Purified Water for El Paso: A Sustainable Water Future The Water Cycle Never Ends Condensation Transpiration Evaporation Precipitation Runoff Ground The earth has always had the same amount of water. Underground The River Desalination

slide-1
SLIDE 1
slide-2
SLIDE 2

Purified Water for El Paso: A Sustainable Water Future

slide-3
SLIDE 3

The Water Cycle Never Ends

The earth has always had the same amount of water.

Evaporation Precipitation Runoff Transpiration Condensation Ground

slide-4
SLIDE 4

The River

Underground Water

Desalination Water Reuse

Conservation

Future Resources

slide-5
SLIDE 5

Colorado New Mexico Texas

United States Mexico

Taos Santa Fe Albuquerque Socorro Las Cruces

El Paso

Juarez

  • Ft. Quitman
Texas Colorado New Mexico
slide-6
SLIDE 6

Helping the Water Cycle

  • EPWU has been treating

wastewater and reusing it for irrigation, industrial, and construction uses since 1963.

  • It’s known as “purple pipe” or

reclaimed water.

slide-7
SLIDE 7

Helping the Water Cycle

Since 1985, EPWU has been using reclaimed water treated to drinking water standards to recharge the aquifer

slide-8
SLIDE 8

2014 Summer Daily Peak

80 100 120 140 160 180 200 220 80 100 120 140 160 180 200 220

2014 Supply Forecast 2014 Peak Demand Forecast

River Water

MGD

Underground Water

slide-9
SLIDE 9

Daily Peak Without River Water

80 100 120 140 160 180 200 220 80 100 120 140 160 180 200 220

2014 Supply Forecast 2014 Peak Demand Forecast

Underground Water

slide-10
SLIDE 10

Daily Peak With Purified Water

80 100 120 140 160 180 200 220 80 100 120 140 160 180 200 220

2014 Supply Forecast 2014 Peak Demand Forecast

Purified Water Underground Water

slide-11
SLIDE 11

What is the Alternative?

  • Increased mining of aquifers
  • Increased desalination $$
  • Drastic conservation
  • Build massive pipelines = $$$$

Only purified water is sustainable

slide-12
SLIDE 12

Water used for irrigation will be treated AGAIN in a rigorous four step process to create high quality, purified water.

slide-13
SLIDE 13

Advanced Purified Treatment Process

Filters

Storage Source: Treated Water

Ultraviolet Light Membrane Filtration STEP 1 STEP 2 STEP 3 STEP 4 Disinfect

slide-14
SLIDE 14

How It Works

STEP 1

  • First, the water goes through

membrane filtration, the same technology that is used at our desalination plant.

slide-15
SLIDE 15

STEP 2

  • Water is treated with

ultraviolet light, the same technology that is used at some of our plants that treat river water.

How It Works

slide-16
SLIDE 16

STEP 3

  • Then, the water goes

through a filtration process, used at all of our treatment plants

How It Works

slide-17
SLIDE 17

STEP 4

  • Then, the water is

disinfected again.

How It Works

X X X X X

slide-18
SLIDE 18

The Result

  • This is a proven technology that works.
  • Purified water is safe to drink.
  • Purified water is some of the highest

quality drinking water produced.

slide-19
SLIDE 19

Wastewater Treatment Plants

Franklin Mountains

NEW MEXICO

EL PASO, TEXAS

Ciudad Juárez

Fort Bliss

Bustamante WWTP 8,000 acre/feet Northwest WWTP 0 acre/feet Haskell Street WWTP 60 acre/feet Fred Hervey WRP 0 acre/feet

slide-20
SLIDE 20

Water Treatment Plants

Franklin Mountains

NEW MEXICO

EL PASO, TEXAS

Ciudad Juárez

Fort Bliss

River Water Plants Groundwater Plants

Desalination Plant Jonathan Rogers WTP Robertson/Umbenhauer WTP Upper Valley WTP

slide-21
SLIDE 21

Israel Africa Singapore Big Spring, TX Wichita Falls, TX Brownwood, TX Abilene, TX El Paso, TX

It’s Already Happening

Cloudcroft, NM Completed In Design

slide-22
SLIDE 22

favor the Advanced Purified Water Treatment Plant

84%

slide-23
SLIDE 23

Getting Support

Public Outreach

  • Speakers Bureau
  • Media Relations
  • Videos

Advisory Panel

  • Health Experts
  • Scientists
  • Engineers
slide-24
SLIDE 24

Timeline

2014 2015 2016 2017 Public Outreach Expert Panel TCEQ approves pilot plant Pilot Plant Design & Testing Plant Construction Plant Design Delivery to Customers TCEQ approves results TCEQ approves design of plant

slide-25
SLIDE 25

Summary

  • Water reuse has been happening in

El Paso for decades.

  • Advanced technology makes purified

water safe to drink.

  • Purified water is a drought-proof,

sustainable supply for our community.
