400 Series Inert Gas Systems NEW 400 SERIES VALVE Regulates and controls the mass flow & maintains pressure in one modular unit Valve Actuator/Regulator (On Primary Cylinder only) 2 NEW CYLINDERS Sizes Benefits 200 Bar Cylinders 80L

slide-1
SLIDE 1

400 Series Inert Gas Systems

slide-2
SLIDE 2

NEW 400 SERIES VALVE

2

Regulates and controls the mass flow & maintains pressure in

  • ne modular unit

Valve Actuator/Regulator

(On Primary Cylinder only)

slide-3
SLIDE 3

NEW CYLINDERS

Sizes Benefits 200 Bar Cylinders 80L To comply with explicit specifications 300 Bar Cylinders 80L & 140L Reduces cylinders needed & hardware

3

80L 140L

Dimensions in inches

slide-4
SLIDE 4

CYLINDER QUANTITY REDUCTION

Benefits Compresses gas and reduces cylinder quantity by 30-40% for 300 Bar, and >50% using 140L

4

283 m3

300 bar

80L - 9 80L - 6 140L - 4

1,415 m3

80L - 42 80L - 30 140L - 17

PROTECTED SPACE

  • r
  • r
slide-5
SLIDE 5

FAST INSTALLATION

Benefits Reduces hardware costs and installation time & provides neat appearance – no completer kits!

5

No Spanners needed! - Quick connect adapters reduce installation time

slide-6
SLIDE 6

FAST INSTALLATION

6

Benefits PLUGGABLE Wire harnesses for pressure switch monitoring reduce installation time & provide neat appearance

slide-7
SLIDE 7

FLEXIBLE DESIGN

Benefits Cylinders can be remote (many metres away) at a central location

7

slide-8
SLIDE 8

PRE-FABRICATED MANIFOLDS

Benefits Saves on installation cost and time

8

Need depictions of each size offering and net cost estimate 8 - Port 4 - Port

Check Valves Pre-Assembled

slide-9
SLIDE 9

SELECTOR VALVE SYSTEM

Benefits Multi-hazard can be protected with common bank of cylinders, reducing system cost

9

Thanks to our new valve, SCH 40 piping may be used throughout the multi-hazard design

slide-10
SLIDE 10

LOWER COST PIPING

Benefits Output pressure is limited to 55 Bar, with auto-shutoff when pressure exceeds 60 Bar, allowing Sch. 40 pipes to be used, even in multi-hazard applications

10

A-106B A-106A A-53B A-53A 1/4 3/8 1/2 3/4 1 1-1/4 1-1/2 2 2-1/2 3 4

Allowable Pipe Grade and Size

Green = Qualified OK to Use Blank = Not Qualified

Sch 40 THDF Per FSSA with allowable 20% Grade NPS Pipe size A-106C A-53B ERW A-53A ERW A-53F Furnace

SG11

slide-11
SLIDE 11

Slide 10 SG11 added commas to benefit statement. Should multi-hazards be multi-hazard applications? Remoed text from below graph...redundant.

Sari Gibson, 7/24/17

slide-12
SLIDE 12

VENT REDUCTION

Benefits 55% reduction in vent area lowers installation costs

11

280 m3 hazard required 0.86 m2 of ventilation @ 60 seconds discharge 280 m3 hazard requires 0.37 m2 of ventilation @ 60 seconds discharge

slide-13
SLIDE 13

GLOBAL COMPLIANCE

APPROVAL STATUS LPCB Approved

12

Current

()

2019 TBA

slide-14
SLIDE 14

ENVIRONMENTALLY FRIENDLY

Benefits 0 ODP, 0 GWP & 0 ALT – Truly green!

13

slide-15
SLIDE 15

SUMMARY – KIDDE 400 SERIES

14

  • Installation cost is reduced
  • Lower cost SCH 40 pipe
  • Smaller vent area
  • Quick connect of hoses and wires
  • Pre-fabricated manifolds
  • Global Approvals
  • Environmentally friendly
  • System cost is reduced
slide-16
SLIDE 16

1 2 3 4 5 6 7 8 10 9

15

SYSTEM ASSEMBLY

A Typical System

Description 1 80L/140L Cylinder 2 Cylinder racking 3 Valve 4 Actuator/Regulator assembly 5 Slave gauge assembly 6 Discharge hose 7 Actuation hose (quick connect) 8 Manifold check valve 9 Pre-fabricated manifold 10 Manifold support brackets

slide-17
SLIDE 17

16

ACTUATOR/REGULATOR ASSEMBLY

Manual Release Valve Attachment Solenoid Only used on Primary Cylinder Actuation Port to Valve

(Regulated to 120 psi)

slide-18
SLIDE 18

17

VALVE ASSEMBLY

Port for Actuator/Regulator, Secondary Cylinder Gauge & Refilling Safety Disc Actuation Port In Discharge Port Discharge Port with Outlet Cap Secondary cylinder gauge with built- in pressure switch Actuation Port to 2nd Cyl.

slide-19
SLIDE 19

18

HOSES (DISCHARGE & ACTUATION)

Discharge Hose 3/4"

  • 410mm (16.1 in.), 90/90
  • 510mm (20 in.), 90/90
  • 300mm (11.8 in.), Straight/Straight

Actuation hoses for:

  • 80L Primary Cyl. Actuation
  • 140L Primary Cyl. Actuation
  • Interconnecting 80L cyl
  • Interconnecting 80L cyl rows
  • Interconnecting 140L cyl
  • Interconnecting 140L rows
slide-20
SLIDE 20

19

CYLINDER RACKING

Microsoft Excel Worksheet

Cylinder Rack Calculator:

slide-21
SLIDE 21

20

PRE-FABRICATED MANIFOLDS

2 STUB 1 ROW 2" MANIFOLD BSP 3 STUB 1 ROW 2" MANIFOLD BSP 4 STUB 1 ROW 2" MANIFOLD BSP 5 STUB 1 ROW 2" MANIFOLD BSP 6 STUB 1 ROW 2" MANIFOLD BSP 4 STUB 2 ROW 2" MANIFOLD BSP 6 STUB 2 ROW 2" MANIFOLD BSP 8 STUB 2 ROW 2" MANIFOLD BSP Pre-fabricated manifold used to connect multiple cylinders or main and reserve cylinders to a common header. These manifolds are assembled with check valves.

slide-22
SLIDE 22

21

SELECTOR VALVES

1 in. Threaded 1-1/2 in. Threaded 2 in. Threaded 3 in. Flanged 4 in. Flanged

Pressure regulator and individual solenoids are mounted on an easy-to-install back-plate 2-way valves

slide-23
SLIDE 23

22

CHECK, BLEEDER & SAFETY VALVES

Manifold Check Valve is connected between the discharge hose and manifold/discharge piping for each cylinder. Comes standard with pre-fabricated manifolds. Closed-pipe safety relief valve End of actuation line bleeder valve

slide-24
SLIDE 24

23

NOZZLES

  • Material: Brass
  • 4 Sizes: ½”, ¾”, 1” & 1 ½”
  • Can be mounted upright or pendent
  • 2 Patterns: 180° & 360°
slide-25
SLIDE 25

Discharge Pressure Switch: Discharge Pressure Switch: Pressure Trip:

Main/Reserve Transfer Switch: DPDT Switch

24

ANCILLARY ITEMS (FROM LEGACY PRODUCTS)

Standard 3PDT rated10 Amp Explosion Proof DPST rated 20 Amps
