A TALE OF TWO SOLAR ARRAYS Presented by : Luc Savoie Apr 2018 4/25/2018 SESA Home Owners Experience 2 SA1 2008 4/25/2018 SESA Home Owners Experience 3 SA1 SPECIFICATIONS Year 2008 Size 7.2 kW grid connected Modules

slide-1
SLIDE 1

A TALE OF TWO SOLAR ARRAYS

slide-2
SLIDE 2

SESA Home Owners Experience

Presented by : Luc Savoie Apr 2018

4/25/2018 2

slide-3
SLIDE 3

SESA Home Owners Experience

SA1 2008

4/25/2018 3

slide-4
SLIDE 4

SESA Home Owners Experience

  • Year

2008

  • Size

7.2 kW grid connected

  • Modules

36 X 200 W

  • Module Type

Sanyo HIP-200BA3

  • Inverter

SMA Sunny Boy 7000

  • Monitoring

None (only inverter read

  • ut)
  • Wiring

6 strings to distribution box in attic

  • Orientation

Solar Azm 154 deg

  • Roof Slope

30 degrees

  • Install Time

2.5 days

  • Cost

$62,907

SA1 SPECIFICATIONS

4/25/2018 4

slide-5
SLIDE 5

SESA Home Owners Experience

SA2 2017

4/25/2018 5

slide-6
SLIDE 6

SESA Home Owners Experience

  • Year

2017

  • Size

6.48 kW grid connected

  • Modules

24 X 270 W (with P300

  • ptimizers)
  • Module Type

Canadian Solar CSK-270M

  • Inverter

Solar Edge SE6000A

  • Monitoring

Solar Edge Dashboard on line

  • Wiring

2 strings with optimizers

  • Orientation

Solar Azm 143 deg

  • Roof Slope

30 degrees

  • Install Time

2 days

  • Cost

$13,244 ($18,104 w/o rebate)

SA2 SPECIFICATIONS

4/25/2018 6

slide-7
SLIDE 7

SESA Home Owners Experience

INCENTIVES?

4/25/2018 7

slide-8
SLIDE 8

SESA Home Owners Experience

GROWTH OF SOLAR IN AB

4/25/2018 8 Courtesy of Gordon Howell

SA 2 SA 1

slide-9
SLIDE 9

SESA Home Owners Experience

SA1 2008 TRACKING

4/25/2018 9

slide-10
SLIDE 10

SESA Home Owners Experience

SA2 2017 TRACKING

4/25/2018 10

GUIDE TO USE DRYER

slide-11
SLIDE 11

SESA Home Owners Experience 4/25/2018 11

SA2 2017 TRACKING

slide-12
SLIDE 12

SESA Home Owners Experience 4/25/2018 12

SOLAR ARRAY CONCERNS

SNOW HAIL SQUIRRELS PIGEONS

slide-13
SLIDE 13

SESA Home Owners Experience 4/25/2018 13

NET BILLING VS NET METERING

Net Billing - Customers can sell any excess energy they generate back to the utility at pre-determined wholesale prices. Both consumption and generation are recorded and billed separately. As a result, customers get charged their full retail rate per kWh when they use energy from the grid, and are paid a wholesale price by their utility when they sell it back. Net Metering - Measures the energy customers generate each billing cycle. Sending excess electricity back to the grid accumulates kWh credits when your solar array generates more energy than you can use. Customers then get charged based on their net usage of kWh at the end of each billing cycle.

slide-14
SLIDE 14

SESA Home Owners Experience 4/25/2018 14

ENMAX ELECTRICITY BILL

slide-15
SLIDE 15

SESA Home Owners Experience

WHY DID I DO SOLAR?

4/25/2018 15

SA1 2008

  • Replacing roofing anyways, interested in solar
  • 3 early teen kids who learned a lot about solar
  • ROI – over 30 years ouch!
  • Could have bought a new vehicle, but….
  • Potential increase in energy price / savings
  • After doing EE, right thing to do

SA2 2017

  • 3 young adults who will be future leaders
  • ROI – reasonable 7 years!
  • Saving money – doing laundry when the sun

shines

  • NDP incentive program (recoup carbon tax)
  • Right thing to do, after doing EE!
slide-16
SLIDE 16

SESA Home Owners Experience 4/25/2018 16

FOR OUR CHILDREN’S FUTURE

slide-17
SLIDE 17

SESA Home Owners Experience 4/25/2018 17

thx
