API 17V - Recommended Practice for Analysis, Design, Installation and Testing of Safety Systems for Subsea Applications

Christopher Curran BSEE Workshop January 2014

Context

• Historically have used API 14C
• Advances in subsea developments led to BSEE

developing numerous NTLs:

– 2009 – G36 Using alternate compliance in safety systems for subsea production operations – Using secondary recovery methods including gas lift and water flood for subsea production operations – Subsea pumping for production operations

• API Summer 2011 – BSEE requested API to

address the gap

2

API RP17V – Subsea Safety Systems

• Work group formed Summer 2011 following

request from BSEE

• Closely following and working with API 14C
• First draft issued to reading group Summer 2012
• Second draft 2Q 2013
• API Ballot closed January 2014
• NB API 17O took 5 years, so this is fast track!
• BSEE have been actively engaged in this work

since its inception

3

Scope Drawing

API 17V – Areas to be covered

• Production and Injection trees
• Flowlines
• Chemical injection
• Manifolds
• Subsea separation
• Subsea boosting
• Subsea compression
• Gas lift
• HIPPS

5

Team Members

Working Group Reading Group Christopher Curran – BP 30+ people Christy Lan – BSEE Aker Solutions Atkins George Ardoin – Chevron ATP BHP Billiton William St George – ExxonMobil BP BSEE Richard Barratt – GE Cameron CSI Marc Young – Xodus ExxonMobil FMC Greg Cellos - BSEE Halliburton Hess IntecSea J P Kenny Shell Siemens Statoil Stone Energy Technip WJP Enterprises

6
