SLIDE 1
Lect ure # 07
OLTP Indexes (Trie Data Structures)
@ Andy_Pavlo // 15- 721 // Spring 2020
15-721 (Spring 2020)
Latches B+Trees Judy Array ART Masstree
2
ADVANCED DATABASE SYSTEMS OLTP Indexes (Trie Data Structures) @ - - PowerPoint PPT Presentation
ADVANCED DATABASE SYSTEMS OLTP Indexes (Trie Data Structures) @ - - PowerPoint PPT Presentation
Lect ure # 07 ADVANCED DATABASE SYSTEMS OLTP Indexes (Trie Data Structures) @ Andy_Pavlo // 15- 721 // Spring 2020 2 Latches B+Trees Judy Array ART Masstree 15-721 (Spring 2020) 3 LATCH IM PLEM ENTATIO N GOALS Small memory
SLIDE 2
SLIDE 3
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO N GOALS
Small memory footprint. Fast execution path when no contention. Deschedule thread when it has been waiting for too long to avoid burning cycles. Each latch should not have to implement their
- wn queue to track waiting threads.
3
Source: Filip Pizlo
SLIDE 4
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO N GOALS
Small memory footprint. Fast execution path when no contention. Deschedule thread when it has been waiting for too long to avoid burning cycles. Each latch should not have to implement their
- wn queue to track waiting threads.
3
Source: Filip Pizlo
SLIDE 5
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Test-and-Set Spinlock Blocking OS Mutex Adaptive Spinlock Queue-based Spinlock Reader-Writer Locks
4
SLIDE 6
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #1: Test-and-Set Spinlock (TaS)
→ Very efficient (single instruction to lock/unlock) → Non-scalable, not cache friendly, not OS friendly. → Example: std::atomic<T>
5
std::atomic_flag latch; ⋮ while (latch.test_and_set(…)) { // Yield? Abort? Retry? }
SLIDE 7
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #1: Test-and-Set Spinlock (TaS)
→ Very efficient (single instruction to lock/unlock) → Non-scalable, not cache friendly, not OS friendly. → Example: std::atomic<T>
5
std::atomic_flag latch; ⋮ while (latch.test_and_set(…)) { // Yield? Abort? Retry? }
SLIDE 8
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #2: Blocking OS Mutex
→ Simple to use → Non-scalable (about 25ns per lock/unlock invocation) → Example: std::mutex
6
std::mutex m; ⋮ m.lock(); // Do something special... m.unlock();
SLIDE 9
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #2: Blocking OS Mutex
→ Simple to use → Non-scalable (about 25ns per lock/unlock invocation) → Example: std::mutex
6
std::mutex m; ⋮ m.lock(); // Do something special... m.unlock(); pthread_mutex_t futex
SLIDE 10
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #2: Blocking OS Mutex
→ Simple to use → Non-scalable (about 25ns per lock/unlock invocation) → Example: std::mutex
6
std::mutex m; ⋮ m.lock(); // Do something special... m.unlock(); pthread_mutex_t futex
Userspace Latch OS Latch
SLIDE 11
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #2: Blocking OS Mutex
→ Simple to use → Non-scalable (about 25ns per lock/unlock invocation) → Example: std::mutex
6
std::mutex m; ⋮ m.lock(); // Do something special... m.unlock(); pthread_mutex_t futex
Userspace Latch OS Latch
SLIDE 12
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #3: Adaptive Spinlock
→ Thread spins on a userspace lock for a brief time. → If they cannot acquire the lock, they then get descheduled and stored in a global "parking lot". → Threads check to see whether other threads are "parked" before spinning and then park themselves. → Example: Apple's WTF::ParkingLot
7
SLIDE 13
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #4: Queue-based Spinlock (MCS)
→ More efficient than mutex, better cache locality → Non-trivial memory management → Example: std::atomic<Latch*>
8
next Base Latch CPU1
SLIDE 14
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #4: Queue-based Spinlock (MCS)
→ More efficient than mutex, better cache locality → Non-trivial memory management → Example: std::atomic<Latch*>
8
next Base Latch next CPU1 Latch CPU1
SLIDE 15
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #4: Queue-based Spinlock (MCS)
→ More efficient than mutex, better cache locality → Non-trivial memory management → Example: std::atomic<Latch*>
8
next Base Latch next CPU1 Latch CPU1
SLIDE 16
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #4: Queue-based Spinlock (MCS)
→ More efficient than mutex, better cache locality → Non-trivial memory management → Example: std::atomic<Latch*>
8
next Base Latch next CPU1 Latch CPU1
SLIDE 17
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #4: Queue-based Spinlock (MCS)
→ More efficient than mutex, better cache locality → Non-trivial memory management → Example: std::atomic<Latch*>
8
next Base Latch next CPU1 Latch next CPU2 Latch CPU1 CPU2
SLIDE 18
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #4: Queue-based Spinlock (MCS)
→ More efficient than mutex, better cache locality → Non-trivial memory management → Example: std::atomic<Latch*>
8
next Base Latch next CPU1 Latch next CPU2 Latch CPU1 CPU2
SLIDE 19
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #4: Queue-based Spinlock (MCS)
→ More efficient than mutex, better cache locality → Non-trivial memory management → Example: std::atomic<Latch*>
8
next Base Latch next CPU1 Latch next CPU2 Latch CPU1 CPU2
SLIDE 20
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #4: Queue-based Spinlock (MCS)
→ More efficient than mutex, better cache locality → Non-trivial memory management → Example: std::atomic<Latch*>
8
next Base Latch next CPU1 Latch next CPU2 Latch CPU1 CPU2 CPU3 next CPU3 Latch
SLIDE 21
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #4: Queue-based Spinlock (MCS)
→ More efficient than mutex, better cache locality → Non-trivial memory management → Example: std::atomic<Latch*>
8
next Base Latch next CPU1 Latch next CPU2 Latch CPU1 CPU2 CPU3 next CPU3 Latch
SLIDE 22
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #4: Queue-based Spinlock (MCS)
→ More efficient than mutex, better cache locality → Non-trivial memory management → Example: std::atomic<Latch*>
8
next Base Latch next CPU1 Latch next CPU2 Latch CPU1 CPU2 CPU3 next CPU3 Latch
SLIDE 23
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #5: Reader-Writer Locks
→ Allows for concurrent readers. → Must manage read/write queues to avoid starvation. → Can be implemented on top of spinlocks.
9
SLIDE 24
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #5: Reader-Writer Locks
→ Allows for concurrent readers. → Must manage read/write queues to avoid starvation. → Can be implemented on top of spinlocks.
9
read write Latch
=0 =0 =0 =0
SLIDE 25
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #5: Reader-Writer Locks
→ Allows for concurrent readers. → Must manage read/write queues to avoid starvation. → Can be implemented on top of spinlocks.
9
read write Latch
=0 =0 =0 =0 =1
SLIDE 26
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #5: Reader-Writer Locks
→ Allows for concurrent readers. → Must manage read/write queues to avoid starvation. → Can be implemented on top of spinlocks.
9
read write Latch
=0 =0 =0 =0 =1
SLIDE 27
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #5: Reader-Writer Locks
→ Allows for concurrent readers. → Must manage read/write queues to avoid starvation. → Can be implemented on top of spinlocks.
9
read write Latch
=0 =0 =0 =0 =1 =2
SLIDE 28
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #5: Reader-Writer Locks
→ Allows for concurrent readers. → Must manage read/write queues to avoid starvation. → Can be implemented on top of spinlocks.
9
read write Latch
=0 =0 =0 =0 =1 =2
SLIDE 29
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #5: Reader-Writer Locks
→ Allows for concurrent readers. → Must manage read/write queues to avoid starvation. → Can be implemented on top of spinlocks.
9
read write Latch
=0 =0 =0 =0 =1 =2 =1
SLIDE 30
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #5: Reader-Writer Locks
→ Allows for concurrent readers. → Must manage read/write queues to avoid starvation. → Can be implemented on top of spinlocks.
9
read write Latch
=0 =0 =0 =0 =1 =2 =1
SLIDE 31
15-721 (Spring 2020)
LATCH IM PLEM ENTATIO NS
Choice #5: Reader-Writer Locks
→ Allows for concurrent readers. → Must manage read/write queues to avoid starvation. → Can be implemented on top of spinlocks.
9
read write Latch
=0 =0 =0 =0 =1 =2 =1 =1
SLIDE 32
15-721 (Spring 2020)
B+ TREE
A B+Tree is a self-balancing tree data structure that keeps data sorted and allows searches, sequential access, insertions, and deletions in O(log n).
→ Generalization of a binary search tree in that a node can have more than two children. → Optimized for systems that read and write large blocks of data.
10
SLIDE 33
15-721 (Spring 2020)
LATCH CRABBIN G / COUPLING
Acquire and release latches on B+Tree nodes when traversing the data structure. A thread can release latch on a parent node if its child node considered safe.
→ Any node that won’t split or merge when updated. → Not full (on insertion) → More than half-full (on deletion)
11
SLIDE 34
15-721 (Spring 2020)
LATCH CRABBIN G
Search: Start at root and go down; repeatedly,
→ Acquire read (R) latch on child → Then unlock the parent node.
Insert/Delete: Start at root and go down,
- btaining write (W) latches as needed.
Once child is locked, check if it is safe:
→ If child is safe, release all locks on ancestors.
12
SLIDE 35
15-721 (Spring 2020)
EXAM PLE # 1: SEARCH 23
13
A B D G
20 10 35 6 12 23 38 44
C E F
SLIDE 36
15-721 (Spring 2020)
EXAM PLE # 1: SEARCH 23
13
A B D G
20 10 35 6 12 23 38 44
C E F R
SLIDE 37
15-721 (Spring 2020)
EXAM PLE # 1: SEARCH 23
13
A B D G
20 10 35 6 12 23 38 44
C E F R
We can release the latch on A as soon as we acquire the latch for C.
SLIDE 38
15-721 (Spring 2020)
EXAM PLE # 1: SEARCH 23
13
A B D G
20 10 35 6 12 23 38 44
C E F R R
We can release the latch on A as soon as we acquire the latch for C.
SLIDE 39
15-721 (Spring 2020)
EXAM PLE # 1: SEARCH 23
13
A B D G
20 10 35 6 12 23 38 44
C E F R
We can release the latch on A as soon as we acquire the latch for C.
SLIDE 40
15-721 (Spring 2020)
EXAM PLE # 2: DELETE 4 4
14
A B D G
20 10 35 6 12 23 38 44
C E F W
SLIDE 41
15-721 (Spring 2020)
EXAM PLE # 2: DELETE 4 4
14
A B D G
20 10 35 6 12 23 38 44
C E F W W
We may need to coalesce C, so we can’t release the latch on A.
SLIDE 42
15-721 (Spring 2020)
EXAM PLE # 2: DELETE 4 4
14
A B D G
20 10 35 6 12 23 38 44
C E F W W W
We may need to coalesce C, so we can’t release the latch on A. G will not merge with F, so we can release latches on A and C.
SLIDE 43
15-721 (Spring 2020)
EXAM PLE # 2: DELETE 4 4
14
A B D G
20 10 35 6 12 23 38 44
C E F W
We may need to coalesce C, so we can’t release the latch on A. G will not merge with F, so we can release latches on A and C.
SLIDE 44
15-721 (Spring 2020)
EXAM PLE # 3: INSERT 4 0
15
A B D G
20 10 35 6 12 23 38 44
C E F W
SLIDE 45
15-721 (Spring 2020)
EXAM PLE # 3: INSERT 4 0
15
A B D G
20 10 35 6 12 23 38 44
C E F W W
C has room if its child has to split, so we can release the latch on A.
SLIDE 46
15-721 (Spring 2020)
EXAM PLE # 3: INSERT 4 0
15
A B D G
20 10 35 6 12 23 38 44
C E F W
C has room if its child has to split, so we can release the latch on A.
SLIDE 47
15-721 (Spring 2020)
EXAM PLE # 3: INSERT 4 0
15
A B D G
20 10 35 6 12 23 38 44
C E F W W
C has room if its child has to split, so we can release the latch on A. G must split, so we can’t release the latch on C.
SLIDE 48
15-721 (Spring 2020)
EXAM PLE # 3: INSERT 4 0
15
A B D G
20 10 35 6 12 23 38 44
C E F W W
C has room if its child has to split, so we can release the latch on A. G must split, so we can’t release the latch on C.
H
44 40 44
SLIDE 49
15-721 (Spring 2020)
EXAM PLE # 3: INSERT 4 0
15
A B D G
20 10 35 6 12 23 38 44
C E F
C has room if its child has to split, so we can release the latch on A. G must split, so we can’t release the latch on C.
H
44 40 44
SLIDE 50
15-721 (Spring 2020)
BETTER LATCH CRABBIN G
The basic latch crabbing algorithm always takes a write latch on the root for any update.
→ This makes the index essentially single threaded.
A better approach is to optimistically assume that the target leaf node is safe.
→ Take R latches as you traverse the tree to reach it and verify. → If leaf is not safe, then do previous algorithm.
17
CONCURRENCY OF OPERATIONS ON B- TREES
ACTA INFORMATICA 1977
SLIDE 51
15-721 (Spring 2020)
EXAM PLE # 4 : DELETE 4 4
18
A B D G
20 10 35 6 12 23 38 44
C E F R
SLIDE 52
15-721 (Spring 2020)
EXAM PLE # 4 : DELETE 4 4
18
A B D G
20 10 35 6 12 23 38 44
C E F R
We assume that C is safe, so we can release the latch on A.
SLIDE 53
15-721 (Spring 2020)
EXAM PLE # 4 : DELETE 4 4
18
A B D G
20 10 35 6 12 23 38 44
C E F W
We assume that C is safe, so we can release the latch on A. Acquire an exclusive latch on G.
SLIDE 54
15-721 (Spring 2020)
EXAM PLE # 4 : DELETE 4 4
18
A B D G
20 10 35 6 12 23 38 44
C E F W
We assume that C is safe, so we can release the latch on A. Acquire an exclusive latch on G.
SLIDE 55
15-721 (Spring 2020)
VERSION ED LATCH COUPLING
Optimistic crabbing scheme where writers are not blocked on readers. Every node now has a version number (counter).
→ Writers increment counter when they acquire latch. → Readers proceed if a node’s latch is available but then do not acquire it. → It then checks whether the latch’s counter has changed from when it checked the latch.
Relies on epoch GC to ensure pointers are valid.
19
THE ART OF PRACTICAL SYNCHRONIZATION
DAMON 2016
SLIDE 56
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
v3 v5 v6 v9 v4 v4 v5
SLIDE 57
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
A: Read v3
v3 v5 v6 v9 v4 v4 v5
@A
SLIDE 58
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
A: Read v3 A: Examine Node
v3 v5 v6 v9 v4 v4 v5
@A @B
SLIDE 59
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
A: Read v3 A: Examine Node
v3 v5 v6 v9 v4 v4 v5
B: Read v5
@A @B
SLIDE 60
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
A: Read v3 A: Examine Node
v3 v5 v6 v9 v4 v4 v5
B: Read v5 A: Recheck v3
@A @B
SLIDE 61
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
A: Read v3 A: Examine Node
v3 v5 v6 v9 v4 v4 v5
B: Read v5 A: Recheck v3 B: Examine Node
@A @B
SLIDE 62
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
A: Read v3 A: Examine Node
v3 v5 v6 v9 v4 v4 v5
B: Read v5 A: Recheck v3 B: Examine Node C: Read v9
@A @B @C
SLIDE 63
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
A: Read v3 A: Examine Node
v3 v5 v6 v9 v4 v4 v5
B: Read v5 A: Recheck v3 B: Examine Node C: Read v9 B: Recheck v5 C: Examine Node
@A @B @C
SLIDE 64
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
A: Read v3 A: Examine Node
v3 v5 v6 v9 v4 v4 v5
B: Read v5 A: Recheck v3 B: Examine Node C: Read v9 B: Recheck v5 C: Examine Node
@A @B @C
SLIDE 65
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
A: Read v3 A: Examine Node
v3 v5 v6 v9 v4 v4 v5
B: Read v5 A: Recheck v3 B: Examine Node
@A @B @C
SLIDE 66
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
A: Read v3 A: Examine Node
v3 v5 v6 v9 v4 v4 v5
B: Read v5 A: Recheck v3 B: Examine Node C: Read v9
@A @B @C
SLIDE 67
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
A: Read v3 A: Examine Node
v3 v5 v6 v9 v4 v4 v5
B: Read v5 A: Recheck v3 B: Examine Node C: Read v9
v6
@A @B @C
SLIDE 68
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
A: Read v3 A: Examine Node
v3 v5 v6 v9 v4 v4 v5
B: Read v5 A: Recheck v3 B: Examine Node C: Read v9 B: Recheck v5
v6
@A @B @C
SLIDE 69
15-721 (Spring 2020)
VERSION ED LATCHES: SEARCH 4 4
20
A B D G
20 10 35 6 12 23 38 44
C E F
A: Read v3 A: Examine Node
v3 v5 v6 v9 v4 v4 v5
B: Read v5 A: Recheck v3 B: Examine Node C: Read v9 B: Recheck v5
v6
@A @B @C
SLIDE 70
15-721 (Spring 2020)
OBSERVATION
The inner node keys in a B+tree cannot tell you whether a key exists in the index. You always must traverse to the leaf node. This means that you could have (at least) one cache miss per level in the tree.
21
SLIDE 71
15-721 (Spring 2020)
TRIE INDEX
Use a digital representation of keys to examine prefixes one-by-one instead of comparing entire key.
→ Also known as Digital Search Tree, Prefix Tree.
22
Keys: HELLO, HAT, HAVE
L L O ¤ ¤ E ¤ H A E V T
SLIDE 72
15-721 (Spring 2020)
TRIE INDEX
Use a digital representation of keys to examine prefixes one-by-one instead of comparing entire key.
→ Also known as Digital Search Tree, Prefix Tree.
22
Keys: HELLO, HAT, HAVE
L L O ¤ ¤ E ¤ H A E V T
SLIDE 73
15-721 (Spring 2020)
TRIE INDEX PROPERTIES
Shape only depends on key space and lengths.
→ Does not depend on existing keys or insertion order. → Does not require rebalancing operations.
All operations have O(k) complexity where k is the length of the key.
→ The path to a leaf node represents the key of the leaf → Keys are stored implicitly and can be reconstructed from paths.
23
SLIDE 74
15-721 (Spring 2020)
TRIE KEY SPAN
The span of a trie level is the number of bits that each partial key / digit represents.
→ If the digit exists in the corpus, then store a pointer to the next level in the trie branch. Otherwise, store null.
This determines the fan-out of each node and the physical height of the tree.
→ n-way Trie = Fan-Out of n
24
SLIDE 75
15-721 (Spring 2020)
TRIE KEY SPAN
Keys: K10,K25,K31
25
K10→ 00000000 00001010 K25→ 00000000 00011001 K31→ 00000000 00011111
1-bit Span Trie
¤ 1 Ø ¤ 1 Ø ¤ 1 ¤ ¤ 1 Ø Ø 1 ¤ ¤ 1 Ø ¤ 1 Ø Ø 1 ¤ Ø 1 ¤ Ø 1 ¤ ¤ 1 ¤ Ø 1 ¤ Ø 1 ¤
←Repeat 10x Tuple Pointer Node Pointer
SLIDE 76
15-721 (Spring 2020)
TRIE KEY SPAN
Keys: K10,K25,K31
25
K10→ 00000000 00001010 K25→ 00000000 00011001 K31→ 00000000 00011111
1-bit Span Trie
¤ 1 Ø ¤ 1 Ø ¤ 1 ¤ ¤ 1 Ø Ø 1 ¤ ¤ 1 Ø ¤ 1 Ø Ø 1 ¤ Ø 1 ¤ Ø 1 ¤ ¤ 1 ¤ Ø 1 ¤ Ø 1 ¤
←Repeat 10x Tuple Pointer Node Pointer
SLIDE 77
15-721 (Spring 2020)
TRIE KEY SPAN
Keys: K10,K25,K31
25
K10→ 00000000 00001010 K25→ 00000000 00011001 K31→ 00000000 00011111
1-bit Span Trie
¤ 1 Ø ¤ 1 Ø ¤ 1 ¤ ¤ 1 Ø Ø 1 ¤ ¤ 1 Ø ¤ 1 Ø Ø 1 ¤ Ø 1 ¤ Ø 1 ¤ ¤ 1 ¤ Ø 1 ¤ Ø 1 ¤
←Repeat 10x Tuple Pointer Node Pointer
SLIDE 78
15-721 (Spring 2020)
TRIE KEY SPAN
Keys: K10,K25,K31
25
K10→ 00000000 00001010 K25→ 00000000 00011001 K31→ 00000000 00011111
1-bit Span Trie
¤ 1 Ø ¤ 1 Ø ¤ 1 ¤ ¤ 1 Ø Ø 1 ¤ ¤ 1 Ø ¤ 1 Ø Ø 1 ¤ Ø 1 ¤ Ø 1 ¤ ¤ 1 ¤ Ø 1 ¤ Ø 1 ¤
←Repeat 10x Tuple Pointer Node Pointer
SLIDE 79
15-721 (Spring 2020)
TRIE KEY SPAN
Keys: K10,K25,K31
25
K10→ 00000000 00001010 K25→ 00000000 00011001 K31→ 00000000 00011111
1-bit Span Trie
¤ 1 Ø ¤ 1 Ø ¤ 1 ¤ ¤ 1 Ø Ø 1 ¤ ¤ 1 Ø ¤ 1 Ø Ø 1 ¤ Ø 1 ¤ Ø 1 ¤ ¤ 1 ¤ Ø 1 ¤ Ø 1 ¤
←Repeat 10x Tuple Pointer Node Pointer
SLIDE 80
15-721 (Spring 2020)
TRIE KEY SPAN
Keys: K10,K25,K31
25
K10→ 00000000 00001010 K25→ 00000000 00011001 K31→ 00000000 00011111
1-bit Span Trie
¤ 1 Ø ¤ 1 Ø ¤ 1 ¤ ¤ 1 Ø Ø 1 ¤ ¤ 1 Ø ¤ 1 Ø Ø 1 ¤ Ø 1 ¤ Ø 1 ¤ ¤ 1 ¤ Ø 1 ¤ Ø 1 ¤
←Repeat 10x Tuple Pointer Node Pointer
SLIDE 81
15-721 (Spring 2020)
TRIE KEY SPAN
Keys: K10,K25,K31
25
K10→ 00000000 00001010 K25→ 00000000 00011001 K31→ 00000000 00011111
1-bit Span Trie
¤ 1 Ø ¤ 1 Ø ¤ 1 ¤ ¤ 1 Ø Ø 1 ¤ ¤ 1 Ø ¤ 1 Ø Ø 1 ¤ Ø 1 ¤ Ø 1 ¤ ¤ 1 ¤ Ø 1 ¤ Ø 1 ¤
←Repeat 10x Tuple Pointer Node Pointer
SLIDE 82
15-721 (Spring 2020)
TRIE KEY SPAN
Keys: K10,K25,K31
25
K10→ 00000000 00001010 K25→ 00000000 00011001 K31→ 00000000 00011111
1-bit Span Trie
←Repeat 10x
¤ Ø ¤ Ø ¤ ¤ ¤ Ø Ø ¤ ¤ Ø ¤ Ø Ø ¤ Ø ¤ Ø ¤ ¤ ¤ Ø ¤ Ø ¤
Tuple Pointer Node Pointer
SLIDE 83
15-721 (Spring 2020)
TRIE KEY SPAN
Keys: K10,K25,K31
25
K10→ 00000000 00001010 K25→ 00000000 00011001 K31→ 00000000 00011111
1-bit Span Trie
←Repeat 10x
¤ Ø ¤ Ø ¤ ¤ ¤ Ø Ø ¤ ¤ Ø ¤ Ø Ø ¤ Ø ¤ Ø ¤ ¤ ¤ Ø ¤ Ø ¤
Tuple Pointer Node Pointer
SLIDE 84
15-721 (Spring 2020)
RADIX TREE
Omit all nodes with only a single child.
→ Also known as Patricia Tree.
Can produce false positives, so the DBMS always checks the original tuple to see whether a key matches.
26
1-bit Span Radix Tree
¤ Ø ¤ Ø ¤ ¤ Ø ¤ ¤ ¤
Repeat 10x
Tuple Pointer Node Pointer
SLIDE 85
15-721 (Spring 2020)
TRIE VARIANTS
Judy Arrays (HP) ART Index (HyPer) Masstree (Silo)
27
SLIDE 86
15-721 (Spring 2020)
J UDY ARRAYS
Variant of a 256-way radix tree. First known radix tree that supports adaptive node representation. Three array types
→ Judy1: Bit array that maps integer keys to true/false. → JudyL: Map integer keys to integer values. → JudySL: Map variable-length keys to integer values.
Open-Source Implementation (LGPL). Patented by HP in 2000. Expires in 2022.
→ Not an issue according to authors. → http://judy.sourceforge.net/
28
SLIDE 87
15-721 (Spring 2020)
J UDY ARRAYS
Do not store meta-data about node in its header.
→ This could lead to additional cache misses.
Pack meta-data about a node in 128-bit "Judy Pointers" stored in its parent node.
→ Node Type → Population Count → Child Key Prefix / Value (if only one child below) → 64-bit Child Pointer
29
A COMPARISON OF ADAPTIVE RADIX TREES AND HASH TABLES
ICDE 2015
SLIDE 88
15-721 (Spring 2020)
J UDY ARRAYS: NODE TYPES
Every node can store up to 256 digits. Not all nodes will be 100% full though. Adapt node's organization based on its keys.
→ Linear Node: Sparse Populations → Bitmap Node: Typical Populations → Uncompressed Node: Dense Population
30
A COMPARISON OF ADAPTIVE RADIX TREES AND HASH TABLES
ICDE 2015
SLIDE 89
15-721 (Spring 2020)
J UDY ARRAYS: LINEAR NODES
Store sorted list of partial prefixes up to two cache lines.
→ Original spec was one cache line
Store separate array of pointers to children ordered according to prefix sorted.
31
Linear Node
K0 K2 K8
¤ ¤ ¤
1 5 ... ... 1 5
SLIDE 90
15-721 (Spring 2020)
J UDY ARRAYS: LINEAR NODES
Store sorted list of partial prefixes up to two cache lines.
→ Original spec was one cache line
Store separate array of pointers to children ordered according to prefix sorted.
31
Linear Node
K0 K2 K8
¤ ¤ ¤
1 5 ... ... 1 5
Sorted Digits
SLIDE 91
15-721 (Spring 2020)
J UDY ARRAYS: LINEAR NODES
Store sorted list of partial prefixes up to two cache lines.
→ Original spec was one cache line
Store separate array of pointers to children ordered according to prefix sorted.
31
Linear Node
K0 K2 K8
¤ ¤ ¤
1 5 ... ... 1 5
Sorted Digits Child Pointers
SLIDE 92
15-721 (Spring 2020)
J UDY ARRAYS: LINEAR NODES
Store sorted list of partial prefixes up to two cache lines.
→ Original spec was one cache line
Store separate array of pointers to children ordered according to prefix sorted.
31
Linear Node
K0 K2 K8
¤ ¤ ¤
1 5 ... ... 1 5
Sorted Digits Child Pointers
6 × 1-byte = 6 bytes 6 × 16-bytes = 96 bytes 102 bytes 128 bytes (padded)
SLIDE 93
15-721 (Spring 2020)
J UDY ARRAYS: BITM AP NODES
256-bit map to mark whether a prefix is present in node. Bitmap is divided into eight segments, each with a pointer to a sub-array with pointers to child nodes.
32
Bitmap Node
01000110 ¤
0-7 8-15 248-255
00000000 ¤
... 00100100 ¤ ...
¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤
SLIDE 94
15-721 (Spring 2020)
J UDY ARRAYS: BITM AP NODES
256-bit map to mark whether a prefix is present in node. Bitmap is divided into eight segments, each with a pointer to a sub-array with pointers to child nodes.
32
Bitmap Node
01000110 ¤
0-7 8-15 248-255
00000000 ¤
... 00100100 ¤ ...
¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤
Prefix Bitmaps
0→00000000 1→00000001 2→00000010 3→00000011 4→00000100 5→00000101 6→00000110 7→00000111 Offset Digit
SLIDE 95
15-721 (Spring 2020)
J UDY ARRAYS: BITM AP NODES
256-bit map to mark whether a prefix is present in node. Bitmap is divided into eight segments, each with a pointer to a sub-array with pointers to child nodes.
32
Bitmap Node
01000110 ¤
0-7 8-15 248-255
00000000 ¤
... 00100100 ¤ ...
¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤
Prefix Bitmaps Sub-Array Pointers
SLIDE 96
15-721 (Spring 2020)
J UDY ARRAYS: BITM AP NODES
256-bit map to mark whether a prefix is present in node. Bitmap is divided into eight segments, each with a pointer to a sub-array with pointers to child nodes.
32
Bitmap Node
01000110 ¤
0-7 8-15 248-255
00000000 ¤
... 00100100 ¤ ...
¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤
Child Pointers Prefix Bitmaps Sub-Array Pointers
SLIDE 97
15-721 (Spring 2020)
ADAPATIVE RADIX TREE (ART)
Developed for TUM HyPer DBMS in 2013. 256-way radix tree that supports different node types based on its population.
→ Stores meta-data about each node in its header.
Concurrency support was added in 2015.
33
THE ADAPTIVE RADIX TREE: ARTFUL INDEXING FOR MAIN- MEMORY DATABASES
ICDE 2013
SLIDE 98
15-721 (Spring 2020)
ART vs. J UDY
Difference #1: Node Types
→ Judy has three node types with different organizations. → ART has four nodes types that (mostly) vary in the maximum number of children.
Difference #2: Purpose
→ Judy is a general-purpose associative array. It "owns" the keys and values. → ART is a table index and does not need to cover the full
- keys. Values are pointers to tuples.
34
SLIDE 99
15-721 (Spring 2020)
ART: INNER NODE TYPES (1)
Store only the 8-bit digits that exist at a given node in a sorted array. The offset in sorted digit array corresponds to offset in value array.
35
Node16
K0 K2 K8
¤ ¤ ¤
1 15 ... ... 1 15
Node4
K0 K2 K3 K8
¤ ¤ ¤ ¤
1 2 3 1 2 3
SLIDE 100
15-721 (Spring 2020)
ART: INNER NODE TYPES (1)
Store only the 8-bit digits that exist at a given node in a sorted array. The offset in sorted digit array corresponds to offset in value array.
35
Node16
K0 K2 K8
¤ ¤ ¤
1 15 ... ... 1 15
Node4
K0 K2 K3 K8
¤ ¤ ¤ ¤
Sorted Digits
1 2 3 1 2 3
SLIDE 101
15-721 (Spring 2020)
ART: INNER NODE TYPES (1)
Store only the 8-bit digits that exist at a given node in a sorted array. The offset in sorted digit array corresponds to offset in value array.
35
Node16
K0 K2 K8
¤ ¤ ¤
1 15 ... ... 1 15
Node4
K0 K2 K3 K8
¤ ¤ ¤ ¤
Sorted Digits Child Pointers
1 2 3 1 2 3
SLIDE 102
15-721 (Spring 2020)
ART: INNER NODE TYPES (2)
Instead of storing 1-byte digits, maintain an array of 1-byte offsets to a child pointer array that is indexed on the digit bits.
36
Node48
K0 ...
¤ ¤ ¤
... 1 47 K1 K2 K255
¤
Ø
¤ ¤
SLIDE 103
15-721 (Spring 2020)
ART: INNER NODE TYPES (2)
Instead of storing 1-byte digits, maintain an array of 1-byte offsets to a child pointer array that is indexed on the digit bits.
36
Node48
K0 ...
¤ ¤ ¤
... 1 47 K1 K2 K255
¤
Ø
¤ ¤
Pointer Array Offsets
SLIDE 104
15-721 (Spring 2020)
ART: INNER NODE TYPES (2)
Instead of storing 1-byte digits, maintain an array of 1-byte offsets to a child pointer array that is indexed on the digit bits.
36
Node48
K0 ...
¤ ¤ ¤
... 1 47 K1 K2 K255
¤
Ø
¤ ¤
Pointer Array Offsets
SLIDE 105
15-721 (Spring 2020)
ART: INNER NODE TYPES (2)
Instead of storing 1-byte digits, maintain an array of 1-byte offsets to a child pointer array that is indexed on the digit bits.
36
Node48
K0 ...
¤ ¤ ¤
... 1 47 K1 K2 K255
¤
Ø
¤ ¤ 256 × 1-byte = 256 bytes 48 × 8-bytes = 384 bytes 640 bytes
Pointer Array Offsets
SLIDE 106
15-721 (Spring 2020)
ART: INNER NODE TYPES (3)
Store an array of 256 pointers to child nodes. This covers all possible values in 8-bit digits. Same as the Judy Array's Uncompressed Node.
37
Node256
K0 ... K1 K2 K255
¤
Ø
¤ ¤
K3 K4 K5
¤
Ø
¤
K6
Ø
SLIDE 107
15-721 (Spring 2020)
ART: INNER NODE TYPES (3)
Store an array of 256 pointers to child nodes. This covers all possible values in 8-bit digits. Same as the Judy Array's Uncompressed Node.
37
Node256
K0 ... K1 K2 K255
¤
Ø
¤ ¤ 256 × 8-byte = 2048 bytes
K3 K4 K5
¤
Ø
¤
K6
Ø
SLIDE 108
15-721 (Spring 2020)
ART: BINARY COM PARABLE KEYS
Not all attribute types can be decomposed into binary comparable digits for a radix tree.
→ Unsigned Integers: Byte order must be flipped for little endian machines. → Signed Integers: Flip two’s-complement so that negative numbers are smaller than positive. → Floats: Classify into group (neg vs. pos, normalized vs. denormalized), then store as unsigned integer. → Compound: Transform each attribute separately.
38
SLIDE 109
15-721 (Spring 2020)
ART: BINARY COM PARABLE KEYS
39
Hex Key: 0A 0B 0C 0D Int Key: 168496141 0A 0B 0C 0D Big Endian 0D 0C 0B 0A Little Endian
0A 0F 0B 0B 1D 0C
¤ ¤ ¤
0D 0B
¤ ¤
8-bit Span Radix Tree
SLIDE 110
15-721 (Spring 2020)
ART: BINARY COM PARABLE KEYS
39
Hex Key: 0A 0B 0C 0D Int Key: 168496141 0A 0B 0C 0D Big Endian 0D 0C 0B 0A Little Endian
Hex: 0A 0B 1D Find: 658205
0A 0F 0B 0B 1D 0C
¤ ¤ ¤
0D 0B
¤ ¤
8-bit Span Radix Tree
SLIDE 111
15-721 (Spring 2020)
ART: BINARY COM PARABLE KEYS
39
Hex Key: 0A 0B 0C 0D Int Key: 168496141 0A 0B 0C 0D Big Endian 0D 0C 0B 0A Little Endian
Hex: 0A 0B 1D Find: 658205
0A 0F 0B 0B 1D 0C
¤ ¤ ¤
0D 0B
¤ ¤
8-bit Span Radix Tree
SLIDE 112
15-721 (Spring 2020)
M ASSTREE
Instead of using different layouts for each trie node based on its size, use an entire B+Tree.
→ Each B+tree represents 8-byte span. → Optimized for long keys. → Uses a latching protocol that is similar to versioned latches.
Part of the Harvard Silo project.
40
CACHE CRAFTINESS FOR FAST MULTICORE KEY- VALUE STORAGE
EUROSYS 2012
Masstree
Bytes [0-7] Bytes [8-15] Bytes [8-15]
¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤ ¤
SLIDE 113
15-721 (Spring 2020)
IN- M EM ORY INDEXES
41
9.94 15.5 13.3 5.43 2.51 2.78 1.51 2.43 8.09 29 25.1 18.9 17.9 30.5 22 3.68 44.9 51.5 42.9 3.43
10 20 30 40 50 60 Insert-Only Read-Only Read/Update Scan/Insert
Operations/sec (M)
Open Bw-Tree Skip List B+Tree Masstree ART
Processor: 1 socket, 10 cores w/ 2×HT Workload: 50m Random Integer Keys (64-bit)
Source: Ziqi Wang
SLIDE 114
15-721 (Spring 2020)
IN- M EM ORY INDEXES
42
2.34 1.79 1.91 2.07 2.18 2.49 1.59 1.15 1.3 3.37 2.86 4.22 0.42 1.44 0.722
1 2 3 4 5 Mono Int Rand Int Emails
Memory (GB)
Open Bw-Tree Skip List B+Tree Masstree ART
Processor: 1 socket, 10 cores w/ 2×HT Workload: 50m Keys
Source: Ziqi Wang
SLIDE 115
15-721 (Spring 2020)
PARTING THOUGHTS
Andy was wrong about the Bw-Tree and latch- free indexes. Radix trees have interesting properties, but a well- written B+tree is still a solid design choice.
43
SLIDE 116
15-721 (Spring 2020)
NEXT CLASS
System Catalogs Data Layout Storage Models
44
