AIA 2030 Commitment : Architects Prepare to Meet the Challenge The raw resource extraction, manufacturing, construction, usage, and end-of-life stages of building products each generate significant greenhouse gas (GHG) emissions. Slowing

slide-1
SLIDE 1

AIA 2030 Commitment : Architects Prepare to Meet the Challenge

slide-2
SLIDE 2

2030 Challenge

“The raw resource extraction, manufacturing, construction, usage, and end-of-life stages of building products each generate significant greenhouse gas (GHG)

  • emissions. Slowing the growth

rate of GHG emissions and then reversing it is the key to addressing climate change.”

Architecture 2030 founder Edward Mazria

slide-3
SLIDE 3

2030 Commitment - Why do it?

slide-4
SLIDE 4

2030 Commitment - Why do it?

slide-5
SLIDE 5

Architecture2030.org

All new buildings, developments and major renovations to have a 50% reduction in fossil fuel, GHG emissions and energy consumption now Further reductions as follows;

  • 60% in 2010
  • 70% in 2015
  • 80% in 2020
  • 90% in 2025
  • Carbon Neutral in 2030

2030 Commitment - Why do it?

  • ximately
slide-6
SLIDE 6

Architecture2030.org

All new buildings, developments and major renovations to have a 50% reduction in fossil fuel, GHG emissions and energy consumption now Further reductions as follows;

  • 60% in 2010
  • 70% in 2015
  • 80% in 2020
  • 90% in 2025
  • Carbon Neutral in 2030

2030 Commitment - Why do it?

  • ximately
slide-7
SLIDE 7

Architecture2030.org

All new buildings, developments and major renovations to have a 50% reduction in fossil fuel, GHG emissions and energy consumption now Further reductions as follows;

  • 60% in 2010
  • 70% in 2015
  • 80% in 2020
  • 90% in 2025
  • Carbon Neutral in 2030

2030 Commitment - Why do it?

As of 2010, the total U.S. building stock is approximately 275 billion square feet.

  • ximately
slide-8
SLIDE 8

Architecture2030.org

All new buildings, developments and major renovations to have a 50% reduction in fossil fuel, GHG emissions and energy consumption now Further reductions as follows;

  • 60% in 2010
  • 70% in 2015
  • 80% in 2020
  • 90% in 2025
  • Carbon Neutral in 2030

2030 Commitment - Why do it?

  • ximately

During normal economic times, we tear down approximately 1.75 billion square feet of buildings each year

slide-9
SLIDE 9

Architecture2030.org

All new buildings, developments and major renovations to have a 50% reduction in fossil fuel, GHG emissions and energy consumption now Further reductions as follows;

  • 60% in 2010
  • 70% in 2015
  • 80% in 2020
  • 90% in 2025
  • Carbon Neutral in 2030

2030 Commitment - Why do it?

  • ximately

Every year, we renovate approximately 5 billion square feet.

slide-10
SLIDE 10

Architecture2030.org

All new buildings, developments and major renovations to have a 50% reduction in fossil fuel, GHG emissions and energy consumption now Further reductions as follows;

  • 60% in 2010
  • 70% in 2015
  • 80% in 2020
  • 90% in 2025
  • Carbon Neutral in 2030

2030 Commitment - Why do it?

  • ximately

Each year we build approximately 5 billion square feet.

slide-11
SLIDE 11

Architecture2030.org

All new buildings, developments and major renovations to have a 50% reduction in fossil fuel, GHG emissions and energy consumption now Further reductions as follows;

  • 60% in 2010
  • 70% in 2015
  • 80% in 2020
  • 90% in 2025
  • Carbon Neutral in 2030

2030 Commitment - Why do it?

  • ximately

By 2035, approximately 75% of the built environment will be either new or renovated. This transformation over the next 25 years represents a historic opportunity for the architecture and building community to avoid dangerous climate change.

slide-12
SLIDE 12

2030 Commitment

Four Parts to the 2030 Commitment

slide-13
SLIDE 13

2030 Commitment

Four Parts to the 2030 Commitment

1.Letter of Commitment

slide-14
SLIDE 14

2030 Commitment

1.Letter of Commitment 2.Immediate Operational Actions 3.Sustainability Action Plan 4.Reporting

slide-15
SLIDE 15

2030 Commitment

1.Letter of Commitment 2.Immediate Operational Actions 3.Sustainability Action Plan 4.Reporting

slide-16
SLIDE 16

2030 Commitment

1.Letter of Commitment 2.Immediate Operational Actions 3.Sustainability Action Plan 4.Reporting

slide-17
SLIDE 17

2030 Commitment

1.Letter of Commitment 2.Immediate Operational Actions 3.Sustainability Action Plan 4.Reporting

slide-18
SLIDE 18

2030 Commitment

1.Letter of Commitment 2.Immediate Operational Actions 3.Sustainability Action Plan 4.Reporting

slide-19
SLIDE 19

2030 Commitment

slide-20
SLIDE 20

1.Gather data

a. Project Gross Square Footage (GSF) b. Predicted Energy Use Intensity (EUI) c. Lighting Power Density (LPD) if interior project d. Was the project modeled? (Y/N) e. Will actual energy use data be collected (Y/N)

  • 2. Enter data into worksheet
  • 3. Print worksheet out and submit to AIA National

2030 Commitment

slide-21
SLIDE 21

Predicted Energy Use Intensity EUI = kBTU/square foot/year Lighting Power Density LPD = Watts/square foot

2030 Commitment

slide-22
SLIDE 22

Reporting Tool - Worksheet

2030 Commitment

2011 Kipnis Architecture + Planning

slide-23
SLIDE 23

Reporting Tool - Worksheet

2030 Commitment

2011 Kipnis Architecture + Planning

slide-24
SLIDE 24

Reporting Tool - Worksheet Input

2030 Commitment

slide-25
SLIDE 25

Reporting Tool - References

2030 Commitment

slide-26
SLIDE 26

Reporting Tool - References Residential EUI

SF Detached = 44 SF Attached = 44 Multi-Fam 2-4 units = 58 Muilt-Fam 5 or more = 50

2030 Commitment

slide-27
SLIDE 27

2030 U.S. Regional Residential EUI’s

2030 Commitment

slide-28
SLIDE 28

2030 U.S. Regional Residential EUI’s

2030 Commitment

slide-29
SLIDE 29

How to Determine an EUI

2030 Commitment

slide-30
SLIDE 30

How to Determine an EUI

  • 1. Check Default Code

a. Usually IECC 2006 (20% reduction) IECC 2009 (35% reduction) or IECC 2012 (45% reduction) b. Goal is 60% reduction for 2010-2014 c. Average Midwest EUI for single family is 49.5 d. Therefore, current 2030 goal is 60% reduction = 19.8

  • 2. Calculate Actual EUI

a. REScheck is standard for many municipalities. b. Different software programs are available that can do this.

  • 3. What if I can’t calculate the EUI?

a. Submit code compliant amounts (20%, 35% or 45%)

2030 Commitment

slide-31
SLIDE 31

2030 Commitment

Analysis Programs

  • 1. REScheck
  • 2. IES VE-ware Plug for SketchUp
  • 3. HEED
  • 4. EcoDesigner for Archicad
  • 5. EnergyPlus OpenStudio
  • 6. GreenSpace Research’s gModeler Plug-in for SketchUp
  • 7. Autodesk’s Green Building Studio
  • 8. Passive House Planning Software (PHPP)
  • 9. Other software
slide-32
SLIDE 32

2030 Commitment

EPW Climate File

slide-33
SLIDE 33

2030 Commitment

EPW Climate File

slide-34
SLIDE 34

2030 Commitment

EPW Climate File

slide-35
SLIDE 35

2030 Commitment

EPW Climate File

slide-36
SLIDE 36

REScheck

2030 Commitment

slide-37
SLIDE 37

2030 Commitment

IES VE-ware (free software/Sketchup Plug-in)

slide-38
SLIDE 38

2030 Commitment

IES VE-ware (free software/Sketchup Plug-in)

slide-39
SLIDE 39

2030 Commitment

IES VE-ware (free software/Sketchup Plug-in)

slide-40
SLIDE 40

2030 Commitment

IES VE-ware (free software/Sketchup Plug-in)

slide-41
SLIDE 41

2030 Commitment

IES VE-Pro (subscription based suite of building performance tools)

slide-42
SLIDE 42

2030 Commitment

IES VE-Pro (subscription based suite of building performance tools)

slide-43
SLIDE 43

2030 Commitment

IES VE-Pro (subscription based suite of building performance tools)

slide-44
SLIDE 44

HEED

2030 Commitment

slide-45
SLIDE 45

HEED

2030 Commitment

slide-46
SLIDE 46

HEED

2030 Commitment

slide-47
SLIDE 47

HEED

2030 Commitment

slide-48
SLIDE 48

Reporting

2030 Commitment

slide-49
SLIDE 49

2030 Commitment

Benefits of 2030 Challenge

a. Understanding of a projects’ EUI. b. Inexpensive, easy and early energy analysis. c. Understanding of the design impact of the following; a. Climate b. Orientation c. Windows d. Insulation e. Mechanical Systems d. Will make your firm more marketable to be able to state the energy use

  • f projects and show how they perform.
