SLIDE 1

Archetype design studio

LANDMARKS PRESERVATION COMMISSION KING MODEL HOUSES: 269 W 138TH ST

SLIDE 2

SLIDE 3

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 3

design studio

RCHETYPE

271 W. 138TH ST. 265 W. 138TH ST. 267 W. 138TH ST. 269 W. 138TH ST. EXISTING CONDITIONS 138TH STREET FRONT VIEW

SLIDE 4

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 4

design studio

RCHETYPE

271 W. 138TH ST. 269 W. 138TH ST. 265 W. 138TH ST. 267 W. 138TH ST. EXISTING CONDITIONS 138TH STREET FRONT VIEW

SLIDE 5

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 5

design studio

RCHETYPE

REAR AERIAL VIEW FRONT AERIAL VIEW

SLIDE 6

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 6

design studio

RCHETYPE

KING MODEL HOUSES NOR TH ENTRANCE ON 139TH STREET. CENTRAL AVENUE SHOWING FOUNTAIN AT INTERSECTION OF A STREET CROSS.

SLIDE 7

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 7

design studio

RCHETYPE

CENTRAL AVENUE looking over towards extended garages BETWEEN 138TH ST. & 139TH ST.

PLOT PLAN

SLIDE 8

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 8

design studio

RCHETYPE

CENTRAL AVENUE looking over towards extended garages BETWEEN 138TH ST. & 139TH ST.

PLOT PLAN

SLIDE 9

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 9

design studio

RCHETYPE

CENTRAL AVENUE SHOWING PLANTER AT INTERSECTION OF A STREET CROSS.

SLIDE 10

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 10

design studio

RCHETYPE

HISTORICAL IMAGE 1980’s TAX PHOTO

SLIDE 11

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 11

design studio

RCHETYPE

HISTORICAL IMAGE historical conditions of the rear of the proper ties.

SLIDE 12

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 12

design studio

RCHETYPE

NO GARAGE SPACE PAR TIAL LOT WIDTH GARAGE SPACE FULL LOT WIDTH GARAGE SPACE

SLIDE 13

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 13

design studio

RCHETYPE

P L P L P L P L 1-05 2-02 2-03 3-03 3-04 B-04 PROPOSED FRONT ELEVATION REPLACE (E) NON-CONFORMING TO HISTORICAL STANDARDS. REPLACE (E) NON-CONFORMING TO HISTORICAL STANDARDS. (E) TRANSOM WINDOW TO REMAIN. (E) LANTERNS TO BE REPLACED TO MATCH GEOR GIAN STYLE. (E) DOOR TO BE RESTORED (SEE P. 13). REPAIR (E) MASONR Y. REFURBISH (E) METALWORK. (N) SECURITY CAMERA. (E) CORNICE TO

REMAIN. REPAIR

ANY CRACKING. RESTORE MISSING TERRACOTTA MASONR Y DETAIL. REPLACE (E) NON-CONFORMING TO HISTORICAL STANDARDS. RESTORE MISSING TERRACOTA MASONR Y DETAIL. (N) LUMA SUR VEILLANCE SECURITY CAMERA.

SLIDE 14

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 14

design studio

RCHETYPE

PREFERRED OPTION: REPLACE DOOR TO MATCH HISTORIC LANDMARK. 221 W 138TH ST.: NATIONAL HISTORIC LANDMARK HOUSE ALTERNATE OPTION: REPAIR & RESTORE EXISTING DOOR. 269 W 138TH ST.: SITE OF PROPOSED WORK

SLIDE 15

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 15

design studio

RCHETYPE

2370-2372 Adam Clayton Powell Jr Blvd WROUGHT IRON ENTRANCE PRECEDENT FOR KING MODEL HOUSES. 2374 Adam Clayton Powell Jr Blvd WROUGHT IRON ENTRANCE PRECEDENT FOR KING MODEL HOUSES.

SLIDE 16

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 16

design studio

RCHETYPE

ENLAR GED PROPOSED WEST ELEVATION (E) METAL GATE TO BE STRIPPED AND REFINISHED (N) metal

ptd. MAILBOX

REFURBISH (E) METALWORK

SLIDE 17

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 17

design studio

RCHETYPE

269 W 138TH ST. ENLAR GED (E) WINDOW VIEW 269 W 138TH ST. ENLAR GED (E) ELEVATION

SLIDE 18

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 18

design studio

RCHETYPE

269 W 138TH ST. EXISTING MASONR Y CONDITION. REPLACE (E) CONCRETE SLAB.

SLIDE 19

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 19

design studio

RCHETYPE

269 W 138TH ST. EXISTING MASONR Y CONDITION 269 W 138TH ST. EXISTING MASONR Y CONDITION

SLIDE 20

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 20

design studio

RCHETYPE

269 W 138TH ST. EXISTING MASONR Y CONDITION 269 W 138TH ST. EXISTING MASONR Y CONDITION

SLIDE 21

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 21

design studio

RCHETYPE

EXISTING CONDITIONS FREDERICK DOUGLAS BLVD. REAR VIEW 267 W. 138TH ST. 269 W. 138TH ST. PLOT PLAN

SLIDE 22

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 22

design studio

RCHETYPE

EXISTING CONDITIONS FREDERICK DOUGLAS BLVD. REAR VIEW 267 W. 138TH ST. 269 W. 138TH ST. 271 W. 138TH ST. PLOT PLAN

SLIDE 23

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 23

design studio

RCHETYPE

EXISTING CONDITIONS FREDERICK DOUGLAS BLVD. REAR VIEW 267 W. 138TH ST. 269 W. 138TH ST. 271 W. 138TH ST.

SLIDE 24

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 24

design studio

RCHETYPE

EXISTING CONDITIONS FREDERICK DOUGLAS BLVD. REAR VIEW 269 W. 138TH ST. 271 W. 138TH ST. PLOT PLAN

SLIDE 25

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 25

design studio

RCHETYPE

P L P L

EXISTING REAR ELEVATION

P L P L P L P L 3-02 2-01 1-03 1-04 12'-012" 3-01 1'-712" 6'-10"

HT. OF GARAGE DOOR

1'-3" 14'-6" 1'-3"

PROPOSED REAR ELEVATION

SLIDE 26

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 26

design studio

RCHETYPE

P L P L P L P L 3-02 2-01 1-03 1-04 3-01 PROPOSED rear ELEVATION EXTERIOR DOOR TO REPLACE (E) WINDOW (E) LANTERNS TO BE REPLACED TO MATCH GEOR GIAN STYLE REPLACE (E) NON-CONFORMING TO HISTORICAL STANDARDS REPLACE (E) NON-CONFORMING TO HISTORICAL STANDARDS (N) FULL WIDTH GARAGE. EXTEND (E) BRICK WALL REPLACE (E) NON-CONFORMING TO HISTORICAL STANDARDS EXTERIOR DOOR TO REPLACE (E) WINDOW (N) MOTION SENSOR LIGHTS (N) LUMA SUR VEILLANCE SECURITY CAMERA.

SLIDE 27

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 27

design studio

RCHETYPE

P L P L P L P L 3-02 2-01 1-03 1-04 3-01 ENLAR GED PROPOSED REAR ELEVATION REPLACE (E) NON-CONFORMING TO HISTORICAL STANDARDS EXTEND (E) BRICK WALL (N) FULL WIDTH GARAGE. (N) MOTION SENSOR LIGHTS (n) EXTERIOR Door (E) LANTERNS TO BE REPLACED TO MATCH GEOR GIAN STYLE (N) LUMA SUR VEILLANCE SECURITY CAMERA.

SLIDE 28

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 28

design studio

RCHETYPE

ENLAR GED PROPOSED REAR ELEVATION EXTERIOR DOOR TO REPLACE (E) WINDOW REPLACE (E) NON-CONFORMING TO HISTORICAL STANDARDS (E) LANTERNS TO BE REPLACED TO MATCH GEOR GIAN STYLE REPLACE (E) NON-CONFORMING TO HISTORICAL STANDARDS P L P L P L P L 3-02 2-01 1-03 1-04 3-01

SLIDE 29

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 29

design studio

RCHETYPE

3'-6" 7'-1114" ±8'-1" CELLAR F.F. TO F.C. 7'-10" BASEMENT F.F. TO F.C. 10'-10" PARLOR F.F. TO F.C. 9'- 8 3 8" SECOND F.F. TO F.C. 10'-0" THIRD F.F. TO F.C. T.O. GARAGE ROOF T.O.2ND LEVEL F.F. T.O. 3RD LEVEL F.F. T.O. ROOF T.O. GARAGE F.F. 8'-712" 10'-212" 10'-1014" 12'-014" 41'-812" EXISTING GRADE TO T.O. ROOF 7'-9 3 4" (E) STAIR AND LANDINGS TO REMAIN 6'-1014" 12'-13 4" 10'-1014" 12'-014" 41'-1012" T.O. 3RD LEVEL F.F. T.O. 2ND LEVEL F.F. T.O. 1ST LEVEL F.F. EXISTING GRADE TO T.O. ROOF SIDEWALK ELEV (N) 2HR PARAPET W/ BRICK VENEER TO MATCH (E) BRICK

COLOR. SSD

(N) 2HR. PARAPET W/ BRICK VENEER TO MATCH FRONT ELEVATION YELLOW BRICK

COLOR. SSD.

7'-212" BASEMENT F.F. TO F.C. (E) STAIR TO REMAIN (E) STAIR TO REMAIN (E) STAIR TO REMAIN (E) STAIR TO REMAIN (N) WALL. SEE PLANS FOR WALL TYPES. TYP. (E) WALLS (E) WALL TO

REMAIN. TYP.

(E) ROOF TO REMAIN (E) SKYLIGHT TO REMAIN (N) MECHANICAL UNITS. SEE MECHANICAL DRAWINGS. (N) WALL. SEE PLANS FOR WALL TYPES. TYP. 4'-012" (E) FLOOR JOISTS AND SUBFLOOR TO REMAIN TYP. REPLACE ALL (E) REAR WINDOWS WITH (N) ALUM. CLAD WD. INSUL. DOUBLE HUNG WINDOW WITH BLACK FINISH TYP. UON. (N) EXTERIOR DOOR TO REPLACE (E) WINDOW. INSULATED W/ BLACK FINISH TO MATCH (N) WINDOWS STEEL DUNNAGE. SSD (E) MASONRY FLEW TO REMAIN (E) FLOOR JOISTS AND SUBFLOOR TO REMAIN TYP. (E) FLOOR JOISTS AND SUBFLOOR TO REMAIN TYP. (E) FLOOR JOISTS AND SUBFLOOR TO REMAIN TYP. (N) SLAB ON GRADE SEE DETAIL 1/A1.0 (N) SLAB ON GRADE SEE DETAIL 1/A1.0 (N) WALL. SEE PLANS FOR WALL TYPES. TYP. (E) WALL. TYP. (N) 1HR. ROOF CEILING WHERE

REQD. SSD.

(N) CONC. SLAB ON GRADE. SSD 1" STRUCTURAL SEPARATION

JOINT. SSD.

1" STRUCTURAL SEPARATION

JOINT. SSD.

(N) EXTERIOR DOOR TO REPLACE (E) WINDOW. INSULATED W/ BLACK FINISH TO MATCH (N) WINDOWS (E) FLOOR JOISTS AND SUBFLOOR TO REMAIN TYP. DASHED (E) STAIRS BYND. TYP. (E) FLOOR JOISTS AND SUBFLOOR TO REMAIN TYP. REPLACE ALL (E) FRONT WINDOWS WITH (N) WD.

INSUL. DOUBLE HUNG

WINDOW WITH BLACK FINISH

TYP. UON.

EXISTING HISTORIC TRANSOM WINDOW TO REMAIN CEILING SOFFIT FOR MECHANICAL EQMNT. SMD. REPLACE ALL (E) FRONT WINDOWS WITH (N) WD.

INSUL. DOUBLE HUNG

WINDOW WITH BLACK FINISH

TYP. UON.

7'-0" MIN. CEILING SOFFIT FOR MECHANICAL EQMNT. SMD. CEILING SOFFIT FOR MECHANICAL EQMNT. SMD. (N) WALL. SEE PLANS FOR WALL TYPES. TYP. DASHED SPREAD FOOTING BYND. SSD. CEILING SOFFIT FOR MECHANICAL

EQMNT. SMD.

MUDROOM STORAGE

REC. ROOM
REC. ROOM

(E) KITCHEN DINING LIVING/DINING ROOM BEDROOM BEDROOM VESTIBULE FOYER BEDROOM BEDROOM BATHROOM (E) BEDROOM 2'-512" 1'-1114" STRUCTURAL BURM. SSD. GARAGE (UNCONDITIONED) PROPOSED BUILDING SECTION (N) FULL WIDTH GARAGE.

(N) REAR DECK. (N) BRICK PARAPET & STONE CAP.

SLIDE 30

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 30

design studio

RCHETYPE

267 W. 138TH ST. 269 W. 138TH ST. 271 W. 138TH ST.

PROPOSED REAR EXTENSION

EXISTING CONDITIONS PROPOSED CONDITIONS

SLIDE 31

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 31

design studio

RCHETYPE

Visibility of 269 w 138th st. rear garage/house from alley visibility of 269 w 138th st. rear garage/house from alley

SLIDE 32

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 32

design studio

RCHETYPE

visibility of 269 w 138th st. rear garage/house from alley GOOGLE EARTH IMAGE FROM MAY 2016 :VISIBILITY OF269 W 138TH REAR GARAGE FROM ALLY. THERE IS NO VISIBILITY OF THE REAR OF THE HOUSE

SLIDE 33

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 33

design studio

RCHETYPE

1 261 w 138th st. Full width lot garage precedent 269 WEST 138TH ST. LEGEND: View 1 APPROVED cer tifjcate of no effect. DOCKET: 157601

SLIDE 34

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 34

design studio

RCHETYPE

1 269 WEST 138TH ST. LEGEND: view 1 262 w 138th st. full width lot garage precedent

SLIDE 35

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 35

design studio

RCHETYPE

1 269 WEST 138TH ST. LEGEND: view 1 246 w 138th st. full width lot garage precedent

SLIDE 36

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 36

design studio

RCHETYPE

2 269 WEST 138TH ST. LEGEND: 1 view 1 view 2 APPROVED cer tifjcate of no effect. DOCKET: 101050 268 w 138th st. full width lot garage precedent

SLIDE 37

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 37

design studio

RCHETYPE

1 269 WEST 138TH ST. LEGEND: view 1 APPROVED cer tifjcate of no effect. DOCKET: 109694 238 w 138th st. full width lot garage precedent

SLIDE 38

A

224 WEST 79TH STREET NEW YORK, NY, 10024 page 38

design studio

RCHETYPE

MATERIALS & DETAILS

MATERIAL SELECTION TO MATCH HISTORICAL STANDARDS BENJAMIN MOORE FOGGY MORNING 2106-70 BENJAMIN MOORE BLACK 2132-10 RESTORATION HARDWARE: CAMBRIDGE SCONCE Luma™ Sur veillance: 500 Series Bullet IP Out- door Camera Luma™ Sur veillance (ALTERNATE): 500 Series DOME IP Outdoor Camera BELDEN BRICK: CREAM BRICK 481-483 SMOOTH BELDEN BRICK: RED BRICK: AMHERST BLEND BK LIGHTING: CATSKILL SERIES FLOOD LIGHT RING VIDEO DOORBELL PRO
