22:010:622 Internet Technology and E-Business Dr. Peter R. Gillett Associate Professor Department of Accounting & Information Systems Rutgers Business School Newark & New Brunswick Dr. Peter R Gillett March 5, 2003 1 Overview

slide-1
SLIDE 1

March 5, 2003

  • Dr. Peter R Gillett

1

22:010:622 Internet Technology and E-Business

  • Dr. Peter R. Gillett

Associate Professor Department of Accounting & Information Systems Rutgers Business School – Newark & New Brunswick

slide-2
SLIDE 2

March 5, 2003

  • Dr. Peter R Gillett

2

Overview

Review of Last Week? Client Threats Data Collection and Analysis Internet Pricing Security Issues Firewalls and Related Technology Simple Game Theory

slide-3
SLIDE 3

March 5, 2003

  • Dr. Peter R Gillett

3

The Big Issues

  • Turban et al. quote a Georgia Tech.

survey (97-98) of the most significant issues facing the Internet:

1.

Censorship (privacy issues)

2.

Privacy

3.

Navigation (not really privacy)

4.

Taxation

5.

Encryption

slide-4
SLIDE 4

March 5, 2003

  • Dr. Peter R Gillett

4

Domain Names

Cybersquatting Name changing Name stealing

slide-5
SLIDE 5

March 5, 2003

  • Dr. Peter R Gillett

5

Client Threats

Active Content

Java applets ActiveX Controls JavaScript VBScript

Cookies Trojan Horses Zombies Viruses Worms Steganography

slide-6
SLIDE 6

March 5, 2003

  • Dr. Peter R Gillett

6

Big Issues

Privacy and the World

The Internet is global Different views:

US: privacy is balanced against the needs of society Europe: privacy a constitutional right

General Issues

Accuracy Property Accessibility and verifiability

slide-7
SLIDE 7

March 5, 2003

  • Dr. Peter R Gillett

7

Data Collection on the Web

Primary types collected on Web Sites

Domains Countries, companies IP address, browser type, etc.

Timing Records

How long on web site? How long to a purchase? When? Repeat visits?

slide-8
SLIDE 8

March 5, 2003

  • Dr. Peter R Gillett

8

Data Collection on the Web

  • Time Series of data
  • Descriptive: what happened
  • Predictive: anticipate what will happen next
  • Explanation: why this lead to a sale.
  • Seasonality effects: E-marketing and winter

holiday season. Day and night.

  • Periodic: weekends
  • Trends: increasing sales overall, decreasing

sales per minute visited

  • Whose property are the predictions?
slide-9
SLIDE 9

March 5, 2003

  • Dr. Peter R Gillett

9

Data Analysis

Where can we get the data about our web

site?

Types of statistical analysis A time series is stationary if it has no

periodic variation and no trend and no change in variance

Looking for trends

slide-10
SLIDE 10

March 5, 2003

  • Dr. Peter R Gillett

10

Competitive v. Cooperative Marketing

Competitive Marketing Cooperative Marketing Frontal Assault (Amazon.com vs. BN.com) Joint Venture (Microsoft) Flank Attack (e*Trade vs. Schwab) Value Chain partnership (Dell, ingredient marketing) Raise Structural barriers (lots of costly development

  • r marketing)

Lower Desire for attack (joint marketing programs)

slide-11
SLIDE 11

March 5, 2003

  • Dr. Peter R Gillett

11

Internet Firms Raising Prices!

  • Why?
  • People seem willing to pay more
  • Costs are higher
  • Not able to buy in bulk like larger brick-and-mortar

stores

  • Equity markets no longer willing to support money-

loosing enterprises

  • What is the cardinal rule of pricing?
  • Why have Internet firms focused on price?
slide-12
SLIDE 12

March 5, 2003

  • Dr. Peter R Gillett

12

Internet Pricing

  • X looses $1 on each unit they sell, but

that is OK since they make it up on volume!

  • How? Primary and secondary data
  • Controlled Experiments
  • Conjoint Surveys
  • Market Intelligence
slide-13
SLIDE 13

March 5, 2003

  • Dr. Peter R Gillett

13

Advantages of Internet Pricing?

Speed Audience Experiments

Fast Large

Market Intelligence

slide-14
SLIDE 14

March 5, 2003

  • Dr. Peter R Gillett

14

Key Security Issues

Authentication Secrecy Data

Firm’s data

Customer data Internal data

Hierarchy of Security

slide-15
SLIDE 15

March 5, 2003

  • Dr. Peter R Gillett

15

Security

Extranets are harder to secure than intranets

Must deal with lots of other systems Outer firewall protects from gross misuse Perhaps the best way: packet filtering firewall

Intranets generally have more tight security

More sensitive information ORB: Object Request Broker model

Sending your Objects (data) where? Not keeping things totally secured

slide-16
SLIDE 16

March 5, 2003

  • Dr. Peter R Gillett

16

Security: Flavors

SecurID: One-Time Pad

Risks?

Lost or stolen

Hashing or finger-printing as an ID

What is hashing? Hashing: many to fewer

slide-17
SLIDE 17

March 5, 2003

  • Dr. Peter R Gillett

17

Bellcore’s S/Key System

Start with a secure password

Using the same algorithm

Host and local server generate many one-time

passwords

Use passwords sequentially After each use, dispose of passwords

Like One-Time Pads Like SecurID’s hardware tokens

slide-18
SLIDE 18

March 5, 2003

  • Dr. Peter R Gillett

18

PPP, PAP, & CHAP

PPP: point to point protocol

Secure links Secure the transmission and exchange Transmit passwords, User Ids, etc. Allows challenges of authentication Things change Packets intercepted, etc.

PAP:

Password Authentication Protocol Clear text id and password pairs Acknowledgements

CHAP

Three-way handshake protocol using hashing

slide-19
SLIDE 19

March 5, 2003

  • Dr. Peter R Gillett

19

Other Security Methods

Business: different needs RADIUS: Remote Authentication Dial In

User Service

TACACS: Cisco’s server security protocol

Administers

Authentication Authorization Account information for users

slide-20
SLIDE 20

March 5, 2003

  • Dr. Peter R Gillett

20

TACACS and Cisco

Uses a centralized server to hold all

information

Why not distributed?

Sends all data in cleartext (TACACS+

uses encryption for sending)

Can handle a few other protocols! Business issues?

slide-21
SLIDE 21

March 5, 2003

  • Dr. Peter R Gillett

21

SSL

Secure Socket Layer History

Unix Sockets and Pipes Sockets and TCP/IP

Internet Engineering Task Force and

Netscape

Goal: “privacy and reliability between two

communicating applications”

slide-22
SLIDE 22

March 5, 2003

  • Dr. Peter R Gillett

22

SSL Goals

Secure crypto connection between 2

parties

Interoperability with different programs Extensibility: add new cryptographic

methods as they appear

Relative efficiency

slide-23
SLIDE 23

March 5, 2003

  • Dr. Peter R Gillett

23

SSL

Two Layers

Low Level: Record Protocol (build on TCP/IP)

encapsulates higher level protocols

Top Level Protocol: Handshake Protocol

Server and client authenticate each other Negotiates encryption algorithms and keys

Top Level: Various Application Protocols

Different programs Netscape, IE, etc.

slide-24
SLIDE 24

March 5, 2003

  • Dr. Peter R Gillett

24

SSL

Private connection (via a socket) Authentication can use asymmetric

encryption (RSA)

Encryption used after initial handshake

Symmetric encryption is used for transmission

(like DES)

The connection must be reliable (TCP/IP)

  • ften over a socket
slide-25
SLIDE 25

March 5, 2003

  • Dr. Peter R Gillett

25

Firewall FAQ

http://www.interhack.net/pubs/fwfaq/firewalls-faq.pdf Filter in/out access control Access control consistency Covers bad application protocols Cost/service benefit Network level Application level

ftp Proxy Direct

slide-26
SLIDE 26

March 5, 2003

  • Dr. Peter R Gillett

26

Firewall FAQ

Allow only what is necessary Consider space between Extranet and Intranet

to be “DMZ”

Try to isolate single points of failure There are few technical solutions for social

problems

Watch out for:

ICMP re-directs Proxies and mirrored data DNS spoofing: IP hijacking, etc.

slide-27
SLIDE 27

March 5, 2003

  • Dr. Peter R Gillett

27

Firewall FAQ

Watch for:

Port Scans Sniffing

Password (use RSA, etc.) Clear Text Sniffing

Preventives

Use sniffers yourself Monitor traffic Anomaly detection

slide-28
SLIDE 28

March 5, 2003

  • Dr. Peter R Gillett

28

Firewall Heuristics

Increase the level of security as you “go

into your network site”

In other words: inner fire-walls “stronger”

than outer fire-walls

Why? Partition Intranet and Extranet into security

zones, possibly orthogonal to each other

Include an experienced human in the loop

slide-29
SLIDE 29

March 5, 2003

  • Dr. Peter R Gillett

29

Other Methods

PGP: protocol, see http://www.pgp.com/ Secure MIME (Multipurpose Internet Mail

Extensions): a hierarchical approach

Cyber Cash SSL: get a secured link (socket)

slide-30
SLIDE 30

March 5, 2003

  • Dr. Peter R Gillett

30

System Penetration

Reconnaissance Probe and attack Toehold Advancement Stealth Listening post Takeover

slide-31
SLIDE 31

March 5, 2003

  • Dr. Peter R Gillett

31

E-Commerce and Business

On-line shopping grew by 300% Between

1997 and 2000

On-line shopping grew by 600% in the last

year

Security made this possible IBM: “e-business is the transformation of

key business processes through the use of Internet technologies”

slide-32
SLIDE 32

March 5, 2003

  • Dr. Peter R Gillett

32

ATM: Asynchronous Transfer Mode

  • http://www.npac.syr.edu/users/mahesh/homepage/atm_tutorial
  • http://www.iec.org/tutorials/atm_fund/topic01.html

Integrates Voice, Video and Data Uses short fixed length packets called cells Not guaranteed delivery: best effort Bandwidth on demand: define circuit then get

bandwidth

Once a path is found from source and destination:

Then virtual circuit is established All cells travel this path

slide-33
SLIDE 33

March 5, 2003

  • Dr. Peter R Gillett

33

ATM Design Questions

Fixed length cells (48 bytes + 5 byte header)

Why? What does this have to do with Video, etc.

Cells are delivered in order (though some can be lost) VPC: Virtual Path Connection: which path to take, that is

for virtual circuits

VCC: Virtual Channel Connection or a Virtual Circuit ATM network focuses on the VPC (the block of common

start and destination virtual circuits)

Why is this good? Failure?

slide-34
SLIDE 34

March 5, 2003

  • Dr. Peter R Gillett

34

ATM Flavors

Five service classes

constant bit rate (CBR) variable bit rate–non-real time (VBR–NRT),

uses statistical multiplexing

variable bit rate–real time (VBR–RT) available bit rate (ABR) unspecified bit rate (UBR)

In what business sense are these useful?

slide-35
SLIDE 35

March 5, 2003

  • Dr. Peter R Gillett

35

ATM: Benefits

ATM is between Circuit Switching and Packet

Switching

Uses “Statistical Multiplexing” for fast switching

technology

Multiplexing: joining data for the trip Gives high bandwidth use

Very high speed Integrated types of traffic (Voice, Data, Video)

slide-36
SLIDE 36

March 5, 2003

  • Dr. Peter R Gillett

36

ATM General Design: PROS

Not hardware or software specific Covers both LANs and WANS Super-scalability:

Number of users (multiplexing) Geographic distance

Consistent speed achievable by keeping

same circuit

slide-37
SLIDE 37

March 5, 2003

  • Dr. Peter R Gillett

37

ATM General Design: CONS

High overhead for each cell (lots of

descriptive information)

Packet loss possible: best effort, not

guaranteed cell arrival (like TCP).

Quality-of-service hard to guarantee

slide-38
SLIDE 38

March 5, 2003

  • Dr. Peter R Gillett

38

ATM: LAN or WAN?

Can perform both broadcast and point-to-

point

Can use IP protocol Can use

144 to 150 Mbps: OC3 622 Mbps: OC12 2.5 Gbps: OC48 Others…

slide-39
SLIDE 39

March 5, 2003

  • Dr. Peter R Gillett

39

VPNs

Virtual Private Networks

Private networks constructed within a public network

infrastructure such as the global Internet

Communications environments in which access is

controlled to permit peer connections only within a defined community of interest, and is constructed through some form of partitioning of a common underlying communications medium, where this underlying communications medium provides services on a non-exclusive basis

slide-40
SLIDE 40

March 5, 2003

  • Dr. Peter R Gillett

40

VPNs

Link layer Network layer Transport layer Application layer

slide-41
SLIDE 41

March 5, 2003

  • Dr. Peter R Gillett

41

Simple Game Theory

Zero Sum Games General Sum Games: all equilibriums don’t have

the same payoffs!

Maximizing I does NOT necessarily Minimize II Pure Strategy: can have no equilibriums! Mixed Strategy

Nash’s Theorem: General Sum Pure Strategy

Games Always Have Mixed Strategy Equilibriums!

slide-42
SLIDE 42

March 5, 2003

  • Dr. Peter R Gillett

42

Simple Game Theory

The Prisoner's Dilemma shows how Pure

Strategy can be locally optimal, but not globally optimal!

Nash Equilibrium: (max payoff) In Nash Equilibrium iff for all si’ we have: gi(s1,…,si’,…sn) <= gi(s1,…,si,…sn) Depends on other player’s choices

slide-43
SLIDE 43

March 5, 2003

  • Dr. Peter R Gillett

43

C D

A2

(3,3) (0,4) (4,0) (1,1)

Prisoner's Dilemma

C

A1

D

slide-44
SLIDE 44

March 5, 2003

  • Dr. Peter R Gillett

44

Lessons

Nash Equilibrium: neither player has an

incentive to move their position

Rigid row and column issue! Not zero sum: no cooperation means not

necessarily globally optimal

What to do?
