Advances in Visual Tracking

Machine Learning Study Group

Presented by Yaochen Xie Dec 7, 2017

Contents

❖ Visual Tracking Overview ❖ Dataset & Evaluation Methodology ❖ Traditional Approach (before 2010)

➢ Mean-Shift, Particle Filter, Optical Flow

❖ The State-of-the-Art (after 2010)

➢ Correlation Filter, Deep Learning

❖ A Summary: Generative models and Discriminative models

What is tracking in Computer Vision?

✴ Understanding geometric correspondences over time ✴ A fundamental problem in computer vision ✴ A challenging and difficult task ✴ Numerous applications

Applications

Motion Analysis Surveillance Autonomous Robots Image Guided Surgery Biomedical Image Analysis Human Computer Interaction

Challenges

Deformation Illumination variation Blur & Fast Motion Background Clutter

Challenges

Out-of-plane rotation In-plane rotation Scale Variation Occlusion Out-of-view

Dataset

OTB (Object Tracking Benchmark)

http://cvlab.hanyang.ac.kr/tracker_benchmark/index.html

The full benchmark contains 100 sequences from recent literatures.

• The sequence names are in CamelCase without

any blanks or underscores.

• When there exist multiple targets each target is

identified as dot+id_number (e.g. Jogging.1 and Jogging.2).

• Each row in the ground-truth files represents the

bounding box of the target in that frame, (x, y, box- width, box-height).

Dataset

OTB (Object Tracking Benchmark)

http://cvlab.hanyang.ac.kr/tracker_benchmark/index.html

Dataset

http://www.votchallenge.net/

VOT 2015

• 60 short sequences
• Chosen from a large pool of

sequences including the ALOV dataset, OTB2 dataset, non- tracking datasets, etc.

• Rotated bounding boxes in order to

provide highly accurate ground truth values for comparing results

VOT Challenge (Visual Object Tracking)

Evaluation

✴ Precision plot : center location error (average Euclidean distance between the center locations) / percentage within a threshold ✴ Success plot :

Evaluation

✴ Temporal Robustness Evaluation (TRE) ✴ Spatial Robustness Evaluation (SRE)

Traditional Approaches - Mean-shift

Intuitive Description:

Traditional Approaches - Mean-shift

Intuitive Description:

Traditional Approaches - Mean-shift

Intuitive Description:

Traditional Approaches - Mean-shift

Intuitive Description:

Traditional Approaches - Mean-shift

Intuitive Description:

Traditional Approaches - Mean-shift

Intuitive Description:

Traditional Approaches - Mean-shift

Intuitive Description:

Traditional Approaches - Mean-shift

Assumption: The data points are sampled from an underlying PDF

Assumed Underlying PDF Real Data Samples

Traditional Approaches - Mean-shift

Histogram and Back Projection

Raw Image Histogram of ROI (or other representations) Back Projection

Traditional Approaches - Mean-shift

Steps of tracking an object

• 1. select your Region of Interest in Frame t 0
• 2. calculate the Histogram of ROI
• 3. generate Back Projection of ROI in Frame t 1
• 4. iterate with Mean-Shift

Or, introducing similarity function to select target candidate…

Traditional Approaches - Mean-shift

Advantages：

• 1. Low computational complexity
• 2. Robust to partial occlusion, deformation, rotation and background

movement

Shortcomings:

• 1. Unable to deal with scale-variation
• 2. Low performance when object moves fast
• 3. Histogram is deficient in describing color features

Traditional Approaches - Particle Filtering

Particle

Traditional Approaches - Particle Filtering

Filter

Traditional Approaches - Particle Filtering

Particle Filtering

Traditional Approaches - Particle Filtering

• Initialization
• Sampling
• Decision
• Resampling

Traditional Approaches - Particle Filtering

Tracking

Traditional Approaches - Particle Filtering

Tracking

Traditional Approaches - Particle Filtering

Tracking

Traditional Approaches - Particle Filtering

Tracking

Traditional Approaches - Particle Filtering

Strengths：

• 1. Markov model reduces complexity of calculations
• 2. Good description of methods
• 3. Able to deal with scale-variation

Weakness:

• 1. Low performance with occlusion
• 2. Histogram is deficient in describing color features

Traditional Approaches - Optical Flow

Optical Flow: The pattern of apparent motion of objects, surfaces, and edges in a visual scene caused by the relative motion between an observer and a scene.

Traditional Approaches - Optical Flow

Assumptions:

• Constant luminance among frames
• Minor movement
• Each frame is sampled consecutively on temporal domain
• Spatial consistency

The State-of-the-Art

• MOSSE (Minimum Output Sum of Squared Error)
• CSK (Circulant Structure of Tracking-by-detection)
• CN (Adaptive Color Attributes)
• GOTURN (Generic Object Tracking Using Regression Networks)
• MDNet (Multi-Domain Convolutional Neural Networks)
• TCNN (Modeling and Propagating CNNs in a Tree Structure)

Correlation Filter based Deep ConvNet based

Correlation Filter based

GOTURN

Strengths

• Offline Training
• Generic Object Tracking
• Avoid Online Fine-turning
• Regression-based Approach

Generic Object Tracking Using Regression Networks

GOTURN

Generic Object Tracking Using Regression Networks

TCNN

• The width of a black arrow

indicates the weight of a CNN for target state estimation while the width of a red edge denotes the affinity between two CNNs.

• The width of box outline means the

reliability of the CNN associated with the box. Modeling and Propagating CNNs in a Tree Structure for Visual Tracking

TCNN

• CNN Architecture

Modeling and Propagating CNNs in a Tree Structure for Visual Tracking

TCNN

• Tree Construction
• Tree structure: , where a vertex corresponds to a

CNN, and a directed edge defines the relationship between CNNs.

• The score of an edge is the affinity between two end vertices, which

is given by Modeling and Propagating CNNs in a Tree Structure for Visual Tracking

TCNN

• Target state estimation
• Candidates generate: sample from normalize distribution in (x, y, s) space,

centered at target location in last frame

• Target score:
• Select target:

Modeling and Propagating CNNs in a Tree Structure for Visual Tracking

To define :

TCNN

• Bounding Box regression

Modeling and Propagating CNNs in a Tree Structure for Visual Tracking

TCNN

• Update Model
• Create node for new CNN associated with parent node:

per 10 consecutive frames

• The CNN in vertex z is fine-tuned from the CNN in using the training

samples collected from two sets of frames, and . Modeling and Propagating CNNs in a Tree Structure for Visual Tracking

TCNN

Modeling and Propagating CNNs in a Tree Structure for Visual Tracking

Generative models and Discriminative models

✴ Generative models ✴ Discriminative models - Tracking-by-detection
