A Comprehensive Study of Con fl ict Resolution Policies in Hardware - - PowerPoint PPT Presentation

A Comprehensive Study of Conflict Resolution Policies in Hardware Transactional Memory

Ege Akpinar, Sasa Tomic, Adrian Cristal, Osman Unsal, M ateo Valero TRANSACT 2011

2

Background Eager HTM

• Conflict resolution especially critical in eager-

versioning, eager-conflict management HTM ) implementations since these implementations are typically optimized for commit and therefore assume that conflicts are rare

• Although conflict resolution policy plays a vital role

in performance, there is not a commonly accepted policy yet

Objective

• This paper aims to

– Evaluate existing conflict resolution policies – Identify and remedy performance bottlenecks that occur common during transactional executions – Propose new policies based on identified performance bottlenecks – Carry out a general comparison of existing and proposed conflict resolution policies

3

Progress – Performance Bottlenecks

• 5 existing performance issues (as mentioned in

Performance Pathologies paper) and two new bottlenecks are described

– Livelock – Deadlock – FriendlyFire – StarvingElder – FutileStall – InactiveStall – CascadingStall

• Remedies are proposed

4

Progress – Performance Bottlenecks

5

Deadlock Livelock

Progress – Performance Bottlenecks

6

FriendlyFire StarvingElder FutileStall

(from Pathologies paper)

Progress – Performance Bottlenecks

7

InactiveStall CascadingStall

(Contributions of this paper)

Progress – Perfect waiting and stalling

• Perfect waiting : Ideal backoff algorithm

where a transaction waits precisely until all conflicting transactions terminate

• Perfect stalling : When a transaction (Tx1)

gets aborted (due to Tx2), it restarts execution and starts waiting when it encounters a conflict with the same transaction (Tx2)

8

Progress - Methodology

• STAM P benchmark suite is used
• Number of ticks spent during parallel sections

are calculated (number of ticks spent after the first transaction to enter that section until the last transaction to exit that section)

• Speedup is calculated using number of ticks

compared to that of single core executions

9

Baseline policy

• Very simple, can be achieved by small

modifications to cache protocol

• A transaction that fails to retrieve a cache line

(likely because it has already been retrieved by another transaction) aborts itself

10

Timestamp policy variations

Timestamp : Time when a transaction begins execution

• A transaction’s timestamp is maintained until

commit (thus, it doesn’t reset after abort or stall)

• Comparison of timestamps yield which

transaction is older/ younger (has begun earlier/ later)

11

Timestamp policy variations

• 5 timestamp policies are

tested

• Variations tackle

– Deadlock – Livelock – StarvingElder – InactiveStall – CascadingStall – FriendlyFire

• Perfect stalling improved

results significantly

12

Size policy variations

Size : Summation of read-set and write-set

• If an element is present in both read-set and

write-set, it contributes twice to size

• Size is a good indicator of amount of work

done since work typically consists of memory accesses (reads/ writes) Largeness factor: A transaction is deemed larger than another only if its size exceeds the other transaction’s size by a largeness factor

13

Size policy variations

• 3 categories of policies are tested
• Variations tackle

– Deadlock – Livelock – StarvingElder – FutileStall – InactiveStall – CascadingStall – FriendlyFire

• A largeness factor of 1.25

performed the best

14

Prioritization policy variations

• Prioritization is based on

– Number of stalled transactions (by a transaction) – Number of aborted transactions (by a transaction)

15

• Primarily aims to avoid

bottlenecks FutileStall and CascadingStall FutileStall CascadingStall

Prioritization policy variations

• 5 prioritization policies are tested
• Variations tackle

– Deadlock – Livelock – InactiveStall – FutileStall – CascadingStall

• Results are highly variable among different

applications

16

Alternating Priorities Policy

Alternating Priorities : Transactions alternate priorities in pairs. Eg. Tx1 gets aborted by Tx2. When they conflict again, Tx1 will abort Tx2.

• Designed for fairness, rather than

performance

• M easured performance and scalability is good

17

Results

• Overall, performance increase (from baseline

policy) of 5-10% was measured, amounting up to

15%

18

Results

19

Conclusion

• Conflict resolution is a vital characteristic for

performance

• Taking into common performance bottlenecks

into consideration has an important effect on performance

• It is difficult to identify a single resolution policy

as the globally best performer since performance varies greatly with application characteristics

• Transactional M emory will be realized only if its

performance promises are solid; therefore, conflict resolution is an important research space

20

Timestamp policies

• Timestamp1: At conflicts, older transactions abort the younger ones and carry on

execution (no stall).

• Timestamp-2: At conflicts, older transactions start waiting on younger

transactions (stall). However, when a younger transaction requests a cache line that is owned by an already stalled older transaction, younger transaction aborts itself (in order to avoid deadlock) and begins perfect waiting.

• Timestamp-3: (StarvingElder remedy) For every transaction, a "committed after

me" list is maintained. When a transaction commits, that transaction’s thread is added to the "committed after me“ list of all transactions that are active, aborted

• r stalled. A transaction’s "committed after me" list is reset after its every commit.

At conflicts, transactions whose threads are present in "committed after me" list

• f conflicting transactions are aborted.
• Timestamp-4: Same as Timestamp-3 configuration except for its InactiveStall
• policy. Instead of aborting the younger transaction, older transaction is aborted at

InactiveStall case.

• Timestamp-5: Naïve timestamp and stall policy (Timestamp-2) with perfect

stalling enhancement.

Size policies

• Size-1 At conflicts, larger transactions take over and smaller

conflicting transactions are aborted. There is no stalling.

• Size-2 At conflicts, larger transactions are favored. However,

at conflicts, owner of the conflicting cache line is allowed to resume execution regardless of its size. When a transaction requests a cache line from a larger stalled transaction, it aborts itself and restarts execution. When the aborted transaction again conflicts with the same larger transaction, it is stalled (perfect stalling).

• Size-3 At conflicts, larger transactions are favored. However,

at conflicts, owner of the conflicting cache line is allowed to resume execution regardless of its size. When a transaction requests a cache line from a larger stalled transaction, small transaction aborts itselfand starts perfect waiting.

Priority policies

• Priority-1 Transactions gain priority when they stall other transactions.

When a transaction requests to acquire a cache line that is already acquired by another transaction and if their priorities are equal, then the current owner is allowed to continue execution.

• Priority-2 Transactions gain priority as they stall other transactions. In

addition, transactions lose priority as they abort other transactions.

• Priority-3 Similar to Priority-2. However, transactions gain (not lose)

priority as they abort other transactions.

• Priority-4 Similar to Priority-1. At conflicts, if a transaction loses, it aborts

instead of stalling.

• Priority-5 Similar to Priority-1, transactions gain priority as they tall others.

However, priority is a measure calculated using the number of transactions in conflict. For instance, when a transaction gets stalled due to a conflict with n transactions, all n transactions gain 1/ n priority.
