ABDA AGM Red Deer 2013 Anker Andersen Update

Todays Agenda :

• Update Alberta installations
• Compact design including crushers
• Recent projects
• Customer stations for Albertans
• Questions and answers

Update Anker Andersen Bottle Depot machines, Alberta.

• St. Albert Bottle Depot, St. Albert. In operation May 2012.
• North Refund Centre, Edmonton. In operation February 2012.
• Plus 2 Bottle Depot, Grande Prairie. In operation February 2012.

These machines have now combined more than 10.000 hours of

• peration !!

• HLZ DD with Duo-Disc Inliner and material sorting of aluminum, bimetal,

clear PET,colored plastics and glass. Placed in the sorting area.

• Feeds directly into compactors for aluminum and clear PET
• Capacity : 2-300 containers per minute.

HLZ high-speed counting and sorting system

St Albert bottle depot

• HLZ DD with Duo-Disc Inliner and material sorting of aluminum, clear PET and

colored plastics. Placed in the sorting area. Feeds directly into compactors for aluminum and clear PET Capacity : 2-300 containers per minute. HLZ high-speed counting and sorting system

• Frontline : 3 Customer stations as Mono-Disc inliners with Count-Only.
• Sorting Area : 1 HLZ DD with material sorting – aluminum, bimetal, PET-Clear,

coloured plastic and glass.

• On the fly change of sorting stations for aluminum cans and clear PET.
• Capacity : 2-300 containers per minute.

HLZ high-speed counting and sorting system

Some highlights :

• Improved efficiency (up to 25-40% measured in GP)
• Higher throughput (volume up without staffing up)
• Low downtime (In 20 months no stops over 2 hours at NRC)
• Totally reliable counting and sorting

HLZ high-speed counting and sorting system

More highlights :

• High capacity : Up to 100.000 units per day demonstrated, 70-

80.000 per day on a regular basis.

• With compactors : substantial reduction in required storage

area.

• Reliable service available (NRC/Lawrence)

HLZ high-speed counting and sorting system

So we can conclude : The Anker Andersen counting and sorting equipment has with now more than 10000 hours of operations fully demonstrated that it is suitable to install in larger Albertan bottle depots. It improves efficiency, throughput and reliability in a cost- effective manner.

• St. Albert : “Thanks to the AA Machine both my brother and I

have been able to go on vacation this year” HLZ high-speed counting and sorting system

HLZ DD C MS Standard Layout Capacity : 10 to 30 million per year

HLZ DD C MS Compact model with NexGen compactors

Compact design means :

• Less footprint (save your warehouse space)
• Simple and efficient compactors without additional conveyors
• Better pricing for the compactors (talk with NexGen about this)

Only problem :

• Access to the Duo-Disc (Walkways/ladders)

NWT, Hay River, QA-project

NWT Hay River QA Project Scope :

• MD-feeder, extended version
• Mono-Disc
• Light curtain for odd objects

Delivery : September 2013.

Allstate Recycling, New York

Allstate Recycling, New York

Allstate Recycling, New York Scope :

• Complete glass in-feed with broken-glass removal
• Duo-Disc with table-top steel belts
• Scanner unit with bar-code recognition
• Sorting line with 6 sorting stations
• Delivery : September 2013

Envirobank, Darwin, NT, Australia

Darwin, Northern Territory, Australia Scope :

• Complete glass in-feed with broken-glass removal
• Complete PET/Can in-feed with bulk-feeder
• Duo-Disc
• Scanner unit with bar-code recognition
• Sorting line with 6 sorting stations
• 3 Light curtains for odd objects
• Delivery : January 2014

Mohawk Redemption Center Ilion, New York

Mohawk Redemption Center, New York State, USA Scope :

• Mono-Disc feeder with extended hopper
• Light curtain for odd objects
• Receipt printer
• Mono-Disc
• Sorting line with sorting stations : aluminum, small PET, large

PET Delivery : November 2013

The customer receipt

Customer stations for bottle depots in Alberta. Why ? At least 2 important reasons: 1. To improve customer experience 2. To minimize manual counting and sorting

.

10 cent containers HLZ friendly 92% of all containers 25 cent containers HLZ friendly 7% of all containers 10 cent containers Not friendly Mainly drink pouches 1% of all containers 25 cent containers Not friendly Less than 1%

First conclusion : Due to the variety of containers in the deposit system it is necessary to have a dedicated operator to operate the customer station. Second conclusion : We will use light curtains to count the difficult objects.

Customer station without sorting

10 cent 92% 25 cent 7% Pouches 1% 25 cent Rest

Customer station with aluminum sorting

10 cent 35% 25 cent 7% Tetra 5% Pouches 1% 25 cent Rest Aluminum 52%

Customer station with sorting of aluminum and clear PET

25 c 3% 10 c 13% Aluminum 52% Large PET Clear 4% Small PET Clear 22% Tetra 5% Pouches 1% 25 c Rest

A few comments :

• The remaining unsorted 10 cent containers will for the most part

be glass bottles. They are delivered in carton packs and are taken around the machíne.

• The unsorted fractions will have to be sorted manually. It is

however possible to use the machine for counting of the sorted fractions.

• Yearly capacity from 4 to 10 million containers per year per

machine.

• You can always start with 1 unit and see how it works before

adding the next units.

• You can start out with manual sorting and add the other

functions at a later time. With an AA customer station you will have :

• First class customer service
• Minimum manual sorting
• No manual counting

• At a payable price :
• Customer Station

CAD 60.000

• With aluminum sorting

CAD 72.000

• With aluminum and PET sorting

CAD 90.000 Plus delivery, installation and spare parts.

• Sorting line new designed with free-hanging

photo-cells and sorting stations for better handling of tetra and gable-top and much easier maintenance.

You can count on us!
