US US 83 83 & SH & SH 15 15 BRIDGE REPLACEMENT PROJECTS OP OPEN N HO HOUS USE Tuesday, August 6, 2019 6:00 P.M. to 8:00 P.M. August 6, 2019 US 83 & SH 15 Bridge Replacements Outline for Presentation 1 Safety 3 2

slide-1
SLIDE 1

US 83 & SH 15 Bridge Replacements August 6, 2019

US US 83 83 & SH & SH 15 15

BRIDGE REPLACEMENT PROJECTS

OP OPEN N HO HOUS USE

Tuesday, August 6, 2019 6:00 P.M. to 8:00 P.M.

slide-2
SLIDE 2

US 83 & SH 15 Bridge Replacements August 6, 2019

Outline for Presentation

2

3 Safety 1 4-5 Goals of Public Involvement 2 6 Project Purpose 3 7 Project Map 4 8-10 Construction Phasing and Timeline 5 11-21 Project Maps and Detour Layouts 6 22 Project Development Timeline 7 23-24 Desired Feedback Comments Deadline and TxDOT Webpage Link 8

slide-3
SLIDE 3

US 83 & SH 15 Bridge Replacements August 6, 2019

slide-4
SLIDE 4

US 83 & SH 15 Bridge Replacements August 6, 2019

Goals of Public Involvement

Pro rovide vide Project roject Inf nformatio

  • rmation To

The e Citize zens ns Of Lips psco comb, mb, Hansf nsfor

  • rd,

, Och chilt iltre ree, , and nd Hemphi hill ll Coun unti ties es Discuss What To Expect Detailed Project Information Status Update Overall Project Timeline

4

slide-5
SLIDE 5

US 83 & SH 15 Bridge Replacements August 6, 2019

Goals of Public Involvement

TxDO DOT Is Reque uesting ting Fe Feed edbac back k Regar arding g All Aspe pects cts Of The e Proposed roposed Project roject We are Here To Answer Your Questions

Provide Us

Your Feedback, Both Written And Verbally Your Involvement Improves This Project

5

slide-6
SLIDE 6

US 83 & SH 15 Bridge Replacements August 6, 2019

Project Overview

6

  • Remove & Replace The Last 5 Timber Pile Bridges In The

Amarillo District (Built In The Mid To Late 1930’s)

  • Structures are still performing & are safe, but have

exceeded the intended design life.

Project ject Purp rpose

  • se
  • Total Construction Estimate: $9.15 Million
  • Status: 60% Project Development Of Plans And

Engineering Design

  • Construction Will Begin As Soon As Summer Of 2020

Project ject Facts ts

slide-7
SLIDE 7

US 83 & SH 15 Bridge Replacements August 6, 2019

Project Overview Map

7

slide-8
SLIDE 8

US 83 & SH 15 Bridge Replacements August 6, 2019

Bridge Construction Phasing

8

EXISTING BRIDGE STEP 1 BRIDGE CONSTRUCTION Traffic

  • Existing bridge open to 2-

way traffic

Const struction uction

  • Construct new bridge

foundations

slide-9
SLIDE 9

US 83 & SH 15 Bridge Replacements August 6, 2019

Bridge Construction Phasing

9

STEP 2 BRIDGE CONSTRUCTION Traffic

  • Shifted to detours

Const struction uction

  • Existing bridge structure

removed

  • Pre-Cast bridge elements

brought in and placed

STEP 3 BRIDGE CONSTRUCTION Traffic

  • New bridge open to traffic

Const struction uction

  • Install Bridge Rail, RipRap

and other misc. items

  • Clean up
slide-10
SLIDE 10

US 83 & SH 15 Bridge Replacements August 6, 2019

Bridge Construction Phasing

10

FINAL BRIDGE

slide-11
SLIDE 11

US 83 & SH 15 Bridge Replacements August 6, 2019

Project Overview Map

11

slide-12
SLIDE 12

US 83 & SH 15 Bridge Replacements August 6, 2019

US 83 at West Fork Horse Creek (North): Project Map

12

slide-13
SLIDE 13

US 83 & SH 15 Bridge Replacements August 6, 2019

US 83 at West Fork Horse Creek (North): Detour

13

slide-14
SLIDE 14

US 83 & SH 15 Bridge Replacements August 6, 2019

US 83 at West Fork Horse Creek (South): Project Map

14

slide-15
SLIDE 15

US 83 & SH 15 Bridge Replacements August 6, 2019

US 83 at West Fork Horse Creek (South): Detour

15

slide-16
SLIDE 16

US 83 & SH 15 Bridge Replacements August 6, 2019

SH 15 at Farwell Creek: Project Map

16

slide-17
SLIDE 17

US 83 & SH 15 Bridge Replacements August 6, 2019

SH 15 at Farwell Creek: Detour

17

slide-18
SLIDE 18

US 83 & SH 15 Bridge Replacements August 6, 2019

SH 15 at Palo Duro Creek: Project Map

18

slide-19
SLIDE 19

US 83 & SH 15 Bridge Replacements August 6, 2019

SH 15 at Palo Duro Creek: Detour

19

slide-20
SLIDE 20

US 83 & SH 15 Bridge Replacements August 6, 2019

SH 15 at Ivanhoe Creek: Project Map

20

slide-21
SLIDE 21

US 83 & SH 15 Bridge Replacements August 6, 2019

SH 15 at Ivanhoe Creek: Detour

21

slide-22
SLIDE 22

US 83 & SH 15 Bridge Replacements August 6, 2019

US 83 & SH 15 Project Timeline

Preliminary Engineering

  • Began May 2019

Public Involvement

  • August 6, 2019

Environmental Decision

  • September 2019

Preliminary Engineering

  • Complete October 2019

Roadway Construction

  • As soon as Summer 2020

We are e Here

slide-23
SLIDE 23

US 83 & SH 15 Bridge Replacements August 6, 2019

Presentation Exhibits

23

Presentation Exhibits Located In The Back Of The Room

www.TxDOT.gov Search “US 83 SH 15 Bridge Replacements”

slide-24
SLIDE 24

US 83 & SH 15 Bridge Replacements August 6, 2019

End of Presentation

24

Brian n Crawf wfor

  • rd,

d, P.E. E. Amarillo District Engineer Texas Department of Transportation 5715 Canyon Drive Amarillo, Texas 79110

Provide Us With Your Comments

Please Fill Out a Comment Card And Place It In The

Drop Box Tonight Or Mail Your Comments To: Comments must be postmarked by 8/21/19

Project information can be found at www.TxDOT.gov Search “US 83 SH 15 Bridge Replacements”
