WASILAH BATA LITE ™

WASILAH GLOBAL GROUP BHD

INTRODUCING

INTRODUCTION Wasilah Bata Lite™ is a new competitive and innovative solution in Industrial Building Systems (IBS) for the modern day construction industry

WASILAH BATA LITE ™

TECHNOLOGY Wasilah Bata Lite™ is develop using Cellular Lightweight Concrete (CLC) technology which consist of Water + Cement + Sand + Foam Agent to create a superior brick product compared to others traditional and conventional brick solutions

INTRODUCTION

• Cellular Lightweight Concrete (CLC) technology was created in

Europe around 80 years ago.

• CLC has many advantages compared to normal bricks. Over the

years it has gain the interest of industry players and housing developers.

• In Europe, an estimated three out of five new houses are built

by using CLC blocks particularly in Germany, Sweden, and the United Kingdom.

• In

Malaysia, CLC blocks has been recognized by the government through professional bodies such as CIDB and SIRIM and listed as part of Industrial Building System (IBS)

• The usage of IBS materials is encouraged by the Green Building

Index (GBI), which provides incentives to housing developers who uses it.

• Introduction of cutting edge technology, and competitive pricing

ensures the quality of each product is maintained.

BENEFITS & ADVANTAGES OF WASILAH BATA LITE ™

GOOD THERMAL INSULATION

• Wasilah Bata Lite™ contains millions of micro-air cell that serves as an

excellence thermal insulation.

• Heat from the sun takes eight hours to penetrate a Bata Lite wall.

This advantage creates a cooling effect where the temperature inside the house remains at a comfortable level, even when the temperature outside reaches more than 40°C.

• As a comparison, red clay bricks requires wall thickness of 3.5 times

greater or 35cm thicker to achieve good insulation compared to Bata Lite™.

COST SAVING

• 1 block of Wasilah Bata Lite™ is equivalent to 8 pcs ordinary brick
• Each Wasilah Bata Lite™ block weights only 1/3 of the total weight of

common bricks.

• The size of Wasilah Bata Lite™ is larger and lighter, enables it to bond

faster and easier, thus saving time and labour costs.

• The accuracy measurement of Wasilah Bata Lite™ ensures walls are

easily plastered and thickness can be reduced to 6-10mm, compared with ordinary brick of 15-25mm.

• In addition, Wasilah Bata Lite ™ uses ordinary cement for bonding and

plastering process whereas AAC blocks need special cement or cement glue which are more expensive.

BENEFITS & ADVANTAGES OF WASILAH BATA LITE ™

FIRE PROOF

• Wasilah Bata Lite™ is manufactured without the use of organic

materials, making it non-flammable. In addition, millions of micro-air cells helps to suppress the fire from spreading through walls.

• Tests have been conducted in several countries according to

ASTM standards, including tests made by SIRIM Malaysia showed a 100mm thick wall that was built using CLC Block could withstand heat up to more than 4 hours, more than the 2 hours time frame set by Malaysia fire department.

BENEFITS & ADVANTAGES OF WASILAH BATA LITE ™

LOW WATER ABSORPTION

• Wasilah Bata Lite™ has the lowest water absorption compared with other types
• f bricks available in the market, which is just 14% of absorption of water

compared to ordinary clay brick.

• Low water absorption could prevent the wall from moss and fungal, thereby

increasing the shelf life of the paint.

GOOD SOUND ABSORPTION

• Acoustic Sound Absorption rate or Absorption Coefficient by Wasilah Bata Lite™

at a deficit of 750Kg/m³ is about 0.35, equivalent to Acoustic Plasters used for special soundproof room.

• Wasilah Bata Lite™ excellence levels of sound absorption makes it highly

suitable to be used as the outer wall and the wall for separating rooms. HIGH COMPRESSIVE STRENGTH

• Wasilah Bata Lite™ has a high compressive strength which comply with

MS 2282-3: 2010 standards set by SIRIM for non-load bearing wall.

• The strength of the block will continue to increase in line with life expectancy like
• ther concrete materials.
• Wasilah Bata Lite™ can also be adjust according to customer requirements,

appropriate to the project, until it can reach load bearing standard.

BENEFITS & ADVANTAGES OF WASILAH BATA LITE ™

SIMPLIFIED

• Wasilah Bata Lite™ can be cut with a regular saw, can be

nailed, and the screwed on.

• This can speed up and simplify work while avoiding waste.

BENEFITS & ADVANTAGES OF WASILAH BATA LITE ™

LIGHTWEIGHT

• Wasilah Bata Lite™ has an extremely low weight of 1/3 of

the total weight of ordinary brick.

• This advantage allows developers to save basic costs and

building Structures that contribute the most to the overall cost of construction.

• In addition, Wasilah Bata Lite ™ can also be transported and

tied with a much simpler and faster, thus saving transport costs and labour.

NO SYMBOL

SPECS BATA LITE™ FEATURES

1

QUALITY PROVEN HIGH PERFORMANCE IN ANY CONDITION

2

LIGHT WEIGHT ULTRA LIGHTWEIGHT SAVES ON STORAGE AND TRANSPORTATION COST

3

SOUND PROOF ABSORBS ECHO AND REDUCE NOISE

4

FIRE RESISTANCE CAN WITHSTAND FIRE

NO SYMBOL

SPECS BATA LITE™ FEATURES 5 WATER RESISTANCE CAN WITHSTAND WATER 6 GOOD INSULATION HEAT ABSORBENT AND MAINTAIN COOLING EFFECTS 7 STABILITY LIGHTWEIGHT ENSURES GROUND STABILITY AND REDUCE SUNK TO THE GROUND 8 ACCURACY EACH BLOCK IS ACCURATELY MEASURED TO SPECIFICATION

NO SYMBOL

SPECS BATA LITE™ FEATURES 9 CLEANLINESS PRODUCT IS NON RESIDUE 10 SAFETY PRODUCT IS NON TOXIC 11 SAW, NAIL, DRILL SAWING, NAILING AND DRILLING WORKS DONE AT EASE 12 LABOUR COST REDUCE MANPOWER HEADCOUNT AND DEPENDENCY ON FOREIGN LABOUR

NO SYMBOL

SPECS BATA LITE™ FEATURES 13 MATERIAL COST REDUCE COST OF MATERIAL USAGE 14 TIME CONSUME EFFICIENTLY REDUCES TIME CONSUMPTION TO COMPLETE PROJECT 15 TIMBER USAGE SAVING THE ENVIRONMENT BY USING LESS TIMBER 16 WASTAGE REDUCES WASTAGE ON MATERIAL COST AS LESS DAMAGE ON PRODUCT

SPECIFICATION AND COMPARISON BETWEEN RED BRICK, AAC BLOCK AND WASILAH BATA LITE™

DESCRIPTION UNIT RED BRICK AAC BLOCK BATA LITE Dimension mm 215 x 65 x 102 600 x 200 x 100 600 x 200 x 100 Quantity Pcs 8.5 1 1 Density kg/m3 1900 500 - 650 800 Weight Kg 2.7 6 - 8 9 -11 Water Absorption % 15 -20 24 - 35 <5 Compressive Test N/mm2 4 - 7 2.7 – 5.0 > 2.0 R Value

• M2. K/W

0.13 0.77 0.55 Fire Resistance Hrs 2 4 4 Tighten & Plaster Cement Type Normal Special ** Normal

* Soaking 10cm cube in water for 24hours ** Ordinary cement can cause cracks in the wall in the long term

No

• Sq. Ft.

Product Pallets Required Pcs / Pallet Total Pcs/Brick Product Pallets Required Block / Pallet Total Pcs/Block 1 1 Red Brick

• 7.5

Bata Lite 1* 2 400 Red Brick 5 600 3,000 Bata Lite 2.08 180 375 3 800 Red Brick 10 600 6,000 Bata Lite 4.17 180 750 4 1,600 Red Brick 20 600 12,000 Bata Lite 8.33 180 1,500 5 3,200 Red Brick 40 600 24,000 Bata Lite 16.67 180 3,000

COMPARISONS BETWEEN RED CLAY BRICK VS BATA LITE™

* The table shows estimation value per sq.ft per pallet for each brick. Actual composition may vary * 1* unit of Bata Lite Block is equivalent to 8 units of normal clay bricks

EXAMPLES OF PROJECTS USING CELLULAR LIGHTWEIGHT CONCRETE BLOCKS FOR THE INNER AND OUTER WALLS

• Palace of Juctice and Perbadanan Putrajaya

– Putrajaya

• KL Hilton and Le Meridien Hotel, KL Sentral

– Kuala Lumpur

• One World Hotel, Damansara Utama, Petaling Jaya

– Selangor

• Vista Bay Apartments, Butterworth

– Penang

• Dell Asia Pacific, Bayan Lepas

– Penang

• Air Asia Low Cost Carrier Terminal (LCCT) Sepang

– Selangor

• Fisheries Development Authority of Malaysia, Kota Bharu

– Kelantan

• Capital Square Condominiums

– Kuala Lumpur

• Tesco Extra, Seberang Prai

– Penang

• Perumahan Rakyat 1 Malaysia (PR1MA)

– Prime Minister Office

• Rumah Mesra Rakyat (RMR1M) Syarikat Perumahan Negara Berhad – SPNB
• My Home Programme - Ministry of Housing and Local Government

– KPKT
