V2x wireless channel modeling for connected cars

Taimoor Abbas Volvo Car Corporations taimoor.abbas@volvocars.com

slide-2
SLIDE 2

V2X Terminology

6/12/2018

2

SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM

V2N V2I V2V P2N V2P P2I I2N

Background

slide-3
SLIDE 3

Wireless channel

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 3

Transmit antenna Receiver antenna Propagation channel

Radio channel

Background

The wireless channel is a medium used to transmit data wirelessly from the transmitter to the receiver antenna.

slide-4
SLIDE 4

Wireless channel

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 4

Background

Why do we need wireless channel modeling? Ideally, modeling a channel means to calculate or estimate all the processing, due to the physical environment, effecting a signal from the transmitter to the receiver. How wireless channel is modeled? Wireless channel is modeled analytically with the help of simulations or empirically by real world measurements. Where it is used? For the wireless system design, it is used for link-level or system simulations as well as to test the hardware especially where control and repeatability is required. It can also be used to bench mark multiple hardware with standard settings. The major benefits are? Easy to use, allow better control and repeatability, cost effective and could be scaled

slide-5
SLIDE 5

Propagation mechanism

5

Background

i

r

t

1

2

Reflection and transmission Diffraction Scattering Waveguiding Line-of-sight (LOS) component Multipath components Typical communication scenario

slide-6
SLIDE 6

Propagation mechanism (cont.)

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 6

Background

d ARX If we assume the TX/RX antennas to be isotropic being in free space,

2

4

RX TX

P P d     =    

( )

2

4       =  d d Lfree

Path loss Small scale fading Large scale fading

slide-7
SLIDE 7

V2V vs v2i

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 7

V2X Channel

slide-8
SLIDE 8

Doppler shift for v2v

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 8

slide-9
SLIDE 9

Key Differences in V2V Channel Modeling

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 9

V2X Channel

Wr Wt dr, Truck dt g1 g2, Truck g2, XC90 dr, XC90 Truck Blue S60 XC90 Black g2, XC90

LOS: Line-Of-Sight OLOS: Obstructed Line-Of-Sight NLOS: Non Line-Of-Sight Multilink

slide-10
SLIDE 10

V2X Channel Measurements

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 10

Modeling

slide-11
SLIDE 11

Channel Sounder

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 11

Modeling

slide-12
SLIDE 12

Measurement based modeling

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 12

1 2 3 4

Note:

  • Measurement tool always has certain

limitations

  • It is necessary to keep those limitations

in mind when establishing models based on the measurements

  • For a channel model to be independent
  • f object, it has to be double directional

and antennas need to be calibrated so that the response could be subtracted later on

slide-13
SLIDE 13

Measurement campaign step by step

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 13

Antenna calibration Channel sounder mounting Conduction measure- ments

slide-14
SLIDE 14

Measurement campaign step by step

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 14

Antenna calibration Channel sounder mounting Conduction measure- ments

slide-15
SLIDE 15

Measurement campaign step by step

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 15

Antenna calibration Channel sounder mounting Conduction measure- ments

slide-16
SLIDE 16

General observations – v2v measurements

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 16

Time-delay characteristics:

100 200 300 400 Propagation distance [m] Power

t = 0 s

100 200 300 400 Propagation distance [m] Power

t = 0.2 s

100 200 300 400 Propagation distance [m] Power

t = 0.4 s

100 200 300 400 Propagation distance [m] Power

t = 0.6 s

100 200 300 400 Propagation distance [m] Power

t = 0.8 s

100 200 300 400 Propagation distance [m] Power

t = 1 s

100 200 300 400 Propagation distance [m] Power

t = 1.3 s

100 200 300 400 Propagation distance [m] Power

t = 1.5 s

100 200 300 400 Propagation distance [m] Power

t = 1.7 s

100 200 300 400 Propagation distance [m] Power

t = 1.9 s

100 200 300 400 Propagation distance [m] Power

t = 2.1 s

100 200 300 400 Propagation distance [m] Power

t = 2.3 s

100 200 300 400 Propagation distance [m] Power

t = 2.5 s

100 200 300 400 Propagation distance [m] Power

t = 2.8 s

100 200 300 400 Propagation distance [m] Power

t = 3 s

100 200 300 400 Propagation distance [m] Power

t = 3.2 s

100 200 300 400 Propagation distance [m] Power

t = 3.4 s

100 200 300 400 Propagation distance [m] Power

t = 3.6 s

100 200 300 400 Propagation distance [m] Power

t = 3.8 s

100 200 300 400 Propagation distance [m] Power

t = 4.1 s

100 200 300 400 Propagation distance [m] Power

t = 4.3 s

100 200 300 400 Propagation distance [m] Power

t = 4.5 s

100 200 300 400 Propagation distance [m] Power

t = 4.7 s

100 200 300 400 Propagation distance [m] Power

t = 4.9 s

100 200 300 400 Propagation distance [m] Power

t = 5.1 s

100 200 300 400 Propagation distance [m] Power

t = 5.3 s

100 200 300 400 Propagation distance [m] Power

t = 5.6 s

RX TX

100 200 300 400 Propagation distance [m] Power

t = 5.8 s

100 200 300 400 Propagation distance [m] Power

t = 6 s

100 200 300 400 Propagation distance [m] Power

t = 6.2 s

LOS

100 200 300 400 Propagation distance [m] Power

t = 6.4 s

100 200 300 400 Propagation distance [m] Power

t = 6.6 s

100 200 300 400 Propagation distance [m] Power

t = 6.9 s

100 200 300 400 Propagation distance [m] Power

t = 7.1 s

100 200 300 400 Propagation distance [m] Power

t = 7.3 s

100 200 300 400 Propagation distance [m] Power

t = 7.5 s

100 200 300 400 Propagation distance [m] Power

t = 7.7 s

100 200 300 400 Propagation distance [m] Power

t = 7.9 s

100 200 300 400 Propagation distance [m] Power

t = 8.1 s

Discrete comp. Diffuse comp. Other vehicles Houses, road signs etc.

  • Rapidly varying channel
  • Discrete components carry significant energy and change delay bin with time
  • Diffuse components following LOS
slide-17
SLIDE 17

General observations – v2v measurements

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 17

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

LOS Discrete components Diffuse components

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

  • 1500
  • 1000
  • 500

500 1000 1500 100 200 300 400 500

  • 90
  • 80
  • 70
  • 60
  • 50

Doppler frequency [Hz] Delay [ns] Power [dB]

Local scattering function:

  • Discrete components: small Doppler spread, but can change delay bin rapidly
  • Diffuse components: large delay and Doppler spread
  • Time-variant Doppler spectrum → Non-stationary conditions
slide-18
SLIDE 18

Measurement based modeling

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 18

The time during which the local scattering function is ”sufficiently constant” is defined as the stationarity time Highway, opposite direction Highway, same direction Urban, same direction 23 ms 1479 ms 1412 ms

slide-19
SLIDE 19

A geometry based stochastic model

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 19

Diffuse scatterers Mobile discrete scatterers Static discrete scatterers

Adding up all components using different antenna patterns → MIMO channels Dependent on antenna pattern

slide-20
SLIDE 20

Deterministic modeling

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 20

  • Non-measurement based modeling could either

be statistical geometry based of deterministic

  • Deterministic approach, such as ray tracing, can

be very realistic but computationally expensive

  • Moreover, it requires accurate geometry
  • Solve approximation to Maxwell’s equation,

using high-frequency approximation

[Maurer et al. 2004]

slide-21
SLIDE 21

Ray tracing example

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 21

slide-22
SLIDE 22

Measurements vs ray tracing

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 22

  • Very good agreement in LOS and near LOS regions.
  • In NLOS, the ray tracing model underestimates the channel

gain.

  • Gap can be reduced by increasing the order of reflection.
  • Contribution of third and higher-order specular and non-

specular reflections is missing in the simulator.

Measuremed PDP Simulated PDP (Ray-tracing) Channel gain

LOS NLOS

slide-23
SLIDE 23
  • A channel model is selected based on what part of the communication system

that is going to be studied.

  • For network level simulations, where communication protocols are studied, a

statistical model (e.g., Rician, Rayleigh, and Nakagami) is the predominant channel model type to keep computational time down.

  • For PHY layer, TDLs and geometry-based stochastic and deterministic channel

models are for obvious reasons the preferred channel models.

  • So selection of channel model has to be made very carefully as the channel is
  • ne of the major performance factors
  • To summarize; following is a receipe on the selection and usage of channel

models.

Channel models for test and simulations

6/12/2018

23

SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM

slide-24
SLIDE 24

V2X- Channel: Specific considerations

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 24

V2X Channel

slide-25
SLIDE 25

V2x channel models classification

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 25

slide-26
SLIDE 26

3GPP TR38.901: V2X-specific Considerations

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 26

slide-27
SLIDE 27

3GPP TR38.901: V2X-specific Considerations

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 27

slide-28
SLIDE 28

3GPP TR38.901: V2X-specific Considerations

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 28

slide-29
SLIDE 29

3GPP TR38.901: V2X-specific Considerations

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 29

slide-30
SLIDE 30

3GPP TR38.901: V2X-specific Considerations

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 30

slide-31
SLIDE 31

Summary of parameter to be used

6/12/2018 SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM 31

slide-32
SLIDE 32

References

6/12/2018

32

SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM

slide-33
SLIDE 33
  • I would like to thank my colleagues from Lund University as some of the work is

produced jointly, especially Fredrik Tufvesson, Johan Kåredal and Mikael Nilsson.

  • Special thanks to Mate Boban from Huawei, Munich, for sharing information

about the activities at 3GPP and for the cooperation under the umbrella of 5GCAR on channel modeling. Thank you for listening!

acknowledgement

6/12/2018

33

SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM

slide-34
SLIDE 34
  • A. Paier, J. Kåredal, N. Czink, C. Dumard, T. Zemen, F. Tufvesson, A. Molisch, C. F. Mecklenbräuker, ”Characterization of

Vehicle-to-Vehicle Radio Channels from Measurements at 5.2GHz,” Wireless Personal Communications, vol. 50, no. 1,

  • pp. 19-29, 2009.
  • J. Kåredal, F. Tufvesson, N. Czink, A. Paier, C. Dumard, T. Zemen, C. Mecklenbräuker, A. Molisch, ”A geometry-based

stochastic MIMO model for vehicle-to-vehicle communications,” IEEE Transactions on Wireless Communications, vol. 8,

  • no. 7, pp. 3646-3657, 2009.
  • A. Molisch, F. Tufvesson, J. Kåredal, C. F. Mecklenbräuker, ”A Survey on Vehicle-to-Vehicle Propagation Channels,” IEEE

Wireless Communications, vol. 16, no. 6, pp. 12-22, 2009.

  • J. Kåredal, F. Tufvesson, T. Abbas, O. Klemp, A. Paier, L. Bernadó, A. Molisch, ”Radio channel measurements at street

intersections for vehicle-to-vehicle applications,” Proc. IEEE Vehicular Technology Conference (VTC2010-spring), Taipei, Taiwan, pp. 1-5, May 16-19, 2010.

  • A. Paier, L. Bernadó, J. Kåredal, O. Klemp, A. Kwoczek, ”Overview of vehicle-to-vehicle radio channel measurements for

collision avoidance applications,” Proc. IEEE Vehicular Technology Conference (VTC2010-spring), Taipei, Taiwan, pp. 1-5, May 16-19, 2010.

  • A. Molisch, F. Tufvesson, J. Kåredal, C. Mecklenbräuker, ”Propagation aspects of vehicle-to-vehicle communications - an
  • verview,” Proc. IEEE Radio and Wirless Symposium (RWS), San Diego, CA, USA, pp. 179-182, Jan. 18-22, 2009.
  • J. Kåredal, F. Tufvesson, N. Czink, A. Paier, C. Dumard, T. Zemen, C. Mecklenbräuker, A. Molisch, ”Measurement-based

modeling of vehicle-to-vehicle MIMO channels,” Proc. IEEE International Conference on Communications (ICC), Dresden, Germany, June 14-18, 2009.

Selected publications

6/12/2018

34

SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM

slide-35
SLIDE 35
  • A. Paier, T. Zemen, J. Kåredal, N. Czink, C. Dumard, F. Tufvesson, C. Mecklenbräuker, A. Molisch, ”Spatial diversity and

spatial correlation evaluation of measured vehicle-to-vehicle radio channels at 5.2 GHz,” Proc. IEEE Digital Signal Processing Workshop/Signal Processing Education Workshop (DSP/SPE), pp. 326-330, Jan 1-4, 2009.

  • L. Bernadó, T. Zemen, A. Paier, J. Kåredal, B. Fleury, ”Parametrization of the local scattering function estimator for

vehicular-to-vehicular channels,” Proc. IEEE Vehicular Technology Conference (VTC2009-fall), Anchorage, AK, USA, pp. 1-5, Sept. 20-23, 2009.

  • A. Paier, T. Zemen, L. Bernado, G. Matz, J. Kåredal, N. Czink, C. Dumard, F. Tufvesson, A. Molisch, C. Mecklenbräuker,

”Non-WSSUS vehicular channel characterization in highway and urban scenarios at 5.2 GHz using the local scattering function,” Proc. International Workshop on Smart Antennas (WSA), pp. 9-15, 2008.

  • L. Bernadó, T. Zemen, A. Paier, G. Matz, J. Kåredal, N. Czink, C. Dumard, F. Tufvesson, M. Hagenauer, A. Molisch, C. F.

Mecklenbräuker, ”Non-WSSUS Vehicular Channel Characterization at 5.2 GHz - Spectral Divergence and Time-Variant Coherence Parameters,” Proc. URSI General Assembly, 2008.

  • A. Paier, J. Kåredal, N. Czink, H. Hofstetter, C. Dumard, T. Zemen, F. Tufvesson, C. Mecklenbräuker, A. Molisch,

”First results from car-to-car and car-to-infrastructure radio channel measurements at 5.2GHz,” Proc. IEEE International Symposium on Personal, Indoor and Mobile Radio Communications (PIMRC), Athens, Greece, pp. 1-5, Sept. 3-7, 2007.

  • A. Paier, J. Kåredal, N. Czink, H. Hofstetter, C. Dumard, T. Zemen, F. Tufvesson, A. Molisch, C. Mecklenbräuker, ”Car-to-

car radio channel measurements at 5 GHz: Pathloss, power-delay profile, and delay-Doppler spectrum,” Proc. IEEE International Symposium on Wireless Communication Systems (ISWCS), Trondheim, Norway, pp. 224-228, Oct. 17-19, 2007.

Selected publications

6/12/2018

35

SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM

slide-36
SLIDE 36
  • C. Mecklenbräuker, A. Molisch, J. Karedal, F. Tufvesson, A. Paier, L. Bernadó, T. Zemen, O. Klemp, N. Czink: Vehicular

channel characterization and its implications for wireless system design and performance, Proceedings of the IEEE, Vol. 99, No. 7, pp. 1189-1212, 2011.

  • T. Abbas, J. Karedal, F. Tufvesson, A. Paier, L. Bernadó, A. Molisch: Directional Analysis of Vehicle-to-Vehicle Propagation

Channels, IEEE Vehicular Technology Conference, IEEE 73rd Vehicular Technology Conference 2011-spring, Budapest, Hungary, 2011-05-15/2011-05-18.

  • T. Abbas, and F. Tufvesson: Line-of-Sight Obstruction Analysis for Vehicle-to-Vehicle Network Simulations in a Two Lane

Highway Scenario, Hindawi International Journal of Antennas and Propagation, Special Issue on Radio Wave Propagation and Wireless Channel Modeling (In press)

  • T. Abbas, L. Bernadó, A. Thiel, C. F. Mecklenbräuker, and F. Tufvesson: Radio Channel Properties for Vehicular

Communication: Merging Lanes Versus Urban Intersections, IEEE Vehicular Technology Magazine, December, 2013 (Invited paper)

  • T. Abbas, J. Kåredal, and F. Tufvesson: Measurement-Based Analysis: The Effect of Complementary Antennas and

Diversity on Vehicle-to-Vehicle Communication, IEEE Antennas and Wireless Propagation Letters, 2012.

  • T. Abbas, J. Nuckelt, T. Kürner, T. Zemen, C. Mecklenbräuker, and F. Tufvesson: Simulation and Measurement Based

Vehicle-to-Vehicle Channel Characterization: Accuracy and Constraint Analysis (Accepted with major revision, 2014 to IEEE Transactions on Antennas and Propagations).

  • T. Abbas: Measurement Based Channel Characterization and Modeling for Vehicle-to-Vehicle Communications, Series of

licentiate and doctoral dissertations, ISSN 1654-790X (No. 58), Department of Electrical and Information Technology, Lund University, Sweden, 2014.

Selected publications

6/12/2018

36

SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM

slide-37
SLIDE 37
  • M. Boban, J. Barros, and O. Tonguz, “Geometry-based vehicle-to-vehicle channel modeling for large-scale simulation,”

IEEE Transactions on Vehicular Technology, Vol. 63, No. 9, November 2014

  • Mikael G. Nilsson et. al “On Multilink Shadowing Effects in Measured V2V Channels on Highway”, 2016
  • Mikael G. Nilsson et. al “A Measurement-Based Multilink Shadowing Model for V2V Network simulations of Highway

Scenarios”, 2017

  • Mikael G. Nilsson et. al “A Path Loss and Shadowing Model for Multilink Vehicle-to-Vehicle Channels in Urban

Intersections”, 2018

  • Mate Boban et. Al “Multi-band Spatio-Temporal Characterization of a V2V Environment Under Blockage“, 2018

Selected publications

6/12/2018

37

SUMMER SCHOOL ON 5G V2X COMMUNICATIONS - TAIMOOR.ABBAS@VOLVOCARS.COM
