Adventures in Fuzzing Instruction Selection EuroLLVM 2017 Justin Bogner 1 Overview Hardening instruction selection using fuzzers Motivated by Global ISel Leveraging libFuzzer to find backend bugs Techniques applicable to

slide-1
SLIDE 1

Adventures in Fuzzing Instruction Selection

1 EuroLLVM 2017 • Justin Bogner

slide-2
SLIDE 2

Overview

  • Hardening instruction selection using fuzzers
  • Motivated by Global ISel
  • Leveraging libFuzzer to find backend bugs
  • Techniques applicable to other parts of LLVM

2 Fuzzing Instruction Selection • EuroLLVM 2017

slide-3
SLIDE 3

Fuzzing Recap

  • Using random inputs to find bugs
  • Input generation
  • Mutations of representative inputs
  • Guided evolutionary fuzzing (afl-fuzz, libFuzzer)

3 Fuzzing Instruction Selection • EuroLLVM 2017

slide-4
SLIDE 4

libFuzzer

4 Fuzzing Instruction Selection • EuroLLVM 2017

extern "C" int LLVMFuzzerTestOneInput( const uint8_t *Data, size_t Size) { if (Size > 0 && Data[0] == 'H') if (Size > 1 && Data[1] == 'i') if (Size > 2 && Data[2] == '!') exit(0); return 0; }

slide-5
SLIDE 5

libFuzzer

5 Fuzzing Instruction Selection • EuroLLVM 2017

extern "C" int LLVMFuzzerTestOneInput( const uint8_t *Data, size_t Size) { if (Size > 0 && Data[0] == 'H') if (Size > 1 && Data[1] == 'i') if (Size > 2 && Data[2] == '!') exit(0); return 0; } Corpus > 0 'H' > 1 > 2 'i' '!'

slide-6
SLIDE 6

libFuzzer

6 Fuzzing Instruction Selection • EuroLLVM 2017

extern "C" int LLVMFuzzerTestOneInput( const uint8_t *Data, size_t Size) { if (Size > 0 && Data[0] == 'H') if (Size > 1 && Data[1] == 'i') if (Size > 2 && Data[2] == '!') exit(0); return 0; } Corpus

Unit: <empty> Mutations: q

> 0 'H' > 1 > 2 'i' '!'

slide-7
SLIDE 7

libFuzzer

7 Fuzzing Instruction Selection • EuroLLVM 2017

extern "C" int LLVMFuzzerTestOneInput( const uint8_t *Data, size_t Size) { if (Size > 0 && Data[0] == 'H') if (Size > 1 && Data[1] == 'i') if (Size > 2 && Data[2] == '!') exit(0); return 0; } Corpus

Unit: <empty> Mutations: q q

> 0 'H' > 1 > 2 'i' '!'

slide-8
SLIDE 8

libFuzzer

8 Fuzzing Instruction Selection • EuroLLVM 2017

extern "C" int LLVMFuzzerTestOneInput( const uint8_t *Data, size_t Size) { if (Size > 0 && Data[0] == 'H') if (Size > 1 && Data[1] == 'i') if (Size > 2 && Data[2] == '!') exit(0); return 0; } Corpus

Unit: <empty> Mutations: q X 7 y q

> 0 'H' > 1 > 2 'i' '!'

slide-9
SLIDE 9

libFuzzer

9 Fuzzing Instruction Selection • EuroLLVM 2017

extern "C" int LLVMFuzzerTestOneInput( const uint8_t *Data, size_t Size) { if (Size > 0 && Data[0] == 'H') if (Size > 1 && Data[1] == 'i') if (Size > 2 && Data[2] == '!') exit(0); return 0; } Corpus

Unit: q Mutations: qZ y q

> 0 'H' > 1 > 2 'i' '!'

slide-10
SLIDE 10

libFuzzer

10 Fuzzing Instruction Selection • EuroLLVM 2017

extern "C" int LLVMFuzzerTestOneInput( const uint8_t *Data, size_t Size) { if (Size > 0 && Data[0] == 'H') if (Size > 1 && Data[1] == 'i') if (Size > 2 && Data[2] == '!') exit(0); return 0; } Corpus

q Unit: q Mutations: qZ y H

> 0 'H' > 1 > 2 'i' '!'

slide-11
SLIDE 11

libFuzzer

11 Fuzzing Instruction Selection • EuroLLVM 2017

extern "C" int LLVMFuzzerTestOneInput( const uint8_t *Data, size_t Size) { if (Size > 0 && Data[0] == 'H') if (Size > 1 && Data[1] == 'i') if (Size > 2 && Data[2] == '!') exit(0); return 0; } Corpus

q Unit: q Mutations: qZ y H qm H

> 0 'H' > 1 > 2 'i' '!'

slide-12
SLIDE 12

libFuzzer

12 Fuzzing Instruction Selection • EuroLLVM 2017

extern "C" int LLVMFuzzerTestOneInput( const uint8_t *Data, size_t Size) { if (Size > 0 && Data[0] == 'H') if (Size > 1 && Data[1] == 'i') if (Size > 2 && Data[2] == '!') exit(0); return 0; } Corpus

q Unit: H Mutations: HF H

> 0 'H' > 1 > 2 'i' '!'

slide-13
SLIDE 13

libFuzzer

13 Fuzzing Instruction Selection • EuroLLVM 2017

extern "C" int LLVMFuzzerTestOneInput( const uint8_t *Data, size_t Size) { if (Size > 0 && Data[0] == 'H') if (Size > 1 && Data[1] == 'i') if (Size > 2 && Data[2] == '!') exit(0); return 0; } Corpus

q Unit: H Mutations: HF Hi H HF

> 0 'H' > 1 > 2 'i' '!'

slide-14
SLIDE 14

libFuzzer

14 Fuzzing Instruction Selection • EuroLLVM 2017

extern "C" int LLVMFuzzerTestOneInput( const uint8_t *Data, size_t Size) { if (Size > 0 && Data[0] == 'H') if (Size > 1 && Data[1] == 'i') if (Size > 2 && Data[2] == '!') exit(0); return 0; } > 0 'H' > 1 > 2 'i' '!' Corpus

q Unit: Hi Mutations: Hh xi HiR Hi! H HF HiR

slide-15
SLIDE 15

Fuzzers in LLVM

  • clang-fuzzer
  • clang-format-fuzzer
  • llvm-as-fuzzer
  • llvm-mc-fuzzer
  • ... but no llc-fuzzer

15 Fuzzing Instruction Selection • EuroLLVM 2017

slide-16
SLIDE 16

Beyond Parser Bugs

16 Fuzzing Instruction Selection • EuroLLVM 2017

static void g(){} signed*Qwchar_t;

  • verridedouble++!=~;inline-=}y=^bitand{;*=or;goto*&&k}==n

int XS/=~char16_t&s<=const_cast<Xchar*>(thread_local3+=char32_t

slide-17
SLIDE 17

Beyond Parser Bugs

17 Fuzzing Instruction Selection • EuroLLVM 2017

@a2 = global i8 addrspace(1)*@0 = private constant i32 0 @1 = private constant i32 1 @2 = private alias i32* @d0 @3 = @a @a = ad private aeflias i32* @1ine internal h2dden vodrsid @fun ction() { entry: ret void }pac e(1) global i8 0

slide-18
SLIDE 18

Structured Fuzzing

18 Fuzzing Instruction Selection • EuroLLVM 2017

00000000 64 65 66 69 6e 65 20 76 6f 69 64 20 40 66 28 29 |define void @f()| 00000010 20 7b 0a 42 42 3a 0a 20 20 25 4c 32 20 3d 20 6c | {.BB:. %L2 = l|

  • 00000020 6f 61 64 20 69 31 2c 20 69 31 2a 20 75 6e 64 65 |oad i1, i1* unde|

+00000020 6f 61 64 20 69 38 2c 20 69 38 2a 20 75 6e 64 65 |oad i8, i8* unde| 00000030 66 0a 20 20 62 72 20 6c 61 62 65 6c 20 25 42 42 |f. br label %BB| 00000040 35 0a 0a 42 42 39 3a 0a 20 20 25 4c 36 20 3d 20 |5..BB9:. %L6 = |

  • 00000050 6c 6f 61 64 20 69 31 2c 20 69 31 2a 20 75 6e 64 |load i1, i1* und|

+00000050 6c 6f 61 64 20 69 38 2c 20 69 38 2a 20 75 6e 64 |load i8, i8* und| 00000060 65 66 0a 20 20 25 42 38 20 3d 20 73 64 69 76 20 |ef. %B8 = sdiv |

  • 00000070 69 31 20 25 4c 36 2c 20 25 4c 32 0a 20 20 25 41 |i1 %L6, %L2. %A|

+00000070 69 38 20 25 4c 36 2c 20 25 4c 32 0a 20 20 25 41 |i8 %L6, %L2. %A| 00000080 37 20 3d 20 61 6c 6c 6f 63 61 20 66 6c 6f 61 74 |7 = alloca float| 00000090 0a 20 20 25 41 34 20 3d 20 61 6c 6c 6f 63 61 20 |. %A4 = alloca |

slide-19
SLIDE 19

Structured Fuzzing

19 Fuzzing Instruction Selection • EuroLLVM 2017

00000000 64 65 66 69 6e 65 20 76 6f 69 64 20 40 66 28 29 |define void @f()| 00000010 20 7b 0a 42 42 3a 0a 20 20 25 4c 32 20 3d 20 6c | {.BB:. %L2 = l|

  • 00000020 6f 61 64 20 69 31 2c 20 69 31 2a 20 75 6e 64 65 |oad i1, i1* unde|

+00000020 6f 61 64 20 69 38 2c 20 69 38 2a 20 75 6e 64 65 |oad i8, i8* unde| 00000030 66 0a 20 20 62 72 20 6c 61 62 65 6c 20 25 42 42 |f. br label %BB| 00000040 35 0a 0a 42 42 39 3a 0a 20 20 25 4c 36 20 3d 20 |5..BB9:. %L6 = |

  • 00000050 6c 6f 61 64 20 69 31 2c 20 69 31 2a 20 75 6e 64 |load i1, i1* und|

+00000050 6c 6f 61 64 20 69 38 2c 20 69 38 2a 20 75 6e 64 |load i8, i8* und| 00000060 65 66 0a 20 20 25 42 38 20 3d 20 73 64 69 76 20 |ef. %B8 = sdiv |

  • 00000070 69 31 20 25 4c 36 2c 20 25 4c 32 0a 20 20 25 41 |i1 %L6, %L2. %A|

+00000070 69 38 20 25 4c 36 2c 20 25 4c 32 0a 20 20 25 41 |i8 %L6, %L2. %A| 00000080 37 20 3d 20 61 6c 6c 6f 63 61 20 66 6c 6f 61 74 |7 = alloca float| 00000090 0a 20 20 25 41 34 20 3d 20 61 6c 6c 6f 63 61 20 |. %A4 = alloca |

slide-20
SLIDE 20

Structured Fuzzing

20 Fuzzing Instruction Selection • EuroLLVM 2017

00000000 64 65 66 69 6e 65 20 76 6f 69 64 20 40 66 28 29 |define void @f()| 00000010 20 7b 0a 42 42 3a 0a 20 20 25 4c 32 20 3d 20 6c | {.BB:. %L2 = l|

  • 00000020 6f 61 64 20 69 31 2c 20 69 31 2a 20 75 6e 64 65 |oad i1, i1* unde|

+00000020 6f 61 64 20 69 38 2c 20 69 38 2a 20 75 6e 64 65 |oad i8, i8* unde| 00000030 66 0a 20 20 62 72 20 6c 61 62 65 6c 20 25 42 42 |f. br label %BB| 00000040 35 0a 0a 42 42 39 3a 0a 20 20 25 4c 36 20 3d 20 |5..BB9:. %L6 = |

  • 00000050 6c 6f 61 64 20 69 31 2c 20 69 31 2a 20 75 6e 64 |load i1, i1* und|

+00000050 6c 6f 61 64 20 69 38 2c 20 69 38 2a 20 75 6e 64 |load i8, i8* und| 00000060 65 66 0a 20 20 25 42 38 20 3d 20 73 64 69 76 20 |ef. %B8 = sdiv |

  • 00000070 69 31 20 25 4c 36 2c 20 25 4c 32 0a 20 20 25 41 |i1 %L6, %L2. %A|

+00000070 69 38 20 25 4c 36 2c 20 25 4c 32 0a 20 20 25 41 |i8 %L6, %L2. %A| 00000080 37 20 3d 20 61 6c 6c 6f 63 61 20 66 6c 6f 61 74 |7 = alloca float| 00000090 0a 20 20 25 41 34 20 3d 20 61 6c 6c 6f 63 61 20 |. %A4 = alloca |

slide-21
SLIDE 21

Custom Mutator API

21 Fuzzing Instruction Selection • EuroLLVM 2017

// Optional user-provided custom mutator. // Mutates raw data in [Data, Data+Size) inplace. // Returns the new size, which is not greater than MaxSize. // Given the same Seed produces the same mutation. size_t LLVMFuzzerCustomMutator(uint8_t *Data, size_t Size, size_t MaxSize, unsigned int Seed);

slide-22
SLIDE 22

Where to Mutate?

22 Fuzzing Instruction Selection • EuroLLVM 2017

IR MIR Assembly Frontend

IR/opt passes Machine passes Selection Entry Point

slide-23
SLIDE 23

llvm-stress

  • Random IR generator
  • Used for new backends and FastISel
  • Excellent for bringup, forgotten later

23 Fuzzing Instruction Selection • EuroLLVM 2017

slide-24
SLIDE 24

LLVM IR Mutator

  • Work in terms of operations on SSA values
  • Each operation has sources and a sink
  • Sinks should be side effects to avoid dead code
  • It's safe to disconnect sinks and DCE at will

24 Fuzzing Instruction Selection • EuroLLVM 2017

slide-25
SLIDE 25

Adding one operation

  • Divide a block into potential

sources and sinks

  • Choose or create one source
  • Choose an operation
  • Fill in the other sources
  • Steal an argument of a later
  • peration as a sink
  • Clean up dead code

25 Fuzzing Instruction Selection • EuroLLVM 2017

define void @f() { BB: %L1 = load i16, i16* undef %L2 = load i16, i16* undef %B1 = lshr i16 %L1, %L2 store i16 %B1, i16* undef ret void }

slide-26
SLIDE 26

Adding one operation

  • Divide a block into potential

sources and sinks

  • Choose or create one source
  • Choose an operation
  • Fill in the other sources
  • Steal an argument of a later
  • peration as a sink
  • Clean up dead code

26 Fuzzing Instruction Selection • EuroLLVM 2017

define void @f() { BB: %L1 = load i16, i16* undef %L2 = load i16, i16* undef %B1 = lshr i16 %L1, %L2 store i16 %B1, i16* undef ret void }

slide-27
SLIDE 27

Adding one operation

  • Divide a block into potential

sources and sinks

  • Choose or create one source
  • Choose an operation
  • Fill in the other sources
  • Steal an argument of a later
  • peration as a sink
  • Clean up dead code

27 Fuzzing Instruction Selection • EuroLLVM 2017

define void @f() { BB: %L1 = load i16, i16* undef %L2 = load i16, i16* undef %B1 = lshr i16 %L1, %L2 store i16 %B1, i16* undef ret void }

slide-28
SLIDE 28

Adding one operation

  • Divide a block into potential

sources and sinks

  • Choose or create one source
  • Choose an operation
  • Fill in the other sources
  • Steal an argument of a later
  • peration as a sink
  • Clean up dead code

28 Fuzzing Instruction Selection • EuroLLVM 2017

define void @f() { BB: %L1 = load i16, i16* undef %L2 = load i16, i16* undef %B2 = add i16 %L1, ? %B1 = lshr i16 %L1, %L2 store i16 %B1, i16* undef ret void }

slide-29
SLIDE 29

Adding one operation

  • Divide a block into potential

sources and sinks

  • Choose or create one source
  • Choose an operation
  • Fill in the other sources
  • Steal an argument of a later
  • peration as a sink
  • Clean up dead code

29 Fuzzing Instruction Selection • EuroLLVM 2017

define void @f() { BB: %L1 = load i16, i16* undef %L2 = load i16, i16* undef %B2 = add i16 %L1, %L1 %B1 = lshr i16 %L1, %L2 store i16 %B1, i16* undef ret void }

slide-30
SLIDE 30

Adding one operation

  • Divide a block into potential

sources and sinks

  • Choose or create one source
  • Choose an operation
  • Fill in the other sources
  • Steal an argument of a later
  • peration as a sink
  • Clean up dead code

30 Fuzzing Instruction Selection • EuroLLVM 2017

define void @f() { BB: %L1 = load i16, i16* undef %L2 = load i16, i16* undef %B2 = add i16 %L1, %L1 %B1 = lshr i16 %L1, %L2 store i16 %B1, i16* undef ret void }

slide-31
SLIDE 31

Adding one operation

  • Divide a block into potential

sources and sinks

  • Choose or create one source
  • Choose an operation
  • Fill in the other sources
  • Steal an argument of a later
  • peration as a sink
  • Clean up dead code

31 Fuzzing Instruction Selection • EuroLLVM 2017

define void @f() { BB: %L1 = load i16, i16* undef %L2 = load i16, i16* undef %B2 = add i16 %L1, %L1 %B1 = lshr i16 %L1, %B2 store i16 %B1, i16* undef ret void }

slide-32
SLIDE 32

Adding one operation

  • Divide a block into potential

sources and sinks

  • Choose or create one source
  • Choose an operation
  • Fill in the other sources
  • Steal an argument of a later
  • peration as a sink
  • Clean up dead code

32 Fuzzing Instruction Selection • EuroLLVM 2017

define void @f() { BB: %L1 = load i16, i16* undef %B2 = add i16 %L1, %L1 %B1 = lshr i16 %L1, %B2 store i16 %B1, i16* undef ret void }

slide-33
SLIDE 33

Splitting Blocks

33 Fuzzing Instruction Selection • EuroLLVM 2017

BB5: %L6 = load i1, i1* undef %B8 = sdiv i1 %L6, %L7 %A7 = alloca float %A4 = alloca float br i1 %B8, label %BB5, label %BB1 BB1: %L5 = load float, float* %A4 %A1 = alloca float %L3 = load float, float* %A1 %L1 = load i32, i32* undef %B6 = frem float %L3, %L5 %A = alloca i32 %L = load i32, i32* %A %B = xor i32 %L, %L1 %B1 = xor i32 %B, %B store i32 %B1, i32* %A store float %B6, float* %A7 store i1 %B8, i1* undef ret void BB: %L7 = load i1, i1* undef br label %BB5 BB5: %L6 = load i1, i1* undef %B8 = sdiv i1 %L6, %L7 %A7 = alloca float %A4 = alloca float %L5 = load float, float* %A4 %A1 = alloca float %L3 = load float, float* %A1 %L1 = load i32, i32* undef %B6 = frem float %L3, %L5 %A = alloca i32 %L = load i32, i32* %A %B = xor i32 %L, %L1 %B1 = xor i32 %B, %B store i32 %B1, i32* %A store float %B6, float* %A7 store i1 %B8, i1* undef ret void BB: %L7 = load i1, i1* undef br label %BB5

slide-34
SLIDE 34

Removing Code

34 Fuzzing Instruction Selection • EuroLLVM 2017

25 50 75 100 70% 90% Max

Ideal Size Size of Bitcode P r

  • b

a b i l i t y

  • f

r e m

  • v

a l

slide-35
SLIDE 35

Finding Bugs

35 Fuzzing Instruction Selection • EuroLLVM 2017 By Sffubs (Own work) [CC BY-SA 3.0] via Wikimedia Commons

slide-36
SLIDE 36

Correctness Checks

  • Garbage in, garbage out
  • Comparing instruction selectors
  • Semantics-preserving mutations

36 Fuzzing Instruction Selection • EuroLLVM 2017

slide-37
SLIDE 37

Mutation Library

  • Legal types are configurable
  • New operations follow a simple interface
  • Mix and match the operations you want

37 Fuzzing Instruction Selection • EuroLLVM 2017

slide-38
SLIDE 38

Mutation Library

38 Fuzzing Instruction Selection • EuroLLVM 2017

MutationStrategy Inject Modify Add FSub SplitBlock Remove ...

slide-39
SLIDE 39

Results

  • Found various AArch64 GlobalISel bugs
  • SelectionDAG is surprisingly hard to crash
  • Test your own backends today
  • IR mutator library available for other fuzzers

39 Fuzzing Instruction Selection • EuroLLVM 2017

slide-40
SLIDE 40

Questions?

40 Fuzzing Instruction Selection • EuroLLVM 2017

slide-41
SLIDE 41

41 Fuzzing Instruction Selection • EuroLLVM 2017
