Challenges in Setting Interactive Classroom (Virtual Class Rooms)

17th October 2013

What is Virtual Classroom?

• Virtual classroom is a replica of the local class room teaching where

in the students at remote locations will get the same feel and experience as if they are in the same classroom.

• Teacher will be able to use all conventional teaching tools and

continue to teach the way he does.

• Students can ask questions and interact with the teacher as if he is in

the local classroom

Options available for an Interactive Classroom / Virtual Class Room

• Video conferencing setup
• Tele-presence based system
• Room / Group Videoconferencing Systems
• PC based solutions / Software based Solutions

What is expected in a Interactive Class Room

• Clear View of teacher to students
• Teacher shall see Students / participants
• Teacher shall be able use conventional teaching tools
• Teacher shall be able to show computer screens
• Teacher is able to show objects
• Interaction with students
• If required, quick test on topic
• Good learning experience

Concerns while choosing a Technology

• Network availability
• Bandwidth available
• No of students expected in a class
• Dedicated / General Purpose Setup
• Modes of Participation
• Scope of expansion (Scalability)

Gadgets / Equipments required for an Interactive Class Room

• Display systems
• Cameras
• Microphones & Speaker system
• Visualizes / Document Cameras
• Interface to Computer systems
• Interactive writing pad/panels
• User Interface for ease of operations

Setup for Interactive Class Rooms

• Dedicated Teaching stations
• Dedicated Learning Class Rooms
• General Purpose Class Rooms

NATIONAL INFORMATICS CENTRE

• Resolution: Standard Definition or High Definition?

– SD (352x288 to 704x576 pixels) 30 fps – HD720p (1280x720 pixels) 30/60 fps – HD1080p (1920x1080 pixels) 30/60fps

• Bandwidth / Date rates:

128 kbps to 6 Mbps

• Content Resolution :

XGA to HD1080p

• Content frame rate :

1 to 30 fps

• Hardware / SW Systems
• AV Accessories
• Management

IIT Madras  IIT Hyderabad IIT Bombay  IIT Gandhinagar IIT Guwahati  IIT Patna

NIC/NICSI

• Each of six IITs has been provided with

– HD VC system with 2 cameras and 2 mics. – 40” HD LCD TV – 2 nos. – 2500 Lumens Projector – White board Digital Converter – A Laptop

• HD Multi Conferencing Unit installed at

(Central location) NIC Delhi

Details of Equipment supplied in Pilot Virtual Class Rooms

NIC/NICSI

• Operations were largely manual
• Picking up of Student’s audio in

large class rooms was a problem.

• Sharing of the written

documents/3D-objects was not possible

• Display size was small
• The Equipments have not been

permanently fixed in the class rooms

• No special site preparation was done

in the Class rooms w.r.to lighting, layouts, acoustics etc.

Observations from Pilot Virtual Class Room Set-up

NIC/NICSI

THE PROJECT

CREATION OF VIRTUAL CLASSROOMS AT IITS OVER NKN

• The project required the Creation of High Definition (HD)

Video Conferencing based Virtual Class Rooms (VCR) at 15 IITs over NKN

• As per the project at each of the IIT, 3 Virtual Class Rooms will

be set up totalling 45 Virtual Class Rooms .

• A total of 38 VCR are being created at 15 IITs
• NIC office at Delhi, Hyderabad, Bhubaneswar, Pune and

Guwahati were also facilitated with similar facility.

• Later the project was extended to creation of additional 23

VCRs at IISC, NITs, IISERs, CMI etc.

• A total of 66 Virtual Classrooms (VCRs) were created under

this project.

NIC/NICSI

S.no Name Of IIT No of VCR

1 IIT-Ropar 2 2 IIT-Hyderabad 3 3 IIT-Kharaghpur 3 4 IIT-Bhubaneswar 3 5 IIT-Guwahati 1 6 IIT-Indore 1 7 IIT Gandhinagar 3 8 IIT Bombay 3 9 IIT Roorkee 3 10 IIT Madras 3 11 IIT Kanpur 3 12 IIT Rajasthan 3 13 IIT Patna 3 14 IIT Delhi 3 15 IIT Mandi 1 TOTAL : 38

VCR Locations at 13 NITs

S.no Name Of NIT No of VCR 1 National Institute of Technology, Agartala 1 2 Motilal Nehru National Institute of Technology, Allahabad 1 3 Maulana Azad National Institute of Technology, Bhopal 1 4 Malaviya National Institute of Technology, Jaipur 1 5 National Institute of Technology, Jalandhar 1 6 National Institute of Technology, Kurukshetra 1 7 Visvesvaraya National Institute of Technology, Nagpur 1 8 National Institute of Technology, Patna 1 9 National Institute of Technology, Raipur 1 10 National Institute of Technology, Silchar, Cachar 1 11 National Institute of Technology, Surathkal, Mangalore 1 12 National Institute of Technology, Tiruchirapalli 1 13 National Institute of Technology, Warangal 1

S.no Name Of Inst (ONE EACH) 1 Indian Institute of Science Education and Research, Kolkata 2 Indian Institute of Science Education and Research, Mohali, Punjab 3 Indian Institute of Science Education and Research, Pune 4 Indian Institute of Science Education and Research, Trivandrum 5 Indian Institute of Science Education and Research, Bhopal 6 TIFR Centre for applicable Mathematics, Bangalore 7 Chennai Mathematical Institute, Chennai

VCR Locations at IISERs & other Institutions Indian Institute of Science, Bangalore 3

NIC ( NIC Delhi & 4 support Centres) 5

LAYOUT of VCR

(DEPLOYUED OVER NKN)

MODES OF VCR

Three modes of operations of VCR

• LOCAL CLASS
• DISTANCE TEACHING
• DISTANCE LEARNING

IIT Delhi (VCR)

IIT Indore IIT Bhubneshwar

Desktop (PC) based video conferencing

Video Conferencing from any PC/Laptop/Desktop equipped web cam, microphone & speakers (HD).

• Based on a New Standard: Scalable Video

Coding (SVC)

• Reaches any desktop or laptop over LAN,

WAN, Internet

• Point to Point
• Multi-point
• Seamless integration with standard video

conferencing end points

VCR Using Desktop based Video Conf.

Share Content

Low Cost Software Videoconferencing Solutions

AIIMS MODEL PROJECT Government of Madhya Pradesh

• AIIMS, New Delhi
• PGIMER, Chandigarh
• IPGMER, Kolkata
• JIPMER, Pondicherry
• GMC, Bhopal
• UCMC, Delhi
• CNBC, Delhi
• LHMC, Delhi
• NEIGRIHIMS, Shillong
• About 450 Schools and Colleges

across State

• More than 40 locations are working
• Dedicated studios for teaching

station and Low cost PC solution for Learning stations.

Teaching Institution Learning Institution

Cources

Classes/Week IIT Madras IIT Mandi 6 13 IIT Roorkee IIT Mandi 3 6 IIT Kharagpur IIT Bhubaneshwar 2 5 IIT Delhi IIT Mandi + IIT Ropar 2 5 IIT Bombay NIT Jaipur 2 4 IIT Bhubaneshwar IIT Kharagpur 2 4 IIT Mandi Ph.D Students 1 2 IISER Bhopal IISER Mohali 1 3 IISER Mohali IISER Bhopal 2 7 IISER Pune IISER Trivandrum 1 3 IISER Trivandrum IISER Bhopal + IISER Pune 2 6 NIT Jalandhar None 1 1 TIFR Bangalore IISER Trivandrum + IISER Pune 1 3 Total 26 62

Other requirements & Challenges

• Knowledge Sharing – Demand & Offerings

(http://virtualclassroom.nic.in)

• Recording of Event/Class
• Streaming / Webcast
• Interactivity
• LMS integration
• Archival of Recordings & Storage

Demonstration

Up scaling the project to all institutions of higher learning

Two Models of establishing Virtual Classrooms :

1.

High end classrooms ( using H/W Codecs with multiple cameras, Multiple HD Displays, Audio systems, Control etc) (established at IITs, NITs) ~ Equipment Cost Rs 30 to 40 Lakhs

• 2. PC based virtual classrooms (using Software based video

conferencing (established in AIIMS, Medical Institutions) ~ Equipment Cost ~Rs 5 Lakhs

• 3. Low cost PC Based Class Room Solution (MP Govt.) ~Rs 2.5 Lakhs
• 4. Very Low Class Rooms ~Rs 1 Lakh
