who we are Diasen was born in 1985 thanks to a genial idea of Floriano Mingarelli, an ”intraprenditore” who mixed experience and ambition to become a leader in our market. Diasen brand is the union of Diathonite – the main product we transform– and Sentinum , the old name of the city where we do business. Our mission is take care about the environment where we create an economic value, we are green-oriented . Our systems are defined eco-friendly to solve easily any kind of problems.
diasen data Average 32 employee age Nations 65 Sales in R&D 5% Technical in 150 the world Range of produts 130
vision mission Our vision is to run our company with respect Innovation, through technology to traditions, and focus on healthy buildings. and chemical engineering, to We aim to develop products safe for people improve buildings with a low and their environment, and solutions that are environmental impact. at the forefront of technology and respect the future generations. green unique efficient
partnership & certifications
what we do Energy saving products mainly cork based plasters called Diathonite. Made of natural components this products clearly interprete the key principles of eco friendly building in accordance with modern standards for thermal and acoustic insulation . Waterproofing one component, two component, elastic products to waterproof concrete, terraces, balconies, swimming pools, roofs, floorings, foundations and tanks. Solvent-free protective coatings for building surfaces that mainly function as an effective waterprofing systems for parking lots, playgrounds, sport fields, swimming pools.
Waterproofing
Waterproofing Liquid : ACRIFLEX RANGE
Coating Acrilic : Oriplast Reflex External coating formulated with special synthetic water-based resins. It reflects UV rays, decreasing the temperature of the support onto which it is applied, allowing a consistent reduction in summer air-conditioning costs. It can be used as an ultra-reflecting protective coating for liquid waterproofing systems, or as a re-waterproofing protection both for new or already existing bituminous membranes. Ready to use and ideal for applications on horizontal, vertical and sloping surfaces. APPLICATION > 90% Reflection 5kg or 25 kg white Various colours brush by hand airspray Yield 1,00 kg/mq Drying time 5h
Waterproofing Liquid : ACRIFLEX PH4 Cement fiber-reinforced liquid waterproofing membrane with ACRIFLEX PH4 high chemical resistance. - Components: Two-component (A+B) - Waterproofing capacity: 9,5 atm - Break elongation: 87% - Crack Bridging Ability: 2.0 mm - Chemical resistance to pH values between 2 and 12: excellent - Resistance to Weathering Test: 2000 hours without alterations - Resistance to UV rays: 1000 hours without alterations - Freeze-thaw cycles resistance: excellent - Punching resistance: 68,7 N 25kg Yield 2 kg/mq 1 bucket 12 mq
Waterproofing Liquid : ACRIFLEX RANGE Liquid and fiber reinforced one-component waterproofing, suitable to ACRIFLEX RAPIDO waterproof planes and slopings coverings, terraces, balconies, waterspouts, flashings, cornices, foundation walls, vertical surfaces and other concrete products. It resist to wash-out, applicable at a temperature of low temperature and high relative umidity level. - Drying time 4h - Wash-out resistance and superficially dry in 20 mins - Resistant to crack bridging and flexible to low temperature. - Fiber reinforced APPLICATION 25kg Yield 2 kg/mq roll brush squeegee airless 1 bucket 12 mq
Waterproofing Liquid: ACRIFLEX RANGE ACRIFLEX – System (primer + waterproofing + coating) W alkable (Floorgum Paint) Sm ooth surface (Grip Primer) Trafficable (Floorgum Tyre) Bitum en m em brane (Sbs-bond) ACRI FLEX Reflective (Oriplast Reflex) Surface w ith rising dam p or counterthrust (Watstop) Sw im m ing pool (Epokoat Swimming)
Waterproofing Liquid : ACRIFLEX RANGE Where to apply Terraces Swimming Pool Foundations Balconies Tanks Roofs
Waterproofing Liquid: Aquabit Bituminous waterproofing paste enriched with polystyrene spheres, suitable for the under-tiles waterproofing of balconies, terraces and floorings, and to waterproof foundations and concrete structures. BENEFIT - No joint - Application of tiles with c ommon adhesives 10l o 25l - Drying time (6h) black balconies and terraces Yield 2.00 l/m² thickness 2.5 mm foundation APPLICATION brush airspray
Waterproofing Liquid: WATstop Three component epoxy resin to waterproof both with negative and positive pressure, to be used as osmotic over undergorund walls, to encapsulate rising dampness and to achieve a vapor barrier on wet supports. Compared to traditional systems, that requires thicknesses not smaller than 1.5 cm - 1.18 inch, this product guarantees an excellent waterproofing with just 2.5 – 3.0 mm / 0.10 - 0.12 inch. Its extreme versatility allows to use it as vapour barrier for wet supports, as encapsulating for rising dampness and saltpeter and as a real waterproofing in counterthrust. APPLICATION 5kg o 10kg BLACK/WHITE Applied as osmotic the yield is 1 kg/m2. Applied as primer the yield is 0.30 kg/m². Applied as steam barrier the yield is 0.60 kg/m². roll brush spatula Applied as waterproofing in counterthrust the yield is 2.00 kg/m²..
Coating Acrilic: Floorgum Paint Liquid coating formulated with water based resins. To be used as a multipurpose pedestrian coating, for the realization of protective pedestrian coatings on liquid waterproofing systems, as an alternative to the traditional ceramic tiles. APPLICATION 25 kg Various colours brush by hand airspray squeegee Yield 1,2 kg/mq Drying time 12h
Coating Acrilic : Floorgum Tyre Mono Monocomponent multi purpose driveaway coating, suitable for indoor and outdoor application. It can be used as a protective coating in combination with liquid waterproofing products, making the surface suitable for vehicles transit, or as an alternative to the traditional asphalt surfaces or some other similar coatings. The product is characterized by an excellent resistance against wearing, weathering agents, UV rays, ponding water. Suitable for direct contact with substances such as oils, fuels and smog.. APPLICATION 25 kg Various colours Yield 1,2 kg/mq brush by hand airspray squeegee Drying time 24h
Waterproofing Liquid: O.R.A. anti-rain Transparent waterproofing for balconies, tiles, terraces and tiled surfaces in general. Solvent based product easy to apply, even for the do-it-yourself market, by roll or brush. It does not alter the appearance of the floor. APPLICATION 5l Yield 0.3l/mq Drying time 4h airspray brush spatula
Coating Epoxy : Epokoat Swimming Two-components epoxy paint, ethyl alcohol based, to use as finishing for swimming pools (in alternative to common tiles or mosaic), drinkable water tanks and tanks containing liquid foodstuff such as wine, vinegar, milk and oil. It realizes a smooth and continuous finishing without weldings, directly applicable over waterproofing liquid systems. APPLICATION 5kg or 25 kg Various colours brush by hand Yield 0,35 kg/mq Drying time 48h
Water-repellent: BKK eco Transparent coating solvent, siloxane based, ideal to protect porous walls made of tiles, stones or concrete from rainwater. It doesn't alter the wall color, protecting from ice and blocking dampness infiltrations. It allows the water inside the wall to evaporate, and it makes possible deep impregnations into the wall, even onto slighty humid surfaces. BENEFITS APPLICATION - Easy and quick application - Trasparent coating 5l - Water-repellent White Yield 0,5 l/mq airless by hand roll Drying time 4h noBKK BKK
REFERENCEs: Oriplast Reflex – Dakar Senegal
REFERENCEs: WATstop Avignone France
REFERENCEs: Farimont Hamilton Bermuda
cork Cork is a raw material which deals with ecological business. Thanks to its mechanical and chemical properties, it is very elastic and waterproof, cork can be useful for thermal and acoustc insulation. why cork? It is ecological It is renewable Save energy It is healthy for the people who deals with it
from raw material to value Cleaning Working Recycling Value
the real value in the market thermal insulation dehumidification acoustic insulation thermal paint
Diathonite: thermal and acoustic plaster Thermal : The product have a high thermal capacity due to the presence of cork and demostrate on the value of λ =0,045 W/mK Dehumidifying : This product is an excellent natural remedy against humidity problems due to its high breathability μ =4 and water absorption Acoustic : Due to the mass and the excellent acoustic absorption, DIATHONITE is even excellent to solve acoustic prblems. The cavernous quality gives to the product an acoustic absorption up to 70%. Natural : DIATHONITE is made of natural components QUALITY Resistant : The product guarantees the resistance and the function of a plaster .
Diathonite Screed + Oriplast Reflex Thermal and Acoustic Insulation + Waterproofing Oriplast Reflex (Waterproofing) Oriplast Reflex (Waterproofing) Diathonite Screed (Acoustic Diathonite Screed (Acoustic 3.0 – 5.0 cm and Thermal Insulation) and Thermal Insulation) Existing Metal or Cement Roof
thermal and acoustic plaster
