A Wormhole Router Design progress report

Wei Song 30/07/2009

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Content

• Motive and Plans
• Wormhole router

– Channel Slicing, motivation – Lookahead, critical cycle – Implementation

• XY/Stochastic routing scheme

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Why a wormhole router now

• Easy
• Smallest cycle period
• Early performance

estimation

• Proof of channel

slicing

wormhole SDM

Larger crossbar / switch network

QoS Fault-tolerance

Larger route scheduler Larger Input/Output buffer controller

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Plan for Router Design (1)

• Wormhole router

– Speed estimation, basic design flow – Channel slicing, lookahead pipeline

• Spatial Design Multiplex (SDM) router

– Utilizing channel slicing (provide virtual circuit) – M sub-channels on a port, crossbar*M – Benes, Clos switch network (ATM) – Route scheduling in the multi-stage switch

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Plan for Router Design (2)

• Dynamic Link Allocation

– Allocate idle sub-channels to active virtual circuits to reduce frame latency – Arbitration planning, crossbar reconfiguration and buffer planning

• Fault-tolerance

– Error detection, deadlock recovery, route scheduling algorithm

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Plan for Router Design (3)

• QoS

– Virtual circuit is latency and bandwidth guaranteed (weak if dynamic link allocation is used) – Best Effort is a problem – Priorities for virtual circuit setup (reduce circuit setup time for high priority services)

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Content

• Motive and Plans
• Wormhole router

– Channel Slicing, motivation – Lookahead, critical cycle – Implementation

• XY/Stochastic routing scheme

2014/5/13 Advanced Processor Technology Group The School of Computer Science

ChSlice: motive

C C C C

2-bit 2-bit

CD CD

16

d_i d_o ack_o ack_i

8 4 ack 16-bit ack of sub-channels

Advantages: data on all sub-channels are synchronized, ease the time division multiple access (TDMA) techniques, such as virtual channel and TDMA Drawbacks: low speed (66% on CD)

2014/5/13 Advanced Processor Technology Group The School of Computer Science

ChSlice: implementation

H H H H H H D D D D D D D D D D D T D D D D D T D D D D D T D D D D D T D D D D D T D D D D D T

sub-channels time head routing data

C C

2-bit 16

d_i0 ack_i0 C C

2-bit

d_i15 ack_i15 d_o0 ack_o0 d_o15 ack_o15

2014/5/13 Advanced Processor Technology Group The School of Computer Science

ChSlice: conclusion

• Advantage

– fast

• Overhead

– extra controllers – larger wire-count

• No TDMA techniques but SDM is easy.

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Content

• Motive and Plans
• Wormhole router

– Channel Slicing, motivation – Lookahead, critical cycle – Implementation

• XY/Stochastic routing scheme

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Lookahead: pipeline style

N CD N+1 CD N+2 CD

Di DN AN DN+1 AN+1 Do Ao Ai

data data data data data data data data N CD N+1 CD N+2 CD Di Ai DN DN+1 Do AN AN+1 Ao

Di DN AN DN+1 AN+1 Do Ao Ai

data data data data data data data data

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Lookahead: conclusion

• Advantage

– fast

• Disadvantage

– not QDI – a small area overhead

N CD N+1 CD N+2 CD Di DN AN DN+1 AN+1 Do Ao Ai

data data data data data data data data

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Lookahead: critical cycle

pipeline pipeline pipeline pipeline pipeline

arbiter ack from

• ther outputs

data from

• ther inputs

crossbar input buffer

• utput buffer

pipeline pipeline pipeline pipeline pipeline

arbiter ack from

• ther outputs

data from

• ther inputs

crossbar input buffer

• utput buffer

long line between routers d_i ack_i d_o ack_o

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Lookahead: implementation

N CD N+1 CD N+2 CD N+1 CD crossbar

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Content

• Motive and Plans
• Wormhole router

– Channel Slicing, motivation – Lookahead, critical cycle – Implementation

• XY/Stochastic routing scheme

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Router: structure

arbiter arbiter 5 input ports 5 output ports ctl ctl

80 16 80 16 80 16 80 16

d_i_0 ack_i_0 d_i_4 ack_i_4 d_o_0 ack_o_0 d_o_4 ack_o_4

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Router: data path

input buffer crossbar

• utput buffer

ip_d

ib_d ic_d

ib_pa ib_a

ip_a

rt_err acken gnt

• c_a

ic_a

• p_a
• p_d
• b_d
• c_d
• b_pa
• b_a

eof 3 2 1 eof 3 2 1 eof 3 2 1

ic_da eof acki

ip_d+ ib_d+ ic_d+ ip_a+ ip_d- ib_a+ ib_d- ip_a- ic_d-

• c_d+
• b_d+
• b_pa+
• p_d+
• b_a+
• c_a+

ic_a+ ib_pa+ ib_a-

• c_d-
• b_d-
• b_pa-
• c_a-

ic_a- ib_pa-

• p_d-
• p_a+
• p_a-
• b_a-

ic_da+ ic_da-

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Router: layout

• Faraday 130nm Technology
• 32-bit, 5 ports, XY routing algorithm
• 0.3x0.3mm (14.3K gates, 0.057mm2)
• Typical corner (25 oC 1.2V)
• Cycle period 1.7 ns (2.35GByte/s per port)

2014/5/13 Advanced Processor Technology Group The School of Computer Science

ChSlice and Lookahead

Speed: ChSlice 24.1% LH 17.2% Area: ChSlice 23.0% LH 5.3%

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Compare to other routers

• MANGO: 1.26ns; 0.12um; bundled data
• ANoC: 4ns; 0.13um; 1-of-4
• QNoC: 4.8ns; 0.18um; bundled data
• ASPIN: 0.88ns; 90nm; dual-rail & bundled data
• Our: 1.7ns; 0.13um; 1-of-4 & lookahead

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Speed vs. data width

QNoC Wormhole

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Content

• Motive and Plans
• Wormhole router

– Channel Slicing, motivation – Lookahead, critical cycle – Implementation

• XY/Stochastic routing scheme

2014/5/13 Advanced Processor Technology Group The School of Computer Science

XY/Stochastic

• Motive

– Two routing algorithm is complicated – The deadlock problem – The involvement of network interfaces – Keep router simple

• Solution

– Router: XY – Network interface: generate, consume, or forward (random)

2014/5/13 Advanced Processor Technology Group The School of Computer Science

XY/Stochastic (request path)

M M

XY/Stochastic Router Only

2014/5/13 Advanced Processor Technology Group The School of Computer Science

XY/Stochastic (ack path)

M M

Same Path Single Jump

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Compare

• Rely on routers

– A larger router (Special router design) – Longer routing overhead – Deadlocks – Shorter search time

• XY/Stochastic routing

– Smaller router (normal router design) – Shorter routing time – Only deadlocks caused by errors – Longer search time (higher priority by QoS)

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Conclusion

• Router design plan

– Wormhole router is the first step

• Wormhole router

– Channel slicing – SDM is better than TDMA for asynchronous routers

• XY/Stochastic routing

2014/5/13 Advanced Processor Technology Group The School of Computer Science

Question?
