Achieving High Throughput and Scalability with JRuby

Fernando Castano fernando.castano@sun.com Sun Microsystems

Agenda

• What is Project Kenai
• Early tests and re-architecture
• How, where and what we benchmark
• Tuning our stack
• References
• Q&A

Project Kenai (Kenai.com)

• Project Kenai is a platform for:
• Developer Collaboration and Tools as a Service
• Enables buildings communities for “connected developer”
• Integrated collaboration services stack
• We develop Project Kenai using Kenai
• Features: (per project)
• SCM (SVN, Hg)
• Bug Tracking
• Forums
• Wiki
• Mailing Lists

First Design: Junction1

wiki forum jira svn hg bugzilla issues scm xml tender junction 1 Apache2 xml sympa lists Services Solr search auth api html

Simple Test: Junction1

• why so slow?
• mpstat+jstack
• too chatty
• XML expensive
• json slow too
• CPU hungry
• no CPU scaling

Improved Design: Junction2

wiki forum jira svn hg bugzilla issues scm Apache2 sympa lists junction2 Solr search auth api/html services

Simple Test: Junction2

• no chatter
• better CPU

usage

• CPU scales
• much better

Infrastructure

• Sun Fire T2000 (web and app tier)
• 8 cores x 4 threads @1.4Ghz
• Sun Fire X4500 (storage)
• quad AMD core, 9.7 TB mirrored, NFS server
• opensolaris nevada 70b
• containers
• smf
• zfs solaris feature
• storage pool with RAIDZ
• nfs protocol
• snapshots
• coolstack and blastwave packages (~lamp stack)

Workload Definition

• statistics from one of Sun's busiest collaboration sites
• less than 2,000,000 trans/month (46 trans/min)
• less than 800 logins/day
• extracted mix of activity (R/W = 80/20)
• Requirements
• Avg response time for 90% in stdy state less and 2 sec
• 500 projects and 1000 concurrent users
• match 80/20 mix
• achieve at least 2000 trans/min
• randomized activities for each user
• don't get static content (images, jsp, etc)
• no think time for now

Kenai Benchmark Kit

• jmeter chosen (vs Faban and loadrunner)
• gnuplot + light scripting for reporting
• beanshell vs TCP server (for forking unix commands)
• not requesting embedded objects (no cache)
• dtrace very helpful (permspace, io, mysql, etc)
• collect mpstat, vmstat, trapstat, netsum, iostat, ... (~ nagios)
• save everything and document changes
• scale 1 dimension at the time
• stickshift profiling (or newrelic) very useful

Baselines

• single thread
• exclusive operation
• prstat (-L -m -p)
• jstack
• stickshift

Operation comment Login 0.45 Logout 0.26 home 0.16 people 0.17 update profile internal error project create internal error projects 0.43parameter show=5 hg_del 5.30 hg_pull 3.10recurring proxy error hg_push 6.90 svn_del 5.04 svn_pull 3.05recurring proxy error svn_push 12.06 Forum_Edit 1.03 0.64 1.90 Wiki_Post 1.18 Wiki_verify 0.68 Wiki_view 0.42 Baselin e (sec) OASIS-1625 (out of memory) Forum_Topic_ Show Forum_Topics _List short wiki, regex bug, 401 returned & jsession lost view + assertion

• verhead

Response Time vs users

trans/min vs users

CPU vs users

Application server at peak

• vmstat and prstat

2 Application servers

High Availability strategy

• Web tier
• 2 servers with Apache2 (hardware load balancer)
• Application tier
• 2 or more servers (Appache2 in web tier load balancing)
• 1 glassfish with 6 domains (jvms) in each app server
• Feature server (sympa, bugzilla, search)
• active-standby with manual failover (chg DNS alias)
• mysql 5.0.45 database
• active-standby with manual failover (chg DNS alias)
• local database (146G), replication coming soon
• NFS server
• active-standby with rsync and manual failover (DNS chg)

Low Level Tuning

• Opensolaris (70b)
• maxusers=4096
• tcp tuning in web tier (spec.org T2000 publications)
• use FX scheduler in app tier: priocntl -s -c FX -i all
• 8k blocksize for zfs pool in NFS server
• java 1.6
• server, LargePageSizeInBytes=256m
• parallelGC, AggresiveOpts, MaxPermSize=512m
• Xmx=Xms=2560m

More Tuning

• Apache 2.2.8
• built our own (studio compiler with -fast)
• using pre-fork module (mpm not so good for us)
• MaxClients = ServerLimit = 600
• 4 virtual hosts to serve static content (jpg, jsp, etc)
• proxy balancing with sticky sessions
• Memcache 1.1.12
• so far only for SCM permissions
• adding as needed if SQL becomes heavy

Jruby 1.1.3 (Rails 2.1) Tuning

• need many runtimes for T2000
• First approach: 1 32bit jvm with 20 runtimes
• runtimes are memory hungry (20MB + objects)
• expensive and frequent full GCs
• performance bad
• Second approach:
• use 6 to 8 glassfish domains per app server
• deploy only 5 runtimes per domain (jvm)
• full GC under control and use more mem (32G available)
• compile.mode=JIT
• bjectspace.enable=false
• bugs fixed: permspace, joni, activerecord (dtrace+prstat)

Glassfish Tuning

• 5 acceptor-threads
• 5 request-processing threads (and warbler)
• connection-pool validation = table
• accepts lots of connections
• connection-pool queue-size-in-bytes=30000
• connection-pool max-pending-count=30000
• Dcom.sun.enterprise.server.ss.ASQuickStartup=false

mysql 5.0.45 Tuning

• So far Query cache hit 98%
• CPU usage < 10%
• Planning to move to 64bit mysql
• 32GB of RAM available for buffers
• ZFS/NFS slow compared to FC storage array

Benchmark constantly or ...

Project Kenai live

References

• Nick Sieger (team leader)
• http://blog.nicksieger.com
• Dtrace toolkit
• http://opensolaris.org/os/community/dtrace/dtracetoolkit/
• More Kenai performance details
• http://jfdo.blogspot.com
• Project Kenai
• http://kenai.com
• Solaris Inernals (Richard McDougall)
• http://www.solarisinternals.com

Q&A
