WESP (Warehouse Efficient Solution Projects) company provides high- quality design and consulting services for variable warehouse projects for manufacturing, trade and transport industries. All our projects are based

• n proven principles of business logistics.

Our successful team consists of experienced professionals who have been designing and developing warehouse logistics, technology, mechanization and automation of loading-unloading, transportation and warehousing operations throughout tens of years. Paying attention to tendencies and requirements of the market, introduction of original solutions, collaboration with our European partners have allowed us to work our way up from a small subcontractor to the well-known market player in the field of warehousing equipment. By choosing our company as your consultant and project designer, you would get reliable and experienced business partner.

GUARANTEED SUCCESS OF YOUR WAREHOUSE COMPANY INTRODUCTION

• Warehouse logistics consulting;
• Warehouse process design;
• Warehouse standard operating procedures;
• Optimization of the warehouse logistics processes;
• Introduction and turnkey handover of the process solutions;
• Manufacturing and sales of racking equipment;
• Project support until commissioning.

GUARANTEED SUCCESS OF YOUR WAREHOUSE COMPLEX SOLUTIONS

RACKING EQUIPMENT

We offer all basic types of warehouse racks of G50 series including the following:

• self-supporting;
• integrated;
• non-standard customized;
• all kinds of accessories (fencing, gates, grids, crash barriers, etc.)

Front Shelf Deep Mezzanine

GUARANTEED SUCCESS OF YOUR WAREHOUSE

AUTOMATION OF THE WAREHOUSE LOGISTICS PROCESSES

• assembly systems: Scan2Pick, Pick2Light, Pick2Voice;
• replenishment systems: Scan2Sort, Put2Light,

Screen2Sort, Touch2Sort;

• transportation systems: roller conveyor, belt conveyor,

chain conveyor, etc;

• sorting systems: oval sorters, line sorters, slide tray

sorters, crossbelt sorters, hang sorters;

• distribution systems: pushers, transfer units, turning

wheels, shoe sorter.

GUARANTEED SUCCESS OF YOUR WAREHOUSE

COMPANY’S STRENGTHS

• Scientific approach towards designing of warehouses;
• Strict compliance with incremental approach to design;
• Design in compliance with current standards of Russian

Federation;

• Development of several options of technological solutions;
• Feasibility study of all the calculations for the options offered;
• Ownership of SRO (self-regulated organization) permission No.

SROGP-309.1-18122013;

• Supply of technological equipment according to the option

chosen;

• Testing of the racking equipment according to GOST 55525-2013.

GUARANTEED SUCCESS OF YOUR WAREHOUSE

OUR PROJECTS PROJECT SUMMARY:

• “А”-class warehouse complex;
• warehouse area - 76 340 m2;
• location – Moscow highway;
• proximity to Ring Road;
• modern engineering infrastructure;
• convenient parking for trucks and cars;
• guest parking.

COMPLEX OF SERVICES PROVIDED 2014:

1) Consulting of one of the leading developers in St Petersburg, ADAMANT Holding, on the following:

• general layout options;
• standard and non-standard space-planning solutions;
• location of the checkpoint;
• vehicle traffic at the warehouse site;
• engineering and warehouse equipment;
• management of warehousing logistics.

2) Consulting of tenants of “Armada Park” warehouse complex : Frujet, РИВ ГОШ, oodji. 3) Individual approach in a format of built-to-suit.

COMPLEX OF SERVICES PROVIDED 2015:

1) Total area of warehouse is 10500 sq.m.; 2) Classic wide aisle technology for processing of goods the largest Russian logistic operator; 3) Total capacity of the warehouse is 13 000 pallet positions; 4) Organizing of picking zone close to 1st level of the racks; 5) Correlation of technical decisions with other departments; 6) Organizing of storage zone for spare parts on the entresol.

Warehouse complex “Armada Park”, Saint Petersburg, 2014-2015

GUARANTEED SUCCESS OF YOUR WAREHOUSE

OUR PROJECTS GUARANTEED SUCCESS OF YOUR WAREHOUSE

GALAKTIKA GROUP OF COMPANIES, Saint Petersgurg, Gatchina

PROJECT SUMMARY:

• “A”-class warehouse complex belonging to the

existing plant;

• warehouse area – 5 500 m2;
• bottom elevation of trusses – 15,5 m;
• column spacing 12 х 24 m;
• high-rise 11-level racks;
• warehouse capacity – 13 000 EUR-pallets;
• narrow passage technology with inductive

guideways;

• automatic transportation of pallets from the

plant to the warehouse.

COMPLEX OF SERVICES PROVIDED: 1) Designing of several options of technological schemes (mechanization, semi-automation, 100% automation) under restrictions of frontage lines; 2 ) Calculation of technical-economic values of technology options efficiency; 3) Reasonable choice of technological scheme based on the strategic development business plan in compliance with the client’s investments

• pportunities;

4) Supply of racking equipment.

OUR PROJECTS GUARANTEED SUCCESS OF YOUR WAREHOUSE

FRUJET, major importer of fruits and vegetables, Saint Petersburg/Moscow PROJECT SUMMARY:

• multi-temperature warehouse complex;
• warehouses area – 15 000 m2;
• built-to-suit;
• warehouse capacity – 5100 FIN- pallets;
• project support until commissioning;
• adaptation of the technology for 2 projects

different in terms of topology in St Petersburg and Moscow

COMPLEX OF SERVICES PROVIDED: 1) Consulting in the field of multi-temperature warehouses designing; 2) Adaptation of the technology and development of different options of space planning decisions; 3) Assistance in RfQ procedure and defining a reasonable warehouse equipment supplier; 4) Supply of racking equipment to 2 sites in St Petersburg and Moscow; 5) Providing maintenance service.

OUR PROJECTS

Power Frost, leading 3PL operator, St Petersburg PROJECT SUMMARY:

• “A”-class multi-temperature warehouse with temperatures

ranging from -25 °C to +5 °C;

• number of compartments: 5;
• floor area - 6000 m2;
• secure storage;
• capacity 7500 EUR-pallets;
• universal length of beams: for 3 FIN-pallets, or for 4 EUR-

pallets. COMPLEX OF SERVICES PROVIDED: 1) Developing several options of racking equipment location; 2) Calculation of technical-economic values for all the options; 3) Supply of racking equipment; 4) Providing maintenance service. OODJI, leading garment manufacturer and distributor in the field of fashion-retail in Russia, St Petersburg PROJECT SUMMARY:

• 155 000 SKU;
• ABC/FMR/XYZ-analysis of the product range;
• provision of different options of warehouse;
• designing of different options of logistic process automation;
• calculation of technical-economic values with an allowance for

engagement of credit funds;

• adjustment of space-planning solutions of the warehouse under

construction. COMPLEX OF SERVICES PROVIDED: 1) Audit of the existing logistic process; 2) Evaluation of the major technical and economic values with subsequent projection to the manufacturing programme of proposed development; 3) Designing of several options of warehouse processes technology; 4) Defining of technical-economic values for all the options; 5) Preparation of the detailed technological requirements to be transferred to the developer.

VERNIY, rapidly developing retailer with high goods turnover, St Petersburg/Moscow PROJECT SUMMARY:

• “A”-class warehouse complex belonging to the existing plant
• warehouses area – 5 000 m2;
• bottom elevation of trusses– 14,5 m;
• warehouses capacity – 6 000 EUR-pallets;
• non-standard solution – racks with the beam span of 4500mm

allowing to place 5 EUR-pallets at one compartment. COMPLEX OF SERVICES PROVIDED: 1) Analysis of pre-design solutions and defining strategy of further cooperation; 2) Design of different options for the placement of racking equipment with application of non-standard solutions. Feasibility studyof the

• ptions designed;

3) Supply of racking equipment; 4) Providing maintenance service. PROJECT SUMMARY:

• “А” –class warehouse complex with variable temperature

conditions;

• warehouses area – 70 000 m2;
• warehouses capacity – 84000 EUR-pallets;
• 2 similar projects in St Petersburg / Moscow ;
• PNK-GROUP Developer.

COMPLEX OF SERVICES PROVIDED: 1) Measurement of the warehouse complex at the construction phase; 2) Providing all necessary coordination with subcontractors; 3) Supply of racking equipment for 2 mirror projects in St Petersburg / Moscow; 4) Providing maintenance service. Remos-Alpha, one of the leaders in the field of corrugated cardboard packages manufacturing, St Petersburg

OUR PROJECTS

OUR PROJECTS GUARANTEED SUCCESS OF YOUR WAREHOUSE

Pharma company. Saint-Petersburg, Kamenka area

COMPLEX OF SERVICES PROVIDED: 1) Warehouse racks designing according to EU standarts and conditions of safe usage; 2) total capacity of the warehouse is 6 000 pallet positions; 3) Close cooperation with sub-contractors during project realization: designing of industrial floors, designing

• f fire alarm system, designing of lightening equipment, etc.;

4) Issue of design documentation type «P» according to construction rules and standarts; 5) Adaptation of warehouse logistic with the plan; 6) Recommendations for business optimization; 7) All warehouse area was equipped with modern technological equipment; 8) Project supervising during all constructions works; 9) Maintenance service.

OUR PROJECTS GUARANTEED SUCCESS OF YOUR WAREHOUSE

ASTYK LOGISTIK LLP, Astana

PROJECT SUMMARY: 1) The largest project of federal scale in the Republic of Kazakhstan (Astana); 2) Warehouse complex with a total area of 20000 sq.m; 3) Hi-tech frameless steel building; 4) Storage zone without columns, building span of 90 m; 5) Wide-passage and narrow-passage technologies in the ratio 45%/55% in terms of storage capacity; 6) Warehouse capacity of 33000 pallets. COMPLEX OF SERVICES PROVIDED: 1) Optimum zoning of the warehouse comples; 2) Development of several design options for the layout of storage racking equipment; 3) Increase of the warehouse storage capacity due to application of non-standard solutions; 4) Calculation of cost/efficiency ratio for the competitive options; 5) Design of the cross functional storage racking system for tenants of variable business segments; 6) Supply and mounting of racking equipment made of S355MC steel with a total capacity of 33000 pallets.

OUR PROJECTS GUARANTEED SUCCESS OF YOUR WAREHOUSE

North-West logistic operator «Be Logistic», Saint-Petersburg, Shushari area

COMPLEX OF SERVICES PROVIDED: 1) Integration of classic technology with exclusive construction decisions by WESP design department; 2) Designing of special area for goods with high risk of fire and explosion. Consolidation with fire alarm system; 3) All warehouse area was equipped with racks equipment. Fire barrier was also installed according to SNiP 31-04-2001 (p. 6.5). Special details were developed to mount sprinkler fire system; 4) Total capacity of the warehouse is 23 000 pallet positions; 5) Supervising of start-up process according to Russian legislation with load of 1.1 of nominal (p. 8 GOST 55525-2013); 6) An independent stress test by professional certified organization.

OUR PROJECTS GUARANTEED SUCCESS OF YOUR WAREHOUSE

ILP Nordway, Saint-Petersburg, Shushari village

COMPLEX OF SERVICES PROVIDED: 1) Adaptation of storage space for large logistic operator(Mediterranean goods) in warehouse section with 18x24 meters column grid; 2) Designing of storage system according to type of goods in percentage distribution, dimensions and weights; 3) Designing few plans and analyzing main logistics criteria. Optimal solution was chosen; 4) Production of storage equipment. Total capacity is 5 000 pallet positions; 5) ILP Nordway was a customer.

OUR PROJECTS GUARANTEED SUCCESS OF YOUR WAREHOUSE

Distributor parts, St. Petersburg

COMPLEX OF SERVICES PROVIDED: 1) 2D and 3D design of self-supported warehouse. One side has 4 floors, another side has 5 floors. Designing according to SNiP 2.01.07-2011 and SP 16.13330.2011; 2) Formulation of project documentation for warehouse of spare car parts, shop and service station. Sections of documentation:

• definition of type warehouse rooms according to fire requirements;
• project of automatic fire alarm system;
• project of fire fighting water line;
• individual technical decisions for evacuation due to fire;
• calculation of fire risk, time of evacuation, fire danger rating.

3) Production of metal construction for installation of temporary warehouse. Total area is 1000 sq.m. Maximum height is 12 meters (1st stage is 350 sq.m.). 4) Civil engineering works, roof works, racks installation have been done.

OUR PROJECTS GUARANTEED SUCCESS OF YOUR WAREHOUSE

Redmond Household Appliances, Saint-Petersburg

COMPLEX OF SERVICES PROVIDED: 1) Technological support of the project on the developed design stage; 2) Coordination of the main project technology solutions; 3) Design of several competitive logistic schemes of interaction of technological areas and sectors; 4) Independent calculation of acceptance and shipment expediting section based on average data; 5) Adaptation of the technological scheme to the temporary warehouse; 6) Shelving delivery in 3 turns; 7) Total volume of supply is 35 thousand pallet positions.

OUR PROJECTS GUARANTEED SUCCESS OF YOUR WAREHOUSE

Miratorg Agro-industrial Holding Company, Moscow

COMPLEX OF SERVICES PROVIDED: 1) Specification section of planning documentation for multi-temperature warehouse has been worked

• ut according to Regulations for Project Documentation Structure and Content №87, 16.02.2008.

2) Storage equipment delivery according to specification project. Basic technical parameters of the warehouse:

• total area of the multi-temperature warehouse is 15 500 sq.m;
• wide-aisle handling technology;
• front two-tier shelvings, front five-tier shelvings, drive-in five-tier shelvings;
• storage capacity is 19 000 europallet positions or 14 500 finnpallet positions;
• pallet loading capacity is 900-1200kg.

OUR PROJECTS GUARANTEED SUCCESS OF YOUR WAREHOUSE

«Iron Mountain» Company, Samara and Nizhny Novgorod

In collaboration with a working group of the customer individual products have been developed that fully satisfy the requirements of the company. COMPLEX OF SERVICES PROVIDED: 1) Development of an integrated project in accordance with the technical specification requirements, internal standards of the Iron Mountain Company, design standards; 2) Implementation of the project in an international team; 3) Supply and installation of equipment in accordance with the implementation schedule; 4) Installation of equipment in the operating warehouse; 5) Preparation of executive documentation.

ПРОЕКТЫ ЗАЛОГ УСПЕШНОЙ РАБОТЫ ВАШЕГО СКЛАДА

Exmo Publishing House, Moscow (list 1)

OUR PROJECTS GUARANTEED SUCCESS OF YOUR WAREHOUSE

1) Audit of existing logistical processes; 2) Optimization of warehouse logistics; 3) Design of warehouse work technology:

• design based on the analysis of the stock-list of goods in the amount and SKU sections (75000 items);
• 15 alternate designs of preliminary technological solutions (combining 9 external warehouses into one logistic distribution center);
• Calculation of technical and economic parameters by aggregated data;
• he best possible solution based on variability for further detail.

4) Specification of logistic calculations:

• Computation of optimal size and quantity of cells for goods handling;
• Evaluation of structure and size of technological areas and areas involved into logistic process;
• Stock movement model design;
• Evaluation of types and amount of required storage equipment;
• Evaluation of individual contributors’ amount, manning table and duty regulations arrangement.

5) Adaptation of the technology to the topology of 10 reviewed warehouse alternate designs; 6) Working out of planning documentation sections:

• Structural and space-planning solutions;
• Power-supply system;
• Technological solutions.

7) Development of the extended terms of reference for the warehousing machinery supply; 8) An independent audit of warehousing machinery suppliers by technical specifications, without particular reference to their name and manufacturer; 9) The complete “turnkey” solution with the application of own-produced equipment:

• Front shelvings, narrow passage technology, 26 500 pallet positions;
• Front shelvings, wide-aisle technology, 7 000 pallet positions;
• Five-storey multilevel shelving, 3 500 sq.m. in area;
• 2.2 km of inductive guides for VNA tracks;
• Lightning fixture set for multilevel shelving luminance, illuminance of 300 lx (about 4000 lights);
• Package of measures for warehouse power contour refurbishing;
• Overall multi-plug sockets instrumentation;
• Patching-in IT equipment to server room.

Exmo Publishing House, Moscow (list 2)

ЗАЛОГ УСПЕШНОЙ РАБОТЫ ВАШЕГО СКЛАДА

Saint Petersburg +7 (812) 333-02-33 Moscow +7 (495) 668-14-31 info@wesp.pro www.wesp.pro
