WARM WELCOME

Presentation Agenda

• DVR Introduction
• Matrix SATATYA Introduction
• SATATYA DVR Solution

 Hardware Solution  Software Solution

• SATATYA DVR Key Features
• SATATYA DVR Feature List

Digital Video Recorder (DVR) Introduction

Video & Audio Streaming

DVR and Its Functions

Recording Compression Storage Playback

Benefits of DVR System

• Provides Enhanced Security Round the Clock
• Reduce Cost of Security Personal
• Theft Reduction
• Increases Productivity
• Comprehensive End-to-End Surveillance

Matrix SATATYA DVR Introduction

What is SATATYA DVR?

• DVRs with 4, 8 and 16 Channels
• Standard and Premium Models
• Stand-Alone and Network Surveillance System
• Plug-n-Play Device
• Combination of Hardware and Software
• Central Monitoring System (CMS), Web Client and Mobile Viewer (MV)
• Comprehensive Solution for Small, Medium and Large Enterprises

Why SATATYA DVR?

Flexibly Record either Manually, Continuously, Scheduled, Motion, Alarm and Event based Remote Monitoring Using Advance CMS, Web Client and Mobile Viewer Synchronous Playback of All Channels Link One Audio Channel with Multiple Video Channels Dual Streaming Pentaplex Functions

Why SATATYA DVR?

Advanced Alarm Management Customized Layout Styles Check System Health Status on a Single Window Matrix DDNS Server for Remote Viewing without any Static IP

SATATYA DVR Integration

• SATATYA can be Easily Integrated with Third Party Products

Analog Cameras Fire Alarm Panel Access Control System

Target Customers…

Retail Stores Shopping Malls Hotels Clubs Large Enterprise Corporates Financial Institutes Private Offices Residential Areas And Many More

SATATYA DVR Solution

SATATYA DVR Solution

CMS SATATYA DS Hardware Web Client Mobile Client

SATATYA DVR SATATYA CMS SATATYA MV

SATATYA Web Client

Hardware Software

SATATYA DVR Hardware

SATATYA DVR Front View

SATATYA DVR Rear View

SATATYA DVR Connectivity

Front Panel of SATATYA DVR Range

SATATYA DVR Essential SATATYA DVR Standard SATATYA DVR Premium

Technical Specifications

Model→ SATATYA DVR4E SATATYA DVR4S

Front Panel No Yes Video Output 1 Main Video (BNC), VGA 1 Main Video (BNC), VGA Audio Output 1 Channel, BNC 1 Channel, RCA Alarm No Yes Image Resolution 2CIF Real Time CIF Real Time Synchronous Playback 4 4 Backup Manual Backup to USB Manual and Scheduled Backup to USB/FTP SATA Ports 1 Port(2TB Capacity) 1 Port(2TB Capacity) USB Ports 2 1

Model→ SATATYA DVR8E SATATYA DVR8S SATATYA DVR8P

Front Panel No Yes Yes Video Output 1 Main, 1 VGA 1 Main, 1 Spot, 1 VGA 1 Main, 1 Spot, 1 VGA, 1 HDMI Audio Output 1 Channel, BNC 1 Channel, BNC 1 Channel, BNC Alarm Output No Yes Yes Image Resolution CIF Real Time CIF Real Time CIF Real Time Synchronous Playback 4 8 8 Backup Manual Backup to USB Manual and Scheduled Backup to USB/FTP Manual and Scheduled Backup to USB/FTP SATA Ports (2 TB Each) 1 2 2 USB Ports 2 1 1

Technical Specifications

Model→ SATATYA DVR16S SATATYA DVR16P

Front Panel Yes Yes Video Output 1 Main, 1 Spot, 1 VGA 1 Main, 1 Spot, 1 VGA, 1 HDMI Loop Output No 16 Channel, Loop Output Audio Output 1 Channel, RCA 1 Channel, RCA Alarm Output Yes Yes Image Resolution CIF Real Time CIF Real Time Synchronous Playback 16 16 Backup Manual Backup over USB, Scheduled Backup over USB/FTP Manual and Scheduled Backup

• ver USB/FTP

SATA Ports(2TB Each) 2 2 USB Ports 2 2

Technical Specifications

SATATYA DVR Software Key Features

H.264 Compression Format

• Latest Video Compression Standard
• Reduces the Video Size
• No Compromise on Image Quality
• High Resolution of Video
• Less Network Bandwidth and Greater Storage Space

Pentaplex Functions

• Simultaneously Perform all Pentaplex Functions

Live Recording from All Cameras Manual or Scheduled Backup Remote Access Real-Time Monitoring Various Playback Modes

Live Recording Backup Remote Access Real-Time Monitoring Playback

Advanced Recording Options

• Manual, Continuous and Scheduled Recording
• Event based Recording
• Pre-Alarm and Post-Alarm Recording
• Privacy Masking while Recording
• Recording on Detection of Motion

Advanced Recording Options

Privacy Masking

• Protect Privacy on Concealing Parts of Image
• Cannot Display or Record Privacy Masked Area
• Important in Areas that Needs Surveillance but Requires Privacy also

Privacy Mask Off Privacy Mask On

Monitoring Features

• Different Monitoring Modes

 Single  Sequential  1x1, 2x2, 3x3, 4x4, 5+1, 7+1, 4+3, 8+2, 12+1  PIP1  PIP2

• Various Layout Templates
• User Defined Layout Styles
• Digital Zoom for Live View and Playback
• Video Freeze and Snapshot

Advanced Search Options

Date Selection Camera Selection Event Legends Time Selection Cursor Channel Selection

Playback Functions

• Live and Remote Playback
• Different Speed Control
• Fast and Slow Forward
• Single Step Forward
• Next and Previous Video
• Synchronous Playback for All Channels

Notification on Event

• Connect Up to 16 Alarm Input Devices
• Connect Up to 3 Alarm Output Devices
• Types of Alarm

 Video Loss

 Video Tamper  Motion Detection

• Take Quick Actions On Generation of Alarm

 Send SMS and Email Notifications

 Take PTZ Tour  Upload Image on FTP

Events and Alerts

Storage

• Up to 4TB Storage Capacity
• Up to 2 SATA HDD Support
• Storage on FIFO Basis

Backup

• Manual Backup on USB Port
• Scheduled Backup on Network
• Export in Native File Format
• Export to AVI on USB/FTP

Video Output

• VGA, HDMI and Main Video Output Ports to Connect Monitor or TV
• Spot Output for Live Monitoring of Video

Access to SATATYA DVR

• Access Live or Recorded Video
• Up to 10 Concurrent Login Sessions
• Authorized User can Access Video through

 SATATYA CMS  SATATYA Web Client  SATATYA Mobile Viewer (MV)

CMS Web Client MV

Remote Functions

• Live Camera Monitoring with PTZ Control
• Menu Configuration
• Record Video
• Live View and Playback

Dual Streaming

• Main Stream and Sub-stream Options
• Records with High Resolution on Main Stream
• Transmits with Lower Bit Rate on Sub-stream
• Preserves Bandwidth and Increases Remote Viewing Performance

Other Features

• 10,000 Events Log
• 3 User Access Level (Default)
• Embedded Web Server
• Intuitive GUI
• Linux Embedded OS
• Online Users List
• Web-based Interface
• System Health Check
• Camera Grouping
• Multiple Concurrent Login

Sessions (Up to 10)

• Multiple Programmable Users

(Up to 16)

Security Features

• Video Access Rights
• Three Authorization Access Levels

 Administrator, Operator and Viewer

• High Level of Access Security

 IP Access Control  Blocking Online Users  Password Protection  Secure Remote Access

Matrix Dyn DNS

• System Constantly Updates IP to DDNS Server
• User can Easily Access the System from Anywhere
• Saves Time
• Eliminates Cost of Separate DDNS Server

Centralized Management Software

• 36 Channels/ Up to 10 Pages
• Different Layout Styles
• Audio/Visual Alerts
• Video Alerts
• Record Plan
• Monitoring Plan
• Device/Camera Group
• Playback Search
• Event Log Search

Web Client

• Asynchronous/Synchronous Playback
• Event Log
• Camera wise Record, Search, Storage, Backup
• Health Status of Device
• PTZ Settings
• User Account Management

Mobile Viewer

• 2×2 Layout
• Digital Zoom
• PTZ Tour
• Set Favorite Channel
• Snapshots in Live View
• Add up to 10 Devices
• Main Stream and Sub Stream in Live View

SATATYA Analog Cameras

Box Cameras

SATATYA Camera Range

PTZ IR Bullet IR Dome Dome Box CADRP700VL90SW CABR600FL60SB/W CABR600FL36SB/W CABR600VL12SG CADR480FL60CB/W CADR600FL36SB/W CADR600FL60SB/W CAD480FL60CB/W CAD600FL36SB/W CAD600FL36CB/W CABX600RLSS

Camera Features

Backlight Compensation (BLC)

Auto White Balance (AWB) Wide Dynamic Range (WDR) Digital Noise Reduction (DNR) Highlight Compensation Capability (HLC)

Technical Specifications of PTZ Camera

Model→ PTZ Camera Variants SATATYA CADRP700VL90SW TVL 700 Image Sensor 1/3” Super Sony HAD CCD II Minimum Illumination Color: 0.015 Lux, B/W: 0.001 Lux Number of LEDs in IR Camera 12 pieces IR array lights IR Camera Range 120-150 m Pan/Tilt/Zoom 360˚ endless pan range 5˚- -90˚(Auto Flip) tilt range 30× Zoom Certification IP66, RoHS

SATATYA DVR Features List

Features List

Channels and Resolution 8 and 16 Channels 120 and 240 FPS H.264 Video Compression CIF, 2CIF and D1 Monitoring 1x1, 2x2, 3x3, 4x4, 5+1, 7+1, 4+3, 8+2, 12+1 Single, Sequential, PIP1 and PIP2 Digital Zoom on Live User Defined Layout Styles User Selectable Display Sequence Search Timeline based Search Channels Date and Time Recording Type Recording Manual and Scheduled Pre-alarm and Post-alarm Channel-wise Frame Rates and Resolution Trigger Based

Features List

Alarm 8 and 16 Alarm Input 3 Alarm Output Motion Detection Video Loss Video Tamper Audio 2 Audio Inputs G.711 Audio Compression 1 Audio Output Action on Events Buzzer Notifications Email Notifications Recall Preset Recording on Selected Channels SMS Notifications TCP Notifications Turn on Alarm Outputs Upload Images on FTP Server

Features List

Remote Functions Live Camera Monitoring with PTZ Control Menu Configuration Record Video Live View and Playback Firmware Upgrade Control IR Remote Control Front Panel Keypad Mouse Security IP Access Control List Block Online Users Secure Remote Access Video Access Rights

Thank You

For Further Information Please Contact: Email ID: Security@MatrixComSec.com Tel: +91 265 2630555 Visit us at www.MatrixSecuSol.com Version: V1R4
