SLIDE 1
2
scenelab.io
@n_mehlhorn
UNDO-REDO WITH ANGULAR & NGRX scenelab.io @n_mehlhorn 2 - - PowerPoint PPT Presentation
UNDO-REDO WITH ANGULAR & NGRX scenelab.io @n_mehlhorn 2 - - PowerPoint PPT Presentation
UNDO-REDO WITH ANGULAR & NGRX scenelab.io @n_mehlhorn 2 Minimize opportunity for error, but accept that mistakes will happen @n_mehlhorn 3 scenelab.io @n_mehlhorn 4 NILS MEHLHORN nils-mehlhorn.de www freelance software engineer
SLIDE 2
SLIDE 3
Minimize opportunity for error, but accept that mistakes will happen
3 @n_mehlhorn
SLIDE 4
4
scenelab.io
@n_mehlhorn
SLIDE 5
NILS MEHLHORN
freelance software engineer founder of scenelab.io
5
nils-mehlhorn.de
www
@n_mehlhorn
@n_mehlhorn
SLIDE 6
6
NGRX BOOK
Pay what you want for the complete learning resource gum.co/angular-ngrx-book
@n_mehlhorn
SLIDE 7
ERROR TOLERANCE = USER-FRIENDLY DESIGN
- users have different backgrounds
- ease onboarding
➙ confidence & creativity
7
browser supports only some interactions
@n_mehlhorn
SLIDE 8
KEYBOARD SHORTCUTS: CONSIDERATIONS
8 @n_mehlhorn
- common combinations: Ctrl + Z / Ctrl + Shift + Z
- provide legend and/or tooltips
- consider existing browser shortcuts
- consider internationalization
SLIDE 9
KEYBOARD SHORTCUTS: IMPLEMENTATION
9 @n_mehlhorn
- Key Event Bindings
- EventManager
- NgRx Effect
<div (keydown.control.z)="undo()" (keydown.control.shift.z)="redo()”> </div>
Recommended Read
Keyboard Shortcuts in Angular -- Netanel Basal
shortcut$ = createEffect(() => fromEvent(document, ‘keydown’) .pipe(...) )
SLIDE 10
10
component service service service service service component component
State everywhere Where to begin?
@n_mehlhorn
SLIDE 11
REDUX / NGRX ARCHITECTURE
11
STORE REDUCER UI
ACTION
dispatch trigger update render
SLIDE 12
12
store component service component service service component service
Single Source of Truth
@n_mehlhorn
SLIDE 13
READ-ONLY STATES
13
S1 S3 S2 REDUCER S4 Services Components Undo-Redo History?
ACTION
@n_mehlhorn
dispatch
SLIDE 14
PURE FUNCTIONS
14
REDUCER S2
ACTION
@n_mehlhorn
S1 META-REDUCER Put Undo-Redo Logic here
SLIDE 15
HISTORY OF STATES
15 interface History { past: Array<State> present: State future: Array<State> } case 'UNDO': const previous = history.past[0] const newPast = history.past.slice(1) history = { past: newPast, present: previous, future: [history.present, ...history.future] } return previous default: const newPresent = reducer(state, action) history = { past: [history.present, ...history.past], present: newPresent, future: [] // clear future } return newPresent @n_mehlhorn
SLIDE 16
HISTORY OF STATES
👎 intuitive implementation 👎 most libraries do this 👏 it can get big 👏 it’s all or nothing
16 @n_mehlhorn
SLIDE 17
17
A1 A2 S1 S2 S3
undo
undoable not undoable
ALL OR NOTHING: GOING BACK MEANS LOSING THE GREEN SQUARE
@n_mehlhorn
SLIDE 18
HISTORY OF STATES
👎 intuitive implementation 👎 most libraries do this 👏 it can get big 👏 it’s all or nothing
18
careful reducer composition required
@n_mehlhorn
SLIDE 19
19
S1 A1 S2 A2 S3 A3 S4 not undoable S1 A1 S2 A2 S3
undo
not undoable S1 A2 S3a
undo
not undoable
HISTORY OF ACTIONS
@n_mehlhorn interface History { actions: Array<Action> base: State }
SLIDE 20
HISTORY OF ACTIONS
20 const lastState = history.actions .slice(0, -1) // every action except the last one .reduce( (state, action) => reducer(state, action), history.base ) interface History { actions: Array<Action> base: State } @n_mehlhorn
SLIDE 21
HISTORY OF ACTIONS
👎 actions < states 👎 ignore some actions 👏 tricky implementation 👏 expensive recalculation
21 @n_mehlhorn
SLIDE 22
22
There’s another way back to the future
Delorean Vectors by Vecteezy
@n_mehlhorn
SLIDE 23
23
JSON Patch
// initial state const state = { "firstname": "John" } // JSON Patch representing what reducer did to change the state const patch = [ { "op": "add", "path": "/lastname", "value": "Doe" } ] // result state when applying patch to S1 const next = { "firstname": "John", "lastname": "Doe" } @n_mehlhorn
SLIDE 24
24
Inverse JSON Patch
// result state from before const next = { "firstname": "John", "lastname": "Doe" } // JSON Patch representing the reverse // of what reducer did to change the state const inversePatch = [ { "op": "remove", "path": "/lastname" } ] // resulting initial state when applying inversePatch to S2 const state = { "firstname": "John" } @n_mehlhorn
SLIDE 25
25
COPY-ON-WRITE
state next draft
@n_mehlhorn
SLIDE 26
26 import produce, {applyPatches} from "immer" const state = { "firstname": "John" } let undoPatches const next = produce( state, draft => { draft.lastname = "Doe" }, (patches, inversePatches) => { undoPatches = inversePatches } ) const patched = applyPatches(next, undoPatches) expect(patched).toEqual(state)
PATCHES WITH IMMER
@n_mehlhorn
SLIDE 27
HISTORY OF PATCHES
👎 lightweight 👎 ignore some actions 👎 feasible implementation 👎 no recalculation 👊 requires Immer
27 @n_mehlhorn
SLIDE 28
NGRX-WIEDER
28
- patch-based undo-redo
- ignore actions
- merge actions
- segmentation
DEMO
@n_mehlhorn
SLIDE 29
Place your screenshot here
29
1. Visit Blog 2. Join Mailing List 3. Follow On Twitter 4. Work With Me
nils-mehlhorn.de
www
@n_mehlhorn
