ADVANCED MEMORY SYSTEMS Mahdi Nazm Bojnordi Assistant Professor School of Computing University of Utah CS/ECE 6810: Computer Architecture Programmable Controller Limitations to Existing Memory Controllers Modern memory controllers are
SLIDE 2
SLIDE 3
Limitations to Existing Memory Controllers
¨ Modern memory controllers are performance-critical and complex
Core 1 Core 2 Core 3 Core 4 Bank 1 Bank 2 Bank 3 Bank 4 Shared Cache
Memory Controller
Address Mapping Command Scheduling Power Management QoS Maintenance Refresh Management
On-chip Off-chip
Multiple performance
- bjectives
Application-specific
- ptimizations
Patches and in-field updates
SLIDE 4
Programmable Memory Controllers
¨ Programmability can make a memory controller higher-performance
and more flexible
Core 1 Core 2 Core 3 Core 4 Bank 1 Bank 2 Bank 3 Bank 4 Shared Cache
On-chip Off-chip
Programmable Framework
Multiple performance
- bjectives
Application-specific
- ptimizations
Patches and in-field updates
- Memory
Controller
SLIDE 5
Design Overview
¨ Key idea: Judicious division of labor between
specialized hardware and firmware
¤ Request and transaction processing in firmware ¤ Configurable timing validation in hardware
Request Processor Transaction Processor Command Logic
PARDIS
SLIDE 6
Request Processing
¨ A RISC ISA for operating on memory requests
ALU
Memory Request Address Mapping Control Flow Application Hints
Address Metadata
Processor Memory
SLIDE 7
Request Processing
¨ Queue management with instruction flags ¤ R flag enqueues a request ¤ T flag dequeues a transaction
Request Processor
Firmware Request Queue Transaction Queue
¨ An instruction can be
annotated with both R and T flags if needed
ADD XOR SUB T AND R
SLIDE 8
Implementation
¨ Two five-stage pipelines and one configurable timing validation
circuit
SLIDE 9
Emerging Technologies
SLIDE 10
DRAM Cell Structure
¨ One-transistor, one-capacitor
¤ Realizing the capacitor is challenging
- 1T-1C DRAM
- Charge based sensing
- Volatile
SLIDE 11
DRAM Cell Structure
¨ One-transistor, one-capacitor
¤ Realizing the capacitor is challenging
- 1T-1C DRAM
- Charge based sensing
- Volatile
SLIDE 12
Memory Scaling in Jeopardy
Scaling of semiconductor memories greatly challenged beyond 20nm
Example: DRAM
SLIDE 13
Memory Scaling in Jeopardy
Scaling of semiconductor memories greatly challenged beyond 20nm
Example: DRAM
A/R < 10
SLIDE 14
Why DRAM Slow?
¨ Logic VLSI Process: optimized for better transistor
performance
¨ DRAM VLSI Process: optimized for low cost and low
leakage
PCB Logic DRAM How to reduce distance?
SLIDE 15
Processing-in-Memory
¨ Increasing bandwidth by placing processing units on
same die with DRAM
¨ Not a new concept!
¤ Merged Logic and DRAM (MLD)
n IBM, Mitsubishi, Samsung, Toshiba, etc.
¤ Other efforts
n FlexRAM n IRAM n Active Pages n …
SLIDE 16
Historical PIM Challenges
¨ Hard to program (no standard interface) ¨ Embedding logic on modified DRAM process
¤ Substantially larger transistors
n Reduce memory capacity
¤ Slower logic and lower performance
¨ Embedding DRAM on modified logic process
¤ Leaky transistors, high refresh rates, increased cost/bit ¤ Increased manufacturing complexity
SLIDE 17
3D Die-Stacking
¨ Different devices are stacked on top of each other ¨ Layers are connected by through-silicon vias (TSVs) ¨ Why? ¤ Communication between devices bottlenecked by limited
I/O pins
¤ Integrating heterogeneous elements on a single wafer is
expensive and suboptimal
PCB Logic DRAM Logic DRAM DRAM
SLIDE 18
3D Stacked Memory
¨ Hybrid Memory Cube (HMC)
¤ A logic layer at the bottom
¨ High Bandwidth Memory (HBM)
¤ Silicon interposer at the bottom
Package Substrate Silicon Interposer DRAM Dice{ … Processor Die Interface Controller Bank In-Package Cache Controller
