Project: MN356 Convent Avenue WINDOW SCHEDULE SIZE DESCRIPTION PRODUCT FLOOR NO. QTY WIDTH HEIGHT R/O TYPE GLASS HEADER MATERIAL MFG NO. NOTES GROUND W01 3 2'-9" 5'-3" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH Primary Façade: Existing brick mold at header W02 7 3'-1" 5'-3" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH Secondary Facade @ W 145th St W02A 1 3'-1" 5'-3" N/A 1/1 DBL HUNG Opaque WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH Secondary Façade: Opaque Glazing Required W03 1 1'-3" 5'-3" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH Back of House W04 1 2'-6" 5'-3" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH W05 2 2'-6" 5'-3" 2'-6-1/2" x 5'-3-1/4" 1/1 DBL HUNG Low E3 7'-2" WOOD/AL MARVIN/CLAD ULTIMATE CUDH-NG Full window assembly W06 2 2'-8" 5'-3" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH FIRST W05 2 2'-6" 5'-3" 2'-6-1/2" x 5'-3-1/4" 1/1 DBL HUNG Low E3 7'-2" WOOD/AL MARVIN/CLAD ULTIMATE INSERT CUDH-NG Full window assembly W07 4 2'-10" 7'-3" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH Primary Façade: Existing brick molds at opening W08 2 3'-1" 7'-3" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH Secondary Façade W09 5 2'-9" 7'-3" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH W09A 1 2'-9" 7'-3" N/A 1/1 DBL HUNG Opaque WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH Secondary Façade: Opaque Glazing Required W10 3 2'-6" 7'-3" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH W11 1 3'-0" 7'-3" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH SECOND W05 2 2'-6" 5'-3" 2'-6-1/2" x 5'-3-1/4" 1/1 DBL HUNG Low E3 7'-2" WOOD/AL MARVIN/CLAD ULTIMATE CUDH-NG Full window assembly W12 4 2'-10" 7'-0" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH Primary Façade: Existing brick molds at opening W13 2 3'-3" 7'-0" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH Primary Façade: Existing brick molds at opening W14 5 2'-9" 7'-0" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH W14A 1 2'-9" 7'-0" N/A 1/1 DBL HUNG Opaque WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH Secondary Façade: Opaque Glazing Required W15 1 3'-1" 7'-0" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH W16 2 2'-6" 4'-6" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH W17 3 2'-6" 7'-0" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH W18 1 3'-0" 7'-0" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/CLAD ULTIMATE INSERT CINDH THIRD W05 2 2'-6" 5'-3" 2'-6-1/2" x 5'-3-1/4" 1/1 DBL HUNG Low E3 7'-2" WOOD/AL MARVIN/INTEGRITY CUDH-NG Full window assembly W12 4 2'-10" 7'-0" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/INTEGRITY CINDH Primary Façade: Existing brick molds at opening W13 2 3'-3" 7'-0" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/INTEGRITY CINDH Primary Façade: Existing brick molds at opening W14 5 2'-9" 7'-0" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/INTEGRITY CINDH W14A 1 2'-9" 7'-0" N/A 1/1 DBL HUNG Opaque WOOD/AL MARVIN/INTEGRITY CINDH Secondary Façade: Opaque Glazing Required W15 1 3'-1" 7'-0" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/INTEGRITY CINDH W16 2 2'-6" 4'-6" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/INTEGRITY CINDH W17 3 2'-6" 7'-0" N/A 1/1 DBL HUNG Low E3 WOOD/AL MARVIN/INTEGRITY CINDH ��

���
