Yukon Presentation November 2012 Disclaimer This presentation - - PowerPoint PPT Presentation

Yukon Presentation November 2012 Disclaimer This presentation contains forward looking statements. All statements, other than statements of historical fact, included herein, including without limitation, statements regarding potential


slide-1
SLIDE 1

Yukon Presentation

November 2012

slide-2
SLIDE 2

Disclaimer

This presentation contains forward looking statements. All statements, other than statements of historical fact, included herein, including without limitation, statements regarding potential mineralisation and reserves, exploration results and future plans and

  • bjectives of Kestrel Gold Inc, are forward-looking statements that involve various risks and uncertainties. There can be no

assurance that such statements will prove to be accurate and actual results and future events could differ materially from those anticipated in such statements. Important factors that could cause actual results to differ materially from Kestrel Gold’s expectations are disclosed under the heading "Risk Factors" and elsewhere in Kestrel’s documents filed from time-to-time with the TSX Venture and other regulatory authorities. None of the material contained in this document is intended or constitutes a solicitation or an offering of securities by Kestrel Gold Inc or any of its affiliated companies or partnerships in any jurisdiction. The information on this presentation is not intended to modify, qualify, supplement or amend information disclosed under corporate and securities legislation of any jurisdiction applicable to Kestrel Gold. And Kestrel Gold makes no commitment and disclaims any duty to update those documents and materials, except as required by law.

Total resources include all categories unless otherwise stated. All currency are in Canadian $ unless otherwise stated.

slide-3
SLIDE 3

King Solomon Dome Project - Yukon

Located in the Yukon Tintina Gold Belt

slide-4
SLIDE 4

King Solomon Dome Project - Yukon

The King Solomon Dome Properties

  • On ridges interpreted to be a potential

source of the estimated 20 million ounce gold rich placer deposits of the Klondike

  • Structurally controlled fracture-faulted

veins within Tanana Terrane Strata comprising schists

  • All properties exhibit high grade gold

mineralisation with values up to 51.2 g/t Au

  • All properties have road access with KSD
  • nly 30 minutes drive from Dawson City.
slide-5
SLIDE 5

King Solomon Dome Project - Yukon

King Solomon Dome Property Exploration

  • Kestrels exploration activities have

advanced all four properties

  • Soil and rock geochemical results have

confirmed the presence of the largest gold anomaly in the Klondike

slide-6
SLIDE 6

King Solomon Dome Project - Yukon

KSD Property Soil Geochemistry

  • Large and significant gold geochemical

anomaly defined (1.6km x 1km)

  • Soil values up to 4 g/t Au (4000ppb)
  • Corresponding strong silver, arsenic, lead

anomalies in and around the main gold zones

slide-7
SLIDE 7

King Solomon Dome Project - Yukon

KSD Property Rock Geochemistry

  • Kestrels 2011 Trenching program returned 23

rocks samples greater than 2 g/t Au (up to 17.1 g/t Au)

  • Strike length of gold bearing quartz vein system
  • ver 1.7 km long (at least 0.4 km wide)
  • New >2 g/t Au zone found in the Dominion

Creek headwaters giving possible offset strike length of 2.6 km

  • Several values greater than 50 g/t Silver
  • Previous bulk sample grades of up to 4 g/t Au

(2276 kg sample) have been recorded in the past

Crosscutting quartz vein (Trench 7-C) That yielded up to 9.4 g/t Au

slide-8
SLIDE 8

King Solomon Dome Project - Yukon

KSD Property 2011 Geophysics

  • Kestrels 2011 IP Geophysical survey identified a large IP anomaly over a distance of 1.2

km

  • The main IP Chargeability anomaly is open to the north and south and to depth and is
  • n trend with the structurally controlled NNW mineralized zone
  • A series of similar readings were observed in the deeper readings adjacent to this large

chargeable unit and suggested that a large mineralized body may widen at depth

  • We knew from favourable trench results testing a previously documented IP survey

that IP chargeability is a good exploration tool

  • Hydrothermal fluids exploit crustal weaknesses in metamorphic rocks replacing

magnetite with gold associated pyrite

slide-9
SLIDE 9

King Solomon Dome Project - Yukon

KSD Property Large Geophysical IP Anomaly widening with depth (pink color)

slide-10
SLIDE 10

King Solomon Dome Project - Yukon

KSD Property large IP Anomaly and coincident large Gold Soil anomaly

slide-11
SLIDE 11

King Solomon Dome Project - Yukon

KSD Property 2012 Geophysics

  • Kestrels 2012 Voltera 3DIP survey identified two deep chargeability anomalies totalling
  • ver 1 km in width
  • The survey was specifically designed to test at depths ranging from 130 m to 500 m
  • At least 3 other anomalies were found at varying depths
  • There is a strong correlation with the surface soil and rock geochemistry values

especially gold, silver, lead and arsenic

slide-12
SLIDE 12

King Solomon Dome Project - Yukon

KSD Property 2012 Geophysics

slide-13
SLIDE 13

King Solomon Dome Project - Yukon

  • The 2012 deeper geophysical survey has

detected what could be a large flat lying litho-tectonic host

  • Inference that an ophiolitic slab and basal

suture zone originally occurred proximal to the productive placer creeks

  • This part of the Klondike Schist assemblage is

thought to be more mafic and favourably reactive to hydrothermal gold bearing fluids

  • Orogenic gold deposits of this type can be

mined deep (>800 m) and the structural

  • rientation of D4 fracture veins suggests this

may be the case

Geological Model

slide-14
SLIDE 14

King Solomon Dome Project - Yukon

Deep system (Mesozonal) for Rich Klondike Gold Source at KSD?

slide-15
SLIDE 15

King Solomon Dome Project - Yukon

A Sulphide gold enriched rich ‘host’ is now a highly plausible possibility based

  • n the results of the 2012 Voltera 3DIP survey indicating large flat lying

chargeability anomalies to at least 350 metres and open in all directions!

slide-16
SLIDE 16

King Solomon Dome Project - Yukon

Magnetics Looking NE – strong NW regional trend (extending to other properties)

slide-17
SLIDE 17

King Solomon Dome Project - Yukon

Dominion Property Soil Geochemistry

  • 2011 Soil sampling

program discovers new 400m long gold anomaly

  • 5.45 g/t and 2.38 g/t rock

samples within anomalous soil region

slide-18
SLIDE 18

King Solomon Dome Project - Yukon

Gold Run Property Soil Geochemistry

  • 2011 Soil sampling

program significantly increases anomalous gold area

  • New zones discovered in

especially in central area

  • f property
slide-19
SLIDE 19

King Solomon Dome Project - Yukon

Gold Run Property Rock and Soil Geochemistry (Doron Zone)

  • New soil anomalies found
  • Previous rock sampling of

trenches includes assays of 2.42 g/t Au over 18.2 m including 9.06 g/t Au over 1.8 m

  • Trenching and diamond

drilling planned

slide-20
SLIDE 20

King Solomon Dome Project - Yukon

Gulf Property Soil and Rock Geochemistry

  • Four (of 11) rock samples

return greater than 1 g/t Au in 2011

  • Grades of up to 51.2 g/t Au
  • Gold anomalies over 1200m
slide-21
SLIDE 21

King Solomon Dome Project - Yukon

  • Blue Sky exploration target - Orogenic Gold Deposits can be very large (up to 50 M oz

Au)

  • In the Klondike, a very large amount of placer gold production (20 M oz Au) is derived

from as little as 400km2 Klondike basement schist implying a spectacular concentration

  • f orogenic gold in the Klondike area yet to be discovered!
  • Unlike all other placer gold rush areas around the world, such as the California

Motherlode district, the source of the Klondike Gold has to date never been found. Significantly, the King Solomon Dome, a central and prominent topographic high surrounded on all sides by rich placer gold streams still being mined today, has never been diamond drilled!

  • The latest deep Voltera IP geophysical survey has significantly improved the geological

model at KSD and created more diamond drill targets that will test for a large flat lying gold enriched host thought to be related to steeper fracture related high grade gold and silver mineralization from depth to surface. Mineralization remains open in all directions!

Conclusion: Orogenic Gold Deposits – The next big find?

slide-22
SLIDE 22

Kestrel Gold Inc.

Contact: Kevin Nephin info@kestrelgold.com Ph: 604-824-6056 Head Office 218-1217 Centre St., NW Calgary, AB T2E 2R8
