WISCONSIN OPENFLOW DEPLOYMENT ST A TUS UPDA TE Theophilus Benson, Aditya Akella, Mike Blodgett, Dale Carder Current Deployment: Campus Map Current Deployment One admin domain SNAC Switch Routing Lavi STP Computer Sciences
SLIDE 2
SLIDE 3
Current Deployment
One admin domain
Computer Sciences 3 switches
T
wo slices
Production slice Research slice FlowVisor:6666 Nox:6633 Nox:2244 SNAC Switch STP Routing Lavi
SLIDE 4
Future Deployment
4 buildings (7-10 switches/ 3 admin domains) Extend the deployment in Computer Sciences
Extend to all 7 floors
Extend to Engineering Buildings
Student labs & data center
Extend to DoIT Building(Campus IT) Establish link to other campuses
Link to GPN switch in Kansas city
SLIDE 5
Future Deployment: Campus Map
SLIDE 6
Future Deployment: Network Map
SLIDE 7
Measuring Success
Network downtime
Fraction of time network is down Number of times network is down
Number of users
Ratio of retained users. Number of current users.
Number of experiments/slices
SLIDE 8
Challenges for GEC8
Interfacing with GENI Convincing users to buy into the OF network
SLIDE 9
Thank Y
- u
Thank you Stanford for the
AWESOME support!!
Support during the OpenFlow/NetFPGA class Support during the campus deployment
