slide-1
SLIDE 1

AN INTRODUCTION TO...

slide-2
SLIDE 2

NUESTRA MISIÓN

Permitir que las marcas de iluminación a nivel global sean pioneras en productos de iluminación de vanguardia.

NUESTRA VISIÓN

Ser el socio en soluciones de tecnología preferido y más fjable para nuestros clientes.

slide-3
SLIDE 3

2008 2005

Marcus Worthington funda Eulum Design en Essex, Inglaterra, como empresa de diseño y desarrollo de productos OEM.

NACE EULUM DESIGN

Marcus Worthington y Brian Gery co-fundaron Eulum Design USA en Doylestown, Pensilvania, como centro de diseño electrónico.

LLEGADA A LOS ESTADOS UNIDOS

Eulum presenta su primera línea de producción de montaje para placas PCB.

LÍNEA DE PRODUCCIÓN

8

La producción se establece en una instalación más grande y Eulum amplía sus líneas de producción de montaje para placas PCB.

NUEVOS DISEÑOS ELECTRÓNICOS EULUM SOCIOS CON XICATO

Presenta la gama de módulos de corriente alterna (120, 230 + 277 VAC) con opciones de regulación integradas.

PRESENTANDO INTALIM EULUM SE ASOCIA CON CASAMBI

Xicato y Eulum forman una sociedad de desarrollo de productos que permitirá a los usuarios conectar los productos de Eulum a la red de iluminación inteligente de Xicato. Eulum desarrolla módulos inalámbricos para conectar dispositivos OEM bajo el sistema Bluetooth de Casambi

EULUM SOCIOS DE LENSVECTOR

Eulum integra la tecnología LensVector Liquid Crystal Beam Shaping con control inalámbrico.

2010 2015 2016 2017 2018

ARCANE

EULUM LANZA UN MÓDULO REVOLUCIONARIO

Se trata de un módulo integrado para uso en focos y downlights con control inalámbrico de intensidad de luz, mezcla de colores y control del haz de luz, incorporando tecnología Casambi y LensVector.

slide-4
SLIDE 4

En Eulum tenemos una gama de drivers y controladores LED estándar para integración con equipos existentes. Nuestro servicio es adaptable proyecto a proyecto abarcando desde el concepto/desarrollo industrial, hasta el diseño térmico y la óptica. Respaldamos el producto OEM con marketing de productos y pruebas de funcionamiento. Nuestros objetivos incluyen soluciones para nuevos diseños de alta demanda, productos especializados, ofertas especiales para nuevos proyectos, ampliaciones de gamas de productos, actualizaciones, adaptaciones y proyectos experimentales para pruebas de mercado.

DISEÑO OPTICO DISEÑO TÉRMICO DISEÑO ELECTRÓNICO PRUEBA Y CERTIFICACION FABRICACIÓN DE LUMINARIAS DISEÑO DE PRODUCTO

INTEGRADO

S O L U C I O N E S C O M P L E TA M E N T E

¿QUÉ HACEMOS?

slide-5
SLIDE 5

PRODUCTOS ESTÁNDAR

Lineal

24mm compatible con Zhaga

  • 48VDC tensión constante o corriente constante
  • 560mm, 280mm, 140mm, 70mm
  • 2700k, 3000k, 3500k, 4000k - 80/90CRI
  • 400lm/ft a 1200lm/ft

18mm tensión constante

  • 48VDC tensión constante o corriente constante
  • 610mm, 305mm, 152mm, 76mm
  • 2700k, 3000k, 3500k, 4000k - 80/90CRI
  • 400lm/ft a 1200lm/ft

39mm tensión constante

  • 24VDC tensión constante o corriente constante
  • 610mm, 305mm, 152mm, 76mm
  • 2700k, 3000k, 3500k, 4000k - 80/90CRI
  • 400lm/ft a 1200lm/ft
  • 48VDC tensión constante o corriente constante
  • 610mm, 305mm
  • 2700k, 3000k, 3500k, 4000k - 80/90CRI
  • 200lm/ft a 600lm/ft

6mm tensión constante

slide-6
SLIDE 6

PRODUCTOS ESTÁNDAR

REDONDO

58mm AC/DC

  • 12V AC/DC
  • Single Cree XHP70
  • Ø58mm
  • 2700k, 3000k, 3500k, 4000k -

80/90CRI

  • Hasta 1200lm

35mm AC/DC

  • 12V AC/DC
  • Single Cree XHP35
  • Ø35mm
  • 2700k, 3000k, 3500k, 4000k -

80/90CRI

  • Hasta 700lm

44mm AC/DC

  • 12VAC/DC
  • Single Cree XHP70
  • Ø44mm
  • 2700k, 3000k, 3500k, 4000k -

80/90CRI

  • Hasta 1000lm

51mm AC/DC

  • 12V AC/DC
  • Single Cree XHP70
  • Ø51mm
  • 2700k, 3000k, 3500k, 4000k -

80/90CRI

  • Hasta 1300lm, Fase regulable

50mm AC

  • 12V AC
  • Triple Cree XP-G2
  • Ø51mm
  • 2700k, 3000k, 3500k, 4000k -

80/90CRI

  • Hasta 900lm, Fase regulable
slide-7
SLIDE 7

Tecnología inalámbrica

PCB con ARCANE integrado

  • Tensión constante 24-48Vcc
  • Color único y RGBW
  • Ø58mm
  • 2700k, 3000k, 3500k, 4000k - 80/90CRI
  • Hasta1500lm
  • Compatible con CASAMBI
  • LensVector Lente integrada

PCB integrado 58mm

  • 12V AC/DC Input
  • Color único y RGBW
  • 58mm Ø
  • 2700k, 3000k, 3500k, 4000k - 80/90CRI
  • Hasta 1200lm
  • Compatible con CASAMBI

PRODUCTOS ESTÁNDAR

slide-8
SLIDE 8

ARCANE

LensVector Crystal Lens Arcane Optic Holder TIR Optic BLE Wireless Module Heatsink PCB Module

Módulo integrado ARCANE

  • De 24Vcc a 48Vcc
  • Color único, blanco dinámico y RGBW
  • Ø64mm x 97mm
  • 2700k, 3000k, 3500k, 4000k - 80/90CRI
  • Hasta 1500lm
  • Casambi Habilitado
  • Lentes de cristal líquido 10º-50º

PRODUCTOS ESTÁNDAR

slide-9
SLIDE 9

controles inálambricos

BLUETOOTH - 0-10V TRANSLATORS

Input Voltage Contact Rating Dimming Power Consumption Confjguration Output Wire Size Operating Temp. Dimensions 120-277VAC 50/60Hz N/A Casambi/ Xicato <1W 1-4 Individual Outputs/Tunable White/RGB/RGBW Up to 4 x 0-10V Outputs (10mA per output max) 16 24AWG / 0.25-1.0sqmm 0-50°C (ambient) 7.17” x 1.9” x 1.07” 183mm x 49mm x 28mm

TRAN-4

Input Voltage Contact Rating Dimming Power Consumption Confjguration Output Wire Size Operating Temp. Dimensions 120-277VAC 50/60Hz 620W Casambi/ Xicato <1W Individual Output Single 0-10V Output (10mA per output max) 16-24AWG / 0.25-1.0sqmm 0-50°C (ambient) 2.9” x 1.9” x 1.07” 72mm x 49mm x 28mm

TRAN-J/E NDRV

12-52VDC 12A MAX Casambi/ Xicato 570W Max 1-4 Individual Outputs/ Tunable-White/RGB/RGBW Class 1: 5A max, Class 2/48V: 2A max, Class 2 24V: 4A max 16-24AWG / 0.25-1.0sqmm 0-50°C (ambient) 7.16” x 2.0” x 1.07” 182mm x 51mm x 28mm Input Voltage Contact Rating Dimming Power Consumption Confjguration Output Wire Size Operating Temp. Dimensions

CONSTANT VOLTAGE PWM DIMMING

PRODUCTOS ESTÁNDAR

slide-10
SLIDE 10

12/48VDC 100W Casambi <1W 2 Individual Outputs / Tunable White Programmable CC output 150 -1000 mA Max 42VDC 16-24AWG / 0.25-1.0sqmm, 0-50°C (ambient) 5.4” x 1.9” x 1.07” 136mm x 49mm x 28mm

LDRV

Input Voltage Contact Rating Dimming Power Consumption Confjguration Output Wire Size Operating Temp. Dimensions

PROGRAMMABLE CONSTANT CURRENT DRIVER

120-277VAC, 50/60Hz 2A Max (554W @ 277V) Casamb/ Xicato <1W Single Output 120-277VAC, 50/60Hz 16-24AWG / 0.25-1.0sqmm 0-50°C (ambient) 7.16” x 2.0” x 1.07” 182mm x 51mm x 28mm

TRED

Input Voltage Contact Rating Dimming Power Consumption Confjguration Output Wire Size Operating Temp. Dimensions

SRPT

120-277VAC, 50/60Hz <1W Casambi/Xicato <1W N/A Casambi/Xicato 16-24AWG / 0.25-1.0sqmm 0-50°C (ambient) 3.97” x 1.98” x 0.86” 101mm x 50.5mm x 22mm Input Voltage Contact Rating Dimming Power Consumption Confjguration Output Wire Size Operating Temp. Dimensions

TRAILING EDGE DIMMING SIGNAL REPEATER

PRODUCTOS ESTÁNDAR

controles inálambricos

slide-11
SLIDE 11

C E R T I F I C A T E O F C O M P L I A N C E

Certificate Number

20170512-E490283

Report Reference

E490283-20170512

Issue Date

2017-MAY-12

Bruce Mahrenholz, Director North American Certification Program UL LLC Any information and documentation involving UL Mark services are provided on behalf of UL LLC (UL) or any authorized licensee of UL. For questions, please contact a local UL Customer Service Representative at http://ul.com/aboutul/locations/

Page 1 of 1

Issued to:

Eulum Design LLC 6131 Kellers Church Rd Pipersville PA 18947

This is to certify that representative samples of

MANAGEMENT EQUIPMENT, ENERGY Series LDRV-CSB-PC2-48V-1000 and LDRV-CSB-PC2- 12V-1000; may be followed by additional prefixes and/or suffixes for commercial purposes. Have been investigated by UL in accordance with the Standard(s) indicated on this Certificate.

Standard(s) for Safety:

UL 916, Energy Management Equipment CSA C22.2 No. 205-12, Signal Equipment

Additional Information:

See the UL Online Certifications Directory at www.ul.com/database for additional information

Only those products bearing the UL Certification Mark should be considered as being covered by UL's Certification and Follow-Up Service. Look for the UL Certification Mark on the product. C E R T I F I C A T E O F C O M P L I A N C E

Certificate Number

20170607-E490283

Report Reference

E490283-20170607

Issue Date

2017-JUNE-07

Bruce Mahrenholz, Director North American Certification Program UL LLC Any information and documentation involving UL Mark services are provided on behalf of UL LLC (UL) or any authorized licensee of UL. For questions, please contact a local UL Customer Service Representative at http://ul.com/aboutul/locations/ Page 1 of 1

Issued to:

Eulum Design LLC 6131 Kellers Church Rd Pipersville PA 18947

This is to certify that representative samples of

MANAGEMENT EQUIPMENT, ENERGY Series NDRV-CSB-48C1, NDRV-CSB-48C2, NDRV-CSB- 24C2 and NDRV-DMX10-48C1, NDRV-DMX10-48C2, NDRV-DMX10-24C2; maybe followed by additional prefixes and/or suffixes for commercial purposes. Have been investigated by UL in accordance with the Standard(s) indicated on this Certificate.

Standard(s) for Safety:

UL 916, Energy Management Equipment CSA C22.2 No. 205-12, Signal Equipment

Additional Information:

See the UL Online Certifications Directory at www.ul.com/database for additional information

Only those products bearing the UL Certification Mark should be considered as being covered by UL's Certification and Follow-Up Service. Look for the UL Certification Mark on the product.

C E R T I F I C A T E O F C O M P L I A N C E

Certificate Number

20170512-E490283

Report Reference

E490283-20170511

Issue Date

2017-MAY-12

Bruce Mahrenholz, Director North American Certification Program UL LLC Any information and documentation involving UL Mark services are provided on behalf of UL LLC (UL) or any authorized licensee of UL. For questions, please contact a local UL Customer Service Representative at http://ul.com/aboutul/locations/ Page 1 of 1

Issued to:

Eulum Design LLC 6131 Kellers Church Rd Pipersville PA 18947

This is to certify that representative samples of

MANAGEMENT EQUIPMENT, ENERGY Listed - Energy Management Equipment, Model Series TRAN-DMX10, TRAN-CSB10-J and TRAN-CSB10; maybe followed by additional prefixes and/or suffixes for commercial purposes. Open Type, Listed - Energy Management Equipment TRAN-CSB10-E; maybe followed by additional prefixes and/or suffixes for commercial purposes. Have been investigated by UL in accordance with the Standard(s) indicated on this Certificate.

Standard(s) for Safety:

UL 916, Energy Management Equipment CSA C22.2 No. 205-12, Signal Equipment

Additional Information:

See the UL Online Certifications Directory at www.ul.com/database for additional information

Only those products bearing the UL Certification Mark should be considered as being covered by UL's Certification and Follow-Up Service. Look for the UL Certification Mark on the product.

C E R T I F I C A T E O F C O M P L I A N C E

Certificate Number

20170516-E490283

Report Reference

E490283-20170513

Issue Date

2017-MAY-16

Bruce Mahrenholz, Director North American Certification Program UL LLC Any information and documentation involving UL Mark services are provided on behalf of UL LLC (UL) or any authorized licensee of UL. For questions, please contact a local UL Customer Service Representative at http://ul.com/aboutul/locations/ Page 1 of 1

Issued to:

Eulum Design LLC 6131 Kellers Church Rd Pipersville PA 18947

This is to certify that representative samples of

MANAGEMENT EQUIPMENT, ENERGY Energy Management Equipment, Model Series TRED-CSB- 2A and SRPT-CSB; maybe followed by additional prefixes and/or suffixes for commercial purposes. Have been investigated by UL in accordance with the Standard(s) indicated on this Certificate.

Standard(s) for Safety:

UL 916 - Standard For Energy Management Equipment. CSA C22.2 No. 205-12 - Standard For Signal Equipment.

Additional Information:

See the UL Online Certifications Directory at www.ul.com/database for additional information

Only those products bearing the UL Certification Mark should be considered as being covered by UL's Certification and Follow-Up Service. Look for the UL Certification Mark on the product.

NORMATIVAS

slide-12
SLIDE 12

EULUM DESIGN LTD Unit 4 & 6 • Zone D • Chelmsford Road Ind. Est Dunmow • CM6 1XG • UK

www.eulum.com info@eulum.com

P.A.E. NEISA AVANCE I.

  • AVDA. DE LA INDUSTRIA 6-8,

NAVES 19-20-21 28108 Alcobendas - MADRID, España. t

www.olfer.com
