More environmental friendly alternatives for biobased materials in tires Heidi Beers Eco Efficiency specialist at Teijin Aramid Subjects Intrinsic Green tires: Recycled PET sustainability of comparison on versus virgin Twaron PET

SLIDE 1

More environmental friendly alternatives for biobased materials in tires

Heidi Beers – Eco Efficiency specialist at Teijin Aramid

SLIDE 2

Subjects

Green tires: comparison on

function

Recycled PET versus virgin PET Intrinsic sustainability of Twaron

SLIDE 3

Teijin Limited: global presence

SLIDE 4

Products Teijin Aramid

SLIDE 5

Intrinsic sustainability of Twaron

in applications

Light Strong Resists heat Endurance

Density 1.44 g/cm3 LOI - 29-37% Decomposition 500 oC 5 times stronger than steel at the same weight. Low maintenance No corrosion

SLIDE 6

Overview of applications

Creating durable tires

Taking the heat in the brakes

Increased lifetime automotive & industrial hoses Longer lasting transmission belts Worry free oil transport When steel fails

Twaron keeps us on-line For vehicles that save lives

SLIDE 7

How does the intrinsic sustainability of Twaron match with tire developments?

Requirements for tire developments: Lower weight tires

Leading to lower rolling resistance
Less CO2 and particulate matter emissions

Less raw materials needed

Requires high strength yarns (per mass unit) Rough comparison on amounts of materials needed for reinforcement:

Twaron: rayon =

1:3

Twaron: PET =

1:2

Steering precision

Requires dimensional stability

SLIDE 8

Subjects

Green tires: comparison on

function

Recycled PET versus Virgin PET Intrinsic sustainability of Twaron

SLIDE 9

What is a “green” tire?

a tire made 100% from natural materials?

A

a tire that results in a better eco performance over the whole life cycle (value chain)?

B

SLIDE 10

Where is the biggest environmental impact in the value chain?

SLIDE 11

TWARON/PET CORDS

67 gr Twaron 67 gr PET 270 gr rubber compound

RAYON CORDS IN CARCASS

300 gr rayon 600 gr rubber compound

TWARON CORDS

100 gr Twaron 200 gr rubber compound

Information: based on public available literature and patents

Rayon replacement in carcass

Rough comparison on amounts of materials needed for reinforcement: Twaron: rayon = 1:3 Twaron: PET = 1:2

SLIDE 12

Rayon replacement in carcass

REINFORCEMENT MATERIAL:

RAYON HYBRID TWARON/PET FULL TWARON Relevant aspects

300 gr. Rayon 300/600 gr. rubber 67 gr. Twaron 67 gr. PET 135/270 gr. rubber 100 gr. Twaron 100/200 gr. rubber Rolling resistance

Dynamic stiffness

+ + ++

Comfort

Fatigue

+ +

Lower weight

Commercially feasible

RAYON TWARON / PET FULL TWARON

Information: based on public available literature and patents

SLIDE 13

From kg to function: Global Warming Potential

Kg CO2-eq / kg

GWP per kg (incl. dipping)

Kg CO2-eq / carcass

GWP per function (incl. rubber)

SLIDE 14

Comparison passenger tire carcass

1. compare on function over total value chain

what, how much (raw materials, production)
how long, how well (use phase)

2. Check all effects over the total value chain 3. Focus on the differences 4. Be conservative VERY IMPORTANT 5. Involve from the start and discuss the results with customers and value chain partners: do they agree? Are there other views that need to be taken into account? Is it both environmentally better, and is it a business case?

How? Eco Efficiency Approach

f TUV certified

Customer Benefit Model.

SLIDE 15

RAW MATERIALS MANU- FACTURING DISTRIBUTION USE PHASE END OF LIFE Twaron/PET Less raw materials: Twaron, PET Rubber equal Less material less transport ecoburden and costs Fuel savings lighter tire, less rolling resistance equal Rayon More raw materials: Rayon Rubber equal More material, more transport ecoburden and costs equal

WHAT AND HOW MUCH HOW LONG, HOW WELL

Benefits for car producers and consumers (drivers, fleet owners) Lower fuel use Better CO2 footprint, less costs! Benefits for tire manufacturers Better CO2 footprint Less costs for raw materials

Differences in the value chain:

SLIDE 16

Subjects

Green tires: comparison on

function

Recycled PET versus Virgin PET Intrinsic sustainability of Twaron

SLIDE 17

Rayon replacement in carcass

RAYON

HYBRID Twaron with

VIRGIN PET

HYBRID Twaron with

RECYCLED PET

Information: based on public available literature and patents

Rough comparison on amounts of materials needed for reinforcement: Twaron: rayon = 1:3 Twaron: PET = 1:2

SLIDE 18

Rayon replacement in carcass

REINFORCEMENT MATERIAL:

RAYON TWARON/ VIRGIN PET TWARON/ RECYCLED PET Relevant aspects

300 gr. Rayon 600 gr. rubber 67 gr. Twaron 67 gr. virgin PET 270 gr. rubber 67 gr. Twaron 67 gr. recycled PET 270 gr. rubber

Rolling resistance

Dynamic stiffness

+ + +

Comfort Fatigue

+ + +

Lower weight

Commercially feasible

RAYON TWARON / VIRGIN PET TWARON / RECYCLED PET

Information: based on public available literature and patents

SLIDE 19

From kg to function: Global Warming Potential

Kg CO2-eq / kg

GWP per kg (incl. dipping)

Kg CO2-eq / carcass

GWP per function (incl. rubber)

SLIDE 20

Conclusion:

Biobased is not always better

A

Calculate per function together with chain partners

B

SLIDE 21
