Runtime CPU Spike Detection using Manual and Compiler-Automated Instrumentation

Adisak Pochanayon

Principal Software Engineer Netherrealm Studios adisak@wbgames.com

Topics to Cover

• This talk is about runtime instrumentation-based

profiling.

• Code Instrumentation Methods
• MK’s PET Profiler (Spike Detector)

Profilers

• Common types of profilers

– Hardware Trace – Hardware Event-based – Software Event-based – Sampling – Instrumented

Manual Instrumentation

• Explicit Instrumentation / Code Markup
• Wrapper Functions
• Detours and Trampolines

Explicit Instrumentation

• Requires code markup (source modification)

– StartMarker(INFO) / StopMarker(INFO)

• Scoped - ScopedMarker(INFO)

class CScopedMarker { CScopedMarker(ProfDesc &info) { StartMarker(info); } ~CScopedMarker(ProfDesc &info) { StopMarker(info); } }; #define ScopedMarker(INFO) CScopedMarker(INFO) \ ProfInfo##__LINE__

Wrapper Functions

• Compile-time

– #define function(…) wrapper_function

• Plus – compiler independent
• Drawback – only works if you have source code
• Link-Time Replacement / Wrapping

– GCC option: -Wl,--wrap,function_name

__wrap_function_name() __real_function_name()

Wrapper Functions

CALLING FUNCTION TARGET FUNCTION

Wrapper Functions

CALLING FUNCTION “WRAPPER” FUNCTION “REAL” FUNCTION

1 4 2 3

Wrapper Functions

• Sample of wrapping malloc() with GCC / SNC

– Add linker flags: -Wl,--wrap,malloc extern "C" void* __real_malloc(size_t); extern "C" void* __wrap_malloc(size_t Size) { // Call the original malloc() function return __real_malloc(Size); }

Detours and Trampolines

• A method of code modification for

Instrumentation

– Can be done on object code / binaries by Profilers – Run-time with instrumentation library calls

• See Microsoft Detours
• MIPS Example Code (Handout)
• This is another form of manual instrumentation but does

not require source markup of the target function.

Detours and Trampolines

CALLING FUNCTION TARGET FUNCTION

Detours

CALLING FUNCTION DETOUR FUNCTION TARGET FUNCTION JUMP

1 2 3

Trampolines

CALLING FUNCTION TARGET FUNCTION TARGET PROLOG Trampoline Buffer TARGET PROLOG COPY

Trampolines

CALLING FUNCTION TARGET FUNCTION TARGET PROLOG JUMP Trampoline Buffer TARGET PROLOG

Trampolines

CALLING FUNCTION TARGET FUNCTION TARGET PROLOG JUMP TARGET PROLOG

Detours and Trampolines

CALLING FUNCTION DETOUR FUNCTION TARGET FUNCTION JUMP TARGET PROLOG JUMP

1 2 3 4 5 6

Detours and Trampolines

• Summary ( Drawbacks )

– Roll your own: Trivial on RISC / harder on CISC – Dealing with Page Protection / NX (No Execute) – Commercial implementations are $$$

• Microsoft Detours Software

– http://research.microsoft.com/en-us/projects/detours/

• Microsoft 1999 Paper on Detours and Trampolines:

– http://research.microsoft.com/pubs/68568/huntusenixnt99.pdf

Manual Instrumentation

• Summary of Manual Inst. methods

– Explicit Markup – Wrapper Functions – Detours and Trampolines

• All require work identifying functions and user

intervention (code markup, library calls, or linker parameters).

Automated Instrumentation

• Chances are you are already using it

– Many profilers support it

• Metrowerks CATS, VTune Call Graph, Visual Studio Profiler &

Visual C++ /callcap and /fastcap, GNU gprof (w/ gcc –pg)

• Compiler-Assisted Instrumentation (CAI)

– Allow for User Implementation of profiler but compiler does markup for you

• GCC: -finstrument-functions / SNC -Xhooktrace
• Visual C++: _penter() & _pexit() using /Gh and /GH

Automated Instrumentation

FUNCTION BODY PROLOG EPILOG

When a compiler generates machine code for a function, it generates a prolog (save registers, stack frame, etc.) and epilog (restore saved registers and states prior to return) in addition to the function body.

Compiler Automated Instrumentation

Automated Instrumentation

FUNCTION BODY PROLOG EPILOG Log Entry { _penter() __cyg_profile_func_enter () } Log Exit { _pexit() __cyg_profile_func_exit () }

GCC & SNC CAI

• Compiler Option: -finstrument-functions

– Generate instrumentation calls for entry and exit to

• functions. Just after function entry and just before

function exit, the following profiling functions will be called with the address of the current function and its call site.

void __cyg_profile_func_enter (void *this_fn, void *call_site); void __cyg_profile_func_exit (void *this_fn,void *call_site);

SNC CAI (PS3 / VITA)

void __cyg_profile_func_enter(void *this_fn, void *call_site) { if(0==tls_PET_bIsInProcessing) { tls_PET_bIsInProcessing=true; _internal_PET_LogEntry(0); tls_PET_bIsInProcessing=false; } }

Visual C++ CAI

• Using _penter() & _pexit() on Visual C++ is a bit

more difficult.

– Visual C++ inserts calls on function entry and exit but does not save any registers – At a very minimum, requires writing assembler to save the registers according to the platform ABI – Requires additional checks to be “useable”

Visual C++ CAI – X86

extern "C" void __declspec(naked) _cdecl _penter( void ) { _asm { push eax push ebx push ecx push edx push ebp push edi push esi } if(0==tls_PET_bIsInProcessing) { tls_PET_bIsInProcessing=true; // Call C Work Function _internal_PET_LogEntry(0); tls_PET_bIsInProcessing=false; } _asm { pop esi pop edi pop ebp pop edx pop ecx pop ebx pop eax ret } }

Visual C++ CAI – XBOX 360

• CAI Supported on XBOX 360 (PowerPC)
• Almost same as PC

1)Save Registers 2)NEW STEP - Check for DPC (deferred procedure call) 3)TLS – re-entrant check 4)Call actual work function 5)Restore Registers

Visual C++ CAI – XBOX 360

• PowerPC version is more complicated

– More ABI Registers to Save and Restore

• Have to save and restore FP regs if doing FP

– Optimizations and Early Outs – TLS access must be done in ASM

• Mixed naked asm / C does not work well like X86

– See handout to follow along…

Visual C++ CAI – XBOX 360

void __declspec(naked) _cdecl __penter( void ) { __asm { // Tiny Prolog // - Set link register (r12) & return address (two steps) std r12,-20h(r1) // Saving LR here is extra step ! mflr r12 stw r12,-8h(r1) // Return Address bl PET_prolog bl _internal_PET_LogEntry b PET_epilog } }

XBOX 360 CAI Flow: _penter()

“C++” Instrumented Function _penter() {asm}

1

XBOX 360 CAI Flow: _penter()

“C++” Instrumented Function _penter() {asm} PET_Prolog {asm}

1 2 3

XBOX 360 CAI Flow: _penter()

“C++” Instrumented Function _penter() {asm} PET_Prolog {asm} PET_Prolog Early Out {asm}

1 2 3 4 3

XBOX 360 CAI Flow: _penter()

“C++” Instrumented Function _penter() {asm} PET_Prolog {asm}

1 2 3

“C++” Profiling Routine for Logging Function Entry

4 5

XBOX 360 CAI Flow: _penter()

“C++” Instrumented Function _penter() {asm} PET_Prolog {asm}

1 2 3

PET_Epilog {asm} “C++” Profiling Routine for Logging Function Entry

4 5 6 7

XBOX 360 CAI Flow: _penter()

“C++” Instrumented Function _penter() {asm} PET_Prolog {asm} PET_Prolog Early Out {asm}

1 2 3 4 3

PET_Epilog {asm} “C++” Profiling Routine for Logging Function Entry

4 5 6 7

Visual C++ CAI – XBOX 360

• PET_Prolog has five sections

– Tiny Prolog to save minimal registers – Check for DPC & possible early out – Check for recursion (TLS var) & possible early out – Save temporaries (including r2) and return to parent – Early out returns all the way to grandparent function

Visual C++ CAI – XBOX 360

• Tiny Prolog to save minimal registers

// Tiny Prolog // - Save extra registers (r11,r14) // - Set stack frame (r1) std r11,-30h(r1) std r14,-28h(r1) // Old Stack Pointer (r1) is at 0(r1) after this instruction stwu r1,-100h(r1)

Visual C++ CAI – XBOX 360

• Check for DPC & possible early out

// Get the TLS thread-specific base lwz r11,0(r13) // Do not try to run in DPC! // In DPC { 0(r13) == 0 } cmplwi cr6,r11,0 beq cr6,label__early_exit_prolog

Visual C++ CAI – XBOX 360

• Check for recursion (TLS var) & possible early out

lau r14,_tls_start // Get the TLS global base lau r12,tls_PET_bIsInProcessing lal r14,r14,_tls_start lal r12,r12,tls_PET_bIsInProcessing sub r11,r11,r14 // TLS Base Offset (r11) add r14,r11,r12 // r14 == &tls_PET_bIsInProcessing // Avoid recursion using thread variable tls_PET_bIsInProcessing lwzx r12,r11,r12 cmplwi cr6,r12,0 bne cr6,label__early_exit_prolog li r12,1 stw r12,0(r14) // Set tls_PET_bIsInProcessing

Visual C++ CAI – XBOX 360

• Check for recursion (TLS var) & possible early out

That may have looked complicated but it’s actually pretty

• simple. Here is the C++ equivalent for the last slide:

if(tls_PET_bIsInProcessing) goto label__early_exit_prolog; tls_PET_bIsInProcessing=true;

Visual C++ CAI – XBOX 360

• Save temporaries (including r2) and return to parent

// Save r0/r2-r10 (temporaries) std r0,8h(r1) std r2,10h(r1) // (r2 is reserved on XBOX 360) std r3,18h(r1) std r4,20h(r1) std r5,28h(r1) std r6,30h(r1) std r7,38h(r1) std r8,40h(r1) std r9,48h(r1) std r10,50h(r1) blr // Return To Caller

Visual C++ CAI – XBOX 360

• Early out returns all the way to grandparent function

label__early_exit_prolog: // Tiny Epilog -- adjust stack (r1) & restore r12/r14/r11 addi r1,r1,100h lwz r12,-8h(r1) mtlr r12 ld r12,-20h(r1) ld r14,-28h(r1) ld r11,-30h(r1) blr

Visual C++ CAI – XBOX 360

• PET_Epilog is simpler (see handout)

– Clear TLS recursion prevention variable – Restore temporaries – Restore registers used in “Tiny Prolog”

• Final note: Worker function must save / restore

FP registers (fr0-fr13) if performing any floating point work.

XBOX 360 CAI Flow: _pexit()

“C++” Instrumented Function _pexit() {asm} PET_Prolog {asm} PET_Prolog Early Out {asm}

1 2 3 4 3

PET_Epilog {asm} “C++” Profiling Routine for Logging Function Exit

4 5 6 7

How to use Instrumentation?

• So now that we have all these methods to

instrument our code what do we do with these techniques?

• Hook it up to your profiling code 
• On the MK team, one of the uses is for an

internally developed Runtime Spike Detector called the PET Profiler.

PET Profiler

• PET = Prolog Epilog Timing

– Times Entry and Exit into functions and detects spikes – Can set a global threshold and any instrumented function that exceeds that threshold gets logged

• With a stack and potentially extra info from markup

– Works with the Compiler-Automated Instrumentation

• Spike detection for every compiled function in game
• Cost is about 15-30% performance overhead with CAI

PET Profiler

• NO CODE MARKUP required to detect spikes

– Turn CAI on, and it will find any function that take longer to execute than the global threshold you set

• PET Tags / Code Markup is still useful

– Simple PET_FUNCTION() (scoped marker) – Provides extra information to PET Profiler – Allows spike detection on platforms without CAI – Alternate Implementions = Enhances other profilers

PET Implementaion

• PET is implemented using TLS info stacks

– Stack is incremented by CAI entry – Stack is decremented by CAI exit – When CAI is not present, PET Stack is inc’d and dec’d by markup (the scoped markers) – Scope Markers and API Markup provide additional information and functionality at a global level, function level, sub-system level, or thread level

PET Implementaion

• DATA in stack

– Can be as small as 4 words depending on #define options selected

1. time entered 2.

• ptional threshhold (to override global threshhold)

3.

• ptional threshhold for children

4. description (most of these are optional)

– function address – function name (pointer to static) – line number – source file name (pointer to static) – user generated description (dynamic string)

PET API / Basic Markup

PET_FUNCTION() PET_SECTION_MANUAL(name) PET_SetGlobalThresholdMSec(msecs) PET_SetFunctionThresholdMSec(msecs) PET_SetChildrenThresholdMSec(msecs) PET_SetAllParentsThresholdMSec(msecs)

PET API / Thresholds

Why threshold functions? Lets say you set the global threshold to 1ms to find any function that takes over 1ms. Your Game::Tick() function for a game at 60 fps will take 16.66ms so to avoid kicking a spike warning, you can insert this markup into Game::Tick() :

PET_FUNCTION(); PET_SetFunctionThresholdMSec(1000.0/MIN_FPS);

Then the PET Profiler will not log a spike in your Game::Tick().

PET Example Thresholds

Script Functions (0.1ms) Global Threshhold for Most Game Functions (1ms) Tick Functions (1 Frame = 16 ms) File I/O Functions (2 s)

PET API / Messages

PET_SetFunctionDescf(FMT,...)

• Allocates a temporary (shared) string from a pool and

formats it with a description.

• If a spike occurs, emits that description in the log.

PET_OTMessagef(FMT,...)

• Logs an additional message if the function is Over the time

Threshold (OT).

• Less overhead than PET_SetFunctionDescf() because
• utput string is only generate if needed for message.

PET API / Messages

• Example:

void ExecuteScript(ScriptContext *sc) { PET_FUNCTION(); sc->ExecuteStep(); PET_OTMessagef("Script function: %s", sc->GetCurrentFunctionName()); }

PET API / Messages

• Example:

void ExecuteScript(ScriptContext *sc) { PET_FUNCTION(); PET_SetFunctionThresholdMSec(0.1); PET_SetFunctionDescf("Script function: %s", sc->GetCurrentFunctionName()); sc->ExecuteStep(); }

PET API / Conditional Control

Control if Profiling is Active PET_SetThreadActive() PET_FUNCTION_IGNORE() PET_FUNCTION_IGNORE_CHILDREN() PET_Pause() PET_Unpause() Conditional Profiling (can allow "channels") PET_FUNCTION_CONDITIONAL(cond) PET_FUNCTION_CONDITIONAL_PAUSED(cond) PET_FUNCTION_CONDITIONAL_IGNORE_CHILDREN(cond) PET_FUNCTION_CONDITIONAL_IGNORE(cond)

PET Sample Log Output

PET: Function took too long: 11.302 MSec Thread: MainThread PEAK CHILD @ frame 2323 Function Name Trace 0) 0x82449eb4 - main 1) 0x824499c8 - GuardedMain 2) 0x82444c80 - FEngineLoop::Tick 3) 0x82440ddc - UMK9GameEngine::Tick 4) 0x82d6d39c - MKScriptVM::Tick 5) 0x82d6f2dc - MKListNoDestroy::ForEach 6) 0x82d6cd54 - MKScriptVM::Step 7) 0x82d690ac - _call_c_function 8) 0x82440ddc - CreateEnduranceOpponentPhase1 9) 0x82440ddc - CreatePlayerPhase1 10) 0x82440ddc - SpawnMKFGCharacterObj 11) 0x82440ddc – CreateMeshes PET: Thread (MainThread) Function took too long: 14.499 MSec 10) 0x82440ddc - SpawnMKFGCharacterObj PET: Thread (MainThread) Function took too long: 14.599 MSec 9) 0x82440ddc - CreatePlayerPhase1 PET: Thread (MainThread) Function took too long: 15.097 MSec 8) 0x82440ddc - CreateEnduranceOpponentPhase1 !!!!!-----------------------------------------------------------!!!!! Slow Script->C Call: _CreateEnduranceOpponentPhase1 takes 16.576 ms (0.995 frames) to execute !!!!!-----------------------------------------------------------!!!!! PET: Thread (MainThread) Function took too long: 15.377 MSec 7) 0x82d690ac - _call_c_function PET: Thread (MainThread) Function took too long: 15.401 MSec 6) 0x82d6cd54 - MKScriptVM::Step PET: Thread (MainThread) Function took too long: 15.490 MSec 5) 0x82d6f2dc - MKListNoDestroy::ForEach PET: Thread (MainThread) Function took too long: 15.578 MSec 4) 0x82d6d39c - MKScriptVM::Tick

PET Sample Log Output

PET: Function took too long: 8.586 MSec Thread: MainThread PEAK CHILD @ frame 2422 Function Name Trace 0) Tick (LaunchEngineLoop.cpp - LINE: 1981) 1) Tick (MK9Game.cpp - LINE: 499) 2) Tick (ScriptCore.cpp - LINE: 908) 3) Step (ScriptCore.cpp - LINE: 440) 4) _call_c_function (ScriptCore.cpp - LINE: 4194) 5) CreateEnduranceOpponentPhase1 (FGPlayer.cpp - LINE: 881) 6) CreatePlayerPhase1 (FGPlayer.cpp - LINE: 527) 7) SpawnMKFGCharacterObj (FGPlayer.cpp - LINE: 243) 8) CreateMeshes (FGPlayer.cpp - LINE: 1088) 9) SetSkeletalMesh (UnSkeletalComponent.cpp - LINE: 3465) PET: Thread (MainThread) Function took too long: 12.851 MSec 8) CreateMeshes (FGPlayer.cpp - LINE: 1088) PET: Thread (MainThread) Function took too long: 15.429 MSec 7) SpawnMKFGCharacterObj (FGPlayer.cpp - LINE: 243) PET: Thread (MainThread) Function took too long: 15.522 MSec 6) CreatePlayerPhase1 (FGPlayer.cpp - LINE: 527) PET: Thread (MainThread) Function took too long: 15.869 MSec 5) CreateEnduranceOpponentPhase1 (FGPlayer.cpp - LINE: 881) !!!!!-----------------------------------------------------------!!!!! Slow Script->C Call: _CreateEnduranceOpponentPhase1 takes 16.446 ms (0.987 frames) to execute !!!!!-----------------------------------------------------------!!!!! PET: Thread (MainThread) Function took too long: 16.015 MSec 4) _call_c_function (ScriptCore.cpp - LINE: 4194) PET: Thread (MainThread) Function took too long: 16.035 MSec 3) Step (ScriptCore.cpp - LINE: 440) PET: Thread (MainThread) Function took too long: 16.200 MSec 2) Tick (ScriptCore.cpp - LINE: 908)

PET Profiler Notes

• API is optional (CAI works without API)
• API compiles out to “nops” in Release Builds

– Zero runtime code overhead when not used

• Manual Instrumentation / Alternate

Implementation Modes are very low overhead

– Depends on amount of instrumentation but typically almost unnoticeable (vs 15-30% for CAI)

PET Profiler Notes

• Markup is not necessary with PET but can give

you finer grain control… especially over specific systems.

• Typical game markup involves adding only 30-50

markup lines total for CAI to get best results.

– PET Profiler will detect spikes and “suggest” lines for you to markup in CAI mode

• More Markup gives better detail in Manual Mode

Real World Examples

• Code Optimization Pass on MK9

– Just turn on in Game and Log

• Created a large list of spiking functions
• Narrowed down to “real” and “false” spikes
• Instrumented small number of “false” spikes with

PET_Pause, PET_Ignore, or appropriate thresholds

• Took list of “real” spikes and distributed to various

programmers for optimization

Real World Examples

• Sometimes running found unusual and

unexpected spikes.

– Load routines were not previously heavily profiled compared to in-game steady 60 FPS state (MK has load screen or decoupled movie so underlying load is not 60FPS) – Example: Selecting characters for ladder could take nearly a second due to poorly written code !!!

Real World Examples

• Tracking down specific issues

– Batman Arkham City has streamed loading. In a couple places, we were looking for stalls in loading. One of my coworkers spent a couple days looking for a stall without success. I went to his office and turned on the PET Profiler and it found the exact code stall in a few minutes on the first attempt.

Real World Examples

• …Tracking down specific issues

– Fighting moves that cause “bog” on VITA

• First tried Manual Instrumentation

– Slow but useful results which were verified in RAZOR – Divide and Conquer / Instrument Children of Slow functions

• Then Automated Instrumentation

– Turn on CAI Mode / Execute slow move – A bunch of functions get logged (instrument if desired) – Much faster at locating issues (automatic)

Real World Examples

• Targeting script calls (*to move to native code?)

– Unreal Script, MKScript, Kismet, etc – Instrument “script execute” function

• Use PET_OTMessagef() or PET_SetFunctionDescf() for extra

info

– Why better than just timing script calls?

• Automated Instrumentation modes will locate stalls in

children functions AND give script context info

Questions ???

Contact Info: Adisak Pochanayon

Principal Software Engineer Netherrealm Studios adisak@wbgames.com

“Automagic” Profiling on MK

• Code Instrumentation

– Manual – Automatic*

• Creating a

profiler

• MK @ 60 FPS

– Detecting spikes
