15-150 Fall 2020 Lecture 12

Stephen Brookes

MIT study says if you get more Z’s, you’ll get more A’s

Midterm 1 Tuesday, October 13 No class that day

Font of all knowledge?

Australian researchers developed a typeface to help students cramming for exams. A study found a small increase in the amount remembered. The font has a back slant and gaps. “If something is too easy to read, it doesn’t create a memory trace.”

Study for the Midterm!

and now…

• Generalizing the subset-sum problem
• Developing specs and code together
• A lesson in program design

We’re dealing with functions for problems that need careful specifications We may be informal (“positive integer x”) or more formal (“x > 0”) But whatever we do, MUST be clear

making change

• Given a non-negative integer n,

a list L of positive integers, and a constraint p : int list -> bool

• Is there a sublist of L that satisfies p

and adds up to n?

making change

• Given a non-negative integer n,

a list L of positive integers, and a constraint p : int list -> bool

• Is there a sublist of L that satisfies p

and adds up to n?

fun sublists L = foldr (fn (x, S) => S @ (map (fn A => x::A) S)) [ [ ] ] L

making change

• Given a non-negative integer n,

a list L of positive integers, and a constraint p : int list -> bool

• Is there a sublist of L that satisfies p

and adds up to n?

fun sublists L = foldr (fn (x, S) => S @ (map (fn A => x::A) S)) [ [ ] ] L

val sublists = fn : 'a list -> 'a list list

• sublists [1,2,3];

val it = [[],[3],[2],[2,3],[1],[1,3],[1,2],[1,2,3]] : int list list

badchange : int * int list -> (int list -> bool) -> bool

A non-recursive function that returns a boolean

badchange : int * int list -> (int list -> bool) -> bool

A non-recursive function that returns a boolean

fun exists q = foldl (fn (x, t) => q x orelse t) false val sum = foldl (op +) 0

badchange : int * int list -> (int list -> bool) -> bool

A non-recursive function that returns a boolean

fun badchange (n, L) p = exists (fn A => sum A = n andalso p A) (sublists L)

fun exists q = foldl (fn (x, t) => q x orelse t) false val sum = foldl (op +) 0

badchange : int * int list -> (int list -> bool) -> bool

A non-recursive function that returns a boolean

fun badchange (n, L) p = exists (fn A => sum A = n andalso p A) (sublists L)

badchange satisfies the spec

fun exists q = foldl (fn (x, t) => q x orelse t) false val sum = foldl (op +) 0

badchange : int * int list -> (int list -> bool) -> bool

A non-recursive function that returns a boolean

fun badchange (n, L) p = exists (fn A => sum A = n andalso p A) (sublists L)

badchange satisfies the spec

fun exists q = foldl (fn (x, t) => q x orelse t) false val sum = foldl (op +) 0

but it’s inefficient!

========>* true

critique

badchange (300, [1,2,3,...,24]) (fn _ => true)

(VERY SLOW!)

========>* true

critique

brute force search

• generates the list of all sublists
• and tests them, sequentially

badchange (300, [1,2,3,...,24]) (fn _ => true)

(VERY SLOW!)

(224) ========>* true

critique

brute force search

• generates the list of all sublists
• and tests them, sequentially

badchange (300, [1,2,3,...,24]) (fn _ => true)

(VERY SLOW!)

(224) … only the final sublist will work! ========>* true

critique

brute force search

• generates the list of all sublists
• and tests them, sequentially

badchange (300, [1,2,3,...,24]) (fn _ => true)

(VERY SLOW!)

1 + 2 + … + 24 = 300

(224) … only the final sublist will work! ========>* true

critique

brute force search

• generates the list of all sublists
• and tests them, sequentially

badchange (300, [1,2,3,...,24]) (fn _ => true)

(VERY SLOW!)

specification

change : int * int list -> (int list -> bool) -> bool REQUIRES p is total, n≥0, L a list of positive integers ENSURES change (n, L) p = true if there is a sublist A of L with sum A = n and p A = true change (n, L) p = false, otherwise + must be faster! “can we make change for (n, L) that satisfies p?”

a better strategy

Avoid building the list of sublists

• only call p on sublists with the correct sum

Deal with special cases first

• n = 0
• n > 0, L = [ ]

For n > 0, L = x::R, use recursion... the spec suggests this might be feasible!

fun change (0, L) p = | change (n, [ ]) p = | change (n, x::R) p =

A recursive function that returns a boolean

p [ ] false if x <= n then change (n-x, R) (fn A => p(x::A))

• relse

change (n, R) p else change (n, R) p

change : int * int list -> (int list -> bool) -> bool

fun change (0, L) p = | change (n, [ ]) p = | change (n, x::R) p =

A recursive function that returns a boolean

change (300, [1,2,3,...,24]) (fn _ => true)

p [ ] false if x <= n then change (n-x, R) (fn A => p(x::A))

• relse

change (n, R) p else change (n, R) p

change : int * int list -> (int list -> bool) -> bool

fun change (0, L) p = | change (n, [ ]) p = | change (n, x::R) p =

A recursive function that returns a boolean

change (300, [1,2,3,...,24]) (fn _ => true) ⟹ true

(very fast)

p [ ] false if x <= n then change (n-x, R) (fn A => p(x::A))

• relse

change (n, R) p else change (n, R) p

change : int * int list -> (int list -> bool) -> bool

equivalently

fun change (0, L) p = | change (n, [ ]) p = | change (n, x::R) p = p [ ] false if x <= n then case change (n-x, R) (fn A => p(x::A)) of true => true | false => change (n, R) p else change (n, R) p

(you’ll soon see why we mention this)

fun change (0, L) p = p [ ] | change (n, [ ]) p = false | change (n, x::R) p = if x <= n then change (n-x, R) (fn A => p(x::A))

• relse

change (n, R) p else change (n, R) p

CHECK that each clause fits this type: the LHS patterns match types int * int list and int list -> bool, and give bindings such that, assuming change : int * int list -> (int list -> bool) -> bool, the RHS expression gets type bool

type check

change : int * int list -> (int list -> bool) -> bool

fun change (0, L) p = p [ ] | change (n, [ ]) p = false | change (n, x::R) p = if x <= n then change (n-x, R) (fn A => p(x::A))

• relse

change (n, R) p else change (n, R) p

REQUIRES p is total, n≥0, L a list of positive integers

CHECK if requires holds for (n, L, p) and change (n, L) p calls change (n’,L’) p’ and recursive call satisfies ensures

then requires holds for (n’, L’, p’) and original call satisfies ensures

spec check

ENSURES change (n, L) p = true iff there is a sublist A of L with sum A = n and p A = true

benefits

• The type check shows that

the function has the intended type(!)

• Use type check to guide the code design
• ML will give same type (or a more general one)
• The spec check is basically a sketch of an

inductive correctness proof

• Use spec check to guide the code design
• Will then be easy to give a fully detailed proof
• f correctness

correctness

• PROOF: induction on L

For all positive integer lists L, n ≥ 0, and total functions p : int list -> bool, change (n, L) p = true if there is a sublist A of L with sum A = n and p A = true change (n, L) p = false, otherwise

why?

examples

change (10, [5,2,5]) (fn _ => true) = true change (10, [10,5,2,5]) (fn A => length(A)>1) = true change (10, [10,5,2]) (fn A => length(A)>1) = false change (210, [1,2,3,...,20]) (fn _ => true) ⟹* true (FAST!)

the right question?

change : int * int list -> (int list -> bool) -> bool

the right question?

Is there a sublist that adds to 300? change : int * int list -> (int list -> bool) -> bool

the right question?

Is there a sublist that adds to 300?

val it = true (YES)

change : int * int list -> (int list -> bool) -> bool

the right question?

Is there a sublist that adds to 300?

val it = true (YES)

What is it?

change : int * int list -> (int list -> bool) -> bool

the right question?

Is there a sublist that adds to 300?

val it = true (YES)

What is it? You didn’t ask

change : int * int list -> (int list -> bool) -> bool

boolean blindness

• A truth value only gives a bit of information
• From the context, we know true (yes) means

“it’s possible to make change...”

• But what if we want more information?
• “a list that works, if there is one”

NEED a function that computes a suitable sublist, if there is one

boolean blindness

• A truth value only gives a bit of information
• From the context, we know true (yes) means

“it’s possible to make change...”

• But what if we want more information?
• “a list that works, if there is one”

PLAN a function that returns an (int list) option NEED a function that computes a suitable sublist, if there is one

boolean blindness

• A truth value only gives a bit of information
• From the context, we know true (yes) means

“it’s possible to make change...”

• But what if we want more information?
• “a list that works, if there is one”

mkchange

mkchange : int * int list -> (int list -> bool) -> int list option REQUIRES p is total, n >= 0, L is a list of positive integers ENSURES mkchange (n, L) p = SOME A, where A is a sublist of L with sum A = n and p A = true, if there is one mkchange (n, L) p = NONE, otherwise A recursive function that returns an (int list) option

mkchange

fun mkchange (0, L) p = | mkchange (n, [ ]) p = | mkchange (n, x::R) p = if p [ ] then SOME [ ] else NONE NONE if x <= n then case mkchange (n-x, R) (fn A => p(x::A)) of SOME A => SOME (x::A) | NONE => mkchange (n, R) p else mkchange (n, R) p

correctness?

• PROOF: induction on L

For all positive integer lists L, n ≥ 0, and total functions p : int list -> bool, mkchange (n, L) p = SOME A where A is a sublist of L with sum A = n and p A = true, if there is one mkchange (n, L) p = NONE, otherwise (similar to the proof of change)

assessment

mkchange : int * int list -> (int list -> bool) -> int list option change : int * int list -> (int list -> bool) -> bool

The definitions have similar control flow,

fun mkchange (0, L) p = if p [ ] then … else … | mkchange (n, [ ]) p = … | mkchange (n, x::R) p = if x <= n then case mkchange (n-x, R) (fn A => p(x::A)) of SOME A => … | NONE => mkchange (n, R) p else mkchange (n, R) p fun change (0, L) p = if p [ ] then … else … | change (n, [ ]) p = … | change (n, x::R) p = if x <= n then case change (n-x, R) (fn A => p(x::A)) of true => … | false => change (n, R) p else change (n, R) p

with pattern-matching based on the result type

change : int * int list -> (int list -> bool) -> bool mkchange : int * int list -> (int list -> bool) -> int list option

problem

problem

problem

What if the boss decides he wants yet another type of answer?

problem

What if the boss decides he wants yet another type of answer? How could we avoid having to keep re-doing the code design all over again?

• Design a very flexible function
• Instead of returning a bool or int list option,

use a type variable ’a for the answer type and use function parameters s and k to represent success and failure

go polymorphic...

s : int list -> ’a k : unit -> ’a

call s if you find a solution call k if you fail

(to be chosen later)

Choose the answer type to suit your task, later!

changer : int * int list -> (int list -> bool)

• > (int list -> 'a) -> (unit -> 'a) -> 'a

more flexible

changer (n, L) p s k

: int list -> t : unit -> t

: t

this recipe works for any type t

• f “answers”

warning

• We’re using a type variable ’a to stand for

the “answer” type, to be chosen later

• When we design the code, we cannot

pattern match on values of type ’a

case of (* what — we don’t know the type *)

changer (n-x, R) p’ s’ k’

case change (n-x, R) p’ of true => … | false => … case mkchange (n-x, R) p’ of SOME A => … | NONE => …

change : int * int list -> … -> bool mkchange : int * int list -> … -> (int list) option

changer : int * int list -> … -> 'a

no problem

• Instead of returning a value,

design the function to

• either call the success continuation with a value
• or call the failure continuation
• Just remember: never return!
• Spoiler alert: This is “continuation-passing style”

success

is a success continuation s : int list -> t

“there will be an answer, let it be s [1,2,3]”

failure

k : unit -> t is a failure continuation

“I don’t have an answer, so try using k( )”

more flexible spec

changer : int * int list -> (int list -> bool)

• > (int list -> 'a) -> (unit -> 'a) -> 'a

REQUIRES n>=0, L a list of positive integers, p total ENSURES changer (n, L) p s k = s A where A is a sublist of L such that sum A = n and p A = true, if there is one changer (n, L) p s k = k ( )

• therwise

success, call s with a value failure, call k

changer

fun changer (0, L) p s k = | changer (n, [ ]) p s k = | changer (n, x::R) p s k = if p [ ] then s [ ] else k( ) k( ) if x <= n then changer (n-x, R) (fn A => p(x::A)) (fn A => s(x::A)) (fn ( ) => changer (n, R) p s k) else changer (n, R) p s k

changer

fun changer (0, L) p s k = if p [ ] then s [ ] else k( ) | changer (n, [ ]) p s k = k( ) | changer (n, x::R) p s k = if x <= n then changer (n-x, R) (fn A => p(x::A)) (fn A => s(x::A)) (fn ( ) => changer (n, R) p s k) else changer (n, R) p s k

check type and spec

examples

• changer (12, [1,1,1,1,1,1,1,2,4,6])

(fn _ => true) SOME (fn () => NONE); val it = SOME [1,1,1,1,1,1,2,4] : int list option

• changer (12, [1,1,1,1,1,1,1,2,4,6])

(fn A => length A < 4) SOME (fn () => NONE); val it = SOME [2,4,6] : int list option

correctness?

• PROOF Induction on L

For all lists L of positive integers, n ≥ 0, total functions p : int list -> bool, all types t and all s : int list -> t, k : unit -> t changer (n, L) p s k = s A where A is a sublist of L with sum A = n and p A = true, if there is one changer (n, L) p s k = k( ), otherwise (similar to the proofs for change, mkchange…)

verbose?

• We make argument assumptions explicit
• We indicate flexibility of result type
• We use accurate math notation
• The requirements are clear

“For all types t, all total functions p, …yada yada yada”

precise!

utility

fun change (n, L) p =

fun mkchange (n, L) p =

changer : int * int list -> (int list -> bool)

• > (int list -> 'a) -> (unit -> 'a) -> 'a

change : int * int list -> (int list -> bool) -> bool mkchange : int * int list -> (int list -> bool) -> int list option

changer (n, L) p (fn _ => true) (fn ( ) => false)

changer (n, L) p SOME (fn ( ) => NONE)

robust

• There’s no need to re-do the code if the

manager decides to change the spec again, e.g. by giving an extra penny

fun generous_change (n, L) p = changer (n, L) p (fn A => 1::A) (fn ( ) => [1])

• generous_change (12, [5,5,2,42]) (fn _ => true)

val it = [1,5,5,2] : int list

generous_change : int * int list -> (int list -> bool) -> int list

lessons

• May be better to solve a more general problem
• suitable for recursion, polymorphic
• Propagate enough information
• a boolean may not be sufficient
• Make sure that requirements hold for

recursive calls… so you can use inductive hypothesis that recursive calls work correctly

reflection

• We ended up showing how continuations

can be used to solve a problem that we initially solved directly

• In fact, for every direct-style function

there is a continuation-style function that “does the same job”…

direct-style

A function of type t1 -> t2 can be applied to an argument of type t1, and returns a value of type t2. A direct-style function evaluates its argument, returns a result.

direct-style

A function of type t1 -> t2 can be applied to an argument of type t1, and returns a value of type t2. A direct-style function evaluates its argument, returns a result.

“here’s my number...”

continuation-style

A continuation-style function of type t1 -> (t2 -> ’a) -> ’a can be applied to an argument of type t1 and a continuation of type t2 -> a, where a is a type of “answers”. Instead of “returning” a result value of type t2, it passes that value to its continuation, to get an “answer”.

continuation-style

A continuation-style function of type t1 -> (t2 -> ’a) -> ’a can be applied to an argument of type t1 and a continuation of type t2 -> a, where a is a type of “answers”. Instead of “returning” a result value of type t2, it passes that value to its continuation, to get an “answer”.

“here’s my number, give me an answer”

continuation?

• A function that represents

“the rest of a computation” or “what to do next”

• Expects to be called

with a value (“the result so far”) and computes a final value (an “answer”)

direct cps

• Every direct-style function definition

can be turned into a cps function definition

• a syntax-based transformation
• The cps version makes control flow and

intermediate values explicit

• The cps version is also tail recursive

and polymorphic

factorial

fun fact n = if n=0 then 1 else n * fact(n-1) (* fact : int -> int *) fun fact_cps n k = if n=0 then k 1 else fact_cps(n-1)(fn x => k(n * x)) (* fact_cps: int -> (int -> ’a) -> ’a *)

direct continuation style style

not tail recursive tail recursive

examples

• fact_cps 3 (fn x => x) = 6
• fact_cps 3 Int.toString = “6”
• fact_cps 3 (fn y => fact_cps y Int.toString) = ????

examples

• fun prod [] = 1

| prod (x::L) = x * prod L; val prod = fn : int list -> int

• fun prod_cps [ ] k = k 1

| prod_cps (x::L) k = prod_cps L (fn y => k(x*y)); val prod_cps = fn : int list -> (int -> 'a) -> 'a

prod_cps is the continuation-style version of prod

examples

• fun prod [] = 1

| prod (x::L) = x * prod L; val prod = fn : int list -> int

• fun Prod [ ] k = k 1

| Prod (x::L) k = x * Prod L k; val Prod = fn : int list -> (int -> int) -> int

Prod is not the cps version of prod! Its type is also weirdly specific (an instance of the expected type, with int for ’a)

examples

• fun split [ ] = ([ ], [ ])

| split [x] = ([x], [ ]) | split (x::y::L) = let val (A, B) = split L in (x::A, y::B) end; val split = fn : 'a list -> 'a list * 'a list

• fun split_cps [ ] k = k ([ ], [ ])

| split_cps [x] k = k ([x], [ ]) | split_cps (x::y::L) k = split_cps L (fn (A, B) => k(x::A, y::B)); val split_cps = fn : 'a list -> ('a list * 'a list -> 'b) -> 'b

split_cps is the continuation-style version of split

connections

• The cps-version of a direct-style function

“does the same job”

F : t1 -> t2 F_cps : t1 -> (t2 -> ’a) -> ’a

Theorem: For all types t, values x : t1, k : t2 -> t, F_cps x k = k (F x).

Prove Theorems like this for (i) fact and fact_cps (ii) prod and prod_cps (iii) split and split_cps

warnings

• It’s easy to go wrong
• A cps function NEVER returns…

it calls a continuation instead

• If ML tells you an unexpected type,

typically less polymorphic, you got it wrong.

The cps version of f is NOT just fun f_cps x k = k(f x)

next Tuesday

• Midterm Exam 1
• Watch for announcements about release

and hand-in instructions

• Online, at home
• No cheating or collaborating
• It’s OK to refer to lecture notes and slides
• No class on Tuesday

October 13

• covers material so far, excluding continuation-passing style
• including map, folds, lists, trees, specs, proofs, work/span,…

next Thursday

• Using continuations for backtracking
• Many search algorithms backtrack

from a dead end, to an earlier choice point, and explore further alternatives

• Easy to implement… with a failure continuation

call it , maybe!

October 13
