• About Acti and product portfolio
• Why Go IP?
• Acti IP Hardware solution
• Acti IP software Solution

Agenda

 Incorporation Date: September 11th, 2003  Headquarter: Taipei, Taiwan  Branch Office:

– Irvine, U.S.,

 Employee: 300+

ACTi Briefing

Customer Profile

Top 4F 3F 2F

1F Basement Price Driven Quality/Solution Driven Platform Driven ACTi Solution Covers 80%+ of Client Requirements

4F 3F 2F

1F

4F 3F 2F 1F

Basement

Hardware Solution

Discovery series

1/3MP FX/VF LENS DNR Less Cost

Essential series

1/2/3/5MP FX/VF LENS Basic/Superior WDR DNR Low light Sensitivity

KCM Series

2/4MP Optical zoom Auto focus ExDR(WDR) 2D+3D DNR Low light Sensitivity Fisheye/PTZ

VMS solution

NVR 3.0

• 16 channels free,

up to 64 ch

• up to 64 channels

Recording

• Support E-

maps/PTZ/Event recording/Speed up/

• Support iOS,

Remote access

ENR-1000

• 4 channels

Recording

• 4 channels

1080P display

• 4 channels

1080p playback

• support DHCP

server

• 2 SATA HDD
• HDMI 1080P

Monitor support

ENR-1100

• 9 channels-

Recording

• 4 channels

1080P display

• 4 channels

1080p playback

• support DHCP

server

• 2 SATA HDD
• HDMI 1080P

Monitor support

GNR-3000

• Recording server
• 64 channels free
• Remote

client/Mobile Client supports

• Support ISCSI

NAS/eSATA

• Extra 4 HDD bays

Why Going IP?

What Benefit Acti provides from IP Solution?

• Multiple functions
• Multiple locations
• One control center

Control Center

Intrusion Alarm Fire Alarm Access Control IP Camera

Campus 1

Intrusion Alarm Fire Alarm Access Control IP Camera

Campus 2

Full System Integration

Speaker Sensor Input Microphone Alarm Output NVR

IP Camera w/ PoE power

Simple IP System

Installing 1 cable for Video / Audio / DI/O / Power

Streamlined Ethernet Installation

Analog System IP System

DVR Buy another DVR for 17th or 33rd or 49th cameras NVR Add cameras licenses up to 64 ch – no additional hardware!

17ch . . . . . . 1ch 2ch 16ch 17ch 1ch 2ch 16ch 64ch

DVR 1 DVR 2 NVR Software tware License se

. . . . . .

Flexible Scalability

10

IP Lower Total Cost of Ownership

Source: Axis Whitepaper, 2007

40 cameras

What Technology Acti Brings to you?

D1 VGA CIF QCIF

1 MP Resolution to 5MP

Optical Zoom /Auto focus

No Good Focus, No Good Quality! Big focus issue of installation! Lots of Lens choice issue! ACTi give you perfect Tracing AF With 4x/ 18x/ 35x Optical Zoom!!

ACTi Zoom & Autofocus

• Save Install time ~ 20min/camera
• 100-camera project
• 2,000 min  33hrs 20min
• What could you do with 33 extra hrs?

15

Autofocus Auto Back Focus Remote Focus Manual focus Time to Focus

1-3 sec 7 sec 7 - 40 sec 5 min +

Installation Use

Yes Yes Yes No

Zoom & Focus for Event Use

Yes No No No

Superior Low Light Sensor Application (SLLS)

Fisheye and Application

Panoramic

Double Panoramic Many eye

Advanced Wide Dynamic range

Restore the detail in high contrast light condition

Advanced WDR OFF Advanced WDR ON

• 2D : Remove noise on single frame
• 3D : Remove the difference in the frame before and after

2D + 3D DNR

2D/3D DNR OFF 2D/3D DNR ON

H.264 and Dual Streams Technology

Optimize the loading of recording and live view

NVR Server

Stream 1 (maximum resolution/H.264) Stream 2 (VGA resolution/MJPEG) Storage Small scale and enough for monitor purpose Live View High resolution to see the detail for playback.

Hardware Solution

Discovery series

1/3MP FX/VF LENS DNR Less Cost

Essential series

1/2/3/5MP FX/VF LENS Basic/Superior WDR DNR Low light Sensitivity

KCM Series

2/4MP Optical zoom Auto focus ExDR(WDR) 2D+3D DNR Low light Sensitivity Fisheye/PTZ

Discovery Series

Product segment Color camera Ture D/N camera SLLS camera

Resolution 1MP 3MP 1MP 3MP 1MP 2MP Type Cube D11 D12 Box

D21/D21v D22/D22v

FX Bullet D31 D32 VF Bullet D41 D42 FX Dome D51 D52 D54 D55 VF Dome D64 D65 D61 D62 FX OD dome D71 D72 VF OD Dome D81 D82

Color camera

Application:

• 1. Retail shop
• 2. Classrooms
• 3. Office
• 1MP 720P
• 3MP

Resolution

• 30fps@1MP/2MP
• 15fps@3MP

FPS

• Fixed Lens

Lens

• POE Class 2

Power consumption

Day and night camera

Application:

• 1. Retail shop
• 2. Classrooms
• 3. Office
• 1MP 720P
• 3MP

Resolution

• 30fps@1MP/2MP
• 15fps@3MP

FPS

• Inter changeable Les(Box)
• Varifocal or Fixed lens
• 2.8-12mm, DC-iris(Box)

Lens

• IR cut Filter D/N
• IR LED Built in

D/N

• IK 10/IP66 housing
• IP 66 housing

Outdoor application

• Micro SDHC support(Vari

focal Dome/OD DOME)

Edge Storage

SLLS camera

Application:

• 1. Retail shop
• 2. Classrooms
• 3. Office
• 1MP 720P
• 2MP 1080P

Resolution

• Superior Low light

Sensor

SLLS

• 30fps@1MP/2MP
• 15fps@3MP

FPS

• Varifocal Lens

Lens

• Micro SDHC support

Edge Storage

Superior Low Light Sensor Application (SLLS)

When D-series goes to E-series…

2 way audio WDR/SWDR 5MP More SLLS Extendable warranty

Essential Series

Product segment

Color camera True D/N Camera

Superior WDR Camera

SLLS Camera

Resolution 1MP 3MP 5MP 1MP 3MP 5MP 1MP 3MP 1MP 2MP

Cube

E11 E12 E13

Box E21/ E21v E22/ E22v

E24 E23

FX Bullet

E31 E32 E33 E34

VF Bullet

E41 E42 E43 E45 E46 E44

FX Dome

E51 E52 E53 E54

VF Dome

E61 E62 E63 E64 E65

FX OD dome

E71 E72 E73 E74

VF OD Dome

E81 E82 E83 E85 E86

Mini Dome

E91 E92

Color camera

• 1MP(720P)
• 3MP
• 5MP

Resolution

• 720P/1080P: 30fps
• 3MP/5MP: 15fps

FPS

• Built in Mic
• Audio out put

Audio(Cube)

• WDR
• DNR

Image processor

• Fixed lens
• Inter changeable

lens(Cube)

Lens

Application:

• 1. Retail shop
• 2. Classrooms
• 3. Office

Day and Night camera

Application:

• 1. Retail shop
• 2. Office
• 3. Hotel
• 1MP(720P)
• 3MP
• 5MP

Resolution

• 720P/1080P: 30fps
• 3MP/5MP: 15fps

FPS

• WDR
• DNR

Image processor

• Varifocal and Fixed lens
• Inter changeable lens(Box)
• 2.8-12mm, DC-iris(Box)

Lens

• Micro SDHC support(Vari

focal Dome/OD DOME)

Edge Storage

Superior Wide Dynamic range camera

Application:

• 1. Retail shop
• 2. Loading dock
• 3. Buildings outdoor
• 4. Parking lot
• 1MP(720P)
• 3MP

Resolution

• 720P/1080P: 30fps
• 3MP: 15fps

FPS

• Superior Wide Dynamic range
• DNR

Image processor

• Built in IR cut filter
• Built in IR LED

D/N

• 2.8-12mm, DC-iris(Box)
• Inter changeable lens(Box)
• Varifocal lens or Fixed Lens

Lens

• Micro SDHC support(Vari focal

Dome/OD DOME)

Edge Storage

SLLS camera

Application:

• 1. Parking Lot
• 2. Loading dock
• 3. Buildings outdoor
• 1MP 720P
• 2MP 1080P

Resolution

• Superior Low light

Sensor

SLLS

• 3.3-12mm
• 2.8-12mm, DC-iris(Box)

Vari-focal lens

• 720P/1080P: 30fps

FPS

• WDR
• DNR

Image processor

• Built in IR cut filter
• Built in IR LED (Bullet)

D/N

KCM series

Optical zoom Auto Focus PTZ Fisheye

KCM Series

Product Type

Optical zoom/Auto focus

Fisheye

Resolution 2MP 4MP 4MP Indoor Box KCM-5211 Indoor Dome KCM-3311 KCM-3911 Outdoor Box KCM-5611 KCM-5211E KCM-5511 Outdoor Dome KCM-7311 KCM-7911 Indoor PTZ KCM-8111 Outdoor PTZ KCM-8211

In/Outdoor Hemispheric Camera

KCM-3911

• 180 / 360 degree viewing

angle

• ePTZ
• 4MP 6fps; 1080pHD 12fps
• Fish Eye Lens

f1.05mm/F2.8

• 1561 TVL
• 6 cropped regions replaces

6 VGA cameras

• AWDR , 2D+3D DNR
• Defogging
• Edge enhancement
• Adaptive Profile

4 MP

6xVGA Image Processor

KCM-7911

Panoramic

IP66

• End user: Ratchbhat Surat University
• Installation Date: 1st week of Aug.
• Solution: 10 units of KCM-7911 and NVR 3.0

Case Study at Thailand

Outdoor Low Light AF Box

• 1080pHD 15fps; 720pHD

30fps

• Optical zoom 18x (f4.7-84.6

mm / F1.6 ~ 2.8) and 22x (f3.2-83mm/ F1.6~3.8)

• Auto Focus
• Low Sensor(KCM-5611)
• Affordable price for outdoor

selection! (KCM-5511)

• AWDR , 2D+3D DNR
• Defogging
• Edge enhancement
• Adaptive Profile

Best Applications

• City Surveillance
• Parking lot

KCM- 5611/5511

2 MP

18x/22x Zoom High C/P

IP66

Superior Low Light Image Processor

• End user: TaTa power
• Installation: 2012~now
• Solution: 400 units KCM-5211E/100 units

KCM-7311 Case study at India

System design Hardware: 284 x KCM-5211E 128 x KCM-3911 Software: Milestone 79 sites in nation wide ACTi unified solution deploied to secure National Electricity Corporation Location: Sudan Project realization: Dec 2011

Impressive superior video quality Reliability of total solution

National Electricity Corporation in Sudan

Indoor/Outdoor AF Dome Camera

• Precision iris control
• 4MP 8fps; 1080pHD 15fps; ;

720pHD 30fps

• 4 cropped regions replaces

4VGA cameras

• Optical zoom 3.6x (f3.3-

12mm / F1.4)

• Auto Focus
• AWDR, 2D+3D DNR
• Defogging
• Edge enhancement
• Adaptive Profile
• IP66/Vandal proof

(KCM-7311)

4 MP

Remotely Zoom Image Processor

Best Applications

• Bank teller window
• Store surveillance
• Entrance

Monitoring

KCM- 3311/7311

P-iris

Outdoor application

• End user: Bamboo Mart
• Installation: from Aug 2012 unit now

Case Study-Thailand

Each Site is about 10-11 units.

• 4 units TCM-1111
• 6 units KCM-3311/1 unit

KCM-3911

• NVR 3.0 under 16 channels free!

Benefit to use ACTi solution:

a. Unified solution no integration issue b. KCM-3911 offers wide coverage c. KCM-3311 offers good clarity and flexible zoom function d. TCM-1111 is cost effective MP

• utdoor selection

e. NVR 3.0 gives friendly inter face and support iOS system.

Indoor PTZ

• 1080p HD 15fps;
• 720p HD 30fps
• Optical zoom 18x (f4.7-84.6

mm / F1.6 ~ 2.8)

• Auto Focus
• Autoflip
• AWDR, 2D+3D DNR
• Defogging
• Edge enhancement
• Adaptive Profile
• 0.05Lux at F1.6
• DC 12V( included)
• High POE Injector(Optional)

2MP

18x PTZ Image Processor

Best Applications

• Bank
• Hotel
• Government
• Warehouse
• Transportation

KCM- 8111/8211

Sensitivity Power Supply Click for Video (need Internet)

IK10/ IP66

VMS solution

NVR 3.0

• 16 channels free,

up to 64 ch

• up to 64 channels

Recording

• Support E-

maps/PTZ/Event recording/Speed up/

• Support iOS,

Remote access

ENR-1000

• 4 channels

Recording

• 4 channels

1080P display

• 4 channels

1080p playback

• support DHCP

server

• 2 SATA HDD
• HDMI 1080P

Monitor support

ENR-1100

• 9 channels-

Recording

• 4 channels

1080P display

• 4 channels

1080p playback

• support DHCP

server

• 2 SATA HDD
• HDMI 1080P

Monitor support

GNR-3000

• Recording server
• 64 channels free
• Remote

client/Mobile Client supports

• Support ISCSI

NAS/eSATA

• Extra 4 HDD bays

New Software Base NVR

NVR 3.0

Up to 64 channels synchronized playback Instant playback in live view window

• Manage up to 64 IP cameras
• PTZ and speed control, preset

points and tours

• E-maps with camera icons and

mini live view

• Scheduled, even triggered, and

manual recording

• Unlimited number of remote

clients using web browser, mobile device, or PC installation program

Software Network Video Recorder (NVR) v3.0

Firewall Friendly

Use HTTP port 80 only NVR 3 NVR 2.3 SI need to open ports in Firewall

• Control port 6001
• Stream port 6002
• Search port 6005/6006

Stable Y Easy Use Easy Maintain Y

Instant Playback

• Playback in live view page

– One click away only

• Pop out window

– Will not miss either live view

• r playback
• Snapshot available

• Unified account & password for corporate user
• Easy management & maintenance

– If account is removed from AD, no need to remove again in NVR server

• Higher security level

– Authentication at AD server

Active Directory

NVR 3 xxxx@acti.com ACTi AD Server Authenticate Login

Stable Easy Use Easy Maintain Y

• Save storage & bandwidth and have full time recording simultaneously

– All evidences are preserved in an efficient way

• MJPEG – Can speed up from any FPS to full FPS

H.264/MPEG4 – Can only speed up from 1 FPS to full FPS

• Milestone’s speed up only applied on MJPEG

– MJPEG is not commonly used codec

Speed Up

No event Record with 1 FPS Event triggered Speed up triggered Record with Full FPS

Friendly User Interface

A. Right click function key B. Camera status

• n device tree

C. Event message panel

• D. Mouse-over

tips

64 ch Sync Playback

Time based search bar Synchronized & continuous playback

ACTi NVR 3.0 vs Others

ACTi NVR3 MileStone NUUO Active Directory Server V V V Instant Play Back V V V Over 4 Channels Play Back V V V User Friendly UI with Professional Functions V V V Speed UP V V V Unified Solution V Flexible Price V *Professional Level NVR With Free Bundle 16 Channels *Upgrade Version up to 64 Channels *Installation within 1 minutes with only 5 clicks *Unified Solution with worry-free one stop shopping and support

New Hardware based NVR

ENR –series 4 ch/9ch/16 ch

Model ENR-1000 ENR-1100 ENR-2000

• Max. Camera

4 9 16

• Max. Bitrate

16 Mbps 36 Mbps 48 Mbps

• Max. fps

4 channels at 1080p/30fps 9 channels at 1080p/30fps 16 channels at 1080p/30fps HDD interface Maximum 2 SATA disks Maximum 2 SATA disks Maximum 4 SATA disks Display port HDMI HDMI HDMI DHCP support Yes Yes Yes

New! ENR series

Q2 2013

Compare for open platform (4ch)

Spec Comparison

ACTi Nuuo QNAP

Model ENR-1000 NE-2040 VS-2004 Pro Channel 4 4 4 Local display Yes, HDMI No VGA Auto Setup Yes No No Mobile client iOS, Android iOS,Android iOS,Android CMS support Yes Yes Yes Remote Client Yes Yes Yes

ACTi v.s. NUUO v.s. QNAP

Compare for open platform (9ch)

Spec Comparison

ACTi Nuuo QNAP

Model ENR-1100 NE-4080 VS-2008 Pro Channel 9 8 8 Local display Yes, HDMI No VGA Auto Setup Yes No No Mobile client iOS, Android iOS,Android iOS,Android CMS support Yes Yes Yes Remote Client Yes Yes Yes

ACTi v.s. NUUO v.s. QNAP

Software Product Position

GNR-3000 NVR 3.0

Standalone NVR ENR-2000

HDMI

Q2 2013

Standalone NVR ENR-1100

Standalone NVR ENR-1000

Single Site with Multiple Channels 64ch Single Site Small-CH 16ch 9ch 4ch

Software based NVR Hardware NVR

16 ch free in NVR 3.0

HDMI

ACTi and 3rd party Vendor VMS Partners – Partial List

ISV + Axis Unified solution Open Platform Panasonic Bosch Mobotix Verint Indigo Vision

ACTi NVR + ACTi Camera

Vivotek + NUUO 64 channels

Milestone + Axis Penetration Alternative Free Bundled

ACTi Unify Solution Win Win

Win Project with ACTi Solution

Q & A

Enjoy Your Life!!

Thank You!
