SLIDE 1
1
2
6th Grade
Earth's Materials and Systems Part 1: The History of Planet Earth
20150827 www.njctl.org
1 6th Grade Earth's Materials and Systems Part 1: The History of - - PowerPoint PPT Presentation
1 6th Grade Earth's Materials and Systems Part 1: The History of - - PowerPoint PPT Presentation
1 6th Grade Earth's Materials and Systems Part 1: The History of Planet Earth 20150827 www.njctl.org 2 Table of Contents: The History of Planet Earth Click on the topic to go to that section Earth's Layers Three Types of Rocks
SLIDE 2
SLIDE 3
3
Table of Contents: The History
- f Planet Earth
- Earth's Layers
- Three Types of Rocks
- Rock Strata
- Early Life on Earth / Fossils
Click on the topic to go to that section
SLIDE 4
4
Earth's Layers
Return to Table
- f Contents
SLIDE 5
5
Review
Earth is a "terrestrial" or rocky
- planet. This means that it is made
up of rocks and minerals. The rocks and minerals that now make up our Earth were once just small chunks revolving around our
- sun. Over billions of years, they
combined to form the planet we live
- n today.
What are the other rocky planets in our solar system?
SLIDE 6
6
The Makeup of Earth
As Earth grew larger, its gravity increased. Pressure beneath Earth's surface caused changes to the Earth's makeup. Distinct layers began to form. Do you remember any of the names of the layers? Brainstorm with your table.
SLIDE 7
7
The Layers of Earth
Our Earth is divided into four major layers:
Crust
Mantle Outer Core Inner Core
SLIDE 8
8
Earth's Crust
Think of the crust of Earth as the crust of a pizza pie. The crust is the outermost layer of Earth, just like the crust above is the outermost layer of the pizza!
SLIDE 9
9
Earth's Crust
This section is very thin compared to
- ther layers of Earth (between 5 and
25 miles thick) and it is very hard and rigid. The crust is composed of plates that slide around on top of the section below it. This portion is called the lithosphere. There are 2 parts to the crust. One is the land. What is the other part?
SLIDE 10
10
Earth's Mantle
The next layer down is the mantle. This is the largest layer about 1,800 miles thick! The mantle is made up of incredibly hot, semisolid rock (basically think of rock in a form sort of like pudding). This layer makes up about 2/3 of Earth's mass.
SLIDE 11
11
1 Which best describes the lithosphere? A The part of the atmosphere which we breathe. B The layer of Earth that makes up the greatest mass. C A layer of Earth that is made of a jellolike substance. D The plates of Earth that slide around the surface.
Answer
SLIDE 12
12
2 What is true of the mantle? A It is the thickest layer of Earth. B It is the top layer of Earth. C It is entirely made of liquid. D It is the least massive portion of Earth.
Answer
SLIDE 13
13
3 The mantle is composed of Earth's land and oceans. True False
Answer
SLIDE 14
14
4 Choose the correct order of Earth's layers from outermost to most inner. A mantle, crust, inner core, outer core B inner core, outer core, crust, mantle C inner core, outer core, mantle, crust D crust, mantle, outer core, inner core
Answer
SLIDE 15
15
Earth's Outer Core
The Outer Core is so hot that it is entirely
- liquid. It is the only liquid layer of Earth.
It is made up of mainly nickel and iron. To give you an idea of how hot it is, nickel becomes a liquid at 2,650 degrees F and iron melts at 2,800 degrees F! What temperature does ice melt at?
SLIDE 16
16
Earth's Inner Core
At the very center of Earth, you will find the Inner Core. Like the Outer Core, this layer is also extremely hot and is made of nickel and iron. Although the temperature is higher, the nickel and iron here are in solid form because of the intense pressure that this layer experiences.
SLIDE 17
17
5 What separates the Inner and Outer Core?
A
The Inner Core is made of liquid; the Outer Core is solid.
B
The Outer Core is hotter than the Inner Core.
C
The Inner Core is solid; the Outer Core is liquid.
D
The Outer Core is under more pressure than the Inner Core.
Answer
SLIDE 18
18
6 Which is the oldest layer of Earth? A crust B mantle C outer core D inner core
Answer
SLIDE 19
19
Size of Earth's Layers
SLIDE 20
20
Three Types
- f Rocks
Return to Table
- f Contents
SLIDE 21
21
Formation of Rocks
The layers of Earth are constantly moving and changing due to intense heat and pressure. The energy of this heat and pressure results in the formation of rocks. But what exactly is a
rock?
With your table, come up with some characteristics
- f rocks.
Answer Rock Relatively hard, naturally forming mineral
SLIDE 22
22
Three Types of Rocks
How a rock forms depends on what type of rock it is. There are three types of rocks: Sedimentary Metamorphic Igneous Click on the rock type to see an example.
SLIDE 23
23
How Do Rocks Form?
The three types of rocks on the previous page each form in different ways. The animation on the next slide will introduce you to the process behind the transformation of rocks from
- ne type to another a
process known as the
rock cycle.
Answer the questions on the accompanying worksheet while watching the animation.
SLIDE 24
24
SLIDE 25
25
7 Which of the following is not a type of rock? A Metamorphic B Glacier C Igneous D Sedimentary
Answer
SLIDE 26
26
Sedimentary Rock
"Sediments" are small fragments of rock. To form Sedimentary rock, these fragments combine together. These rocks are typically multicolored with many different textures.
SLIDE 27
27
Igneous Rock
"Igneous" has the same root word as "ignite." What does ignite mean? These rocks are typically dark, very shiny, and made up of crystals. Igneous rocks form when magma, which we can think of as "liquid fire," cools down.
SLIDE 28
28
Types of Igneous Rock
"Intrusive" igneous rock is still inside Earth. There are two types of igneous rock. "Extrusive" igneous rock has
exited Earth.
SLIDE 29
29
Metamorphosis
A "Metamorphosis" is when something changes into something new. You have learned about a few organisms which undergo metamorphosis in your science classes over the years. At your table, talk for a few minutes about the 2 organisms below and the metamorphosis they undergo during their lives.
SLIDE 30
30
Metamorphic Rock
These rocks are typically made up of layers that formed as the rock was squashed under pressure. Just like the frog, metamorphic rock is formed when another one type
- f rock changes into a new type of rock.
Metamorphic rock forms when another type of rock changes its chemical makeup because
- f heat and pressure.
SLIDE 31
31
8 Which type of rock is made up of pieces
- f other
rocks?
A
Metamorphic
B Extrusive Igneous C Intrusive Igneous D Sedimentary
Answer
SLIDE 32
32
9 Which type of rock is formed of magma below the surface of Earth?
A
Metamorphic
B Extrusive Igneous C Intrusive Igneous D Sedimentary
Answer
SLIDE 33
33
10 Which type of rock is formed when other rocks undergo a transformation due to heat or pressure?
A
Metamorphic
B Extrusive Igneous C Intrusive Igneous D Sedimentary
Answer
SLIDE 34
34
11 Which type of rock is formed from magma cooling on Earth's surface?
A
Metamorphic
B Extrusive Igneous C Intrusive Igneous D Sedimentary
Answer
SLIDE 35
35
12 This is an example of ________ rock. A Sedimentary B Igneous C Metamorphic
Answer
SLIDE 36
36
13 This is an example of ________ rock. A Sedimentary B Igneous C Metamorphic
Answer
SLIDE 37
37
14 This is an example of ________ rock. A Sedimentary B Igneous C Metamorphic
Answer
SLIDE 38
38
15 This is an example of ________ rock. A Sedimentary B Igneous C Metamorphic
Answer
SLIDE 39
39
Early Life on Earth / Fossils
Return to Table
- f Contents
SLIDE 40
40
The Age of Earth
Scientists estimate that the Earth formed around 4.6 billion years ago. We can learn about the history of Earth by studying rocks and fossils.
SLIDE 41
41
First Life on Earth
There is evidence within the rocks on Earth that suggests that life first appeared on Earth about 3.6 billion years ago.
The image above is of stromatolites , the oldest fossils on record. They provide us with evidence of very simple life forms like bacteria as long as 3.5 billion years ago.
SLIDE 42
42
bacteria
Prokaryotes
The first cells that existed on Earth were closely related to
- prokaryotes. These are cells that do not have a nucleus.
Most prokaryotes are singlecelled organisms. Why were the first
- rganisms on Earth
very simple? What is a more common name for prokaryotes? Move the image once you come up with an idea.
SLIDE 43
43
Prokaryotes
Very specific conditions were needed for these living organisms to form. Organic chemicals (chemicals that include carbon) as well as some sort of heat were needed to form these cells.
SLIDE 44
44
Photosynthetic Organisms
Food was scarce on the early Earth. Why do you think this was? What do most organisms that we know of today eat? Come up with a theory at your table.
SLIDE 45
45
Photosynthetic Organisms
Food was scarce on the early Earth because there were only a few
- rganisms to begin with! Some prokaryotes developed
the ability to create their own food by converting sunlight, carbon dioxide, and water into sugar and oxygen. The creation of oxygen through this process led the way for more complex organisms, like animals, to evolve.
SLIDE 46
46
How Do Scientists Reconstruct the Past?
Scientists can estimate what life was like billions of years ago thanks to the discovery of fossils. What is a fossil?
SLIDE 47
47
Fossils are typically found in Sedimentary Rock
How Do Scientists Reconstruct the Past?
A fossil is the preserved remains of an organism which is found in rock formations. In what type of rock do you think fossils usually can be found ? Think about how rocks are formed. The answer is under the photo to the right
SLIDE 48
48
How Do Scientists Reconstruct the Past?
Photo : Thomas Bresson Fossilized Seaweed
The first fossils that hint at the existence of complex organisms are roughly 1.8 billion years old. The first algae appeared about 1.2 billion years ago.
SLIDE 49
49
How Do Scientists Reconstruct the Past?
How can scientists come up with the ages on the previous slide? It is difficult for scientists to figure out the age of the actual fossils, so instead they find the age of the sedimentary rock in which the fossil was found. The different colored layers in the picture above would help scientists estimate the age of fossils.
SLIDE 50
50
Activity Fossil Layers
Most fossils can be found in layers of sedimentary rock. Some can also be found in metamorphic rock, but they would be distorted due to heat and pressure. In this activity, you will create your
- wn "sedimentary rock" full of fossils
and then examine the affect that pressure has on them.
SLIDE 51
51
Fossil Excavation
As was mentioned in the section on the Types of Rocks, the older rocks will be further down within Earth. Fossilized organisms will be about the same age as the layer of rock they are found in. It is the job of a paleontologist to excavate, or dig up, these fossils and determine their ages.
SLIDE 52
52
16 Fossils are usually found in _________ rock. A metamorphic B sedimentary C igneous
Answer
SLIDE 53
53
17 Old fossils will be found ______ Earth than younger fossils. A deeper down in B on the surface of C anywhere on
Answer
SLIDE 54
54
18 Scientists use _________ to determine the age of fossils. A chemistry B microscopes C rock layers
Answer
SLIDE 55
55
Activity Cookie Excavation
The work of a paleontologist is very delicate and difficult. It requires a lot of patience and care. In this activity, you will practice these skills on different types of cookies. Can you excavate the chocolate chips from the cookies using only your paleontology tools?
SLIDE 56
56
Vertebrate Fossil Webquest
Now that the "fossils" have been excavated, how do they get from the site to the museum? Use the site above to track a vertebrate fossil!
SLIDE 57
57
Rock Strata
Return to Table
- f Contents
SLIDE 58
58
How Do We Determine a Fossil's Age?
In our last section, we learned that we can tell a fossil's age based on the rock it is found in. This provides us with a general range for the age of the fossil. The deeper it is within Earth, the older the fossil is.
SLIDE 59
59
19 What kind of rock is featured on the previous page?
A
Sedimentary B Metamorphic
C Igneous
Answer
B
SLIDE 60
60
20 Which type(s) of rocks can contain fossils?
A
Sedimentary B Metamorphic
C Igneous
Answer
SLIDE 61
61
Life on Earth
One goal of geology (the study of rocks) is to develop a timeline
- f Earth's past...
...and we can use this information to make connections between the first simple life forms to the diversity on Earth today.
SLIDE 62
62
Absolute Age
Scientists use various techniques to determine the age of rocks. Sometimes, scientists are able to determine the absolute age, or the exact age, of a rock or fossil. The absolute age of the petrified wood above is 2,500 years old.
SLIDE 63
63
How Do Scientists Determine Absolute Age?
Scientists use a technique called radiometric dating to determine absolute age. Radiometric dating compares the ratio of a radioactive element with the amount that has decayed in the rock or fossil.
SLIDE 64
64
Half Life
When it comes to relative age, scientists analyze the amount of certain radioactive elements within the object. They then use the "half life" of the element to determine the object's age. The half life is the period of time it takes for half of the substance to decay.
SLIDE 65
65
Carbon Dating
A radioactive version of the element Carbon is known as Carbon 14 because it has an atomic mass of 14 (rather than the usual 12). What is atomic mass? Carbon 14 has a half life
- f about 5,700 years.
Carbon 14 is found in every living thing.
SLIDE 66
66
Carbon Dating
This means that if there are 100 atoms of Carbon 14 in the tree when it was alive, there will be only 50 left after it has been dead for 5,700 years. So after one half life, the amount
- f Carbon 14 is cut in half .
SLIDE 67
67
21 After two half lives, how much Carbon 14 would be left from the tree on the previous slide? (hint: what was Carbon14's half life?)
Answer
SLIDE 68
68
22 After one half life, what percentage of Carbon 14 remains? ______%
Answer
SLIDE 69
69
23 After two half lives, what percentage of Carbon 14 remains? ______%
Answer
SLIDE 70
70
Carbon 14
In organisms that were once living, the amount of Carbon 14 will be cut in half every 5,700 years. Scientists use this information to determine how long an organism has been dead ... and therefore find out roughly how old it is!
SLIDE 71
71
Webquest The Radioactive Dating Game
In this activity, you will learn about different types of radiometric dating , such as carbon dating. You will understand how decay and half life work to enable this dating. You will finish it up with a game that tests your ability to match the percentage of the dating element that remains to the age of the object!
SLIDE 72
72
Relative Age
When scientists cannot be exact, they try to determine an object's
relative age. This is when they compare the age of an object or
event to another object or event. Scientists can estimate the age of this volcano by looking at rocks and fossils found around its base. Why would they use the base of the volcano and not the top?
SLIDE 73
73
Index Fossils
What is an index fossil? Click on the dinosaur below to uncover the definition! An index fossil is used to determine the age range of a rock layer. It is the fossil of an organism that existed only for a limited period of time. Since scientists know that the stegosaurus lived between 150 and 155 million years ago, any rock layer containing a stegosaurus fossil will be around that age as well.
SLIDE 74
74
Layers of Rock
When new rock is formed on the surface of Earth, it settles on top of what was there before it. The deeper you dig into Earth's surface, the farther back in time you will see.
SLIDE 75
75
24 In the diagram below, in what layer would the oldest rocks be found? A B C
Layer 1 Layer 2 Layer 3
Permission Granted: FL Museum of Natural History
Answer
