Verifying social expectations by model checking truncated paths

Stephen Cranefield

Department of Information Science University of Otago, Dunedin, New Zealand

and Michael Winikoff

School of CS & IT, RMIT University, Melbourne, Australia

Relationship to other papers in the session

• Spoletini and Verdicchio

– Monitoring commitments (vs. “social expectations”) – Language is a propositional temporal logic – Application of model checking (automata vs. labelling approaches) – Different viewpoint when representing commitments – Applicable to online monitoring only? (may not avoid premature fulfilment in offline mode) – Basic architecture proposed (word composer and word analyser) – Separation of past and present operators

• Lacroix et al.

– Generating behaviour for simulations vs. analysing observed behaviour – Spatial rather than temporal focus – Parameter-based rather than logical model of institutions and norms

Motivation

• ANIREM@AAMAS’05

Motivation

• ANIREM@AAMAS’05
• Language for expressing

conditional expectations with a rich temporal structure If you pay me the fe If you pay me the fee for e for this service, this service, starting starting the week after payment is the week after payment is made, each week made, each week for a year I will send a for a year I will send a current market current market analysis report to you, analysis report to you, unless you cancel the unless you cancel the subscription subscription first. first.

Motivation

• ANIREM@AAMAS’05
• Language for expressing

conditional expectations with a rich temporal structure

• hyMITL± combined Metric

Interval Temporal Logic with 1st order CTL± (with bounded quantification) and hybrid logic

Motivation

• ANIREM@AAMAS’05
• Language for expressing

conditional expectations with a rich temporal structure

• hyMITL± combined Metric

Interval Temporal Logic with 1st order CTL± (with bounded quantification) and hybrid logic

• Evolution of expectations

using formula progression

Motivation

• ANIREM@AAMAS’05
• Language for expressing

conditional expectations with a rich temporal structure

• hyMITL± combined Metric

Interval Temporal Logic with 1st order CTL± (with bounded quantification) and hybrid logic

• Evolution of expectations

using formula progression

• Process defined

algorithmically, not logically

Goals of this work

• Provide a logical account of the fulfilment and violation
• f temporally rich social expectations over observed

histories

• Introduce expectations by rules. Informally: l → Exp r
• Express expectations in terms of the current time point

(i.e. use formula progression to carry then forward)

• Show that the theory can be implemented in a model

checker

– Currently need restriction to propositional temporal logic

r … p p q

φ

For each state in model: Yes/No

“Model checking a path”

Points of difference

• The concept of social expectations as a generalisation
• f learned regularities, promises, formal commitments,

etc.

– Abstracts away from social context (e.g. debtor and creditor for a commitment) and the implications of violation and fulfilment – Focuses on conditional activation (dependent on history and current state), and monitoring to determine fulfilment and violation

• Online vs. offline monitoring

– Online: events arrive sequentially and the new last state in the history is checked for fulfilments and violations – Offline: traces may be kept for later analysis. All states in the provided history need to be checked

Our logic

• A hybrid propositional temporal logic, with past and future
• perators (an extension of the Hybrid Logics Model

Checker’s language):

• Plus derived temporal operators Exp, Fulf, Viol and

Progress (more detail later)

Premature fulfilment in offline monitoring (informal notation)

?

Premature fulfilment in offline monitoring (informal notation)

Unknown at s1

Semantics on complete paths

… …

V: Props →℘(States) g: StateVars → States Model (ℳ ) Point in model Variable bindings

⊨ Op(φ1,…,φn)

iff …

Some constraint

• n the model

structure

Semantics on truncated paths

• Based on work of Eisner et al. (2003).
• Introduce TruncS operator (truncate and use “strong” semantics)

⊨ TruncSφ

… …

V: Props →℘(States) g: StateVars → States Model (ℳ ) Point in model Variable bindings

iff …

Semantics on truncated paths

• Based on work of Eisner et al. (2003).
• Introduce TruncS operator (truncate and use “strong” semantics)

… …

V: Props →℘(States) g: StateVars → States Model (ℳ ) Point in model Variable bindings

⊨+ φ

… …

V: Props →℘(States) g: StateVars → States Model (ℳ ) Point in model Variable bindings

Strong (⊨+) vs. weak (⊨-) semantics ℳ, g, i ⊨+ φ :

φ strongly holds at index i of model ℳ. ℳ “supplies all the evidence needed” to conclude that φ holds

ℳ, g, i ⊨- φ :

φ weakly holds at index i of model ℳ. ℳ “carries no evidence” against φ

Strong semantics

If i > |ℳ| ℳ, g, i ⊭+ φ (Skeptical) else ℳ, g, i ⊨+ p (for proposition p) iff si ∈ V(p) ℳ, g, i ⊨+ ¬φ iff ℳ, g, i ⊭- φ ℳ, g, i ⊨+ φ ∧ ϕ iff ℳ, g, i ⊨+ φ and ℳ, g, i ⊨+ ϕ ℳ, g, i ⊨+ 〇φ iff ℳ, g, i+1 ⊨+ φ ℳ, g, i ⊨+ φ U ϕ iff ∃k ≥ i: ℳ, g, k ⊨+ ϕ and ∀j s.t. i ≤ j < k, ℳ, g, j ⊨+ φ …

Weak semantics

If i > |ℳ| ℳ, g, i ⊨- φ (Generous) else ℳ, g, i ⊨- p (for proposition p) iff si ∈ V(p) ℳ, g, i ⊨- ¬φ iff ℳ, g, i ⊭+ φ ℳ, g, i ⊨- φ ∧ ϕ iff ℳ, g, i ⊨- φ and ℳ, g, i ⊨- ϕ ℳ, g, i ⊨- 〇φ iff ℳ, g, i+1 ⊨- φ ℳ, g, i ⊨- φ U ϕ iff ∃k ≥ i: ℳ, g, k ⊨- ϕ and ∀j s.t. i ≤ j < k, ℳ, g, j ⊨- φ …

Defining Fulf and Viol

• Fulf φ ≡ Exp φ ∧ TruncS φ
• Viol φ ≡ Exp φ ∧ TruncS ¬φ

Carrying forward unresolved expectations

• Expections should always be expressed in terms of the current

state:

• – Exp 〇 φ Exp φ
• Expectations should be simplified if partially satisfied in previous

state

• – Exp (p ∧ 〇 φ) Exp φ

if p held in the earlier state

• This is the notion of formula progression (Bacchus and Kabanza,

2000), so we have (informally, again):

– Exp φ ∧ ¬ Fulf φ ∧ ¬ Viol φ ∧ Progress(φ,ϕ) → 〇 Exp ϕ

Comparison with the Verdicchio and Colombetti semantics

…

Comm(e,a,b,ûûp) Done(e, mc(a, b, ûûp)) Comm(e,a,b,ûûp) Comm(e,a,b,ûûp) p Fulf(e,a,b ûûp)

V&C: Our approach: …

Exp(l,r,n,ûûp) Exp(l,r,n,ûp) Exp(l,r,n,p) p Fulf p Progress(ûûp,ûp) Progress(ûp,p)

Formula progression

Semantics of progression

Monitoring expectations using HLMC

• The Hybrid Logics Model Checker (HLMC) [Dragone, 2005]

– Inputs: an XML representation of a model and a textual encoding of the formula to be checked. The model can have multiple modalities with no restrictions on their structure. – Output: List of states in which the formula is true – Two algorithms: MCLITE (binders excluded from language; runs in polynomial time) and MCFULL (runs in polynomial space and time exponential on the nesting degree

• f binders in the formula)

[Franceschet and de Rijke, 2006] – MCFULL: a recursive algorithm that labels each subformula with true or false, for each state, then uses those labels to label the formula itself – “MCFULL can be viewed as a general model checker for the hybridization of any temporal logic” (by adding appropriate labelling subprocedures for each modal

• perator)
• Extensions made:

– Based on a restriction to a single “next state” modality – Generalised notion of a label: for each subformula and each state index i, store values under the weak and strong semantics for each possible future truncation point – Implement ExistsExp, ExistsFulf, ExistsViol and Progress modalities

The need for generalised labels

The MCFULL labelling procedure

… … … … … … … … … …

… …

¬

… …

Li(¬p ∩ ûq) = ¤i≤k≤n (Lk(ûq) , ⁄i≤j≤k Lj(¬p))

• Labelling ↓xφ(x) is a little more complicated (not discussed today)

If trunc’d after State Labels under weak & strong semantics “Generalised label”

HLMC extensions

Swap and negate copy Formula for ∩ is modified to act on generalised labels. Also, weak semantics allows U to act like W (weak until) up to truncation point

Hypothetical Exp, Fulf and Viol modalities

• We use these versions of Exp, Fulf and Viol:

– Exp(λ, ρ, n, φ) Fulf(λ, ρ, n, φ) Viol(λ, ρ, n, φ)

If we had a rule with condition λ and expectation ρ, the rule would have fired at the state named by nominal n, giving rise to the [fulfilled or violated] expectation φ in the current state (Note: ρ may have become φ by multiple progression steps)

• We actually implement ExistsExp(λ, ρ), etc.

– “There exists some pair (n, φ) making Exp(λ, ρ, n, φ) true”

• For each state, the extended model checker reports all

such pairs making the input formula Exists…(λ, ρ)

Semantics of Exp(λ, ρ, n, φ), Fulf(λ, ρ, n, φ) and Viol(λ, ρ, n, φ)

Semantics of ExistsExp(λ, ρ, n, φ) Computing witnesses

Example

• Rule: “After ordering an item, you can’t
• rder again until you’ve paid”
• Scenario 1:
• Scenario 2:

Conclusions

• Logical account given of expectations and their

fulfilment and violation

• Semantics applicable to both offline and online

monitoring (but implementation is only for the offline mode so far)

• Implemented by extending the HLMC model checker
• Further work:

– Extend to real-time temporal logic, and allow predicates and restricted quantification – Adapt implementation for online monitoring – Real-world applications
