slide-1
SLIDE 1

Wireless replacement for cables in CAN Network Pros and Cons

by Derek Sum

slide-2
SLIDE 2

TABLE OF CONTENT

  • Introduction
  • Concept of wireless cable replacement
  • Wireless CAN cable hardware
  • Real time performance and latency
  • Data throughput and bandwidth
  • Diagnostic over wireless link
  • Cable Length vs Radio Range
  • Data Security
  • Error handling
slide-3
SLIDE 3

CABLE REPLACEMENT

Can we make a cut on the cable and use wireless to continue the communication?

slide-4
SLIDE 4

WHY WE NEED WIRELESS

Simplify Cable Harnessing in a system. Difficulty of cable servicing/maintenance Cable is expensive Isolation

slide-5
SLIDE 5

CURRENT WIRELESS TECHNOLOGY

Licensed Free ISM Band 2.4Ghz, 915Mhz, and 868Mhz FHSS - frequency hopping spread spectrum Wi-Fi, Bluetooth, Zigbee or proprietary radio protocol

slide-6
SLIDE 6

ADVANTAGE OF CAN BUS SYSTEM

Broadcast Communication – Distributed Control System

  • Real Time performance

Scheduling and Priority Mechanism Excellent Error Handling Capabilities

slide-7
SLIDE 7

CONCEPT OF WIRELESS CABLE REPLACEMENT

CAN's arbitration feature is lost Same as the Error Checking The concept of original system design to be changed or adapted.

slide-8
SLIDE 8

CONCEPT OF WIRELESS CABLE REPLACEMENT WHAT NEED TO THINK ABOUT

Arbitration and error checking takes place independently in both side Message is accepted on the radio transmitting side not the receiving side Message Re-scheduling on both side In result, concept of original system design to be changed or adapted.

slide-9
SLIDE 9

WIRELESS CAN CABLE HARDWARE WHAT SHOULD IT BE?

API for Radio information and status API for CAN information and status

slide-10
SLIDE 10

WHY NOT WIFI OR BLUETOOTH

  • Range – Short i.e. BT
  • Data throughput
  • Latency – Unpredictable latency
  • Security – Well Known encryption mechanism
slide-11
SLIDE 11

REAL TIME PERFORMANCE AND LATENCY

In the wireless environment, latency is inevitable A lot of radio protocols quietly handle acknowledgement, error detection and retransmission These are the expenses of data throughput and variable latency

slide-12
SLIDE 12

REAL TIME PERFORMANCE AND LATENCY

Internal wait buffer as well as processing of cross traffic If there is any error causing re-transmission

  • f the packet?

How clean is the air space? Q: Can we know the latency?

slide-13
SLIDE 13

REAL TIME PERFORMANCE AND LATENCY

We need to know:

  • 1. maximum latency within a successful radio

packet transmission.

  • 2. Control of the re-transmission mechanism

To handle normal condition as well as worst case scenario

slide-14
SLIDE 14

DATA THROUGHPUT AND BANDWIDTH BETWEEN RADIO AND CAN PROTOCOL

Data throughput is a major consideration for any Wireless implementation Radio Protocol such as Wifi can be up to 20, 40Mhz with possible data throughput of hundreds Mbits However, 1 to 2Mhz radio bandwidths is widely used by industrial applications with CAN.

slide-15
SLIDE 15

DATA THROUGHPUT AND BANDWIDTH BETWEEN RADIO AND CAN PROTOCOL

There is overhead on each Radio Packet Actual data throughput may less than what it could be imagined.(industrial application 20kbps to 128kbps) Filtering and message scheduling is required for higher CAN Bandwidth. The capacity of the Radio device need to be available

slide-16
SLIDE 16

DIAGNOSTIC OVER WIRELESS LINK

Fact: In One way or the other, a wireless cable replacement is also an individual ECU within a system. Therefore: Wireless link should provide self-check information such as: Radio packet information, radio signal quality, any history of error occurrence, any re- transmission of the packet

slide-17
SLIDE 17

DIAGNOSTIC OVER WIRELESS LINK Diagnostic Higher Layer Protocol Protocol such as J1939, 15765..etc has timing requirement over the handshaking and transmitting of the CAN messages The real time figure will be important i.e.

  • A controllable latency over the radio packet
  • Good buffering to handle burst messages

The rule of thumb is that if the message burst exceeds the capacity of the buffer * latency, there will be CAN message loss.

slide-18
SLIDE 18

CABLE LENGTH RADIO RANGE VS CAN BUS DISTANCE The recommend practice of CAN cable length on different bandwidth is well known. However, there are factors that affecting the Radio range:

  • output power and it antenna diagram
  • the quality of the antennas
  • physical objects in the wave path causing radio

shadows, reflections and absorptions,

  • weather conditions
slide-19
SLIDE 19

CABLE LENGTH RADIO RANGE VS CAN BUS DISTANCE The simple rule is that frequency band is proportional to the available bandwidth but inversely to the effective distance and propagation through obstacles. E.g. the ISM band is widely used for 2 solution types:

  • 900 MHz for longer range, lower bandwidth
  • 2.4 GHz for higher bandwidth, lower range
slide-20
SLIDE 20

CABLE LENGTH RADIO RANGE VS CAN BUS DISTANCE

2.4GHz offers:

  • more bandwidth (i.e. data throughput)
  • a worldwide frequency band for use in multiple countries
  • smaller antenna implementation.

900Mhz offers:

  • System implementation requires a larger range
  • Remote movable device/system in large area.
  • Government restriction of the use of a higher frequency band in certain heavy

duty industrial areas.

slide-21
SLIDE 21

CABLE LENGTH RADIO RANGE VS CAN BUS DISTANCE

It is recommended that any wireless connection should better be verified by practical tests on site. However we could still enhanced the radio range performance by:

  • Increase the antenna power i.e. Use of a power amplifier to increase

the dBm level of the transmitter

  • Use of advanced receiving antennas. e.g. Diversity antennas, array

antennas, rake antennas, etc.

slide-22
SLIDE 22

DATA SECURITY OVER WIRELESS

Things to concern over Wireless communication with CAN

  • No more physical appearance
  • radio packet and its content is exposed to the Air
  • Possible risk of steal, modify, duplicate the content of

radio packet

slide-23
SLIDE 23

DATA SECURITY OVER WIRELESS

Protocol such as Wifi, Bluetooth has well known encryption and security. Prefer propriety radio protocol which we are in control of the radio packet format. Additional with possible authentication, encryption or addressing method to enhanced safety of data Note: any additional security methods could possibly reduce the payload capacity and prolong the latency

slide-24
SLIDE 24

ERROR HANDLING OF CAN OVER WIRELESS

The CAN Bus protocol has a state of the art complete error handling mechanism. However, in a wireless implementation, the physical network will be split into two, with each network having 2 sets of error handling mechanism(CAN and Radio).

slide-25
SLIDE 25

ERROR HANDLING OF CAN OVER WIRELESS

Wireless cable replacement should possible to broadcast its status as well as Error Handling Status to the CAN Network Vice versa, a pair of wireless cable replacements could also monitor the CAN Network and thus report abnormal CAN activities to the other side over the radio link.

slide-26
SLIDE 26

CONCLUSION

  • A propriety radio protocol with Controllable/Measurable latency
  • A good size of internal buffer that takes account
  • Wireless link self-information/status need to be available for CAN

System use (or system designer)

  • Error handling information available between CAN protocol and

Radio Protocol.

  • A certain level of data security that does not affect the actual

throughput or cause delay over the communication.

slide-27
SLIDE 27

Thank you
