SLIDE 1

Working with Hash Tables

Daniel Petrolito (ANZ Bank)

SLIDE 2

Working With Hash Tables

Daniel
ANZ – Data Scientist
SAS 3+ years
Programming 6 years

SLIDE 3

Combining Data

Combining tables
Base table
Lookup table(s)
Want flexibility without too much complexity
Options
Data Step

✓ Flexible ❖ Must pre-sort data

SQL

✓ In-database ❖ Cartesian joins

Others

✓ Macros ✓ Arrays ✓ User-defined formats ✓ Hash tables

SLIDE 4

Combining Data – techniques

You may have tried the following:

Index the fields you are joining on
Reduce number of rows and columns as early in your process as

possible

Do joins where the data originates
SAS dataset compression (compress=yes)
Column lengths
Hash Tables

SLIDE 5

Hash Tables - Introduction

Optimized for speed through

complex hashing algorithms

Think of it as a SAS indexed

data table loaded in memory

SLIDE 6

Benefits & Consequences of Hash Tables

Pros

In-memory, faster lookups than

any other technique

Can join multiple tables, using

different keys, in a single data step

No sorting required

Cons

Object-oriented syntax - not

intuitive to code

Large memory requirement
Data step only

SLIDE 7

Simple Example

People (Base Table) name age John 41 Sally 33 Rebecca 22 Reference (Lookup Table) Name age state John 50VIC Sally 35NSW

Hashtest (Results) name age state rc John 50VIC Sally 35NSW Rebecca 22 160038

Once only, define & populate the hash table For each record in the base table, look up the hash table

Lookup failed – program accordingly

SLIDE 8

Hash Table Methods

Find()
Add()
Replace()
Iterate()
Output()

SLIDE 9

When Not To Use Hash Tables

Speed is not required
Team not technical savvy
Joins are more optimized to be done from external

databases/sources

Not used to replace every left join
Look up table is too big (memory constraint)

SLIDE 10

Real World Example

Build a fast SAS solution working with millions
f rows of data that would join on multiple

tables and calculate complicated metrics.

Run thousands of times (Monte Carlo

simulation) Issues

First SQL solution was too slow
Dynamic & complex joins

SLIDE 11

Real World Example – Solution with Hash Tables

key range value X123 60 0.1 X123 70 0.2 X123 80 0.3

Hash tables flexible to only fetch data when

needed.

Dynamic look up keys:
hh.find(key:some_variable)
Ranged look ups:
hh.find_next()

SLIDE 12
