Agenda 6:00 to 6:10 Welcome and Introductions (Charles Thomas, PE, SSCAFCA) 6:10 to 6:30 Project Background/Description (David Gatterman, PE, SSCAFCA) 6:30 to 7:00 Conceptual Design Plans (George Radnovich, ASLA, Sites SW and Tyler

SLIDE 1

SLIDE 2

Agenda

 6:00 to 6:10 Welcome and Introductions (Charles Thomas,

PE, SSCAFCA)

 6:10 to 6:30 Project Background/Description (David

Gatterman, PE, SSCAFCA)

 6:30 to 7:00 Conceptual Design Plans (George Radnovich,

ASLA, Sites SW and Tyler Ashton, PE, Wilson & Co)

 7:00 to 7:15 Environmental Investigations/Certification

(Cassandra D’Antonio, Sites SW)

 7:15 to 7:30 Moving Forward/Project Schedule (David

Gatterman, P.E., SSCAFCA)

 7:30 to 8:00 Questions/Comments (All Participants)

SLIDE 3

Project Team SSCAFCA

Chuck Thomas, P.E., Executive Engineer David Gatterman, P.E., Environmental Services Director

Sites Southwest, LLC

George Radnovich, ASLA, Project Manager Cassandra D’Antonio, Environmental Project Manager Victor Trujillo, Lead Landscape Architect Wilson & Company Tyler Ashton, P.E., Lead Engineer

SLIDE 4

Black Arroyo Master Plan

 SSCAFCA owns approximately 72 acres along the Black

Arroyo in Rio Rancho, NM

 14 acres of site to be preserved as an Environmental

Mitigation Zone for Wildlife Habitat

 8.5 acres of site set aside for Education (school)  Purpose of the Master Plan:

 Safe access with respect to flooding  Alternative use potentials for the property  Arid land protection/restoration  Educational/recreational opportunities for the property

SLIDE 5

Black Arroyo Wildlife Park Master Plan

SLIDE 6

Black Arroyo Trail Project SSCAFCA is proposing to design and construct a multi-

use trail system, including trailheads, parking, and arroyo crossings, throughout the 72-acre Black Arroyo Wildlife Park:

 ADA-accessible  Two pedestrian bridges and two culverted crossings along the

Black Arroyo or its tributaries

 Trail head parking/drop-off areas  Connectivity to Maggie Cordova Elementary School  Main trail would be approximately 1.25 miles long and 10 to 12

feet wide (12 shown)

 Trail alignments, locations of arroyo crossings, and parking

areas generally conform to those identified in the May 2013 Master Plan

SLIDE 7

Black Arroyo Trail Project

Funding for the Black Arroyo Trail Project ($722,832) has been obtained from the following sources:

1. FHWA Transportation Alternatives Program $556,400
2. State Funds (using state appropriation) $71,615
3. Local Match (using balance of state appropriation) $94,817

SLIDE 8

Black Arroyo Trail Project

TRAILHEAD LOCATION 1 TRAILHEAD LOCATION 2 TRAILHEAD LOCATION 3

SLIDE 9

Black Arroyo Trail Project

TRAILHEAD LOCATION 1 ENLARGEMENT

SLIDE 10

Black Arroyo Trail Project

SLIDE 11

Black Arroyo Trail Project

SLIDE 12

Black Arroyo Trail Project

TRAILHEAD LOCATION 2 ENLARGEMENT

SLIDE 13

Black Arroyo Trail Project

SLIDE 14

Black Arroyo Trail Project

TRAILHEAD LOCATION 3 ENLARGEMENT

SLIDE 15

Black Arroyo Trail Project

SLIDE 16

Black Arroyo Trail Project

SLIDE 17

Black Arroyo Trail Project

SLIDE 18

Black Arroyo Trail Project

SLIDE 19

Black Arroyo Trail Project

Environmental Investigations

 Two (2) Active Burrowing Owl Nests (1 in the northern part of

the arroyo and one in the mid section

 Highly erodible soils (sand) throughout project area with high

number of weedy annuals, though none noted as noxious

 No wetland areas  Bank swallow habitat present though decreasing in quality and

no birds were observed during survey. Heavy rains of September 2013 may have contributed to decreasing quality of habitat, as much of the burrows were sloughing

 Vegetation primarily consists of sand sage, Indian rice-grass,

juniper, and a large number of weedy annuals. Weedy annual density number probably a result of proximity to primary thoroughfares and thus seed dispersal

Environmental Certifications/Approvals/Permits

SLIDE 20

Black Arroyo Trail Project

 Moving Forward/Project Schedule:

 Complete plans, specifications, and estimates (PS&E) by

August 1, 2014

 Obtain approval from NMDOT of PS&E by August 15,

2014

 Issue Invitation to Bid by late September 2014  Bid opening in October 2014  Issue contract for construction November/December

2014

 Complete project construction Spring 2015

SLIDE 21

Black Arroyo Trail Project

QUESTIONS?

Project Contacts

David Gatterman, P.E.

Environmental Services Director Phone: (505) 892-7426 Email: dgatterman@sscafca.com

George Radnovich, ASLA

Project Manager Phone: (505) 822-8200 Email: grad@sites-sw.com
