• 3. Feature Extraction

2

3.1 Feature Extraction from Speech

… or other types of audio like music

See Schukat-Talamazzini Chapter 3

3

Goal of Feature Extraction

• Capture essential information about speech
• Be robust against background noise
• Steps:
• Sampling and quantization
• Short time analysis
• Transform to frequency space
• Filtering
• Optimize class separability

4

Overview Feature Extraction

Convert the continuous speech signal into a sequence of vectors Each window gives one vector The following slides will give the details of this procedure From: HTK-manual

5

Sampling and Quantization

Measure signal periodically and store in variable Sampling rate: T Quantization: use B bits to represent signal a 2B possible values fn: sampled values of the signal numbered using index n what happens when you store a signal in a computer?

6

Sampling Theorem

• Reconstruction of original signal is
• nly possible if the signals highest

frequency is limited

• Let fG the frequency limit
• Else: spectral aliasing

that is frequencies will be confused T fG 2 1

7

Pre-emphasis

• Correct for filtering of the lips
• Boosts higher frequencies
• Iterative scheme:
• Typical values: =0.95

1 ´ n n n

f f f

What does it do for =1

8

From Signal to Spectrum: Fourier Transform

• Definition

n n i n m n i m

e w f e F ) (

) (

wn : window function : frequency times 2 i: imaginary unit The window cut’s the sum to a number of finite values Complex exponentials are easier than cos or sin functions

9

Example: putting a rectangular on a speech signal

Fram e shi f t t yp. : 10m s Fram e w i dt h t yp. : 25m s

10

Fourier Transform in Practice

• Use “Fast Fourier Transform” (FFT)
• Requires number of samples N to be power
• f 2 (e.g. N=256)
• Code available
• Complexity N log( N)

11

Established Window Functions

• Use to get sharper peaks
• Rectangular window:
• Generalized Hamming Window:
• Gauss window:
• Parabola window:

1

R n

w

) 1 2 cos( ) 1 ( N n wH

n 2

) 2 / 3 2 / ( 5 . N N n G n

e w

) 1 ( 4 N n N n wP

n

( =0.54 : standard Hamming window)

n=0...N-1

• Window functions vanish outside this interval

12

Rewrite of Fourier Transform

• Definition:
• Window functions vanish outside the

interval n=0...N-1

• Define

N 1 2

n n i n m n i m

e w f e F ) (

) (

1 2 ) ( N n N n i n n m m

e w f F

13

Example for ö

Short time spectrum Smoothed spectrum

Frequency (Hz) Frequency (Hz)

How can you best look at multiple spectra at the same time

14

Spectrogram

• Calculate a spectrum for any point in time
• Code the local intensity: color/grey scale

Time

15

Spectrogram

http://www.wilhelm-kurz-software.de/dynaplot/applicationnotes/spectrogram.htm

"To return to the main menu, press the star key".

16

Use praat to generate a Spectrogram

• Praat: software for doing

phonetics by computer

• Written by: Paul Boersma

and David Weenink

• quite powerful:

spectrograms, formants, pitch, …

• Download:

http://www.fon.hum.uva.nl/ praat/

17

Use praat to generate a Spectrogram

• Praat: software for doing

phonetics by computer

• Written by: Paul Boersma

and David Weenink

• quite powerful:

spectrograms, formants, pitch, …

• Download:

http://www.fon.hum.uva.nl/ praat/

18

Use praat to generate a Spectrogram

a demo

19

Smoothing the Spectrum: filter bank

• Idea: imitate ear
• Do an average over neighboring frequencies
• Scale the frequencies according to the Mel or the

Bark scale a Reduction from 256 Fourier coefficients to 24

• utputs of a filter bank

20

Example of a Filterbank

21

Filterbank

• Spacing of center frequency:

– According to mel scale:

• Low frequency cut off:

– E.g. 300 Hz (for telephone speech)

• High frequency cut off:

– E.g. 3400 Hz (for telephone speech )

• Different settings for e.g. head set connected PC

) 700 1 ( log 2595 ) (

10

f f Mel

How can you adjust to different vocal tracts?

22

Vocal Tract Length Normalization

• Idea:
• Average position of formants depends on length
• f vocal tract
• a varying position of frequencies of filter bank
• A kind of speaker adaptation

23

Vocal Tract Length Normalization: Frequency Warping

• Translation table

for frequencies

• Keep minimum

and maximum frequency unchanged

min=0.8 to max=1.2

24

Training the Warping Factor

• Issue: how to scale for a specific speaker
• Slow version:
• Use 11 different warping factors
• Do speech recognition with all of them
• Pick the best one
• Oldest approach
• Not very efficient
• Improvement: 10% less recognition errors

25

From Spectrum to Cepstrum

• Name: swapping of letters (spectrum/cepstrum)
• Useful as a preparation to remove channel

distortions

• Cepstral mean subtraction (CMS)

method to remove channel distortions What are examples

• f channel distortions?

26

Definition “Cepstrum”

Fourier Transform log Discrete Cosine Transform Signal Spectrum Cepstrum

27

Math for Cepstrum

• en: original signal (e.g. excitation from glotis)
• fn: measured signal
• hn: impulse response of channel (e.g. vocal

tract, telephone, room acoustics)

n n n m m

e h f

28

Math for Cepstrum

• Apply Fourier transform F
• Use convolution theorem

} { } {

n n n m n

e h f F F

} { } { } {

n n n

e h f F F F

29

Math for Cepstrum

• Apply logarithm
• Impulse response and excitation now separated
• If stationary part of impulse response hn can

now be removed

}) { log( }) { log( }) { log(

n n n

e h f F F F

30

Cepstrum: do discrete cosine transform after log

• Discrete cosine transform:

,... 2 , 1 ) ) 2 / 1 ( cos( ) log( 2

1 ) ( ) (

n N l n F N c

N l m l m n

You do not need to remember this formula

31

Dynamic Features

• Spectrum captures local aspects of speech
• Window size 25 ms
• Capture slow changes in spectrum
• Other name: delta features

32

Dynamic Features

• Capture slow changes in spectrum

33

Dynamic Features

• Calculate first and second derivatives
• Naïve approach to first derivative

– Continuous function – Time discrete sampling

t t t f t t f dt t df 2 ) ( ) ( ) ( 2 ) ( ) ( ) (

m m m

t f t f dt t df

tm: m-th sample of the signal

34

Difference/Regression

Sample i-th component of feature vector m m-3 m-2 m+1 m-1 m+2 m+3 Regression curve Line through extremes

35

Regression Formula

M i M i i m i m

i t f t f i dt t df

1 2 1

2 )) ( ) ( ( ) (

Can you make it agree with

t t t f t t f dt t df 2 ) ( ) ( ) (

36

Dynamic Features

• Invented by Furui 1981
• Standard in any modern ASR system
• Alternative:
• Linear mapping of neighboring feature vectors
• Issue:
• Dimension of feature vectors

37

Linear Discriminant Analysis

• Method to decrease size of feature vector
• Maximize severability of class regions
• Linear transform of feature vectors
• More: later in the lecture

38 Complete Pipeline for Mel-Frequency Cepstral Coefficients (MFCC)

Sampling Windowing Fast Fourier Transform

512 Fourier Coefficients

Absolute Value Mel-scaled Filterbank log Discrete Cosine Transform Dynamic Features (1. and 2. derivative) Linear Discriminant Analysis

16 kHz; 16 Bit quantization

Pre-emphasis

Signal

Feature Vectors Window size: 25 ms Typical values: 24 filterbank values keep only 20 lowest cepstra 60 dimensional vector

39

Alternative Feature Extraction Methods

• LP-Cepstrum (LP=linear prediction)
• Derived from speech coding
• No longer much in use
• PLP (=Perceptual linear prediction)
• For certain applications popular
• Claim: mode noise robust than MFCCs
• Main change: us |.|1/3 instead of log in MFCC

40

Summary

• Classical “plain vanilla” feature extraction:

Mel-Frequency Cepstral Coefficients

• Main deficiency: not very noise robust
• Used in
• Speech Recognition
• Speaker Recognition
• Music genre classification

41

3.2 Feature Extraction from Image Processing

42

Overview

• Feature types:
• Color
• Texture
• Edge

43


44

Physics

• It’s all electromagnetic (EM) radiation
• Different colors correspond to radiation of

different wavelengths

• Intensity of each wavelength specified by

amplitude

• We perceive EM radiation within the 400-

700 nm range, a tiny piece of spectrum between infra-red and ultraviolet

45

Visible Light

46

Color and Wavelength

Most light we see is not just a single wavelength, but a combination of many wavelengths (see below). This profile is often referred to as a spectrum, or spectral power distribution.

47

Image Representation (RGB)

48

Image Representation (Channels)

49

Image Representation

(r,g,b)

C pixels wide R pixels long

50

Color Histogram

Calculate percentage of color present in image Deficiency: loss of regional information

51

Localized Features

Do color histogram for any region of the image

52

Edge Detection: Sobel Operator

) / arctan( | | 1 2 1 1 2 1 1 1 2 2 1 1

2 2

Gx Gy Gy Gx G Gy Gx

Apply matrices Gx and Gy to any image region

53

Texture Image Examples

• From the VisTex Texture Database

54 Gaussian window modulated with a complex sinusoid Gabor filters at different scales and spatial frequencies Top row shows anti-symmetric (or odd) filters, bottom row the symmetric (or even) filters Visual Cortical cells have band-pass responses very similar to Gabor filters

Gabor filters

) 2 / ) ( exp( ) 2 / ) ( exp( )) ( exp( ) , (

2 2 2 2

j K G

You do not need to remember this formula

55

Summary

• Main features for image recognition
• Color
• Edges
• Texture
