SLIDE 1

A Technology Leap – Air Barrier Integration into Building Envelopes

A research project with the Air Barrier Association of America Inc. Presented by:

Mr. Laverne Dalgleish

SLIDE 2

A Technology Leap – Air Barrier Integration into Building Enclosures

 Why is a air barrier needed?

SLIDE 3

A Technology Leap – Air Barrier Integration into Building Enclosures

 Hypothesis

Air barrier systems should be incorporated in

every building as they are cost effective by saving a significant amount of energy (in the range of 30% to 40%) and incorporating air barriers assist in solving moisture problems and indoor air quality problems, not create them

SLIDE 4

A Technology Leap – Air Barrier Integration into Building Enclosures

 How leaky are the average building?

9-10 L/(s·m²) @ 75 Pa across the US Cost effective to reduce the air leakage to

between 0.75 L/(s·m²) @ 75 Pa

Some propose 0.02 L/(s·m²) @ 75 Pa Current proposal is 2.00 L/(s·m²) @ 75 Pa Either way major improvements can be made

SLIDE 5

A Technology Leap – Air Barrier Integration into Building Enclosures

 Barriers

Air barriers are new technology to most of the

construction industry

Energy savings although agreed to by most

people, cannot be defended scientifically

Estimation of air leakage of existing practices

has not been confirmed

SLIDE 6

A Technology Leap – Air Barrier Integration into Building Enclosures

 Barriers

Interaction of different air barrier materials is

not understood

Installation practices, although understood to

be key, have not be researched to determine impact of improper installations

Action of air leakage on moisture (liquid and

vapor) has not been quantified

SLIDE 7

A Technology Leap – Air Barrier Integration into Building Enclosures

 Barriers

Common comment is that we should not

make buildings too tight

Air tightness is blamed for mold and mildew

problems

Air tightness is blamed for indoor air quality

problems

SLIDE 8

A Technology Leap – Air Barrier Integration into Building Enclosures

 Opportunities

Current air barrier market is non-existent (less

than 10% same say less than 1%)

States have added or are considering adding

air barrier requirements to their code

Market growth expected to be exponential

SLIDE 9

A Technology Leap – Air Barrier Integration into Building Enclosures

 Challenges

Air barrier industry needs to address these

barriers and grow the industry through education or misconceptions will grow and could hamper or destroy the industry

SLIDE 10

10

Baseline Air-Leakage Baseline Construction Required Modifications Target Air-Leakage

NIST study establishes no relationship between any of these points

Construction Costs Energy Savings

SLIDE 11

A Technology Leap – Air Barrier Integration into Building Enclosures

 Challenges

“Air Barriers cannot be dealt with without

understanding that they are part of a wall assembly” (or roof assembly, foundation assembly, etc.)

N.B. Hutcheon’s CBD-48 - Require

remen ents ts for Ex Exterio rior r Walls

SLIDE 12

A Technology Leap – Air Barrier Integration into Building Enclosures

 Key Properties (in order of importance)

MoistureLiquid – Water Resistive barrier Air – Air barrier Heat – Heat barrier (Insulation) MoistureVapor – Vapor barrier

SLIDE 13

A Technology Leap – Air Barrier Integration into Building Enclosures

 What is an Air Barrier?

Depends on what are you talking about

 Air barrier in general  Air barrier material  Air barrier component  Air barrier sub-assembly  Air barrier assembly  Air barrier system

SLIDE 14

A Technology Leap – Air Barrier Integration into Building Enclosures

 Types of Air Barrier Materials

 Self-Adhered Sheet Materials

SLIDE 15

A Technology Leap – Air Barrier Integration into Building Enclosures

 Types of Air Barrier Materials

 Fluid Applied Materials



Liquid Applied Materials

SLIDE 16

A Technology Leap – Air Barrier Integration into Building Enclosures

 Types of Air Barrier Materials

 Fluid Applied Materials



Medium Density (min 28 kg/m³) Spray Polyurethane Foam – Rigid Closed Cell

SLIDE 17

A Technology Leap – Air Barrier Integration into Building Enclosures

 Types of Air Barrier Materials

 Mechanically Fastened



Boardstock Materials

SLIDE 18

A Technology Leap – Air Barrier Integration into Building Enclosures

 Types of Air Barrier Materials

 Mechanically Fastened



Film Materials

SLIDE 19

A Technology Leap – Air Barrier Integration into Building Enclosures

 Types of Air Barrier Materials

 Thermofusable

SLIDE 20

A Technology Leap – Air Barrier Integration into Building Enclosures

Air permeance

 Air that travels though a material

Air leakage

 Air that goes around the material and

travels through holes

SLIDE 21

A Technology Leap – Air Barrier Integration into Building Enclosures

 Air Barriers

Stops the air flow through materials (air

permeance) and through the holes (air leakage)

A building will always have pressure

differences, we cannot control that so we must control the holes

SLIDE 22

A Technology Leap – Air Barrier Integration into Building Enclosures

Pressure differences are created by

 Wind

SLIDE 23

A Technology Leap – Air Barrier Integration into Building Enclosures

Pressure differences are created by

 Stack effect

SLIDE 24

A Technology Leap – Air Barrier Integration into Building Enclosures

Pressure differences are created by

 Mechanical equipment

SLIDE 25

WIND PRE RESS SSURE RE FAN AN PRE RESS SSURE RE WIND PRE RESS SSURE RE ( UNDE DER SU SUCT CTIO ION ) ST STAC ACK K PRES RESSURE ST STAC ACK K PRE RESSURE

SLIDE 26

Air Flow

Direction of Air Flow CONDENSATION (at cold sheathing) Hole AIR PATH

SLIDE 27

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 28

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 29

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 30

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 31

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 32

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 33

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 34

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 35

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 36

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 37

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 38

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 39

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 40

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 41

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 42

42

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 43

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 44

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 45

A Technology Leap – Air Barrier Integration into Building Enclosures

 Meeting the Challenges and Addressing

the Barriers

A three year research project headed by the

Air Barrier Association of America Inc. which includes industry members, US Department of Energy, Oak Ridge National Laboratories and Syracuse University.

SLIDE 46

A Technology Leap – Air Barrier Integration into Building Enclosures



The Project



Consists of 8 phases



Project administration (reporting, project administration)



Sub-system and wall characterization



Material property characterization



Laboratory wall testing



Advanced moisture engineering modeling



Exterior field testing of air barrier systems



Wall optimization



Information technology transfer, publications, etc.

SLIDE 47

47

Three critical competencies

Modeling Field Lab

SLIDE 48

A Technology Leap – Air Barrier Integration into Building Enclosures



The Project



Project administration (reporting, project administration)



All participants will be kept informed on the progress, the issues raised and discussion on solutions



All information will be restricted to participants until there is agreement for part or all of the information to be released

SLIDE 49

A Technology Leap – Air Barrier Integration into Building Enclosures



The Project



Material property characterization



Each of the participants shall submit materials to the project



The research project covers self adhered membranes, fluid applied membranes and mechanically fastened membranes



All materials shall meet the requirements to be an air barrier material [0.02 L(s·m²) @ 75Pa pressure difference]



Materials shall be grouped after their characterization

SLIDE 50

A Technology Leap – Air Barrier Integration into Building Enclosures



The Project



Sub-assembly and wall characterization



All participants shall define the assembly, the sub- components of the assembly and issues that impact the assembly

For example: Do a lot of staples or a few staples

have a significant impact on the air permeance of an assembly? How critical is the initial bond to the substrate for self adhered membranes?



All participants have the opportunity to pose their questions and challenges

SLIDE 51

51 Laboratory Analysis System & Sub-System Characterization Thermal + Water + Air Leakage

A Technical Leap - Air Barrier Integration to Building Enclosures

Deliverables Air Flow Characterization Water Retention & Drainage

1) Water WRB Retention 2) Drainage Water Performance 3) Drainage Drying + Solar 4) Wall Wetting and Drying

Thermal Testing

1) Air Leakage through Wall system 2) Flow at joints/interfaces 3) Air flow distribution

10 Walls 6 - Subsystems 10 Walls 4 Walls

SLIDE 52

A Technology Leap – Air Barrier Integration into Building Enclosures



The Project



Material property characterization



Material properties that deal with heat, air and moisture (liquid and vapor) will be included

SLIDE 53

A Technology Leap – Air Barrier Integration into Building Enclosures



The Project



Sub assembly testing



Participants are establishing specific installation issues for testing.

SLIDE 54

54

Laboratory Analysis System & Sub-System Characterization Thermal + Water + Air Leakage

A Technical Leap - Air Barrier Integration to Building Enclosures

Responsibility Air Flow Characterization Water Retention & Drainage

ORNL + University

Thermal Testing



Sub assembly testing



Participants will establish specific installation issues for testing.

SLIDE 62

SLIDE 63

SLIDE 64

A Technology Leap – Air Barrier Integration into Building Enclosures



The Project



Advanced moisture engineering modeling



Information gained from the material characterization and the building assembly testing shall be used to provide the inputs into the computer modeling program



At this point, different scenarios can be run to determine whether a specific building assembly is providing the expected results



Potential concerns can be isolated and solutions proposed

SLIDE 65

65

SLIDE 66

A Technology Leap – Air Barrier Integration into Building Enclosures



The Project



Exterior field testing of air barrier systems



Parallel to the above tasks, a test house shall be constructed



Participants were consulted to determine size, shape, type and location



Building assemblies will undergo a two year field exposure test where continuous monitoring will confirm expected results or show potential challenges.

SLIDE 67

A Technology Leap – Air Barrier Integration into Building Enclosures



The Project



Wall optimization



Information being fed back shall result in proposed changes to material characteristics, design details and installation practices to optimize various materials



Participants shall have the opportunity to confirm material performance or adjust material requirements and have a minimum of a three year jump on non- participants



Some redesigns of materials and of assemblies shall be retested to confirm expected results shown by the modeling

SLIDE 68

68 Weather Data Laboratory Analysis System & Sub-System Characterization Thermal + Water + Air Leakage Define 18 Building Envelope Walls for Air Barrier & Energy Efficiency Analysis Develop Field Data for 18 Wall Systems Validate MOISTURE-EXPERT Model HYGROTHERMAL MODELING System Optimization Parametric Investigations Material Properties Development of Air Barrier Guidelines for Energy Efficient Wall Systems

A Technical Leap - Air Barrier Integration to Building Enclosures

Assumption: 18 wall Laboratory Characterization Field Analysis Model Validation Analysis for USA Climate Zones Guideline Development

SLIDE 69

69

Define 18 Building Envelope Walls for Air Barrier & Energy Efficiency Analysis Executive Committee (1-ABAA, 1-ORNL) ABAA DOE/ORNL ABAA Industry Members Steering Committee X1 Xn X2

….

Scientific Members Steering Committee DOE BA SU

….

X1...Xn = Industry Members DOE = Department of Energy SU = Syracuse University BA = Building America

A Technical Leap - Air Barrier Integration to Building Enclosures

SLIDE 70

70

Develop Field Data for 18 Wall Systems

A Technical Leap - Air Barrier Integration to Building Enclosures

Committee for Test Building Construction (DOE, ABAA, INDUSTRY, University) Responsibility: Mr. Dalgleish (ABAA) Site Location & Preparation Architecturual Design/ Flexible & Interchangeable Wall ABAA ABAA Site Legalities & 3 year ABAA use with option for 3 additional years then (60 % SU and 40 % ORNL) ABAA Contractor Selection & Building/Inspection ABAA …………..Continued

SLIDE 71

71

Develop Field Data for 18 Wall Systems

A Technical Leap - Air Barrier Integration to Building Enclosures

Committee for Test Building Construction (DOE, ABAA, INDUSTRY, University) Responsibility: Mr. Dalgleish (ABAA) Selection of Walls Construction of Walls 1st set year 1 2nd set year 2

ABAA

Instrumentation & Data Acquitition Monitoring and Reporting

Page 2/2

Industry ABAA ORNL ORNL ORNL SU

SLIDE 72

72 Develop Field Data for 18 Wall Systems

A Technical Leap - Air Barrier Integration to Building Enclosures

Multiplexer Power supply Modem CR10X DAS

Sensor Accuracy Sensitivity Repeatability Supply Voltage Fenwall Uni-curve 10K ohm thermistor ±.2%

±0.2%

2.5Vdc Honeywell Hy-Cal Humidity Sensor HIH-3610 Series ±2%

±0.5%

5Vdc Wood moisture content sensors ±2% within 8- 30% MC

±2%

12Vdc Heat Flux Transducer (Concept Engineering Model F-002-4

(1.8·Btu/Ft2··Hr)/Mv
Outdoor RH (Vaisala

CS500) ±3%

12Vdc

Wind Speed (R. M. Young Model 05305 Wind Monitor) ±.4%

Wind Direction (R. M.

Young Model 05305 Wind Monitor) ±3°

12Vdc

Rainfall (Texas Electronics Model TE525) ±1%@1”/hr

Solar pyranometer, vertical

(LI-Cor LI200X ±3% 0.2·kW·m-2·mV-1

Solar pyranometer,

horizontal (Kipp & Zonen SP-Lite ±3% 10µV·W-1·m-2

Campbell Sci CR10X w/32

Channel multiplexer ±0.1% of FSR

12Vdc

Instrumentation & Data Acquitition

Wall Sensors

Temperature sensors RH sensors Tracer Gas sensor Moisture Content sensors Pressure Sensors Vertical Rain Gauges Solar

Weather Station

Temperature, RH Solar Radiation Rain, Solar Pressures

SLIDE 73

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 74

A Technology Leap – Air Barrier Integration into Building Enclosures

SLIDE 75
