[PPT] - @andy_pavlo Part #1 Background Part # 2 Engineering Part # 3 PowerPoint Presentation

SLIDE 1

@andy_pavlo

SLIDE 2

Part #1 Part # 2 Part # 3 Background Engineering Oracle Rant

SLIDE 3 AUTONOMOUS DBMSs

3

SELF-ADAPTIVE DATABASES

1970-1990s Self-Adaptive Databases

→Index Selection →Partitioning / Sharding →Data Placement

SLIDE 4 AUTONOMOUS DBMSs

3

SELF-ADAPTIVE DATABASES

1970-1990s Self-Adaptive Databases

SELECT * FROM A JOIN B ON A.ID = B.ID WHERE A.VAL > 123 AND B.NAME LIKE 'XY%' Admin

SLIDE 5 AUTONOMOUS DBMSs

3

SELF-ADAPTIVE DATABASES

1970-1990s Self-Adaptive Databases

SELECT * FROM A JOIN B ON A.ID = B.ID WHERE A.VAL > 123 AND B.NAME LIKE 'XY%' A.ID A.VAL B.ID B.NAME Tuning Algorithm Admin

SLIDE 6 AUTONOMOUS DBMSs

3

SELF-ADAPTIVE DATABASES

1970-1990s Self-Adaptive Databases

SELECT * FROM A JOIN B ON A.ID = B.ID WHERE A.VAL > 123 AND B.NAME LIKE 'XY%' A.ID A.VAL B.ID B.NAME

+100 +200 +50

Tuning Algorithm Admin

SLIDE 7 AUTONOMOUS DBMSs

3

SELF-ADAPTIVE DATABASES

1970-1990s Self-Adaptive Databases

SELECT * FROM A JOIN B ON A.ID = B.ID WHERE A.VAL > 123 AND B.NAME LIKE 'XY%' A.ID A.VAL B.ID B.NAME

+100 +200 +50

Tuning Algorithm Admin

SLIDE 8 AUTONOMOUS DBMSs

3

SELF-ADAPTIVE DATABASES

1970-1990s Self-Adaptive Databases

SELECT * FROM A JOIN B ON A.ID = B.ID WHERE A.VAL > 123 AND B.NAME LIKE 'XY%' A.ID A.VAL B.ID B.NAME

+100 +200 +50

Tuning Algorithm Admin

SLIDE 9 AUTONOMOUS DBMSs

3

SELF-ADAPTIVE DATABASES

1970-1990s Self-Adaptive Databases

SELECT * FROM A JOIN B ON A.ID = B.ID WHERE A.VAL > 123 AND B.NAME LIKE 'XY%' A.ID A.VAL B.ID B.NAME Tuning Algorithm Admin

→Index Selection →Partitioning / Sharding →Data Placement

SLIDE 10 AUTONOMOUS DBMSs

4

SELF-TUNING DATABASES

1990-2000s Self-Tuning Databases

SELECT * FROM A JOIN B ON A.ID = B.ID WHERE A.VAL > 123 AND B.NAME LIKE 'XY%' Tuning Algorithm Admin

→Index Selection →Partitioning / Sharding →Data Placement

A.ID A.VAL B.ID B.NAME

SLIDE 11 AUTONOMOUS DBMSs

4

SELF-TUNING DATABASES

1990-2000s Self-Tuning Databases

SELECT * FROM A JOIN B ON A.ID = B.ID WHERE A.VAL > 123 AND B.NAME LIKE 'XY%' Tuning Algorithm Admin

AutoAdmin

A.ID A.VAL B.ID B.NAME Optimizer Cost Model

SLIDE 12 AUTONOMOUS DBMSs

4

SELF-TUNING DATABASES

1990-2000s Self-Tuning Databases

SELECT * FROM A JOIN B ON A.ID = B.ID WHERE A.VAL > 123 AND B.NAME LIKE 'XY%' Tuning Algorithm Admin

AutoAdmin

A.ID A.VAL B.ID B.NAME Optimizer Cost Model

SLIDE 13

541 291

200 400 600 2000 2004 2008 2012 2016 Number of Knobs

AUTONOMOUS DBMSs

4

SELF-TUNING DATABASES

1990-2000s Self-Tuning Databases

→Knob Configuration

SLIDE 14 AUTONOMOUS DBMSs

5

CLOUD MANAGED DATABASES

2010s Cloud Databases

SLIDE 15 AUTONOMOUS DBMSs

5

CLOUD MANAGED DATABASES

2010s Cloud Databases

SLIDE 16 AUTONOMOUS DBMSs

5

CLOUD MANAGED DATABASES

2010s Cloud Databases

→Initial Placement →Tenant Migration

SLIDE 17

W hy is this previous work insufficient?

SLIDE 18 AUTONOMOUS DBMSs

7

A BRIEF HISTORY

Problem #1 Human Judgements Problem #2 Reactionary Measures

SLIDE 19

W hat is different this time?

SLIDE 20 AUTONOMOUS DATABASES

Better hardware. Better machine learning tools. Better appreciation for data. We seek to complete the circle in autonomous databases.

WHY NOW?

SLIDE 21 CARNEGIE MELLON UNIVERSITY

10

RESEARCH PROJECTS

OtterTune Existing Systems Peloton New System

SLIDE 22

OtterTune

Database Tuning-as-a-Service → Automatically generate DBMS knob configurations. → Reuse data from previous tuning sessions.

ttertune.cs.cmu.edu

Supported Systems

SLIDE 23 OTTERTUNE

12

AUTOMATIC DBMS TUNING SERVICE

TARGET DATABASE

CONTROLLER

COLLECTOR

SLIDE 24 OTTERTUNE

12

AUTOMATIC DBMS TUNING SERVICE

TARGET DATABASE

TUNING MANAGER CONTROLLER

COLLECTOR Configur igurat ation

n

Recommend nder Knob Analyzer Metric Analyzer Interna ernal Reposit sitory ry

SLIDE 25 OTTERTUNE

12

AUTOMATIC DBMS TUNING SERVICE

TARGET DATABASE

TUNING MANAGER CONTROLLER

COLLECTOR Configur igurat ation

n

Recommend nder Knob Analyzer Metric Analyzer Interna ernal Reposit sitory ry

SLIDE 26 OTTERTUNE

12

AUTOMATIC DBMS TUNING SERVICE

TARGET DATABASE

TUNING MANAGER CONTROLLER

COLLECTOR Configur igurat ation

n

Recommend nder Knob Analyzer Metric Analyzer Interna ernal Reposit sitory ry

SLIDE 27 OTTERTUNE

12

AUTOMATIC DBMS TUNING SERVICE

TARGET DATABASE

TUNING MANAGER CONTROLLER

COLLECTOR Configur igurat ation

n

Recommend nder Knob Analyzer Metric Analyzer Interna ernal Reposit sitory ry

SLIDE 28 OTTERTUNE

12

AUTOMATIC DBMS TUNING SERVICE

TARGET DATABASE

TUNING MANAGER CONTROLLER

COLLECTOR Configur igurat ation

n

Recommend nder Knob Analyzer Metric Analyzer Interna ernal Reposit sitory ry

SLIDE 29 OTTERTUNE

12

AUTOMATIC DBMS TUNING SERVICE

TARGET DATABASE

TUNING MANAGER CONTROLLER

COLLECTOR Configur igurat ation

n

Recommend nder Knob Analyzer Metric Analyzer Interna ernal Reposit sitory ry

SLIDE 30 OTTERTUNE

12

AUTOMATIC DBMS TUNING SERVICE

TARGET DATABASE

TUNING MANAGER CONTROLLER

COLLECTOR Configur igurat ation

n

Recommend nder Knob Analyzer Metric Analyzer Interna ernal Reposit sitory ry INSTALL AGENT

SLIDE 31 OTTERTUNE

13

DEMO

Demonstration

Postgres v9.3 TPC-C Benchmark

SLIDE 32 OTTERTUNE TPC-C TUNING AUTOMATIC DATABASE MANAGEMENT SYSTEM TUNING THROUGH LARGE-SCALE MACHINE LEARNING SIGMOD 2017 165 508 562 736 686

250 500 750 1000

426 845 714 843 946

250 500 750 1000

Throughput (txn/sec)

Default RDS DBA Scripts OtterTune

14

SLIDE 33

Peloton

Self-Driving Database System → In-memory DBMS with integrated ML/RL framework. → Designed for autonomous

perations.

pelotondb.io

SLIDE 34 PELOTON

16

THE SELF-DRIVING DBMS

TARGET DATABASE WORKLOAD HISTORY

SLIDE 35 PELOTON

16

THE SELF-DRIVING DBMS

FORECAST MODELS TARGET DATABASE WORKLOAD HISTORY

SLIDE 36

"THE BRAIN"

PELOTON

16

THE SELF-DRIVING DBMS

FORECAST MODELS

Search Tree ACTION CATALOG

TARGET DATABASE WORKLOAD HISTORY

SLIDE 37

"THE BRAIN"

PELOTON

16

THE SELF-DRIVING DBMS

FORECAST MODELS

Search Tree ACTION CATALOG ACTION SEQUENCE

TARGET DATABASE WORKLOAD HISTORY

SLIDE 38

"THE BRAIN"

PELOTON

16

THE SELF-DRIVING DBMS

FORECAST MODELS

Search Tree ACTION CATALOG ACTION SEQUENCE

TARGET DATABASE WORKLOAD HISTORY

SLIDE 39

"THE BRAIN"

PELOTON

16

THE SELF-DRIVING DBMS

FORECAST MODELS

Search Tree ACTION CATALOG ACTION SEQUENCE

TARGET DATABASE WORKLOAD HISTORY

SLIDE 40

"THE BRAIN"

PELOTON

16

THE SELF-DRIVING DBMS

FORECAST MODELS

Search Tree ACTION CATALOG ACTION SEQUENCE

TARGET DATABASE WORKLOAD HISTORY

? ? ?

SLIDE 41 PELOTON BUS TRACKING APP WITH ONE-HOUR HORIZON QUERY-BASED WORKLOAD FORECASTING FOR SELF-DRIVING DATABASE MANAGEMENT SYSTEM SIGMOD 2018 15000 30000 45000 60000 9-Jan 11-Jan 13-Jan 15-Jan 17-Jan

Ensemble (LR+RNN)

17

Actual Predicted Queries Per Hour

SLIDE 42 PELOTON ADMISSIONS APP WITH THREE-DAY HORIZON

5 10 15 26-Nov 30-Nov 4-Dec 8-Dec 12-Dec 16-Dec

Millions

Actual Predicted Ensemble (LR+RNN)

18

Queries Per Hour

SLIDE 43 PELOTON ADMISSIONS APP WITH THREE-DAY HORIZON

5 10 15 26-Nov 30-Nov 4-Dec 8-Dec 12-Dec 16-Dec

Millions

Actual Predicted Ensemble (LR+RNN)

18

Queries Per Hour

SLIDE 44 PELOTON ADMISSIONS APP WITH THREE-DAY HORIZON

5 10 15 26-Nov 30-Nov 4-Dec 8-Dec 12-Dec 16-Dec

Millions

Actual Predicted

5 10 15 26-Nov 30-Nov 4-Dec 8-Dec 12-Dec 16-Dec

Millions

Ensemble (LR+RNN) Hybrid (LR+RNN+KR)

18

Queries Per Hour

SLIDE 45 OTTERTUNE

19

DEMO

Let's on check the demo…

SLIDE 46

Design Considerations for Autonomous Operation

SLIDE 47 AUTONMOUS DBMS

21

DESIGN CONSIDERATIONS

Configuration Knobs Internal Metrics Action Engineering

SLIDE 48

Anything that requires a human value judgement should be marked as off-limits to autonomous components.

– File Paths – Network Addresses – Durability / Isolation Levels 22

UNTUNABLE KNOBS CONFIGURATION KNOBS

SLIDE 49 CONFIGURATION KNOBS

The autonomous components need hints about how to change a knob

– Min/max ranges. – Separate knobs to enable/disable a feature. – Non-uniform deltas. 23

HOW TO CHANGE

SLIDE 50 CONFIGURATION KNOBS

The autonomous components need hints about how to change a knob

– Min/max ranges. – Separate knobs to enable/disable a feature. – Non-uniform deltas. 23

HOW TO CHANGE

1 KB 1 MB 1 GB 1 TB

+10 KB +10 MB +10 GB

SLIDE 51 CONFIGURATION KNOBS

The autonomous components need hints about how to change a knob

– Min/max ranges. – Separate knobs to enable/disable a feature. – Non-uniform deltas. 23

HOW TO CHANGE

SLIDE 52 CONFIGURATION KNOBS

Indicate which knobs are constrained by hardware resources.

– The sum of all buffers cannot exceed the total amount of available memory.

The problem is that sometimes it makes sense to overprovision.

24

HARDWARE RESOURCES

SLIDE 53 INTERNAL METRICS

Expose DBMS's hardware capabilities:

– CPU, Memory, Disk, Network 25

HARDWARE INFORMATION Configu figura rati tion

n

Reco commender nder

SLIDE 54 INTERNAL METRICS

Expose DBMS's hardware capabilities:

– CPU, Memory, Disk, Network

Otherwise you have to come up with clever ways to approximate this…

25

HARDWARE INFORMATION

Microbenchmark Threads

SLIDE 55 INTERNAL METRICS

26

HARDWARE MICROBENCHMARKS c3.large i3.large m3.lar… r3.large c3.xlarge r3.xlarge i2.xlarge i3.xlarge m3.xlar… d2.xlar… c3.2xlarge d2.2xlarge h1.2xlarge i2.2xlarge i3.2xlarge m3.2xlar… r3.2xlarge c3.4xlarge d2.4xlar… h1.4xlarge i2.4xlarge i3.4xlarge r3.4xlarge c3.8xlarge h1.8xlarge

0.3
0.2
0.1

0.1 0.2 0.3 0.60 0.64 0.68 0.72 0.76 0.80

Factor 2 Factor 1 2 vCPUs 4 vCPUs 8 vCPUs 16 vCPUs 32 vCPUs Factor Analysis

SLIDE 56 INTERNAL METRICS

If the DBMS has sub-components that are tunable, then it must expose separate metrics for those components. Bad Example:

27

SUB-COMPONENTS

SLIDE 57 INTERNAL METRICS

28

SUB-COMPONENTS

RocksDB Column Family Knobs Column Family Metrics

Missing: Reads Writes

SLIDE 58 INTERNAL METRICS

28

SUB-COMPONENTS

RocksDB Column Family Knobs Global Metrics

Aggregated Metrics

SLIDE 59 ACTION ENGINEERING

No action should ever require the DBMS to restart in order for it to take affect. The commercial systems are much better than this than the open-source systems.

29

NO SHUTDOWN

SLIDE 60 ACTION ENGINEERING

Provide a notification callback to indicate when an action starts and when it completes. Harder for changes that can be used before the action completes.

30

NOTIFICATIONS

SLIDE 61 ACTION ENGINEERING

Support executing the same action with different resource usage levels.

31

RESOURCE USAGE

SLIDE 62 ACTION ENGINEERING

Allow replica configurations to diverge from each other.

32

REPLICA EXPLORATION

Master Replicas

SLIDE 63 ACTION ENGINEERING

Allow replica configurations to diverge from each other.

32

REPLICA EXPLORATION

Master Replicas

SLIDE 64 ACTION ENGINEERING

Allow replica configurations to diverge from each other.

32

REPLICA EXPLORATION

Master Replicas

SLIDE 65 ACTION ENGINEERING

Allow replica configurations to diverge from each other.

32

REPLICA EXPLORATION

Master Replicas

SLIDE 66 ACTION ENGINEERING

Allow replica configurations to diverge from each other.

32

REPLICA EXPLORATION

Master Replicas

SLIDE 67

W hat About Oracle's Self-Driving DBMS?

SLIDE 68 ORACLE SELF-DRIVING DBMS

34 September 2017 January 2017

SLIDE 69 ORACLE

Automatic Indexing Automatic Recovery Automatic Scaling Automatic Query Tuning

SELF-DRIVING DBMS

34 September 2017

SLIDE 70 ORACLE

Automatic Indexing Automatic Recovery Automatic Scaling Automatic Query Tuning

SELF-DRIVING DBMS

34

Problem #2 Reactionary Measures

September 2017

SLIDE 71 ORACLE

Automatic Indexing Automatic Recovery Automatic Scaling Automatic Query Tuning

SELF-DRIVING DBMS

34

Problem #2 Reactionary Measures

September 2017

SLIDE 72 ORACLE

Automatic Indexing Automatic Recovery Automatic Scaling Automatic Query Tuning

SELF-DRIVING DBMS

34

Problem #2 Reactionary Measures

September 2017

SLIDE 73 CONCLUSION

True autonomous DBMSs are achievable in the next decade. You should think about how each new feature can be controlled by a machine.

MAIN TAKEAWAYS

35

SLIDE 74 OTTERTUNE

36

DEMO

Demo Results

SLIDE 75

END

@andy_pavlo

SLIDE 76
