A Core MPLS IP VPN Architecture draft-muthukrishnan-rfc2917bis-00.txt Chandrasekar Kathivelu Karthik Muthukrishnan IETF - San Diego, 12/00 I-D Authors Internet Engineering Task Force Karthik Muthukrishnan INTERNET-DRAFT Chandrasekar

slide-1
SLIDE 1

A Core MPLS IP VPN Architecture

draft-muthukrishnan-rfc2917bis-00.txt

Chandrasekar Kathivelu Karthik Muthukrishnan

IETF - San Diego, 12/00

slide-2
SLIDE 2

I-D Authors

Internet Engineering Task Force Karthik Muthukrishnan INTERNET-DRAFT Chandrasekar Kathirvelu Expires May 2001 Lucent Technologies Andrew Malis Fred Ammann Vivace Networks, Inc. COMMCARE telecommunications Jing Ming Xiao Junichi Sumimoto China UNICOM NTT

slide-3
SLIDE 3

Berlin Office Green Foods Boston Office Green Foods

IP VPN - Green Foods

Paris Office Green Foods Remote Workers PSTN/Cable/DSL/Wireless

Omni Present Provider

slide-4
SLIDE 4

Internet

IP VPN - Red Foods

Omni Present Provider

London Office Red Foods Paris Office Red Foods PSTN/DSL/Cable/ Wireless

slide-5
SLIDE 5

Problem Statement

  • Omni present provider rarely present..
  • Regional providers provide last mile service
  • National/International carriers provide

global connectivity

  • Need bridge to connect regional and global

carriers

slide-6
SLIDE 6

Hierarchical VPNs - Business Model

Boston Provider

Boston Office Green Foods

International Provider Paris Provider Berlin Provider

Paris Office Green Foods Berlin Office Green Foods

London Provider

London Office Red Foods Paris Office Red Foods

slide-7
SLIDE 7

Hierarchical VPNs - Network Model

Boston Provider

Boston Office Green Foods

International Provider Paris Provider Berlin Provider

Paris Office Green Foods Berlin Office Green Foods

London Provider

London Office Red Foods Paris Office Red Foods

VR VR VR VR VR VR VR VR VR VR VR VR VR VR VR VR VR VR

slide-8
SLIDE 8

Hierarchical VPNs

Boston Provider

Boston Office Green Foods

International Provider Paris Provider Berlin Provider

Paris Office Green Foods Berlin Office Green Foods

London Provider

London Office Red Foods Paris Office Red Foods

VR VR VR VR VR VR VR VR

VR

VR VR VR VR VR VR VR VR VR

slide-9
SLIDE 9

VPN LSP Tunnels

VR VR VR VR VR

Inter VR link

Purple VPN’s LSP Tunnel

Inter VR link Inter VR link

slide-10
SLIDE 10

Inter VR Links

VR VR VR

Inter VR link Inter VR link

VR VR VR

Level 1 VPN Level 2 VPN Level 2 VPN

slide-11
SLIDE 11

Inter VR Links

  • Supports hierarchical relationship
  • Level 1 .. Level 2 .. Level N VPNs
  • Supports peering relationship
  • Internet connectivity
  • Inter VPN [controlled] connectivity

– Controlled by standard routing policies at both ends

  • More details coming soon in a draft
