Adaptive Scheduling for Systems with Asymmetric Memory Hierarchies

Po-An Tsai, Changping Chen, and Daniel Sanchez

Die-stacking has enabled near-data processing

Die-stacking has enabled near-data processing

Conventional multicore processors use a multi-level deep cache hierarchy to reduce data movement Shared LLC Cores Private Caches

Die-stacking has enabled near-data processing

Conventional multicore processors use a multi-level deep cache hierarchy to reduce data movement Shared LLC Cores Private Caches DRAM Dies Logic Layer Near-data processors place cores close to main memory to reduce data movement NDP Core Vault Controller Private cache only (shallow hierarchy)

Die-stacking has enabled near-data processing

Conventional multicore processors use a multi-level deep cache hierarchy to reduce data movement Shared LLC Cores Private Caches DRAM Dies Logic Layer Near-data processors place cores close to main memory to reduce data movement NDP Core Vault Controller Private cache only (shallow hierarchy) Neither shallow nor deep hierarchies work well for all applications…

Asymmetric hierarchies get the best of both worlds

Asymmetric hierarchies get the best of both worlds

Prior work proposes hybrid system with asymmetric memory hierarchies to get the best of both

Asymmetric hierarchies get the best of both worlds

[Ahn et al., ISCA’15][Gao et al., PACT’15] [Hsieh et al., ISCA’16][Boroumand et al., ASPLOS’18]

Applications have strong hierarchy preferences

4

Applications have strong hierarchy preferences

4

10 20 30 40 50 60 70 80 Deep hier. LLC hit Shallow hierarchy Deep hier. LLC miss Access latency (ns)

Applications have strong hierarchy preferences

4 Performance/J of milc

• n different hierarchies

10 20 30 40 50 60 70 80 Deep hier. LLC hit Shallow hierarchy Deep hier. LLC miss Access latency (ns) 0.5 1 1.5 2 2.5 3 Deep hierarchy Shallow hierarchy Normalized Perf/J

Applications have strong hierarchy preferences

4 Performance/J of milc

• n different hierarchies

Performance/J of xalanc

• n different hierarchies

10 20 30 40 50 60 70 80 Deep hier. LLC hit Shallow hierarchy Deep hier. LLC miss Access latency (ns) 0.5 1 1.5 2 2.5 3 Deep hierarchy Shallow hierarchy Normalized Perf/J 0.2 0.4 0.6 0.8 1 1.2 Deep hierarchy Shallow hierarchy Normalized Perf/J

Applications have strong hierarchy preferences

4 Performance/J of milc

• n different hierarchies

How well each application can use the shared LLC is critical to its preference

Performance/J of xalanc

• n different hierarchies

10 20 30 40 50 60 70 80 Deep hier. LLC hit Shallow hierarchy Deep hier. LLC miss Access latency (ns) 0.5 1 1.5 2 2.5 3 Deep hierarchy Shallow hierarchy Normalized Perf/J 0.2 0.4 0.6 0.8 1 1.2 Deep hierarchy Shallow hierarchy Normalized Perf/J

Scheduling programs to the right hierarchy is hard

5

Scheduling programs to the right hierarchy is hard

5

Many applications prefer different hierarchies over time because they have different phases

Performance/J of gems

Scheduling programs to the right hierarchy is hard

5

Many applications prefer different hierarchies over time because they have different phases Applications may prefer different hierarchies due to resource contention with other applications

0.5 1 1.5 2 2.5 Shallow hierarchy Deep hierarchy 2MB LLC Deep hierarchy 4MB LLC Deep hierarchy 8MB LLC Deep hierarchy 16MB LLC Normalized Perf/J

Performance/J of gems Performance/J of xalanc

Prior schedulers focus on different systems and constraints

6

Prior schedulers focus on different systems and constraints

6

 Contention-aware scheduling (Bubble-up [Mars, MICRO’11], CRUISE [Jaleel, ASPLOS’12])

 Focuses on symmetric memory systems (multi-socket LLCs/NUMA) LLC 1 8MB LLC 2 8MB

Prior schedulers focus on different systems and constraints

6

 Contention-aware scheduling (Bubble-up [Mars, MICRO’11], CRUISE [Jaleel, ASPLOS’12])

 Focuses on symmetric memory systems (multi-socket LLCs/NUMA)

 Heterogeneous core-aware scheduling (PIE [Van Craeynest, ISCA’12][Cong, ISPLED’11])

 Focuses on asymmetric core microarchitectures (big.LITTLE systems) In-order cores OoO cores LLC 1 8MB LLC 2 8MB

Prior schedulers focus on different systems and constraints

6

 Contention-aware scheduling (Bubble-up [Mars, MICRO’11], CRUISE [Jaleel, ASPLOS’12])

 Focuses on symmetric memory systems (multi-socket LLCs/NUMA)

 Heterogeneous core-aware scheduling (PIE [Van Craeynest, ISCA’12][Cong, ISPLED’11])

 Focuses on asymmetric core microarchitectures (big.LITTLE systems)

 NDP-aware workload partitioning (PIM-enabled Instructions [Ahn, ISCA’15], TOM [Hsieh, ISCA’16])

 Focuses on single workloads and requires software modifications or compiler support In-order cores OoO cores LLC 1 8MB LLC 2 8MB

Prior schedulers focus on different systems and constraints

6

 Contention-aware scheduling (Bubble-up [Mars, MICRO’11], CRUISE [Jaleel, ASPLOS’12])

 Focuses on symmetric memory systems (multi-socket LLCs/NUMA)

 Heterogeneous core-aware scheduling (PIE [Van Craeynest, ISCA’12][Cong, ISPLED’11])

 Focuses on asymmetric core microarchitectures (big.LITTLE systems)

 NDP-aware workload partitioning (PIM-enabled Instructions [Ahn, ISCA’15], TOM [Hsieh, ISCA’16])

 Focuses on single workloads and requires software modifications or compiler support

By contrast, our goal is to schedule threads considering both memory and core asymmetries, with no program modifications and transparently to users

In-order cores OoO cores LLC 1 8MB LLC 2 8MB

7 Hardware utility monitors Hardware Software Sample accesses Misses Cache size Miss curves Produce

AMS: An asymmetry-aware scheduler

Analytical model that estimates performance under different hierarchies First contribution

Schedule threads

Second contribution Two thread placement algorithms (AMS-Greedy/AMS-DP) that extend techniques originally designed for cache partitioning

AMS analytical model

8

 AMS estimates application preferences using total memory access latency

AMS analytical model

8

 AMS estimates application preferences using total memory access latency

AMS analytical model

8 # Misses Miss curve from hardware monitors LLC Capacity (MB) 2 4 6 8

 AMS estimates application preferences using total memory access latency  Deep hierarchy has a shared LLC

 Lat = (# accesses x Latency of LLC) + (# misses x Latency of deep mem)

AMS analytical model

8 # Misses Miss curve from hardware monitors LLC Capacity (MB) 2 4 6 8

 AMS estimates application preferences using total memory access latency  Deep hierarchy has a shared LLC

 Lat = (# accesses x Latency of LLC) + (# misses x Latency of deep mem)

AMS analytical model

8 # Misses Miss curve from hardware monitors LLC Capacity (MB) 2 4 6 8 A function of LLC capacity

 AMS estimates application preferences using total memory access latency  Deep hierarchy has a shared LLC

 Lat = (# accesses x Latency of LLC) + (# misses x Latency of deep mem)

AMS analytical model

8 # Misses Miss curve from hardware monitors LLC Capacity (MB) 2 4 6 8 Latency Latency curve model Processor-die core LLC Capacity (MB) 2 4 6 8 A function of LLC capacity

 AMS estimates application preferences using total memory access latency  Deep hierarchy has a shared LLC

 Lat = (# accesses x Latency of LLC) + (# misses x Latency of deep mem)

 Shallow hierarchy has no shared LLC  Lat = # accesses x Latency of shallow mem

AMS analytical model

8 # Misses Miss curve from hardware monitors LLC Capacity (MB) 2 4 6 8 NDP core Latency Latency curve model Processor-die core LLC Capacity (MB) 2 4 6 8 A function of LLC capacity

 AMS estimates application preferences using total memory access latency  Deep hierarchy has a shared LLC

 Lat = (# accesses x Latency of LLC) + (# misses x Latency of deep mem)

 Shallow hierarchy has no shared LLC  Lat = # accesses x Latency of shallow mem

AMS analytical model

8 # Misses Miss curve from hardware monitors LLC Capacity (MB) 2 4 6 8 NDP core Latency Latency curve model Processor-die core LLC Capacity (MB) 2 4 6 8 A function of LLC capacity Use processor-die core Use NDP core

Handling heterogeneous cores

9

 Combine model from prior work (PIE) with our memory latency model

Handling heterogeneous cores

9

 Combine model from prior work (PIE) with our memory latency model

NDP core Memory latency Latency curves Processor-die core LLC Capacity (MB) 2 4 6 8

Handling heterogeneous cores

9

 Combine model from prior work (PIE) with our memory latency model

NDP core Memory latency Latency curves Processor-die core LLC Capacity (MB) 2 4 6 8

Weigh by MLP

Processor-die core LLC Capacity (MB) 2 4 6 8 NDP core Memory stalls Memory stall curves

Handling heterogeneous cores

9

 Combine model from prior work (PIE) with our memory latency model

NDP core Memory latency Latency curves Processor-die core LLC Capacity (MB) 2 4 6 8

Weigh by MLP Add non-memory component weighed by ILP

Processor-die core LLC Capacity (MB) 2 4 6 8 NDP core Memory stalls Memory stall curves

Handling heterogeneous cores

9

 Combine model from prior work (PIE) with our memory latency model

NDP core Memory latency Latency curves Processor-die core LLC Capacity (MB) 2 4 6 8

Weigh by MLP Add non-memory component weighed by ILP

Processor-die core LLC Capacity (MB) 2 4 6 8 NDP core Memory stalls Memory stall curves Processor-die core LLC Capacity (MB) 2 4 6 8 NDP core Core cycles Core cycle curves

Non-mem cycles

Handling heterogeneous cores

9

 Combine model from prior work (PIE) with our memory latency model

NDP core Memory latency Latency curves Processor-die core LLC Capacity (MB) 2 4 6 8

Weigh by MLP Add non-memory component weighed by ILP

Processor-die core LLC Capacity (MB) 2 4 6 8 NDP core Memory stalls Memory stall curves Processor-die core LLC Capacity (MB) 2 4 6 8 NDP core Core cycles Core cycle curves

Non-mem cycles

Can be extended to other asymmetries, like frequencies (see paper)

AMS-Greedy overview

10

 Solve an optimization problem that seeks to minimize total cost

AMS-Greedy overview

10

 Solve an optimization problem that seeks to minimize total cost  Initially, starts by mapping all threads to the deep hierarchy (processor-die)

and moves some threads to the NDP cores over multiple rounds

AMS-Greedy overview

10

 Solve an optimization problem that seeks to minimize total cost  Initially, starts by mapping all threads to the deep hierarchy (processor-die)

and moves some threads to the NDP cores over multiple rounds

AMS-Greedy overview

10 Input: Cost curves of all threads for deep hierarchy

 Solve an optimization problem that seeks to minimize total cost  Initially, starts by mapping all threads to the deep hierarchy (processor-die)

and moves some threads to the NDP cores over multiple rounds

AMS-Greedy overview

10 Input: Cost curves of all threads for deep hierarchy Cache partitioning

• algo. from

prior work Partition plan T1: 3MB T2: 1MB T3: 4MB …

 Solve an optimization problem that seeks to minimize total cost  Initially, starts by mapping all threads to the deep hierarchy (processor-die)

and moves some threads to the NDP cores over multiple rounds

AMS-Greedy overview

10 Input: Cost curves of all threads for deep hierarchy Cache partitioning

• algo. from

prior work Partition plan T1: 3MB T2: 1MB T3: 4MB … Compare cost of deep/shallow

• hier. according

to the plan Map some threads to shallow hierarchy

 Solve an optimization problem that seeks to minimize total cost  Initially, starts by mapping all threads to the deep hierarchy (processor-die)

and moves some threads to the NDP cores over multiple rounds

AMS-Greedy overview

10 Input: Cost curves of all threads for deep hierarchy Cache partitioning

• algo. from

prior work Partition plan T1: 3MB T2: 1MB T3: 4MB … Compare cost of deep/shallow

• hier. according

to the plan Map some threads to shallow hierarchy

Do remaining threads fit in deep hier.?

 Solve an optimization problem that seeks to minimize total cost  Initially, starts by mapping all threads to the deep hierarchy (processor-die)

and moves some threads to the NDP cores over multiple rounds

AMS-Greedy overview

10 Input: Cost curves of all threads for deep hierarchy Cache partitioning

• algo. from

prior work Partition plan T1: 3MB T2: 1MB T3: 4MB … Compare cost of deep/shallow

• hier. according

to the plan Map some threads to shallow hierarchy

Do remaining threads fit in deep hier.?

Yes Done

 Solve an optimization problem that seeks to minimize total cost  Initially, starts by mapping all threads to the deep hierarchy (processor-die)

and moves some threads to the NDP cores over multiple rounds

AMS-Greedy overview

10 Input: Cost curves of all threads for deep hierarchy Cache partitioning

• algo. from

prior work Partition plan T1: 3MB T2: 1MB T3: 4MB … Compare cost of deep/shallow

• hier. according

to the plan Map some threads to shallow hierarchy

Do remaining threads fit in deep hier.?

Yes Done No Cost curves for threads still mapped the deep hierarchy

AMS-Greedy: Leveraging cache partitioning to schedule threads

11

AMS-Greedy: Leveraging cache partitioning to schedule threads

11

Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8

Thread 1 Thread 2 Thread 3

AMS-Greedy: Leveraging cache partitioning to schedule threads

11

Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8

Partition the LLC among threads 1-3

Thread 1 Thread 2 Thread 3

8MB

AMS-Greedy: Leveraging cache partitioning to schedule threads

11

Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8

3MB Partition the LLC among threads 1-3

Thread 1 Thread 2 Thread 3

4MB 8MB 1MB

AMS-Greedy: Leveraging cache partitioning to schedule threads

11

Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8

3MB Partition the LLC among threads 1-3

Thread 1 Thread 2 Thread 3

4MB 8MB 1MB

: Opportunity cost

AMS-Greedy: Leveraging cache partitioning to schedule threads

11

 Uses opportunity cost to decide which thread should give up processor-die

Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8

3MB Partition the LLC among threads 1-3

Thread 1 Thread 2 Thread 3

4MB 8MB 1MB

: Opportunity cost Opportunity cost <0 move to NDP

AMS-Greedy: Leveraging cache partitioning to schedule threads

11

 Uses opportunity cost to decide which thread should give up processor-die

Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8

3MB Partition the LLC among threads 1-3

Thread 1 Thread 2 Thread 3

4MB 8MB 1MB

: Opportunity cost Opportunity cost <0 move to NDP

Perform multiple rounds

• f partitioning until the

processor die is not

• versubscribed

AMS-Greedy: Leveraging cache partitioning to schedule threads

11

 Uses opportunity cost to decide which thread should give up processor-die

Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8 Cost LLC Capacity (MB) 2 4 6 8

3MB Partition the LLC among threads 1-3

Thread 1 Thread 2 Thread 3

4MB 8MB 1MB

: Opportunity cost Opportunity cost <0 move to NDP

Perform multiple rounds

• f partitioning until the

processor die is not

• versubscribed

Overhead: 0.1% of system cycles when scheduling every 50ms

AMS-DP: Scheduling threads with dynamic programming

12

AMS-DP: Scheduling threads with dynamic programming

12

 Prior work has shown that dynamic programming (DP) solve cache partitioning

• ptimally in polynomial time

 We propose an algorithm using DP to solve our optimization problem optimally

AMS-DP: Scheduling threads with dynamic programming

12

 Prior work has shown that dynamic programming (DP) solve cache partitioning

• ptimally in polynomial time

 We propose an algorithm using DP to solve our optimization problem optimally

AMS-DP: Scheduling threads with dynamic programming

12

 Prior work has shown that dynamic programming (DP) solve cache partitioning

• ptimally in polynomial time

 We propose an algorithm using DP to solve our optimization problem optimally

AMS-DP: Scheduling threads with dynamic programming

12

 Prior work has shown that dynamic programming (DP) solve cache partitioning

• ptimally in polynomial time

 We propose an algorithm using DP to solve our optimization problem optimally

 AMS-DP serves as the upper bound of AMS-Greedy

 But it is more expensive

Data placement for asymmetric hierarchies

13

Data placement for asymmetric hierarchies

13

Data placement for asymmetric hierarchies

13

Data placement for asymmetric hierarchies

13

 NDP systems have different constraints from NUMA systems

 NDP cores have plentiful intra-stack bandwidth but limited inter-stack bandwidth

Data placement for asymmetric hierarchies

13

 NDP systems have different constraints from NUMA systems

 NDP cores have plentiful intra-stack bandwidth but limited inter-stack bandwidth

 We use simple heuristics to keep data from a thread in a single stack

 Threads try to allocate to the same stack so long as the stack has enough capacity

See paper for more details

14

 Handling multithreaded workloads  AMS-DP formulation  Different system scenarios

 Oversubscribed systems  Short-lived workloads or latency critical workloads

Evaluation

15

Evaluation

15

 Modeled system:

Evaluation

15

 Modeled system:

Evaluation

15

 Modeled system:

Deep hierarchy: 8-core processor 32KB L1, 256KB L2, 16MB shared LLC

Evaluation

15

 Modeled system:

Deep hierarchy: 8-core processor 32KB L1, 256KB L2, 16MB shared LLC Shallow hierarchy: 4 memory stacks, each with 2 NDP cores. Each core has private 32KB L1 + 256KB L2

Evaluation

15

 Modeled system:  Workloads

 Multi-programmed SPECCPU  Multithreaded SPECOMP/PARSEC

(see paper) Deep hierarchy: 8-core processor 32KB L1, 256KB L2, 16MB shared LLC Shallow hierarchy: 4 memory stacks, each with 2 NDP cores. Each core has private 32KB L1 + 256KB L2

Evaluation

15

 Modeled system:  Workloads

 Multi-programmed SPECCPU  Multithreaded SPECOMP/PARSEC

(see paper) Deep hierarchy: 8-core processor 32KB L1, 256KB L2, 16MB shared LLC Shallow hierarchy: 4 memory stacks, each with 2 NDP cores. Each core has private 32KB L1 + 256KB L2

 Compared schedulers

Evaluation

15

 Modeled system:  Workloads

 Multi-programmed SPECCPU  Multithreaded SPECOMP/PARSEC

(see paper) Deep hierarchy: 8-core processor 32KB L1, 256KB L2, 16MB shared LLC Shallow hierarchy: 4 memory stacks, each with 2 NDP cores. Each core has private 32KB L1 + 256KB L2

 Compared schedulers

 Random (baseline that we normalize to)

Evaluation

15

 Modeled system:  Workloads

 Multi-programmed SPECCPU  Multithreaded SPECOMP/PARSEC

(see paper) Deep hierarchy: 8-core processor 32KB L1, 256KB L2, 16MB shared LLC Shallow hierarchy: 4 memory stacks, each with 2 NDP cores. Each core has private 32KB L1 + 256KB L2

 Compared schedulers

 Random (baseline that we normalize to)  Always NDP/Always processor-die

Evaluation

15

 Modeled system:  Workloads

 Multi-programmed SPECCPU  Multithreaded SPECOMP/PARSEC

(see paper) Deep hierarchy: 8-core processor 32KB L1, 256KB L2, 16MB shared LLC Shallow hierarchy: 4 memory stacks, each with 2 NDP cores. Each core has private 32KB L1 + 256KB L2

 Compared schedulers

 Random (baseline that we normalize to)  Always NDP/Always processor-die  Extended CRUISE [ASPLOS’12]/PIE [ISCA’11]

Evaluation

15

 Modeled system:  Workloads

 Multi-programmed SPECCPU  Multithreaded SPECOMP/PARSEC

(see paper) Deep hierarchy: 8-core processor 32KB L1, 256KB L2, 16MB shared LLC Shallow hierarchy: 4 memory stacks, each with 2 NDP cores. Each core has private 32KB L1 + 256KB L2

 Compared schedulers

 Random (baseline that we normalize to)  Always NDP/Always processor-die  Extended CRUISE [ASPLOS’12]/PIE [ISCA’11]  AMS-Greedy/AMS-DP

AMS finds the right hierarchy for each application

16

AMS finds the right hierarchy for each application

16

AMS finds the right hierarchy for each application

16 Always processor never leverages the NDP capability of the asymmetric system and is 8% worse than Random

AMS finds the right hierarchy for each application

16 Always processor never leverages the NDP capability of the asymmetric system and is 8% worse than Random Always NDP sometimes hurts applications that prefer deep hierarchies because it never leverages the LLC. Only 9% better

AMS finds the right hierarchy for each application

16 Always processor never leverages the NDP capability of the asymmetric system and is 8% worse than Random Always NDP sometimes hurts applications that prefer deep hierarchies because it never leverages the LLC. Only 9% better AMS-Greedy never hurts performance and improves weighted speedup by up to 37% and by 18% on average

AMS handles resource contention better than prior work

17

 Run workloads with 100% utilization to stress contention

AMS handles resource contention better than prior work

17

 Run workloads with 100% utilization to stress contention

AMS handles resource contention better than prior work

17

 Run workloads with 100% utilization to stress contention

AMS handles resource contention better than prior work

17

AMS-Greedy performs very close to AMS-DP , only 1% worse

 Run workloads with 100% utilization to stress contention

AMS handles resource contention better than prior work

17

AMS-Greedy performs very close to AMS-DP , only 1% worse Both AMS-Greedy and AMS- DP outperform CRUISE

AMS handles asymmetric core + memory well

18

AMS handles asymmetric core + memory well

18

 Deep hierarchy uses Haswell-like cores  Shallow hierarchy uses Silvermont-like cores

AMS handles asymmetric core + memory well

18

 Deep hierarchy uses Haswell-like cores  Shallow hierarchy uses Silvermont-like cores

AMS handles asymmetric core + memory well

18

 Deep hierarchy uses Haswell-like cores  Shallow hierarchy uses Silvermont-like cores

AMS-Greedy with the PIE model improves performance more than handling core/memory asymmetries separately

See paper for more evaluation results

19

 A case study to show AMS adapts to application phases  Multithreaded workloads  Detailed runtime overheads  Sensitivity study for system parameters

 Number of cores, LLC capacity, main memory capacity  Performance without and with hardware support for cache partitioning

Conclusion

20

Conclusion

20

 Scheduling computation in asymmetric systems is very challenging

Conclusion

20

 Scheduling computation in asymmetric systems is very challenging  We present AMS, an adaptive scheduler for asymmetric systems  AMS uses analytical models to adapt quickly and thread mapping algorithms

inspired by cache partitioning algorithms to find high-quality mappings

Hardware utility monitors Hardware Software Sample accesses Misses Cache size Miss curves Produce Analytical model that estimates performance under different hierarchies First contribution

Schedule threads

Second contribution Two thread placement algorithms that extends techniques originally designed for cache partitioning

Thanks! Any questions?

21

 Scheduling computation in asymmetric systems is very challenging  We present AMS, an adaptive scheduler for asymmetric systems  AMS uses analytical models to adapt quickly and thread mapping algorithms

inspired by cache partitioning algorithms to find high-quality mappings

Hardware utility monitors Hardware Software Sample accesses Misses Cache size Miss curves Produce Analytical model that estimates performance under different hierarchies First contribution

Schedule threads

Second contribution Two thread placement algorithms that extends techniques originally designed for cache partitioning
