MEETING THE CHALLENGES OF MEETING THE CHALLENGES OF DIFFICULT ENVIRONMENTS WITH DIFFICULT ENVIRONMENTS WITH AIRGrav AIRGrav Stefan Elieff Sander Geophysics Sander Geophysics Sander Geophysics Founded in 1956 - currently 160 employees,

slide-1
SLIDE 1

Sander Geophysics

MEETING THE CHALLENGES OF MEETING THE CHALLENGES OF DIFFICULT ENVIRONMENTS WITH DIFFICULT ENVIRONMENTS WITH

AIRGrav AIRGrav

Stefan Elieff Sander Geophysics

slide-2
SLIDE 2

Sander Geophysics

Sander Geophysics

 Founded in 1956 - currently 160 employees, 16 aircraft  Head office at Ottawa International Airport, Canada  World-wide operations – fixed-wing and helicopter  High resolution airborne geophysics – petroleum, mineral, environmental

− Magnetic − Gamma ray spectrometry − Gravimetry − LIDAR Laser Scanning − EM

slide-3
SLIDE 3

Sander Geophysics

Worldwide Operations

slide-4
SLIDE 4

Sander Geophysics

Mauritanian Sahara Desert

slide-5
SLIDE 5

Sander Geophysics

Jungles of Papua New Guinea Jungles of Papua New Guinea

slide-6
SLIDE 6

Sander Geophysics

Empty Quarter, Saudi Arabia Empty Quarter, Saudi Arabia

slide-7
SLIDE 7

Sander Geophysics

Ice Sheets and Glaciers of Antarctica Ice Sheets and Glaciers of Antarctica

slide-8
SLIDE 8

Sander Geophysics

Difficult Environments Difficult Environments

Stakes are higher: c Stakes are higher: costs, logistics, limited time

  • sts, logistics, limited time

window for operations window for operations Fly often Fly often

– Wide range of conditions Wide range of conditions – Reliable equipment Reliable equipment

Fly efficiently Fly efficiently

– All sensors collecting optimal data All sensors collecting optimal data – Optimal data throughout flight Optimal data throughout flight

slide-9
SLIDE 9

Sander Geophysics

SGL SGL AIRGrav AIRGrav AIRBORNE GRAVITY AIRBORNE GRAVITY

System design: System design:

– Three accelerometers (x y z) on a three axis Three accelerometers (x y z) on a three axis gyro stabilized platform gyro stabilized platform – Dual frequency GPS Dual frequency GPS receivers receivers – Gravity = inertial accelerations – GPS Gravity = inertial accelerations – GPS accelerations accelerations

Excellent tolerance of aircraft motion Excellent tolerance of aircraft motion

– Maintains accuracy in turbulence and while Maintains accuracy in turbulence and while following terrain (flying drape) following terrain (flying drape) – Short lead-ins to lines (about 1 minute) Short lead-ins to lines (about 1 minute)

High resolution and accuracy High resolution and accuracy

slide-10
SLIDE 10

Sander Geophysics

Turbulence

  • Hot, low altitude
  • No significant

impact on gravity until turbulence extremes

  • Other factors (ie

GPS) dominant

Influence of Turbulence - Sahara Desert Surveys

Relative turbulence for each line Relative noise estimate

slide-11
SLIDE 11

Sander Geophysics

Drape

  • Instrument height limits (laser, spectrometer)
  • Loss of resolution (attenuation with height)
slide-12
SLIDE 12

Sander Geophysics

20 40 60 80

  • 30
  • 25
  • 20
  • 15
  • 10
  • 5

Effect of altitude on airborne gravity data resolution

150 m 300 m 1500 m

Distance from start of line (km) Gravity (mGal)

slide-13
SLIDE 13

Sander Geophysics

EARLIER ANTARCTIC AIRBORNE GRAVITY EARLIER ANTARCTIC AIRBORNE GRAVITY

Science surveys since late 1970s Science surveys since late 1970s

Successful, but with Successful, but with shortcomings shortcomings

  • Limited resolution & accuracy

Limited resolution & accuracy

  • Long lead-ins to lines

Long lead-ins to lines

  • Inability to acquire accurate data

Inability to acquire accurate data while following terrain (drape) while following terrain (drape)

Prevents broader application in Prevents broader application in Antarctic research Antarctic research

slide-14
SLIDE 14

Sander Geophysics

IPY – AGAP PROJECT IPY – AGAP PROJECT

International Polar Year International Polar Year 2007-2008 2007-2008

Lamont-Doherty Earth Lamont-Doherty Earth Observatory of Columbia Observatory of Columbia University (LDEO) University (LDEO)

leading U.S. airborne leading U.S. airborne portion of the AGAP portion of the AGAP project project

– A Antarctica's ntarctica's – Ga Gamburtsev mburtsev – P Province rovince

slide-15
SLIDE 15

Sander Geophysics

Science Goals: Science Goals:

  • Map the hidden

Map the hidden Gamburtsev Mountains Gamburtsev Mountains buried under ice (over buried under ice (over 4 km thick in places) 4 km thick in places)

  • History of ice sheet – the

History of ice sheet – the cradle of formation? cradle of formation?

  • Tectonic history of

Tectonic history of Antarctica Antarctica

  • Locate places to drill for

Locate places to drill for the oldest ice cores the oldest ice cores

  • Subglacial lakes

Subglacial lakes

slide-16
SLIDE 16

Sander Geophysics

IPY - AGAP: GRAVITY METER? IPY - AGAP: GRAVITY METER?

  • Use commercial

Use commercial gravity meter from gravity meter from exploration industry? exploration industry?

  • Need to test suitability

Need to test suitability for polar research for polar research and Antarctic and Antarctic environment first... environment first...

slide-17
SLIDE 17

Sander Geophysics

IPY - AGAP: GRAVITY METER? IPY - AGAP: GRAVITY METER?

Calgary & Eureka tests Calgary & Eureka tests Summer 2007 Summer 2007

slide-18
SLIDE 18

Sander Geophysics

IPY - AGAP: GRAVITY METER IPY - AGAP: GRAVITY METER

SGL's AIRGrav system SGL's AIRGrav system selected for use in selected for use in Antarctica for AGAP Antarctica for AGAP

Comparison of AIRGrav and Comparison of AIRGrav and GT-1A airborne gravimeters GT-1A airborne gravimeters for research applications. for research applications. Michael Studinger, Robin Michael Studinger, Robin Bell, and Nick Frearson, Bell, and Nick Frearson, Geophysics Geophysics,Vol. 73, No. 6 ,Vol. 73, No. 6 November-December 2008 November-December 2008

slide-19
SLIDE 19

Sander Geophysics

IPY - AGAP: 2008-2009 FIELD SEASON IPY - AGAP: 2008-2009 FIELD SEASON

  • LDEO:

LDEO: magnetic, ice magnetic, ice penetrating penetrating radar, laser radar, laser scanner scanner

  • SGL: gravity,

SGL: gravity, aircraft aircraft attitude attitude

  • Kenn Borek Air:

Kenn Borek Air: Twin Otter Twin Otter

slide-20
SLIDE 20

Sander Geophysics

Williams 'Field', McMurdo, Antarctica Williams 'Field', McMurdo, Antarctica Kenn Borek Twin Otter C-FSJB Kenn Borek Twin Otter C-FSJB

slide-21
SLIDE 21

Sander Geophysics

AGAP Airborne Science Team AGAP Airborne Science Team BAS Twin Otter VP-FBL BAS Twin Otter VP-FBL

slide-22
SLIDE 22

Sander Geophysics

slide-23
SLIDE 23

Sander Geophysics

AGAP-South Field Camp

  • Extremely

Extremely remote – 600 km from South Pole, 1500 km from McMurdo

  • -25ºC to -35ºC (plus wind chill)
slide-24
SLIDE 24

Sander Geophysics

slide-25
SLIDE 25

Sander Geophysics

AGAP-South Field Camp

  • Actual altitude: 3500m (11,500 ft)
  • Physiological altitude: up to 14,000 ft
slide-26
SLIDE 26

Sander Geophysics

  • Antarctica – a moving ice sheet
  • GPS base stations are not stationary
slide-27
SLIDE 27

Sander Geophysics

slide-28
SLIDE 28

Sander Geophysics

  • 0.08
  • 0.06
  • 0.04
  • 0.02

0.00 0.02 0.04 0.06 0.08

  • 0.08
  • 0.06
  • 0.04
  • 0.02

0.00 0.02 0.04 0.06 0.08

AGAP-S GPS Reference Station Motion

UPS X Offset (m) UPS Y Offset (m)

AGAP-South 5 mm per day movement

slide-29
SLIDE 29

Sander Geophysics

AGAP-South Operations

  • Logistical / Operational challenges
  • Delays getting camp operational
  • Fuel supply
  • Weather
  • Aircraft snags
  • Short flying 'season'
  • Must take advantage of every flying opportunity
slide-30
SLIDE 30

Sander Geophysics

AGAP-South Operations

  • 53 flights: 55,000lkm of data between 22nd

December 2008 and 17th January 2009

  • Most productive period:
  • 21 flights in 6 days
  • Round the clock flying: 4 flights per day, 22

hours per day, 4,000+ km per day.

  • 40% of the survey completed during this period
  • AIRGrav system – no delays, no downtime,

through entire survey

slide-31
SLIDE 31

Sander Geophysics

slide-32
SLIDE 32

Sander Geophysics

Gamburtsev Mountains as imaged by AIRGrav. Similar in size and character to the European Alps

slide-33
SLIDE 33

Sander Geophysics

Two days ago...first AGAP research paper published.

slide-34
SLIDE 34

Sander Geophysics

British Antarctic Survey (BAS)

  • Traditional L&R airborne gravity meter modified by ZLS
  • Flew northern area from AGAP-North camp
slide-35
SLIDE 35

Sander Geophysics

AGAP Performance Comparison

AIRGrav AIRGrav

  • Flown drape (benefits

grav, mag, laser)

  • 3.5km lead-ins
  • 3500m resolution
  • 1 mGal crossover

errors BAS L&R BAS L&R

  • Flown constant height

(no laser instrument)

  • 15-20km lead-ins
  • 8000m resolution
  • 3.5 mGal crossover

errors

slide-36
SLIDE 36

Sander Geophysics

Continued Continued LDEO / SGL LDEO / SGL collaboration collaboration

slide-37
SLIDE 37

Sander Geophysics

NASA IceBridge NASA IceBridge

  • Multi-year, multi-instrument,

Multi-year, multi-instrument, multi-aircraft campaign multi-aircraft campaign

  • Monitor ice at Earth's poles

Monitor ice at Earth's poles

  • Bridging the gap between

Bridging the gap between ICESat (ended 2009) and ICESat (ended 2009) and ICESat 2 (launch 2015?) ICESat 2 (launch 2015?)

slide-38
SLIDE 38

Sander Geophysics

DC-8 in Antarctic and Arctic DC-8 in Antarctic and Arctic P-3 in Arctic P-3 in Arctic

slide-39
SLIDE 39

Sander Geophysics

IceBridge Radar & Laser IceBridge Radar & Laser

slide-40
SLIDE 40

Sander Geophysics

Role of airborne gravity Role of airborne gravity

slide-41
SLIDE 41

Sander Geophysics

Role of airborne gravity Role of airborne gravity

slide-42
SLIDE 42

Sander Geophysics

Role of airborne gravity Role of airborne gravity

Source: NRCan

  • Sea ice surface rises, no open leads...

Thicker ice or geoid?

  • Horizontal gravity components from AIRGrav
slide-43
SLIDE 43

Sander Geophysics

IceBridge Antarctica 2009

Based in Punta Arenas, Based in Punta Arenas, Chile Chile 21 missions (17 planned) 21 missions (17 planned) 155,305 flight 155,305 flight kilometres kilometres 227.4 flight hours 227.4 flight hours

slide-44
SLIDE 44

Sander Geophysics

IceBridge Arctic 2010

  • NASA DC8 and P3
  • Based in Thule and

Kangerlussuaq, Greenland

slide-45
SLIDE 45

Sander Geophysics

IceBridge Antarctica 2010

slide-46
SLIDE 46

Sander Geophysics

NASA IceBridge Extremes

  • Long flights: duration up to 12.5 hours

Long flights: duration up to 12.5 hours

  • Long distances: up to 9000 km

Long distances: up to 9000 km

  • Long differential GPS baselines: over 4000 km

Long differential GPS baselines: over 4000 km

  • Altitude range: 150-12,000 m (500' – 40,000')

Altitude range: 150-12,000 m (500' – 40,000')

  • Speed range: 270-450 knots (140-230 m/s)

Speed range: 270-450 knots (140-230 m/s)

slide-47
SLIDE 47

Sander Geophysics

Extremely large survey aircraft... Extremely large survey aircraft...

slide-48
SLIDE 48

Sander Geophysics

IceBridge DC8 & P3: Multi-instrument platforms IceBridge DC8 & P3: Multi-instrument platforms

slide-49
SLIDE 49

Sander Geophysics

Multi-instrument = conflicting requirements Multi-instrument = conflicting requirements

Laser scanner –

  • ften highest

priority

  • Many lines flown

with constant course changes, curved paths

slide-50
SLIDE 50

Sander Geophysics

Multi-instrument = conflicting requirements Multi-instrument = conflicting requirements

Straight flight Constant turns

slide-51
SLIDE 51

Sander Geophysics

Multi-instrument = conflicting requirements Multi-instrument = conflicting requirements

  • Impact on 'low priority' AIRGrav data:

Impact on 'low priority' AIRGrav data:

  • Increased noise (filtering kept constant)

Increased noise (filtering kept constant)

  • Decrease resolution (filtering strengthened to

Decrease resolution (filtering strengthened to maintain accuracy) maintain accuracy)

  • Unlikely any usable data would be recovered by other

Unlikely any usable data would be recovered by other gravity instruments gravity instruments

  • Reduced accuracy / resolution compares well against

Reduced accuracy / resolution compares well against traditional instruments flown in ideal conditions traditional instruments flown in ideal conditions

slide-52
SLIDE 52

Sander Geophysics

  • No re-flights, no significant delays possible

No re-flights, no significant delays possible

  • Instrument must be available to fly whenever

Instrument must be available to fly whenever required required AGAP and IceBridge 2008-2010 AGAP and IceBridge 2008-2010

  • 116 survey flights in Twin Otter, DC8, and P3

116 survey flights in Twin Otter, DC8, and P3

  • >99% success rate. Only 1 flight with lost

>99% success rate. Only 1 flight with lost gravity data (in-flight computer failure) gravity data (in-flight computer failure)

IceBridge flights with AIRGrav continue... IceBridge flights with AIRGrav continue...

Multi-instrument = conflicting requirements Multi-instrument = conflicting requirements

slide-53
SLIDE 53

Sander Geophysics

Pine Island Glacier, Antarctica

slide-54
SLIDE 54

Sander Geophysics

slide-55
SLIDE 55

Sander Geophysics

slide-56
SLIDE 56

Sander Geophysics

Pine Island Glacier

NASA Earth Observatory

slide-57
SLIDE 57

Sander Geophysics

ACKNOWLEDGEMENTS ACKNOWLEDGEMENTS

Michael Studinger Michael Studinger (NASA) (NASA) Nick Frearson Nick Frearson (LDEO) (LDEO) Robin Bell Robin Bell (LDEO) (LDEO) ...plus many others from Lamont-Doherty Earth Observatory of Columbia University & NASA

slide-58
SLIDE 58

Sander Geophysics

ACKNOWLEDGEMENTS ACKNOWLEDGEMENTS

Sander Geophysics Sander Geophysics

Field crews... AGAP: Dan Geue, Martin Bates IceBridge: Kevin Charles, Sean O'Rourke, Eric Renaud ...and many others at SGL

slide-59
SLIDE 59

Sander Geophysics

Thank you Thank you

slide-60
SLIDE 60

Sander Geophysics

Incredible views out the window...

slide-61
SLIDE 61

Sander Geophysics

slide-62
SLIDE 62

Sander Geophysics

slide-63
SLIDE 63

Sander Geophysics

slide-64
SLIDE 64

Sander Geophysics

slide-65
SLIDE 65

Sander Geophysics

slide-66
SLIDE 66

Sander Geophysics

slide-67
SLIDE 67

Sander Geophysics

slide-68
SLIDE 68

Sander Geophysics

Logistical Logistical

challenges...

challenges...
