Was it Frag-Ment to be? Luke Sleeman - Freelance Android developer - - PowerPoint PPT Presentation

Was it Frag-Ment to be?

Luke Sleeman - Freelance Android developer

http://lukesleeman.com luke.sleeman@gmail.com @LukeSleeman

Was it Frag-Ment to be?

• Intro - What are fragments? History
• Problems with fragments - Lifecycle, Bugs, Hard to use right
• Best Practises: Don't use them - Places where we might have used

fragments, alternatives

• Best Practises: Risk mitigation - Googles suggestions
• Summary - What we learnt, key takeaways
• Questions

Intro

What is a fragment?

A UI control you can compose to build responsive tablet UI’s

What is a fragment?

A UI control you can compose to build responsive tablet UI’s

What is a fragment?

A reusable group of Views to build our ui.

What is a fragment?

A reusable group of Views to build our ui.

What is a fragment?

An application component with a lifecycle

What is a fragment?

An application component with a lifecycle

History - Android 2.x

History - Android 3.x

History - Android 4.x

Problems

Problem - Fragments ‘sorta’ work

‘Sorta’ works is the worst kind of works

Problem - Lifecycle

Problem - Lifecycle

• Add in asynchronous fragment transactions
• Child fragments
• Viewpagers which cache state and lazy construct fragments …
• Ultimately you have no idea what state your fragment will be in at

any point in time.

Problem - Communication

Activity List Fragment Detail Fragment

? ? ???

Problems - Lifecycle & Communication

private void updateTimeStamps(){
 ...
 String format = getContext().getString(R.string…) ...
 }

 private void newDataReceived(List<> ...){
 ...
 updateTimeStamps();
 ...
 }

 private void setTimeZone(TimeZone timeZone){
 ...
 updateTimeStamps();
 ...

 }

 public void startDataRefresh(){
 ...
 setTimeZone(TimeZone.getDefault());
 ...
 }

Problems - Lifecycle & Communication

private void updateTimeStamps(){
 ...
 String format = getContext().getString(R.string…) ...
 }

 private void newDataReceived(List<> ...){
 ...
 updateTimeStamps();
 ...
 }

 private void setTimeZone(TimeZone timeZone){
 ...
 updateTimeStamps();
 ...

 }

 public void startDataRefresh(){
 ...
 setTimeZone(TimeZone.getDefault());
 ...
 }

Problems - Lifecycle & Communication

private void updateTimeStamps(){
 ...
 String format = getContext().getString(R.string…) ...
 }

 private void newDataReceived(List<> ...){
 ...
 updateTimeStamps();
 ...
 }

 private void setTimeZone(TimeZone timeZone){
 ...
 updateTimeStamps();
 ...

 }

 public void startDataRefresh(){
 ...
 setTimeZone(TimeZone.getDefault());
 ...
 }

Problems - Lifecycle & Communication

private void updateTimeStamps(){
 ...
 String format = getContext().getString(R.string…) ...
 }

 private void newDataReceived(List<> ...){
 ...
 updateTimeStamps();
 ...
 }

 private void setTimeZone(TimeZone timeZone){
 ...
 updateTimeStamps();
 ...

 }

 public void startDataRefresh(){
 ...
 setTimeZone(TimeZone.getDefault());
 ...
 }

Problems (from google)

• “Fragments are so general they become really difficult to explain to

people”

• “A lot of times, you build up a fragment transaction, commit it, and

things work completely differently from how you expect”

• Even more lifecycle to manage made stuff to complicated - “and the

bugs didn’t help!”

• People think ‘they are just like views’. <fragment> tag turned out to

be a bad bit of syntactic sugar.

Summary - Problems

• 0. They almost work! But:
• 1. Lifecycle makes them prone to programmer error.
• 2. No clear use case - Replace views? Replace activities? Tablet

UIs?

• 3. No guarantees about what state your fragment will be in.

Best Practises

1 - Don’t use them! 2 - Mitigate the risks if you do use them

Don’t use them - Normal Screens

Don’t use them - Tablet UI’s

Don’t use them - composable parts of UI

Use a ViewGroup!

(Subclass LinearLayout or FrameLayout)

Subclass ViewGroup

public class UserSummaryView extends LinearLayout {

 private ImageView profileImage;
 private TextView name;
 private TextView title;
 private TextView bio;

 public UserSummaryView(Context context) {
 super(context);
 init(context);
 }

 public UserSummaryView(Context context, AttributeSet attrs) {
 super(context, attrs);
 init(context);
 }

 public UserSummaryView(Context context, AttributeSet attrs, int defStyleAttr) {
 super(context, attrs, defStyleAttr);
 init(context);
 }

Subclass ViewGroup

public class UserSummaryView extends LinearLayout {

 private ImageView profileImage;
 private TextView name;
 private TextView title;
 private TextView bio;

 public UserSummaryView(Context context) {
 super(context);
 init(context);
 }

 public UserSummaryView(Context context, AttributeSet attrs) {
 super(context, attrs);
 init(context);
 }

 public UserSummaryView(Context context, AttributeSet attrs, int defStyleAttr) {
 super(context, attrs, defStyleAttr);
 init(context);
 }

Subclass ViewGroup

public class UserSummaryView extends LinearLayout {

 private ImageView profileImage;
 private TextView name;
 private TextView title;
 private TextView bio;

 public UserSummaryView(Context context) {
 super(context);
 init(context);
 }

 public UserSummaryView(Context context, AttributeSet attrs) {
 super(context, attrs);
 init(context);
 }

 public UserSummaryView(Context context, AttributeSet attrs, int defStyleAttr) {
 super(context, attrs, defStyleAttr);
 init(context);
 }

Subclass ViewGroup

private void init(Context context){

setOrientation(VERTICAL);

LayoutInflater.from(context).inflate( R.layout.view_user_summary, this);

 profileImage = (ImageView)findViewById(R.id.user_summary_image);
 name = (TextView)findViewById(R.id.user_summary_name);
 title = (TextView)findViewById(R.id.user_summary_title);
 bio = (TextView)findViewById(R.id.user_summary_bio);
 }

 public void setUser(User user){
 Picasso.with(getContext()) .load(user.getProfileImageUrl()) .into(profileImage);
 name.setText(user.getName());
 title.setText(user.getJobTitle());
 bio.setText(user.getBio());
 }

Subclass ViewGroup

private void init(Context context){

setOrientation(VERTICAL);

LayoutInflater.from(context).inflate( R.layout.view_user_summary, this);

 profileImage = (ImageView)findViewById(R.id.user_summary_image);
 name = (TextView)findViewById(R.id.user_summary_name);
 title = (TextView)findViewById(R.id.user_summary_title);
 bio = (TextView)findViewById(R.id.user_summary_bio);
 }

 public void setUser(User user){
 Picasso.with(getContext()) .load(user.getProfileImageUrl()) .into(profileImage);
 name.setText(user.getName());
 title.setText(user.getJobTitle());
 bio.setText(user.getBio());
 }

Subclass ViewGroup

<?xml version="1.0" encoding="utf-8"?>
 <LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
 xmlns:tools="http://schemas.android.com/tools"
 android:orientation="vertical"
 android:layout_width="match_parent"
 android:layout_height="match_parent">

 <ImageView
 android:id="@+id/user_summary_image"
 android:layout_width="match_parent"
 android:layout_height="256dp"
 tools:src="@drawable/profile_sample"
 android:scaleType="centerCrop"
 />

 <TextView
 tools:text="Luke Sleeman"
 android:layout_width="match_parent"
 android:layout_height="wrap_content"
 android:id="@+id/user_summary_name" …

Subclass ViewGroup

<?xml version="1.0" encoding="utf-8"?>
 <LinearLayout xmlns:android="http://schemas.android.com/apk/res/android"
 xmlns:tools="http://schemas.android.com/tools"
 android:orientation="vertical"
 android:layout_width="match_parent"
 android:layout_height="match_parent">

 <ImageView
 android:id="@+id/user_summary_image"
 android:layout_width="match_parent"
 android:layout_height="256dp"
 tools:src="@drawable/profile_sample"
 android:scaleType="centerCrop"
 />

 <TextView
 tools:text="Luke Sleeman"
 android:layout_width="match_parent"
 android:layout_height="wrap_content"
 android:id="@+id/user_summary_name" …

Subclass ViewGroup

<?xml version="1.0" encoding="utf-8"?>
 <merge xmlns:android="http://schemas.android.com/apk/res/android"
 xmlns:tools="http://schemas.android.com/tools"
 tools:parentTag="LinearLayout"
 tools:orientation="vertical"
 android:layout_width="match_parent"
 android:layout_height="match_parent">
 <ImageView
 android:id="@+id/user_summary_image"
 android:layout_width="match_parent"
 android:layout_height="256dp"
 tools:src="@drawable/profile_sample"
 android:scaleType="centerCrop"
 />

 <TextView
 tools:text="Luke Sleeman"
 android:layout_width="match_parent"
 android:layout_height="wrap_content"
 android:id="@+id/user_summary_name" …

Subclass ViewGroup

<?xml version="1.0" encoding="utf-8"?>
 <merge xmlns:android="http://schemas.android.com/apk/res/android"
 xmlns:tools="http://schemas.android.com/tools"
 tools:parentTag="LinearLayout"
 tools:orientation="vertical"
 android:layout_width="match_parent"
 android:layout_height="match_parent">
 <ImageView
 android:id="@+id/user_summary_image"
 android:layout_width="match_parent"
 android:layout_height="256dp"
 tools:src="@drawable/profile_sample"
 android:scaleType="centerCrop"
 />

 <TextView
 tools:text="Luke Sleeman"
 android:layout_width="match_parent"
 android:layout_height="wrap_content"
 android:id="@+id/user_summary_name" …

Subclass ViewGroup

… <com.example.UserSummaryView
 android:id="@+id/main_summary_view"
 android:layout_width="match_parent"
 android:layout_height="match_parent"
 /> … … @Override
 protected void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);
 setContentView(R.layout.activity_main);

 UserSummaryView summaryView = (UserSummaryView)findViewById(R.id.main_summary_view);
 summaryView.setUser(testUser);
 } …

Subclass ViewGroup

… <com.example.UserSummaryView
 android:id="@+id/main_summary_view"
 android:layout_width="match_parent"
 android:layout_height="match_parent"
 /> … … @Override
 protected void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);
 setContentView(R.layout.activity_main);

 UserSummaryView summaryView = (UserSummaryView)findViewById(R.id.main_summary_view);
 summaryView.setUser(testUser);
 } …

Subclass ViewGroup

… <com.example.UserSummaryView
 android:id="@+id/main_summary_view"
 android:layout_width="match_parent"
 android:layout_height="match_parent"
 /> … … @Override
 protected void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);
 setContentView(R.layout.activity_main);

 UserSummaryView summaryView = (UserSummaryView)findViewById(R.id.main_summary_view);
 summaryView.setUser(testUser);
 } …

Don’t use them - Navigation Drawer

Use Activities!

Navigation Drawer

public abstract class AbstractDrawerActivity extends AppCompatActivity { protected void startActivityAndCloseDrawer(Class<? extends Activity> toStart) {

 // Same activity, just return
 if (getActivity().getClass().equals(toStart))
 return;

 final Intent launchIntent = new Intent(getActivity(),toStart) .addFlags(Intent.FLAG_ACTIVITY_CLEAR_TOP);

 drawerLayout.closeDrawer(GravityCompat.START);
 drawerLayout.postDelayed(new Runnable() {
 @Override
 public void run() {
 startActivity(launchIntent);
 getActivity().overridePendingTransition(R.anim.activity_in, R.anim.activity_out);
 }
 }, CLOSE_DELAY);
 }

Navigation Drawer

public abstract class AbstractDrawerActivity extends AppCompatActivity { protected void startActivityAndCloseDrawer(Class<? extends Activity> toStart) {

 // Same activity, just return
 if (getActivity().getClass().equals(toStart))
 return;

 final Intent launchIntent = new Intent(getActivity(),toStart) .addFlags(Intent.FLAG_ACTIVITY_CLEAR_TOP);

 drawerLayout.closeDrawer(GravityCompat.START);
 drawerLayout.postDelayed(new Runnable() {
 @Override
 public void run() {
 startActivity(launchIntent);
 getActivity().overridePendingTransition(R.anim.activity_in, R.anim.activity_out);
 }
 }, CLOSE_DELAY);
 }

Navigation Drawer

public abstract class AbstractDrawerActivity extends AppCompatActivity { protected void startActivityAndCloseDrawer(Class<? extends Activity> toStart) {

 // Same activity, just return
 if (getActivity().getClass().equals(toStart))
 return;

 final Intent launchIntent = new Intent(getActivity(),toStart) .addFlags(Intent.FLAG_ACTIVITY_CLEAR_TOP);

 drawerLayout.closeDrawer(GravityCompat.START);
 drawerLayout.postDelayed(new Runnable() {
 @Override
 public void run() {
 startActivity(launchIntent);
 getActivity().overridePendingTransition(R.anim.activity_in, R.anim.activity_out);
 }
 }, CLOSE_DELAY);
 }

Navigation Drawer

public abstract class AbstractDrawerActivity extends AppCompatActivity { protected void startActivityAndCloseDrawer(Class<? extends Activity> toStart) {

 // Same activity, just return
 if (getActivity().getClass().equals(toStart))
 return;

 final Intent launchIntent = new Intent(getActivity(),toStart) .addFlags(Intent.FLAG_ACTIVITY_CLEAR_TOP);

 drawerLayout.closeDrawer(GravityCompat.START);
 drawerLayout.postDelayed(new Runnable() {
 @Override
 public void run() {
 startActivity(launchIntent);
 getActivity().overridePendingTransition(R.anim.activity_in, R.anim.activity_out);
 }
 }, CLOSE_DELAY);
 }

Navigation Drawer

public abstract class AbstractDrawerActivity extends AppCompatActivity { protected void startActivityAndCloseDrawer(Class<? extends Activity> toStart) {

 // Same activity, just return
 if (getActivity().getClass().equals(toStart))
 return;

 final Intent launchIntent = new Intent(getActivity(),toStart) .addFlags(Intent.FLAG_ACTIVITY_CLEAR_TOP);

 drawerLayout.closeDrawer(GravityCompat.START);
 drawerLayout.postDelayed(new Runnable() {
 @Override
 public void run() {
 startActivity(launchIntent);
 getActivity().overridePendingTransition(R.anim.activity_in, R.anim.activity_out);
 }
 }, CLOSE_DELAY);
 }

Navigation Drawer

public abstract class AbstractDrawerActivity extends AppCompatActivity { protected void startActivityAndCloseDrawer(Class<? extends Activity> toStart) {

 // Same activity, just return
 if (getActivity().getClass().equals(toStart))
 return;

 final Intent launchIntent = new Intent(getActivity(),toStart) .addFlags(Intent.FLAG_ACTIVITY_CLEAR_TOP);

 drawerLayout.closeDrawer(GravityCompat.START);
 drawerLayout.postDelayed(new Runnable() {
 @Override
 public void run() {
 startActivity(launchIntent);
 getActivity().overridePendingTransition(R.anim.activity_in, R.anim.activity_out);
 }
 }, CLOSE_DELAY);
 }

Navigation Drawer

<!—- Animate in —-> <set xmlns:android="http://schemas.android.com/apk/res/android">
 <alpha
 android:duration="@integer/activity_animation_duration"
 android:fromAlpha="0.0"
 android:toAlpha="1.0"
 android:interpolator="@android:anim/decelerate_interpolator"/>

 <translate
 android:duration="@integer/activity_animation_duration"
 android:fromYDelta="15%"
 android:toYDelta="0%"
 android:interpolator="@android:anim/decelerate_interpolator"/>
 </set> <!—- Animate out —-> <set xmlns:android="http://schemas.android.com/apk/res/android" >
 <alpha
 android:duration="@integer/activity_animation_duration"
 android:fromAlpha="1.0"
 android:toAlpha="0.0"
 android:interpolator="@android:anim/accelerate_interpolator"/>

 <translate
 android:duration="@integer/activity_animation_duration"
 android:fromYDelta="0%"
 android:toYDelta="-15%"
 android:interpolator="@android:anim/accelerate_interpolator"/>
 </set>

Don’t use them - ViewPager

Don’t use them - ViewPager

public class ViewListAdapter extends PagerAdapter {

 private ViewGroup [] views;

 public CustomPagerAdapter(ViewGroup... views) {
 this.views = views;
 }

 @Override
 public Object instantiateItem(ViewGroup collection, int position) {
 ViewGroup layout = views[position];
 collection.addView(layout);
 return layout;
 }

 @Override
 public void destroyItem(ViewGroup collection, int position, Object view) {
 collection.removeView((View) view);
 }

 @Override
 public int getCount() { return views.length; }

 @Override
 public boolean isViewFromObject(View view, Object object) { return view == object; }
 }

Don’t use them - ViewPager

public class ViewListAdapter extends PagerAdapter {

 private ViewGroup [] views;

 public CustomPagerAdapter(ViewGroup... views) {
 this.views = views;
 }

 @Override
 public Object instantiateItem(ViewGroup collection, int position) {
 ViewGroup layout = views[position];
 collection.addView(layout);
 return layout;
 }

 @Override
 public void destroyItem(ViewGroup collection, int position, Object view) {
 collection.removeView((View) view);
 }

 @Override
 public int getCount() { return views.length; }

 @Override
 public boolean isViewFromObject(View view, Object object) { return view == object; }
 }

Don’t use them - ViewPager

public class ViewListAdapter extends PagerAdapter {

 private ViewGroup [] views;

 public CustomPagerAdapter(ViewGroup... views) {
 this.views = views;
 }

 @Override
 public Object instantiateItem(ViewGroup collection, int position) {
 ViewGroup layout = views[position];
 collection.addView(layout);
 return layout;
 }

 @Override
 public void destroyItem(ViewGroup collection, int position, Object view) {
 collection.removeView((View) view);
 }

 @Override
 public int getCount() { return views.length; }

 @Override
 public boolean isViewFromObject(View view, Object object) { return view == object; }
 }

Don’t use them - setRetainInstance()

Luke's a bad dev!


(Well, perhaps not)

Cancel short tasks

Don’t use them - setRetainInstance()

Don’t use them - Lifecycle, Navigation

• What about Managing the back stack? Navigation? Passing data?
• There are 3rd party libraries and solutions
• Flow and Mortar From Square
• https://www.bignerdranch.com/blog/an-investigation-into-flow-

and-mortar/

Flow - Screens & Navigation

Screen Screen Screen

Activity

RecipeSearch ViewRecipe

flow.set(new ViewRecipeKey(234));

RecipeSearch ViewRecipe

flow.goBack();

Mortar

Custom View Presenter

// Lifecycle methods
 void onEnterScope(MortarScope scope) void onLoad(Bundle savedInstanceState) void onSave(Bundle outState) void onExitScope() “Mortar provides a simplified, composable overlay for the Android lifecycle”

Best Practises

Mitigate the risks if you do use them

What the Fragment? - Google I/O 2016

https://youtu.be/k3IT-IJ0J98

What is a fragment? (according to google)

• Roughly equivalent to an activity in terms of level of abstraction
• Part of the? in MV?
• Quote: “Seriously, the are not just fancy view groups”, “Don’t use a

fragment when a ViewGroup or <include> will do”

• Fragments provide glue and coordination of components, driven by

the knowledge of external lifecycle

Fragment = Component + Lifecycle

UI Components that have a lifecycle

Googles suggestions - How to use them

“Make sure that you keep your thinking just scoped to the Fragment.” “Make sure its not trying to take on responsibilities

• utside of its self”.

Googles suggestions - How to use them

DO NOT ‘go fishing’ for things when you get attached to an activity - go looking for other fragments, try and pull in various deps, etc

Googles suggestions - How to use them

Beware of dependencies! You can use onInflate() and fragment args to get data in

Activity List Fragment Detail Fragment

? ? ???

Google suggestions - don’t worry about lifecycle

static final int INITIALIZING = 0; // Not yet created.
 static final int CREATED = 1; // Created.
 static final int ACTIVITY_CREATED = 2; // The activity has finished its creation.
 static final int STOPPED = 3; // Fully created, not started.
 static final int STARTED = 4; // Created and started, not resumed.
 static final int RESUMED = 5; // Created started and resumed.

Use the support library Fragments!

• Child FragmentManager state guaranteed after super.onCreate()
• executePendingTransactions() didn’t do all the pending stuff for
• children. Now fixed!
• We now have FragmentTransaction.commitNow()
• Added Fragment.onAttachFragment () - good time to setup

listeners, etc

Pro-tip - Test with Do not keep activities

Summary

Summary - Problems with Fragments

• Treat fragments with respect - they

are dangerous

• Lifecycle, Child fragments and

Async fragment transactions!

• Lack of clear use case causes

problems - where to put them in your architecture

Summary - Don't use them

• You can probably get by with a lot less fragments than you think
• Don’t need them for normal activities
• Don’t need them for tablet layouts/responsive UI
• Don’t need them as composable UI building blocks
• (Probably) Don’t need them for drawers and viewpagers

If you have to use them, do this:

• Don’t misuse them - e.g., they are not ViewGroups!
• Keep communication to a minimum - “Make sure its not trying to

take on responsibilities outside of its self”

• Use support library
• Try and reduce the impact of the lifecycle as much as possible

Questions?

Case study - Fragments with Viewpager

• Viewpager may not construct all its

views at once. Depends on how many pages your caching

• FragmentPagerAdapter may build a

new fragment using getItem or may re-use an already constructed fragment by looking it up by ID

• Two different view pager adapters,

which deal with state in a different manner

Case study - Fragments with Viewpager

• Often used with nested fragments.

EG, you may have a Fragment which takes up the screen, which contains a view pager inside it, which of course has other fragments

• No way to get the current fragment.

Or fragments based on position

• Existing PagerAdapters are awful -

you can’t reliably modify their contents, get fragment at index, etc.

Case study - Fragments with Viewpager

• Who knows when any of the lifecycle methods will

be called ?! Often depends on position index, and what page your are selecting.

• eg. I have code that runs when the page changes

to update some stuff (activity action bar colour). It works fine when I select next page, or two pages

• down. Dies with :



 java.lang.IllegalStateException: Fragment TimelineListFragment_{b20af32 id=0x7f0c00bb android:switcher: 2131493051:1949793103} not attached to Activity

 When I select something 5 pages across

S.O.L.I.D principals of OO design

S - Single Responsibility Principal O L I D

Googles suggestions - Setup is conditional

• code from 14:30 in presentation.

Googles suggestions

• Fragments are great of libraries - don’t need to add stuff into
• nCreate, onPause, onResume, etc. Instead just add this fragment

and it does it all - e.g., the map fragment

• can even use <fragment>

Flow and Morter From Square

• TODO ***Small example of what they each do*** leave out of GDG

presentation

• https://www.bignerdranch.com/blog/an-investigation-into-flow-and-

mortar/

• https://corner.squareup.com/2014/10/advocating-against-android-

fragments.html

• https://www.reddit.com/r/androiddev/comments/2iodnx/

advocating_against_android_fragments/
