22 January 2019 1 2 Use of Eucalyptus at Kinleith Mill - - PowerPoint PPT Presentation

1

EPA Hearing 22 January 2019

2

3

Use of Eucalyptus at Kinleith Mill

• Eucalyptus is the hardwood species of choice

for commercial, technical and operational reasons

• Eucalyptus is chipped on site at Kinleith Mill

and pulped in the No3 continuous digester

• Pulping process is NSSC (neutral sulphite semi

chemical)

• High yield (70-75%)
• The eucalyptus pulp is used exclusively on the

No6 paper machine at Kinleith Mill which manufactures kraftliner and semi chemical medium

• Kraftliner and Semi chemical medium are high

performance grades used by the corrugated packing industry in New Zealand

Lignin Primary Wall Outer Layer of Secondary Wall Main Body of Secondary Wall Tertiary Wall Lumen Adjacent Fibre Adjacent Fibre

4

Eucalyptus Pulp and Packaging

• Eucalyptus pulp compliments radiata and recycled pulp

when manufacturing high performance papers

• Eucalyptus pulp improves compressive strength

properties of Kinleith papers, complementing the containability achieved with softwood fibre

• High yield Eucalyptus pulp contains residual lignin

which “sets” during the corrugating process resulting in high strength corrugated board

• Hardwood fibres are shorter than softwood. This

improves corrugator runnabilty and reduces flute fracture

5

New Zealand Exports

• New Zealand is an exporter of a wide range
• f primary produce
• Kiwifruit, apple, meat, dairy products etc
• Supply chains are often long and include

significant periods in cool storage

• The level of humidity in cool storage cycles

numerous times which stresses packaging

• High performance packaging is critical to the

safe and efficient transport of each product

• Virgin pulp based packaging products are a

durable, cost effective and environmentally friendly solution

• Eucalyptus pulp a key input into Kraftliner

and Semi chemical medium, both of which are tailored for packaging solutions in demanding applications

6

New Zealand Exports

Apple

• NZ$780 mil YE Dec 2018
• 21 million cartons
• Forecast to increase in 2019
• Planting continues to increase

Kiwifruit

• Export revenue $2.2 bil YE Mar19
• 150 million single layer trays
• Japan, EU and China 72% share
• Higher value Gold share increasing
