spark

• Interactively through the included command

line interface

• Programmatically via standalone programs

submitted as jobs to the master node

3/28/16 QCON-SP Andrew Hart 51

Using Spark: Spark is GREAT for experimenting

• Run experimental programs on small sample

datasets on a single machine

• To scale up, simply re-target the SparkContext

to point to the master node of a Spark cluster

3/28/16 QCON-SP Andrew Hart 52

Bitcoin

3/28/16 QCON-SP Andrew Hart 53

Bitcoin is…

• A decentralized digital currency

– value is exchanged directly between individuals with no need for a traditional central authority (e.g.: bank)

• A global payment network

– transactions are broadcast and verified by network peers, with each using a complete copy of the network transaction history (the "blockchain")

3/28/16 QCON-SP Andrew Hart 54

Bitcoin is…

• A decentralized digital currency

– value is exchanged directly between individuals with no need for a traditional central authority (e.g.: bank)

• A global payment network

– transactions are broadcast and verified by network peers, with each using a complete copy of the network transaction history (the "blockchain")

3/28/16 QCON-SP Andrew Hart 55

Bitcoin Protocol

• Open source software

(http://github.com/bitcoin/bitcoin) for processing peer-to-peer financial transactions with zero trust

• The backbone of an experimental financial

system secured by math (instead of a trusted authority)

3/28/16 QCON-SP Andrew Hart 56

Bitcoin: Open Data

• Unprecedented transparency into the

workings of a financial network

– Peer-to-peer payments made using Bitcoin – Trading markets speculating on Bitcoin value

• Global, 24x7, Free
• Interesting research datasets abound

3/28/16 QCON-SP Andrew Hart 57

Bitcoin Exchange Companies

3/28/16 QCON-SP Andrew Hart 58

• Bitcoin exchange Logos

3/28/16 QCON-SP Andrew Hart 59

• Bitcoin exchange Logos

3/28/16 QCON-SP Andrew Hart 60

3/28/16 QCON-SP Andrew Hart 61

Spark Demos

3/28/16 QCON-SP Andrew Hart 62

The Hardware:

3/28/16 QCON-SP Andrew Hart 63

Master Node 6 CPU Cores 8GB RAM 6 CPU Cores 8GB RAM 6 CPU Cores 8GB RAM

The Goal:

• Demonstrate experimenting with Spark CLI
• Demonstrate program execution on a

standalone Spark cluster

3/28/16 QCON-SP Andrew Hart 64

The Data:

• 1 month of log files containing transactions

from 10 global exchanges (in 3 currencies)

• 1 trade per line, JSON encoded
• Organized into files by exchange, currency,

and date

3/28/16 QCON-SP Andrew Hart 65

The Question:

• What is the cumulative value of all "buy"-type

transactions in the dataset?

• Bonus: bucketed by fiat currency

3/28/16 QCON-SP Andrew Hart 66

3/28/16 QCON-SP Andrew Hart 67

Wrap-up

3/28/16 QCON-SP Andrew Hart 68

Things to keep in mind using Spark:

• Speed comes from avoiding writes to disk

– Allocate enough memory in your cluster to hold your data completely in memory

• Once data fits in memory, adding more is not

going to boost performance

3/28/16 QCON-SP Andrew Hart 69

Things to keep in mind using Spark:

• Once data fits in memory, most apps are CPU
• r network bound

– Allocate more cores in your cluster to increase parallelism (and tune Spark to use them!) – Have disks around to handle spillover, configure to reduce unnecessary writes

3/28/16 QCON-SP Andrew Hart 70

Spark ecosystem:

3/28/16 QCON-SP Andrew Hart 71

image credit: https://databricks.com/spark/about

Spark ecosystem (BDAS Stack):

3/28/16 QCON-SP Andrew Hart 72

image credit: https://amplab.cs.berkeley.edu/software/

Spark at the ASF:

3/28/16 QCON-SP Andrew Hart 73

https://spark.apache.org/

• Outstanding documentation
• Community mailing lists
• Updated project status
• Entered Incubator in 2013
• Graduated to "Top Level" project 2014
• 44 committers, 800+ contributors

Thank you! Contact: Twitter: @andrewfhart Email: ahart@apache.org Web: http://andrewfhart.com/

3/28/16 QCON-SP Andrew Hart 74
